Page 1
Philips
Internal Drive
DVD-ROM
16 x
SPD2200FM
Simply superior performance
Read DVD data at incredible 16X
Philips innovative technology enables DVD data to read at 16X and can play all DVD
formats and CD data with the stability you expect.
Extreme Reliability and Robustness
• Confidently play your DVDs on all drives and set-top devices
Page 2
Internal Drive
SPD2200FM/00
DVD-ROM 16 x
Specifications Product highlights
Storage Media
• Mass storage class compliant
• Reading speeds: 16x on DVD-ROM, 7x on
DVD+R, 7x on DVD+RW, 7x on DVD-R, 7x on
DVD-RW, 48x on CD-R, 48x CD-ROM
• Disc capacity: DVD5/9,DVD+R/+RW/-R/
RW,CD-ROM
• Disc size: 80,120 mm
Accessories
• Included accessories: 4 mounting screws, CDROM with software & manual
• Printed user guide: How To manual (Ch/Eng)
• Warranty card: Warranty Chinese version
Power
• Adaptor type: DC 5V/12V
Technical specifications
• Humidity: 5 - 90 %RH (no condensation)
• Operating temperature range: 5 - 50 °C
• Access time: CD: <120msec (typical), DVD:
<140msec (typical)
• Storage temperature range: -20 .. +60 °C
• Safety standards: EN60950, EN60825,UL1950
• EMC standards: EN55022, EMS55024,FCC Part
15
•
DVD compatibility
DVD Compatibility ensures playability of self-made DVD
discs on as many set-top players and DVD-ROMs as
possible.
Issue date 2007-08-04
Version: 1.0
12 NC: 9082 100 08306
EAN: 87 10895 97070 9
© 2007 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
