Philips
Internal Drive
DVD
16x ReWriter
SPD1400BD
Simply superior performance
8.5GB of data on one DVD+R DL disc
Philips innovative recording technology let you record with high speed twice as much
video, photo, music and data.
Superior Performance
• 8.5GB storage capacity on a single sided double layer disc
• 16X top writing speed on DVD+R/-R
• DVD ReWriter supporting 16X DVD-R
Convenience
• Set-up and use in minutes on any PC or Laptop
• Extensive software package for DVD and CD applications
•Dual Format
Extreme Reliability and Robustness
• Safe and reliable re-writing with Seamless Link
• Dynamic Calibration ensure writing quality at high DVD speed
• Optimum recording speed for any recordable disc
• Confidently play your DVDs on all drives and set-top devices
Page 2
For preview purpose only
Internal Drive
DVD 16x ReWriter
Technical specifications Product highlights
Writing Speed
• DVD+R: 16X (21600KB/sec) by CAV
• DVD-R: 16X (21600KB/sec) by CAV
• DVD+R DL: 8X (10800KB/sec) by Z-CLV
• DVD-R DL: 4X (5400KB/sec) by CLV
• CD-R: 48x (7200KB/sec) by P-CAV
Rewriting Speed
• DVD+RW: 8X (10800KB/sec) by CLV
• CD-RW: 32X (4800KB/sec) by Z-CLV in
UltraSpeed disc
• DVD-RW: 6X (8100KB/sec) by CLV
Reading Speed
• DVD ROM: 16X (21600KB/sec) by CAV
• CD-R: 48X (7200KB/sec) by CAV
• Buffer size: 2MB
Dimensions
• Product dimension (WxDxH) inch:
146X178X42
• Product weight: 0.9 kg
Power
• Adaptor type: DC 5V/12V
• Power consumption: 12 W
Technical specifications
• Humidity: 5 - 90 %RH (no condensation)
• Operating temperature range: 5 - 50 °C
• Safety standards: EN60950,
EN60825,UL1950
• EMC standards: EN55022, EMS55024,FCC
Part 15
• Access time: CD: <120msec (typical), DVD:
<140msec (typical)
Connectivity
• Other connections: 12 V DC in, Analog
audio Left/Right out 2x, IDE interface
connector, Master/Slave select jumper
Convenience
• Ease of Installation: Plug & Play
Packaging Data
• 12NC: 908210007108
• EAN/UPC/GTIN: 8710895944441
• Gross weight: 0.9 kg
• Height: 42 mm
• Length: 178 mm
• Width: 146 mm
Software
• Ahead Nero Suite 6: Nero Burning Rom 6,
InCD 4, Nero Vision express 2, Nero media
Player 1, EasyWrite Reader 4, Nero Burning
Rights 1
Accessories
• Included Accessories: 4 mounting screws,
CD-ROM with software + manual, User
Manual
System Requirements
• Hard disk space: 100MB
• PC OS: Win 98 SE, 2000, ME, XP
• Processor: Pentium 3 550MHz or higher
CPU
• RAM memory: 128 MB
Inner Carton
• EAN/UPC/GTIN: 8710895944441
• Gross weight: 0.9 kg
• Height: 42 mm
• Length: 178 mm
• Width: 146 mm
• Quantity: 1
Outer Carton
• EAN/UPC/GTIN: 8710895945042
• Quantity: 2
Outer Carton 2
• EAN/UPC/GTIN: 8710895945059
• Quantity: 128
•
SPD1400BD/97
8.5GB storage capacity
Single sided double layer disc with 8.5 GB storage
capacity
16X write speed on DVD+R/-R
Top speed 16X recording on DVD+R and DVD-R discs
16X write speed on DVD-R
16x DVD-R writing speed
Ease of use
Ease of use means every customer is able to install and
operate even complex products.
Extensive Software Package
Complete software bundle offering all functionality in a
simple intuitive way.
Dual Format
Drive supporting both +R/+RW and -R/RW DVD formats
Seamless Link
Seamless Link prevents loss of discs caused by writing
errors
Dynamic Calibration
Dynamic Calibration optimizes DVD writing quality of
high-speed DVD+RW drives.
Thermo Balanced Writing
Always the best and fastest recording of any of your
recordable discs
DVD compatibility
DVD Compatibility ensures playability of self-made DVD
discs on as many set-top players and DVD-ROMs as
possible.
Date of issue 2006-07-21
Version: 1.0
12 NC: 9082 100 07108
EAN: 87 10895 94444 1
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
© 2006 Koninklijke Philips Electronics N.V.
All Rights reserved.
www.philips.com
