Philips SL PAR 150, Showline SL PAR 150 Technical Specifications

The SL PAR 150 is a die-cast aluminum LED Par can
that utilizes nine homogenized RGBW LEDs to pro­duce over 3500 lumens of output. The manual zoom
provides a beam angle range from 10

0

to 520 and the
split yoke bracket allows for easy hanging or floor
mounting.

The rugged construction, internal power supply, and
ease of use make the SL PAR 150 a natural replace­ment for conventional PAR fixtures. Whether illumi­nating stages, buildings, clubs, landscapes or other
entertainment and architectural elements, the SL PAR
150 provides designers with the highest output and
best color uniformity.

Simple daisy chaining of power and data, along with a
split yoke bracket permit quick setup in any orienta­tion. Configuration is also made easy through use of
the standard Showline LCD menu system.

SL PAR 150

Drawing Diagram :

Features :

- Rugged Construction

- Osram SMD LED’s for exceptional output and color

- Built-in color presets, effects and chases

- HSIC (Hue - Saturation - Intensity - Color temperature) operation mode

- 8 or 16-bit DMX-512A operation for smooth stepless fades

- On-board LCD Menu System for addressing and setup

- Remote configuration available via RDM

- PowerCon in and thru power connections

- 5-pin DMX-512A(RDM) in and thru connections

Technical Specifications :

Ordering Information :

Philips Group 2012. All rights reserved.
The Company reserves the right to make any variation in design or construction to the equipment described.
E&OE. Philips Entertainment delivers fully integrated lighting solutions; from simple lamps to complete
systems designed with the specfic needs of the entertainment and specialized display lighting markets.

Philips Entertainment Lighting Asia Limited
Unit C, 14/F, Roxy Industry Centre
No. 41 - 49 Kwai Cheong Road
Kwai Chung, N.T. Hong Kong
Tel: [phone]
Fax: [phone]

Philips Entertainment New Zealand
19 - 21 Kawana Street, Northcote
Auckland 0627, New Zealand
Tel: [phone]
Fax: [phone]

Philips Entertainment Europe
Marssteden 152
Enschede 7547 TD
The Netherlands
Tel: [phone]
Fax: [phone]

Philips Entertainment U.S.
10911 Petal Street
Dallas, TX 75238
Tel: [phone]
Fax: [phone]

www.philips.com/showline

88-095-4182-36 SL PAR 150 RGBW IP20 with powercon I/O Connector AC90-240V

Harmonize Color Calibration Technology

At the heart of all Showline products is Philips Harmonize
Calibration technology. Harmonize is a proprietary, advanced LED
color matching system, consisting of 3 correction modules: RGB,
RGBW and Cool White/Warm White. Every Showline fixture
undergoes rigorous testing to provide you with consistent control
of color and intensity as well as output of the highest quality.

Version:

SL PAR 150 RGBW, IP20

Optics:

10 - 52 degree beam angle
9 high power 15w RGBW LEDs

Controls:
DMX-512A(RDM)
Local LCD control
Master/slave

Modes:

HSIC
8 bit RGBW
16 bit RGBW

Features:

Color Gel filter preset
Chase - Strobe + Duration Effect Engine
LED & Tungsten Curves selection

Physical:

90 - 240VAC, 150W
318mm x 284mm x 345mm, 8Kg

Luminance:

3500 lumens
CRI/CQS:
90 (RGBW)
