Page 1
Philips
Internal Drive
DVD
20 x ReWriter
SPD2514BM
Multi SATA drive
The Philips internal DVD RW drive reads and writes all DVD, dual layer and CD formats.
It's easy to install even for inexperienced users. And coming from the co-inventor of Bluray, DVD and CD optical media, you can be sure it's ultra-reliable.
Witness the latest technology
• Double layer writer for +R and -R, DL media
• DVD-RAM format supported
Superior Performance
• 8 x writing on DVD+R DL
•8.5 GB storage capacity on a single-sided double-layer disc
• Amazing 20 x writing speed
Convenience
• Plug & Play for easier installation
•Dual Format
Extreme Reliability and Robustness
• Dynamic Calibration ensures quality when writing at high speed
• Safe and reliable re-writing with Seamless Link
Page 2
Internal Drive
SPD2514BM/00
DVD 20 x ReWriter
Specifications Product highlights
Writing Speed
• DVD+R: 20 X (24300KB/sec) by CAV
• DVD-R: 20 X (24300KB/sec) by CAV
• DVD+R DL: 8 X (10800KB/sec) by Z-CLV
• DVD-R DL: 8 X (10800KB/sec) by Z-CLV
• CD-R: 48 X (7200KB/sec) by CAV
• DVD-RAM: 12 X (16200KB/sec) by PCAV
Re-writing Speed
• DVD+RW: 8 X (10800KB/sec) by CLV
• DVD-RW: 6 X (8100KB/sec) by CLV
• CD-RW: 32 X (4800KB/sec) by CAV
Reading Speed
• DVD-ROM: 16 X (21600KB/sec) by CAV
• CD-R: 48 X (7200KB/sec) by CAV
• DVD-RAM: 12 X (16200KB/sec) by PCAV
• Access time: 140
• Buffer size: 2 MB
Connectivity
• Interface: SATA
• Other connections: 12 V DC in, Analogue audio
Left/Right out, DC power connector, Digital
audio out, IDE interface connector, Master/Slave
select jumper
Convenience
• Ease of Installation: Plug & Play
System Requirements
• Hard disk space: 650 MB
• PC OS: Windows® Vista, XP, 2000 SP4, ME, NT,
98 SE
• Processor: Pentium 4 1.3 GHz or Higher CPU
• RAM memory: 128 MB
Technical specifications
• Humidity: 20 - 80 %RH (no condensation)
• Operating temperature range: 5 - 50 °C
• Storage temperature range: -40 - 80 °C
• Safety standards: EN60950, EN60825,UL1950
• EMC standards: EN55022, EMS55024,FCC Part
15
Packaging dimensions
• EAN: 87 12581 34873 1
• Number of products included: 1
• Packaging type: Box
• Packaging dimensions (W x H x D):
17
x 14.8 x 4.2 cm
• Gross weight: 0.86 kg
• Net weight: 0.74 kg
• Tare weight: 0.12 kg
Outer Box
• EAN: 87 12581 34874 8
• Number of consumer packages: 10
• Gross weight: 9.1 kg
• Outer carton (L x W x H): 38 x 32 x 24 cm
• Net weight: 7.4 kg
• Tare weight: 1.7 kg
•
Dynamic Calibration
Dynamic Calibration optimises DVD writing quality of
high-speed DVD+RW drives.
Dual format writer on +/- DL
New drive, enabling writing on both +R and -R 8.5 GB
double layer media
Plug & Play
Plug & Play gives you the ability to install or add a new
component and have it work without having to perform
any complex installation procedures or technical
analyses.
Seamless Link
Seamless Link prevents loss of discs caused by writing
errors
8.5 GB of storage capacity
Store 8.5 GB of data or 4 hours of DVD quality video on
one single-sided double-layer disc
DVD-RAM
The DVD-RAM format is supported, which makes this
product a true MultiRecording drive supporting all CD
and DVD formats.
20 x writing speed
With the latest technology this drive has a maximum 20
x writing speed. This creates the fastest drive in the world
with speed and stability.
Issue date 2009-01-22
Version: 1.0.3
12 NC: 8670 000 31943
EAN: 87 12581 34873 1
© 2009 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
