Page 1
Philips
Multimedia Speakers 2.1
SPA7380
Immersive bass
Takes gaming to a new level
Four sophisticated integrated circuits drive the subwoofer and two satellite speakers for
quality sound while Philips SPD bass port technology delivers pure deep bass, and all with
60W output for the explosive bass that gamers want.
Impressive sound
• 60W output power
• SPD™ innovative bass port technology for deep, rounded tones
• Advanced integrated circuits
• PP subwoofer driver material
• Side firing bass port speaker design
• Well damped driver reduces vibration and sound distortion
Contemporary design
• Long tube design generates more bass
• Curvilinear cabinet for well-rounded sound
Simplicity
• AUX-in and headphone out on wired control
• Compatible with any media
• AUX-in for easy connection to almost any electronic device
Page 2
SPA7380/37
Multimedia Speakers 2.1
Highlights
60W output power
60W output – wow! We gamers all want
higher power because for gaming speakers the
bigger the output, the better the bass and
overall sound quality. So enjoy your next game
with this powerful, big 60W output which gives
you all the explosive bass you want.
Extended tube design
All gamers want their speakers to have as
m
uch bass as possible, and these speakers are
specially designed to deliver the bass you want.
The long tube design of this satellite speaker
gives better quality sound with extended bass.
This creates more volume to generate more
bass and bring you more enjoyment from your
games.
Advanced integrated circuits
The Philips integrated circuits in this speaker
are very sophisticated. Normal speakers have
between one to a maximum of 3 channels but
this speaker comes with 4 channels to give you
the better sound quality you need. Philips uses
4 integrated amplifier chips to drive the 2
channels of two satellite speakers and 2
channels the subwoofer. These TDA7379
amplifier chips provide a good solid foundation
for quality sound and all the power needed to
drive the subwoofer and satellites.
SPD™ technology
Philips Sound Purification Duct (SPD) bass port
te
chnology delivers the deep, pure tones of the
original bass sound. Using an SPD foam
material to process the inner surface of the
bass pipe, the special acoustic damping
invented by Philips reduces noise turbulence
and stabilizes the tuning frequency. Philips
technical and consumer tests confirm this
buffer provides less colored, purer quality bass.
PP subwoofer driver material
The polypropylene (PP) material in the driver,
which is heavy, makes for better bass. It can
help rolling out and produces a more bass with
better clarity and balance. Easier to integrate
with the full range driver and results in less
vibration.
AUX-in and headphone out
Now you can enjoy your favorite music and
entertainment even easier and more
conveniently, via the aux-in and headphone out
jack on wired control. Usually, if you want to
connect another device other than your PC
you have to unplug the 3.5mm jack from the
computer and that is not always expedient. But
with the aux-in and headphone out
connections on front you can quickly and easily
listen to music straight from almost any device.
Page 3
SPA7380/37
Multimedia Speakers 2.1
Specifications
Audio system
• Frequency range: 20Hz-20kHz
• Input impedance: 20Kohm
• Output power in total: 60W
• Power: 220V 50Hz
• Signal/Noise ratio: >75dB
•THD: <1%
Audio systems L/R channels
• Audio power amplifier: Class-AB Amplifier
• Channel separation: >45dB
• Input sensitivity: 600mV
• Rated output power: 14W x2
Subwoofer audio systems
• audio power amplifier: Class-AB Amplifier (BTL)
• Input sensitivity: 130mV
• Rated outputer power: 32W
Left/Right speakers
• Driver power range: 1-30Wx2
• Frequency range: 80Hz-18kHz
• Norminal impedance: 4ohm
• Sensitivity: 86dB(2.83V/1m)
• Speaker driver: 3"
Subwoofer speaker
• Driver power range: 2-120W
• Frequency range: 45Hz-200Hz
• Norminal impedance: 4ohm
• Sensitivity: 88dB(2.83V/1m)
• Speaker driver: 5.25"
Connectivity
• Cable length: Power cord, audio cable, satellite
cable : 1.3M
• Connector: 3.5mm stereo
Power
•Power LED indicator: Green
Convenience
• Remote control: volume control, headphone
output, additional audio input, power indicator
Packaging content
• 3.5 mm stereo line cable
• Number of satellites: 2
• Quick installation guide
• Remote Control: Wired
•Subwoofer
Product dimensions
• Product dimensions (W x H x D):
16.5 x 23 x 9.5 cm
• Product dimensions (W x H x D):
6.5 x 9.1 x 3.7 inch
• Weight: 1.978 lb
• Weight: 0.897 kg
Packaging dimensions
• Packaging dimensions (W x H x D):
13.6 x 16.3 x 9.8 inch
• Packaging dimensions (W x H x D):
.5 x 41.5 x 25 cm
34
• Gross weight: 5.87 kg
• Gross weight: 12.941 lb
• Nett weight: 10.695 lb
• Nett weight: 4.851 kg
• Number of products included: 1
• Packaging type: Carton
• Tare weight: 1.019 kg
• Tare weight: 2.246 lb
• Type of shelf placement: Laying
• UPC: 6 09585 22854 2
Outer Carton
• Gross weight: 12.76 kg
• Gross weight: 28.131 lb
• GTIN: 1 06 09585 22854 9
•Outer carton (L x W x H): 52.5 x 36.5 x 43.5 cm
•Outer carton (L x W x H): 20.7 x 14.4 x 17.1 inch
• Nett weight: 21.389 lb
• Nett weight: 9.702 kg
• Number of consumer packagings: 2
• Tare weight: 6.742 lb
• Tare weight: 3.058 kg
•
Issue date 2018-04-25
Version: 1.0.2
12 NC: 8670 000 93472
UPC: 6 09585 22854 2
