SP9863
SP9861
SP9860
www.philips.com/support/ifu-lux
SP98xx/14
SP98xx/13
SP98xx/12
SP98xx/14
SP98xx/16
SP98xx/17
7
6
22 21
19
20
18
17
16
15
14
13
12
11
8
10
9
1
2
3
4
5
empty page before TOC
English 6
简体中文
41
English
6
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
Please read this user manual, as it contains
information about the features of this shaver as
well as some tips to make shaving easier and more
enjoyable.
General description (Fig. 1)
1 Protection cap for cleansing brush attachment
2 Click-on cleansing brush attachment
3 Attachment holder
4 Supply unit
5 USB plug
6 Qi charging pad
7 Pouch
8 Replacement reminder
9 Notification symbol
10 Cleaning reminder
11 Travel lock symbol
12 Battery charge indicator
13 Battery charge percentage
14 Personal comfort settings bar
15 Personal comfort settings decrease button
16 Personal comfort settings increase button
17 On/off button
18 Shaving unit with hair chamber
19 Click-on precision trimmer attachment
20 Click-on beard styler attachment
21 Comb for beard styler attachment
22 Click-on nose trimmer attachment
The accessories supplied may vary for different
products. The box shows the accessories that have
been supplied with your appliance.
English
Important safety information
Read this important information carefully before
you use the appliance and its accessories and save
it for future reference. The accessories supplied
may vary for different products.
Danger
- Keep the supply unit dry.
Warning
- The appliance is a Class III
construction.
- To charge the battery, only use
the detachable supply unit and
charging pad (supply unit, type
HQ87. Charging pad, type
HQ8509 or HQ8510) provided
with the appliance.
- Do not use an USB extension
cord.
English
7
8
English
- This appliance can be used by
children aged from 8 years and
above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge if
they have been given
supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved. Children
shall not play with the
appliance. Cleaning and user
maintenance shall not be made
by children without supervision.
- Always check the appliance and
its attachments before you use
it. Do not use the appliance or
its attachments if it is damaged,
as this may cause injury. Always
replace a damaged part with
one of the original type.
- Do not open the appliance to
replace the rechargeable
battery.
English
- The charging pad is not
intended for use in a car. It may
interfere with the automotive
electronic systems.
Caution
- Never immerse the charging pad in water,
nor rinse it under the tap.
- Always make sure the charging pad is
completely dry before you connect it to the
wall socket.
- Never use water hotter than 60°C to rinse
the shaver.
- Only use this appliance for its intended
purpose as shown in the user manual.
- For safety reasons, do not use the shaver
while you drive a car.
- For hygienic reasons, the appliance should
only be used by one person.
- Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive
liquids such as petrol or acetone to clean
the appliance.
- Do not put the appliance or any part in the
dishwasher.
9
English
10
- Water may trickle out of the shaver after you
rinse it. This is normal and not dangerous
because all electronics are enclosed in a
sealed power unit inside the shaver.
- Do not use the supply unit in or near wall
sockets that contain an electric air freshener
to prevent irreparable damage to the supply
unit.
- Do not use the appliance on chapped skin,
open wounds, healing wounds, skin
recovering from surgery or if you suffer from
a skin disease or skin irritation, such as
severe acne, sunburn, skin infection, skin
cancer, inflammation, eczema, psoriasis,
nylon allergy etc.
- Do not use the appliance if you are taking
steroid-based medication.
- If you wear piercings on your face, remove
the piercings before you use the click-on
attachments or make sure that you do not
use the appliance on or near the piercing.
English
- If you wear jewelry, contact lenses or
glasses, remove them before you use the
click-on attachments, or make sure that you
do not use the appliance on or near jewelry
or glasses.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
General
- This shaver is waterproof. It is suitable for use in
the bath or shower and for cleaning under the
tap.
- The supply unit is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
The display
Note: Remove any sticker or protective foil from
the display before using the product.
Charging
When the shaver is charging, the ring on the pad
lights up and the battery charge indicator on the
shaver flashes white.
The battery charge is indicated by the battery
charge percentage flashing on the display, which is
shown when the shaver is moved.
Quick charge: After approx. 18 minutes charging,
the appliance contains enough energy for one
shave.
11
English
12
Battery fully charged
When the battery is fully charged, the battery
charge indicator and the ring on the pad light up
white continuously.
Note: Both lights switch off automatically after 15
minutes.
The battery charge percentage lights up white
continuously, which is shown when the shaver is
moved.
Battery low
When the battery is almost empty, the battery
charge indicator flashes orange and the shaver
beeps. At this point there is enough energy left for
one shave..
Remaining battery charge
The remaining battery charge is indicated by the
battery charge percentage shown on the display.
Personal comfort settings
The shaver has a feature that allows you to
personalize your settings. Depending on your
personal shaving needs, choose between three
settings, from low to high: comfort, dynamic or
efficiency. When you press the button on the left
or right of the display, the segment of the personal
comfort settings bar lights up to indicate the
selected setting. To select a lower or higher setting,
press the button on the left or right of the display.
Cleaning reminder
3 sec.
Clean the shaver after every use for optimal
performance (see 'Cleaning and maintenance').
When you switch off the shaver, the cleaning
reminder flashes to remind you to clean the
shaver.
Travel lock
When you are going to travel, you can lock the
shaver to prevent it from accidentally turning on.
Replacement reminder
For maximum shaving performance, replace the
shaving heads every two years. The shaver is
equipped with a replacement reminder which
reminds you to replace the shaving heads. The
shaver beeps, the replacement reminder lights up
and the arrows flash to indicate that you have to
replace the shaving heads.
Note: After replacing the shaving heads, you can
reset the replacement reminder by pressing the
on/off button for 7 seconds. If you do not reset the
replacement reminder, the shaver resets
automatically after 9 shaves.
Notification symbol
Overheating
English
13
14
English
If the shaver overheats during charging, the
notification symbol flashes. When this happens,
the shaver stops charging automatically. Charging
continues once the temperature of the shaver has
decreased to the normal level after approx. 10
minutes.
Blocked shaving heads
If the shaving heads are blocked, the notification
symbol lights up red continuously. The
replacement reminder and the cleaning reminder
alternately flash white and the shaver beeps. In
this case, the motor cannot run because the
shaving heads are dirty or damaged. If the shaving
heads are dirty, you have to clean them. If the
shaving heads are damaged, you have to replace
them.
Foreign object on Qi charging pad
If there is a foreign (metal) object on the Qi
charging pad during charging, the notification
symbol on the Qi charging pad lights up. The Qi
charging pad switches off automatically and
restarts 5 minutes after the foreign object has
been removed.
Do not place any foreign (metal) objects on the Qi
charging pad. Only use the Qi charging pad to
charge the shaver or another device (e.g.
smartphone) compliant with Qi charging.
Charging
Charge the shaver before you use it for the first
time and when the display indicates that the
battery is almost empty.
Charging takes approx. 3 hours. A fully charged
shaver has a shaving timeof up to 60 minutes.
Note: You cannot use the shaver while it is
2
1
charging.
Quick charge
After approx. 18 minutes of charging the shaver
contains enough power for one shave.
Charging with the Qi charging pad
Note: The charging pad is Qi compliant. Only
charge the Qi compatible shaver or other Qi
charging compliant appliances on the Qi charging
pad provided.
Note: Carefully shake off excess water before
placing the shaver on the Qi pad.
1 Put the USB plug in the supply unit supplied.
2 Put the supply unit in the wall socket.
3 Place the shaver on the cross mark of the Qi
charging pad. Make sure the shaver fits into the
cavity of the Qi charging pad.
Only charge the shaver on the provided Qi
charging pad.
English
15
- The Qi charging pad beeps and the ring on the
pad lights up when the shaver is correctly
placed and connected for charging.
English
16
- When the shaver is charging, the ring on the
pad lights up and the battery charge indicator
on the shaver flashes white. The battery charge
is indicated by the battery charge percentage
flashing on the display, which is shown when
the shaver is moved.
4 When the battery is fully charged, the battery
charge indicator and the ring on the pad light
up white continuously. Both lights switch off
automatically after 15 minutes.
Using the shaver
Always check the shaver and all accessories
before use. Do not use the shaver or any
accessory if it is damaged, as this may cause
injury. Always replace a damaged part with one of
the original type.
This symbol indicates that the shaver can be used
in the bath or shower.
- Use this shaver for its intended household use
as described in this manual.
- For hygienic reasons, the shaver should only be
used by one person.
- Trimming is easier when the skin and hair are
dry.
Note: This shaver is waterproof. It is suitable for
use in the bath or shower and for cleaning under
the tap. For safety reasons, the shaver can
therefore only be used without charging cord.
Switching the shaver on and off
1 To switch on the shaver, press the on/off
button once.
The battery charge percentage lights up for a
few seconds.
Shaving
English
2 To switch off the shaver, press the on/off
button once.
The battery charge percentage lights up for a
few seconds and shows the remaining battery
charge.
17
Skin adaptation period
Your first shaves may not bring you the result you
expect and your skin may even become slightly
irritated. This is normal. Your skin and beard need
time to adapt to any new shaving system. To allow
your skin to adapt to this new appliance, we advise
you to shave regularly (at least 3 times a week) and
exclusively with this appliance for a period of 3
weeks.
Shaving tips
- For the best results on skin comfort, pre-trim
your beard if you have not shaved for 3 days or
longer.
- Select your personal comfort setting (see
'Personal comfort settings').
Dry shaving
1 Switch on the shaver.
2 Move the shaving heads over your skin in
circular movements to catch all hairs growing in
different directions. Make sure each shaving
head is fully in contact with the skin. Exert
gentle pressure for a close, comfortable shave.
Note: Do not press too hard, this can cause skin
irritation.
3 Switch off and clean the shaver after each use.
The display lights up for a few seconds to show
the remaining battery charge.
18
English
Wet shaving
For a more comfortable shave, you can also use
this shaver on a wet face with shaving foam or
shaving gel.
1 Apply some water to your skin.
2 Apply shaving foam or shaving gel to your skin.
3 Rinse the shaving unit under the tap to ensure
that the shaving unit glides smoothly over your
skin.
4 Switch on the shaver.
5 Move the shaving heads over your skin in
circular movements to catch all hairs growing in
different directions. Make sure each shaving
head is fully in contact with the skin. Exert
gentle pressure for a close, comfortable shave.
Note: Do not press too hard, this can cause skin
irritation.
Note: Rinse the shaving unit regularly to ensure
that it continues to glide smoothly over your
skin.
6 Dry your face.
7 Switch off the shaver and clean it after each
use.
Note: Make sure that you rinse all foam or shaving
gel off the shaver.
Using click-on attachments
It is recommended not to use the click-on
cleansing brush attachment directly after shaving
to prevent skin irritation.
Removing or attaching click-on attachments
1 Make sure the shaver is switched off.
2 Pull the attachment straight off the shaver.
Note: Do not twist the attachment while you
pull it off the shaver.
3 Insert the lug of the attachment into the slot in
the top of the shaver. Then press down the
attachment to attach it to the shaver(‘click’).
Attachment holder
Note: Attach the click-on cleansing brush
attachment on the attachment holder first, before
you place the attachment onto the appliance.
1 Place the click-on attachment onto the
attachment holder until it locks into position
with a click.
English
19
Using the precision trimmer attachment
You can use the precision trimmer attachment to
touch up your beard, sideburns and moustache.
English
20
1 Attach the attachment to the appliance (‘click’).
2 Switch on the appliance.
3 Hold the precision trimmer perpendicular to the
skin and move it downwards while exerting
gentle pressure.
4 Switch off the appliance and clean the
attachment after use (see 'Deactivating the
travel lock').
Using the beard styler attachment with comb
You can use the beard styler with the comb
attached to style your beard at one fixed setting,
but also at different length settings. You can also
use it to pre-trim any long hairs before shaving for
a more comfortable shave.
Note: The beard styler is only intended for
trimming facial hair. Do not use on areas below the
neck.
The length settings on the beard styler attachment
correspond to the remaining hair length after
cutting and range from 1 to 5mm (3/64 - 3/16in).
1 Attach the attachment to the appliance ('click').
1
2
English
2 Slide the comb straight into the guiding grooves
on both sides of the beard styler attachment
(‘click’).
3 Press the length selector and then push it to
the left or right to select the desired hair length
setting.
4 Switch on the appliance.
5 Move the appliance upwards while you exert
gentle pressure. Make sure the front of the
comb is in full contact with the skin.
6 Clean the attachment after use.
Using the beard styler attachment without comb
You can use the beard styler attachment without
the comb to contour your beard, moustache,
sideburns or neckline to a length of 0.5mm (1/32
in).
Note: The beard styler is only intended for
trimming facial hair. Do not use on areas below the
neck.
1 Pull the comb off the beard styler attachment.
Note: Grab the comb in the center to pull it off
the beard styler attachment. Do not pull at the
sides of the comb.
2 Switch on the appliance.
21
English
22
3 Hold the beard styler attachment perpendicular
to the skin and move the appliance downwards
while you exert gentle pressure.
4 Clean the attachment after use.
Using the cleansing brush attachment
Note: For better shaving results, use the click-on
cleansing brush attachment before shaving.
Use the rotating cleansing brush with your daily
cleansing cream. The cleansing brush removes oil
and dirt, contributing to a healthy and oil-free skin.
We advise you to use it no more than twice a day.
Start with the lowest personal comfort setting to
familiarize yourself with the attachment.
Do not use the appliance on damaged or irritated
skin or on wounds.
1 Place the attachment on the attachment
holder.
2 Attach the attachment to the appliance (‘click’).
3 Moisten the attachment with water.
Note: Do not use the appliance with a dry
cleansing brush attachment, as this can irritate
the skin.
20 sec.
20 sec.
20 sec.
English
4 Moisten your face with water and apply a
cleanser to your face.
5 Place the attachment on your cheek.
6 Switch on the appliance.
7 Gently move the brush across your skin from
the nose towards the ear. Do not push too hard
onto the skin to make sure that the treatment
remains comfortable.
Note: Do not cleanse the sensitive area around
your eyes.
8 After approx. 20 seconds, move the appliance
to your other cheek and start cleansing this part
of your face.
9 After approx. 20 seconds, move the appliance
to your forehead and start cleansing this part of
your face. Gently move the brush head from left
to right.
Note: We advise you to not overdo the
cleansing and to not cleanse any zone longer
than 20 seconds.
10 Switch off the appliance and clean the
attachment after use.
11 After the treatment, rinse and dry your
face.Your face is now ready for the next step of
your daily skincare routine.
23
Loading...
