Philips SQM5822, SQM5822-27 User Manual

Register your product and get support at

www.philips.com/welcome

EN Fixed wall mount

SQM5822/27

1

2

Table of contents

1 Important 3

2 Your xed wall mount 3

2.1 What’s in the box 4

2.2 What you’ll also need 4

3 Installing your wall mount 5

3.1 Mounting the wall plate (drywall) 5

3.2 Mounting the wall plate (concrete) 5

3.3 Attaching the arms to the display 6

4 Mounting and adjusting 7

5 Guarantee and service 8

3

1 Important

Take time to read this manual before you
use your wall mount. It contains important
information and notes regarding operating your
wall mount.

© 2009 Koninklijke Philips Electronics N.V.
All rights reserved. Reproduction in whole or in
part is prohibited without the written consent of
the copyright owner. Trademarks are the
property of Koninklijke Philips Electronics N.V.
or their respective owners.

B Warnings

• Make sure these instructions are read
and thoroughly understood before
attempting installation. If you are
unsure of any part of this installation,
contact a professional installer for
assistance or contact Customer Service
at 1-919- 573-7854.

• This product has been designed
for application on a vertical wall in
commercial and residential buildings,
constructed of wood wall studs or
masonary (solid concrete, brick, and
stone). If you are unsure of your wall
composition or for assistance with other
surfaces, contact a qualied installer.

• This product is not designed for use on
walls constructed of metal studs. If you
are unsure of your wall composition
or for assistance with other surfaces,
contact a qualied installer.

• The wall or mounting surface must be
capable of supporting the combined
weight of the mount and the display;
otherwise the structure must be
reinforced.

• Do not exceed the maximum load
capacity of 132lbs for this product.

• Fits 30-55” screens

• Safety gear and proper tools must
be used. Failure to do so can result in
property damage and/or serious injury.

• A minimum of two people are required
for this installation. Do not attempt
to install this mount alone under any
circumstance.

• Follow all instructions and
recommendations regarding adequate
ventilation and suitable locations for
mounting your display. Consult the
owner’s manual for your display for
more information.

• This mount is equipped with a safety
device that must be used whenever
the mount holds a display. Not using
the safety device can cause property
damage, serious injury, or death.

2 Your xed wall mount

Congratulations on your purchase and welcome
to Philips!

To fully benefit from the support that Philips
offers, register your product at
www.philips.com/welcome.

Designed to fit most TV brands with a focus
on safety and ease of use. Includes Easy 1-2-3
installation kit, complete with: all necessary
hardware for mounting on different types of
walls, mounting templates and bubble level. C-UL
US listed for weight capacity up to 132lbs.
