Philips SJA9190-17 User Manual

EN User manual 2

SP Manual de utilizador 16

SJA9190/17

Contents

3 Safety Instructions 6 Introduction 7 Installation 8 Operation 10 Troubleshooting and FAQs 11 FCC Information 14 Warranty 15 Technical Support

Safety Instructions

When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:

1. Read and understand all instructions.

2. Follow all warnings and instructions marked on the product.

3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners; use a damp cloth for cleaning.

4. Do not use this product near water for example, near a bath tub, wash bowl, kitchen sink, or swimming pool, or in a wet basement.

5. Do not place this product on an unstable cart, stand or table, as the product may fall, causing serious damage to the product.

6. Slots and openings in the cabinet and the back or bottom of this product are provided for ventilation (to protect it from overheating) and should not be blocked or covered. The openings should never be blocked by placing this product on a bed, sofa, rug or other similar surface. This product should never be placed near or over a radiator or heat register. This prod-

Safety Instructions

uct should never be placed in a built-in installation unless proper ventilation is provided.

7. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your dealer or local power company.

8. Do not allow anything to rest on the power cord. Do not place this product where the cord will be abused by people walking on it.

9. Do not overload wall outlets and extension cords, as this can result in the risk of fire or electric shock.

10.Never push objects of any kind into this product through cabinet slots, as they may touch dangerous voltage points or short out parts, resulting in the risk of fire or electric shock. Never spill liquid of any kind on the product.

11.To reduce the risk of electric shock, do not disassemble this product, but take it to a qualified serviceman, when service or repair work is required. Opening or removing covers may expose you to dangerous voltage or other risks. Incorrect reassembly can cause electric shock when this product is subsequently used.

Safety Instructions

12.Unplug this product from the wall outlet and refer servicing to a qualified service personnel under the following conditions: a) when the power supply cord or plug is damaged or frayed; b) if liquid has spilled into the product; c) if the product has been exposed to rain or water; d) if the product does not operate normally when you follow the operating instructions (adjust only those controls that are discussed in the operating instructions, as improper adjustment of other controls may result in damage, often requiring extensive work by a qualified technician to restore the product to normal performance); e) if the product has been dropped or the cabinet has been damaged; f) if the product exhibits a distinct change in performance.

13.Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning.

14.Do not use the telephone to report a gas leak in the vicinity of the leak.

Save these instructions.

Introduction

The SJA9190 lets you know who’s calling by announcing the Caller’s telephone number when the phone rings, without interrupting what you’re doing. If the Caller’s telephone number is not available, the unit will announce “Number Unknown.” If the Caller has blocked their telephone number, the unit will announce “Number Blocked.”

Check the Package Contents

Check the package contents to make sure you have the following items: talking Caller ID unit and telephone line cord.

Care and handling of your batteries

Please read these instructions before installing batteries. Make sure to insert the batteries properly, following the symbols showing you the correct way to position the positive (+) and negative (-) ends of the batteries.

Replace batteries with the size and type specified by the device’s manufacturer. Remove all used batteries from the device at the same time, then replace them with new batteries of

Introduction

the same size and type.

Don’t dispose of batteries in a fire—they may rupture or leak.

Don’t mix old and new batteries, or mix different types or makes of batteries. This can cause rupture or leakage, resulting in personal injury or property damage.

Installation

Don’t give batteries to young children.

Installation

Set up the product by installing three (3) “AAA” batteries inside the battery compartment on the underside of the unit. The unit will also work with a compatible AC Adapter (7.5VDC output with negative pin polarity.) Plug one end of the telephone cord into the telephone jack on the wall, and the other end into either of the telephone jacks on the back of the unit. An extra telephone jack is provided on the back of the unit for connecting a telephone or

Operation

other device at your option.

Screening telephone calls while you’re at home

The talking Caller ID works with standard (number-only) and deluxe (name and number) Caller ID service available from your local telephone company. The unit identifies calls by announcing the Caller’s ten-digit telephone number between the first and second ring. If the call is coming from a number that has been blocked, it will announce “Number Blocked.” If the telephone number is unidentified, the unit will announce “Number Unknown.” If the phone is still ringing, and you didn’t hear the number being announced, just press the big key and it will repeat the number.

Audibly Reviewing Calls

The unit stores the last ten calls in memory for audible review. This is convenient for finding out who called while you were out. There are two ways to perform audible call review:

1. Press the big key to hear the date, time, and telephone number of the most recent call in the log. Subsequent pressing and releasing this key will go further back into the call log and announce information about earlier

Operation

calls. Pressing the big key while an announcement is in process pre-empts the current announcement and goes to the next call. After the final call is announced, the unit beeps. Continued pressing will start back at the top of the log again.

2. Hold down the big key for 2-seconds, and it will announce the number of new calls followed by the date, time, and telephone number of every new call in the log. After the final call is announced, the unit beeps.

Language Selection

The unit speaks in English and Spanish. To change the selected language, hold down the small key and momentarily press and release the big key. The unit announces “January” in the selected language.

Erasing Calls

To erase the calls in the audible call log, hold down the big key for 4-seconds. The unit beeps confirming the calls have been erased.

Volume Control

There are four volume settings - low, medium, high, and off. To change the volume, press and release the small key very quickly. You may find it helpful to press the key using the eraser-

Operation

end of a pencil. The key is designed so that it is difficult to change the setting by accident. The unit beeps reflecting the new volume setting. It beeps twice to indicate the volume is turned OFF. If the volume is set to OFF, incoming calls will not be announced. Calls reviewed while the

Troubleshooting & FAQ

volume is OFF will be announced at medium volume level.

Troubleshooting & FAQs

Having problems? Before contacting PHILIPS or your dealer, check the following list of suggestions. You might be able to solve the problem yourself.

Question:

My unit does not announce anything when the phone rings.

Answers:

Make sure the volume is turned up. To turn up the volume, press the volume control button (small button) with your finger or a pencil eraser until you hear the unit “beep” at the desired volume level. If you hear the unit beep twice, then the volume is off.
