SP9860
www.philips.com/support/ifu-lux
4
3
16
15
14
13
12
11
10
9
8
7
6
5
1
2
empty page before TOC
English 6
Français (Canada) 32
English
6
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
Please read this user manual, as it contains
information about the features of this shaver as
well as some tips to make shaving easier and more
enjoyable.
General description (Fig. 1)
1 Supply unit
2 USB plug
3 Qi charging pad
4 Pouch
5 Notification symbol
6 Cleaning reminder
7 Replacement reminder
8 Travel lock symbol
9 Battery charge indicator
10 Battery charge percentage
11 Personal comfort settings bar
12 Personal comfort settings increase button
13 Personal comfort settings decrease button
14 On/off button
15 Shaving unit with hair chamber
16 Click-on precision trimmer attachment
The accessories supplied may vary for different
products. The box shows the accessories that have
been supplied with your appliance.
Important safety information
Read this important information carefully before
you use the appliance and its accessories and save
it for future reference. The accessories supplied
may vary for different products.
English
Danger
Warning
English
- Keep the supply unit dry.
- The appliance is a Class III
construction.
- To charge the battery, only use
the detachable supply unit and
charging pad (supply unit, type
HQ87. Charging pad, type
HQ8509 or HQ8510) provided
with the appliance.
- Do not use an USB extension
cord.
- Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made
by children without supervision.
7
English
8
- Always check the appliance and
its attachments before you use
it. Do not use the appliance or
its attachments if it is damaged,
as this may cause injury. Always
replace a damaged part with
one of the original type.
- Do not open the appliance to
replace the rechargeable
battery.
- The charging pad is not
intended for use in a car. It may
interfere with the automotive
electronic systems.
Caution
- Never immerse the charging pad in water,
nor rinse it under the tap.
- Always make sure the charging pad is
completely dry before you connect it to the
wall socket.
- Never use water hotter than 60°C to rinse
the shaver.
- Only use this appliance for its intended
purpose as shown in the user manual.
English
- For safety reasons, do not use the shaver
while you drive a car.
- For hygienic reasons, the appliance should
only be used by one person.
- Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive
liquids such as petrol or acetone to clean
the appliance.
- Do not put the appliance or any part in the
dishwasher.
- Water may trickle out of the shaver after you
rinse it. This is normal and not dangerous
because all electronics are enclosed in a
sealed power unit inside the shaver.
- Do not use the supply unit in or near wall
sockets that contain an electric air freshener
to prevent irreparable damage to the supply
unit.
- Do not use the appliance on chapped skin,
open wounds, healing wounds, skin
recovering from surgery or if you suffer from
a skin disease or skin irritation, such as
severe acne, sunburn, skin infection, skin
cancer, inflammation, eczema, psoriasis,
nylon allergy etc.
9
English
10
- Do not use the appliance if you are taking
steroid-based medication.
- If you wear piercings on your face, remove
the piercings before you use the click-on
attachments or make sure that you do not
use the appliance on or near the piercing.
- If you wear jewelry, contact lenses or
glasses, remove them before you use the
click-on attachments, or make sure that you
do not use the appliance on or near jewelry
or glasses.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
General
- This shaver is waterproof. It is suitable for use in
the bath or shower and for cleaning under the
tap.
- The supply unit is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
The display
Note: Remove any sticker or protective foil from
the display before using the product.
Charging
When the shaver is charging, the ring on the pad
lights up and the battery charge indicator on the
shaver flashes white.
The battery charge is indicated by the battery
charge percentage flashing on the display, which is
shown when the shaver is moved.
Quick charge: After approx. 18 minutes charging,
the appliance contains enough energy for one
shave.
Battery fully charged
When the battery is fully charged, the battery
charge indicator and the ring on the pad light up
white continuously.
Note: Both lights switch off automatically after 15
minutes.
The battery charge percentage lights up white
continuously, which is shown when the shaver is
moved.
Battery low
When the battery is almost empty, the battery
charge indicator flashes orange and the shaver
beeps. At this point there is enough energy left for
one shave..
English
11
Remaining battery charge
The remaining battery charge is indicated by the
battery charge percentage shown on the display.
3 sec.
English
12
Personal comfort settings
The shaver has a feature that allows you to
personalize your settings. Depending on your
personal shaving needs, choose between three
settings, from low to high: comfort, dynamic or
efficiency. When you press the button on the left
or right of the display, the segment of the personal
comfort settings bar lights up to indicate the
selected setting. To select a lower or higher setting,
press the button on the left or right of the display.
Cleaning reminder
Clean the shaver after every use for optimal
performance (see 'Cleaning and maintenance').
When you switch off the shaver, the cleaning
reminder flashes to remind you to clean the
shaver.
Travel lock
When you are going to travel, you can lock the
shaver to prevent it from accidentally turning on.
Replacement reminder
For maximum shaving performance, replace the
shaving heads every two years. The shaver is
equipped with a replacement reminder which
reminds you to replace the shaving heads. The
shaver beeps, the replacement reminder lights up
and the arrows flash to indicate that you have to
replace the shaving heads.
Note: After replacing the shaving heads, you can
reset the replacement reminder by pressing the
on/off button for 7 seconds. If you do not reset the
replacement reminder, the shaver resets
automatically after 9 shaves.
Notification symbol
Overheating
If the shaver overheats during charging, the
notification symbol flashes. When this happens,
the shaver stops charging automatically. Charging
continues once the temperature of the shaver has
decreased to the normal level after approx. 10
minutes.
Blocked shaving heads
If the shaving heads are blocked, the notification
symbol lights up red continuously. The
replacement reminder and the cleaning reminder
alternately flash white and the shaver beeps. In
this case, the motor cannot run because the
shaving heads are dirty or damaged. If the shaving
heads are dirty, you have to clean them. If the
shaving heads are damaged, you have to replace
them.
Foreign object on Qi charging pad
If there is a foreign (metal) object on the Qi
charging pad during charging, the notification
symbol on the Qi charging pad lights up. The Qi
charging pad switches off automatically and
restarts 5 minutes after the foreign object has
been removed.
Do not place any foreign (metal) objects on the Qi
charging pad. Only use the Qi charging pad to
charge the shaver or another device (e.g.
smartphone) compliant with Qi charging.
English
13
2
1
English
14
Charging
Charge the shaver before you use it for the first
time and when the display indicates that the
battery is almost empty.
Charging takes approx. 3 hours. A fully charged
shaver has a shaving timeof up to 60 minutes.
Note: You cannot use the shaver while it is
charging.
Quick charge
After approx. 18 minutes of charging the shaver
contains enough power for one shave.
Charging with the Qi charging pad
Note: The charging pad is Qi compliant. Only
charge the Qi compatible shaver or other Qi
charging compliant appliances on the Qi charging
pad provided.
Note: Carefully shake off excess water before
placing the shaver on the Qi pad.
1 Put the USB plug in the supply unit supplied.
2 Put the supply unit in the wall socket.
3 Place the shaver on the cross mark of the Qi
charging pad. Make sure the shaver fits into the
cavity of the Qi charging pad.
Only charge the shaver on the provided Qi
charging pad.
- The Qi charging pad beeps and the ring on the
pad lights up when the shaver is correctly
placed and connected for charging.
- When the shaver is charging, the ring on the
pad lights up and the battery charge indicator
on the shaver flashes white. The battery charge
is indicated by the battery charge percentage
flashing on the display, which is shown when
the shaver is moved.
4 When the battery is fully charged, the battery
charge indicator and the ring on the pad light
up white continuously. Both lights switch off
automatically after 15 minutes.
Using the shaver
Always check the shaver and all accessories
before use. Do not use the shaver or any
accessory if it is damaged, as this may cause
injury. Always replace a damaged part with one of
the original type.
This symbol indicates that the shaver can be used
in the bath or shower.
- Use this shaver for its intended household use
as described in this manual.
- For hygienic reasons, the shaver should only be
used by one person.
- Trimming is easier when the skin and hair are
dry.
Note: This shaver is waterproof. It is suitable for
use in the bath or shower and for cleaning under
the tap. For safety reasons, the shaver can
therefore only be used without charging cord.
English
15
English
16
Switching the shaver on and off
1 To switch on the shaver, press the on/off
button once.
The battery charge percentage lights up for a
few seconds.
2 To switch off the shaver, press the on/off
button once.
The battery charge percentage lights up for a
few seconds and shows the remaining battery
charge.
Shaving
Skin adaptation period
Your first shaves may not bring you the result you
expect and your skin may even become slightly
irritated. This is normal. Your skin and beard need
time to adapt to any new shaving system. To allow
your skin to adapt to this new appliance, we advise
you to shave regularly (at least 3 times a week) and
exclusively with this appliance for a period of 3
weeks.
Shaving tips
- For the best results on skin comfort, pre-trim
your beard if you have not shaved for 3 days or
longer.
- Select your personal comfort setting (see
'Personal comfort settings').
Dry shaving
1 Switch on the shaver.
English
2 Move the shaving heads over your skin in
circular movements to catch all hairs growing in
different directions. Make sure each shaving
head is fully in contact with the skin. Exert
gentle pressure for a close, comfortable shave.
Note: Do not press too hard, this can cause skin
irritation.
3 Switch off and clean the shaver after each use.
The display lights up for a few seconds to show
the remaining battery charge.
Wet shaving
For a more comfortable shave, you can also use
this shaver on a wet face with shaving foam or
shaving gel.
1 Apply some water to your skin.
2 Apply shaving foam or shaving gel to your skin.
17
3 Rinse the shaving unit under the tap to ensure
that the shaving unit glides smoothly over your
skin.
4 Switch on the shaver.
English
18
5 Move the shaving heads over your skin in
circular movements to catch all hairs growing in
different directions. Make sure each shaving
head is fully in contact with the skin. Exert
gentle pressure for a close, comfortable shave.
Note: Do not press too hard, this can cause skin
irritation.
Note: Rinse the shaving unit regularly to ensure
that it continues to glide smoothly over your
skin.
6 Dry your face.
7 Switch off the shaver and clean it after each
use.
Note: Make sure that you rinse all foam or shaving
gel off the shaver.
Using click-on attachments
Removing or attaching click-on attachments
1 Make sure the shaver is switched off.
2 Pull the attachment straight off the shaver.
Note: Do not twist the attachment while you
pull it off the shaver.
3 Insert the lug of the attachment into the slot in
the top of the shaver. Then press down the
attachment to attach it to the shaver(‘click’).
Using the precision trimmer attachment
You can use the precision trimmer attachment to
touch up your beard, sideburns and moustache.
1 Attach the attachment to the appliance (‘click’).
3 sec.
2 Switch on the appliance.
3 Hold the precision trimmer perpendicular to the
skin and move it downwards while exerting
gentle pressure.
4 Switch off the appliance and clean the
attachment after use (see 'Deactivating the
travel lock').
Travel lock
You can lock the shaver when you are going to
travel to prevent it from turning on accidentally.
Activating the travel lock
1 Press the on/off button for 3 seconds to enter
the travel lock mode.
While you activate the travel lock, the travel lock
symbol lights up briefly and the shaver
produces a short sound. When the travel lock is
activated, the travel lock symbol flashes.
If you try to switch on the shaver while the
travel lock is active, the travel lock symbol
flashes.
English
19
Deactivating the travel lock
1 Press the on/off button for 3 seconds.
While you deactivate the travel lock, the travel
lock symbol lights up briefly and the shaver
produces a short sound. The shaver switches on
and is now ready for use again.
Note: The shaver unlocks automatically when it
is placed on the Qi charging pad.
Loading...
