Page 1
www.philips.com/welcome
User manual
Always there to help you
Register your product and get support at
SHB5000
Question?
Contact
Philips
Page 2
Page 3
1
English
EN
Contents
1 Important 2
Hearing Safety 2
Electric-, Magnetic- and
Electromagnetic Fields (EMF) 2
General information 2
Disposal of your old product 3
Remove the integrated battery 3
Notice for the European Union 3
Trademarks 3
2 Your bluetooth stereo headset 4
Introduction 4
What's in the box 4
What else you'll need 4
Compatibility 5
Overview of your Bluetooth stereo
headset 5
3 Get started 6
Charge the headset 6
Pair the headset with your mobile phone 6
4 Use the headset 7
Connect the headset to a mobile phone 7
Use your headset 7
Clip the headset 8
Get the best t 8
5 Technical data 9
6 Frequently asked questions 10
Bluetooth headset does not switch on. 10
Fail to pair with a mobile phone. 10
Pairing does not work. 10
The mobile phone cannot nd the
headset. 10
Voice dialing or redialing does not work. 10
The headset is connected to a
Bluetooth stereo enabled mobile
phone, but music will play on the
mobile phone's speaker only. 10
Audio quality is poor and crackling
noises can be heard. 10
Audio quality is poor when streaming
from the mobile phone is very slow,
or audio streaming does not work at all. 10
I hear but cannot control music on my
device (e.g. skip forward/backward). 11
Page 4
2 EN
1 Important
Hearing Safety
Danger
• To avoid hearing damage, limit the time you use the
headphones at high volume and set the volume to a
safe level. The louder the volume, the shorter is the safe
listening time.
Be sure to observe the following guidelines
when using your headphones.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the volume
continuously upwards as your hearing
adapts.
• Do not turn up the volume so high that
you can’t hear what’s around you.
• You should use caution or temporarily
discontinue use in potentially hazardous
situations.
• Excessive sound pressure from earphones
and headphones can cause hearing loss.
• Using this headset with both ears covered
while driving is not recommended and may
be illegal in some areas while driving.
• For your safety, avoid distractions from
music or phone calls while in trafc or
other potentially dangerous environments.
Electric-, Magnetic- and
Electromagnetic Fields (EMF)
1. Royal Philips Electronics manufactures and
sells many products targeted at consumers,
which, like any electronic apparatus, in
general have the ability to emit and receive
electromagnetic signals.
2. One of Philips’ leading Business Principles
is to take all necessary health and safety
measures for our products, to comply with all
applicable legal requirements and to stay well
within the EMF standards applicable at the
time of producing products.
3. Philips is committed to develop, produce and
market products that cause no adverse health
effects.
4. Philips conrms that if its products are
handled properly for their intended use,
they are safe to use according to scientic
evidence available today.
5. Philips plays an active role in the development
of international EMF and safety standards,
enabling Philips to anticipate further
developments in standardization for early
integration in its products.
General information
To avoid damage or malfunction:
• Do not expose the headset to excessive heat.
• Do not drop your headset.
• Apparatus shall not be exposed to dripping
or splashing.
• Do not allow your headset to be submerged
in water.
• Do not use any cleaning agents containing
alcohol, ammonia, benzene, or abrasives.
• If cleaning is required use a soft cloth, if
necessary dampened with a minimum
amount of water or diluted mild soap, to
clean the product.
About operating and storage temperatures
• Do not operate or store in a place where
temperature is below -15ºC (5ºF) or above
55ºC (131ºF) as this may shorten your
battery life.
• The integrated battery shall not be exposed to
excessive heat such as sunshine, re or the like.
Page 5
3
English
EN
Disposal of your old product
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC.
Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste. Correct disposal of
your old product helps to prevent potential
negative consequences for the environment and
human health.
Battery disposal
Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot
be disposed of with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries. The correct
disposal of batteries helps prevent potentially
negative consequences on the environment and
human health.
Remove the integrated
battery
Warning
• Make sure the headset is disconnected from the USB
charging cable before removing the battery.
If there is no collection/recycling system for
electronic products in your country, you can
protect the environment by removing and
recycling the battery before disposing the
headset.
Notice for the European
Union
Hereby, Philips Consumer Lifestyle, BG
Communications, Headphones & Accessories,
declares that this Philips Bluetooth stereo
headset SHB5000/SHB5000WT is in
compliance with the essential requirements and
other relevant provisions of Directive 1999/5/
EC .
Trademarks
Trademarks are the proper ty of Koninklijke
Philips Electronics N.V. or their respective
owners. The Bluetooth word mark and logos
are owned by the Bluetooth SIG, Inc. and
any use of such marks by Koninklijke Philips
Electronics N.V. is under license.
a
b
Page 6
4 EN
2 Your bluetooth
stereo headset
Congratulations on your purchase, and
welcome to Philips! To fully benet from the
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With this Philips Bluetooth stereo headset, you
can:
• Enjoy convenient wireless hands-free call
• Enjoy and control wireless music
• Switch between calls and music
What's in the box
• Main unit
• Headset
• USB charging cable
• Exchangeable rubber ear caps
• Quick start guide
What else you'll need
A mobile phone that is capable of Bluetooth
stereo streaming is compatible with the
Bluetooth A2DP prole.
Other devices (Notebooks, PDA's, Bluetooth
adapters, MP3 players etc.) are also compatible
if they share the Bluetooth proles supported
by the headsets. These proles are:
For wireless Hands-Free communication:
• The Bluetooth Headset proles (HSP) or
the Bluetooth Hands-Free prole (HFP).
For wireless stereo listening:
• The Bluetooth Advanced Audio
Distribution prole (A2DP).
For wireless music control:
• The Bluetooth Audio Video Remote
Control prole (AVRCP).
Philips Bluetooth stereo headset SHB5000/SHB5000WT
Quick start guide
EN
Page 7
5
English
EN
Compatibility
Your headset is compatible with Bluetooth
enabled mobile phones. It features Bluetooth
version 3.0. It also works with devices featuring
other Bluetooth versions that support the
Headset prole (HSP), Hands-Free prole
(HFP), Advanced Audio Distribution prole
(A2DP) and Audio/Video Remote Control
prole (AVRCP).
Overview of your Bluetooth
stereo headset
a
• Turn the headset on or off
• Play/Pause/Pick up call/Hang up/Redial/
Reject call
b Charging slot
c Audio output jack
d Volume/Track control
e Microphone
Page 8
6 EN
3 Get started
Charge the headset
Warning
• Before you use your headset for the rst time, charge
the battery for four hours for optimum battery capacity
and lifetime.
• Use only the original USB charging cable to avoid any
damage.
• End a call before charging the headset, as connecting
the headset for charging will power off the unit.
Plug the headset into a powered USB port with
an USB charging cable.
» LED turns white during charging and
turns off when the headset is fully
charged.
Tip
• Normally, a full charge takes three hours.
Pair the headset with your
mobile phone
Before you use the headset with your mobile
phone for the rst time, pair it with the mobile
phone. A successful pairing establishes a unique
encrypted link between the headset and the
mobile phone. The headset stores the last four
links in the memory. If you try to pair more
than four devices, the link for the earliest paired
devices is replaced by the new link.
1 Make sure that the mobile phone is turned
on and its Bluetooth feature is activated.
2 Make sure that the headset is charged and
turned off.
3 Press and hold until the LED starts
ashing white and blue alternately.
» The headset is in pairing mode, which
lasts two minutes.
4 Pair the headset with the mobile phone.
For details, refer to the user manual of
your mobile phone.
A sample pairing is shown below.
1 Activate the Bluetooth feature of your
mobile phone, search for the mode
number of the headset.
2 On mobile phones featuring Bluetooth
2.1+EDR or higher, you do not need to
enter a pass code.
3 From the found devices, select Philips
SHB5000.
• Enter "0000" (4 zeros) if prompted to
enter the pin code of the headset.
Settings
Select
Back
Connectivity
10:37
Enter Password
****
0000
Settings
Bluetooth
Select
Back
Connectivity
10:35
Add
Bluetooth
device
Settings
Devices Found
Select
Back
10:36
Philips SHB6000
Settings
Select
Back
Connectivity
10:37
Enter Password
****
0000
Settings
Bluetooth
Select
Back
Connectivity
10:35
Add
Bluetooth
device
Settings
Devices Found
Select
Back
10:36
Philips SHB5000
Page 9
7
English
EN
4 Use the headset
Connect the headset to a
mobile phone
1 Turn on your mobile phone.
2 Press and hold to turn the headset on.
» The blue LED ashes.
» The headset is reconnected to the last
connected device automatically. If the
last one is not available, the headset
tries to reconnect to the second last
connected device.
Tip
• If you turn on the mobile phone or its Bluetooth
feature after turning on the headset, connect the
headset from the Bluetooth menu on your mobile
phone.
Use your headset
Task Operation Sound or
LED Indicator
Turn the
headset on.
Press and hold
for more
than 1 second
• 4 scale
tones from
low to high
• Blue LED
ashes
Turn the
headset off.
Press and hold
for more
than 4 seconds
• 4 scale
tones from
high to low
• White LED
ashes and
goes out
Play or pause
music.
Press
Pick up or
terminate a
call.
Press
1 short beep
Reject a call. Press and hold
for more
than 1 second
1 long beep
Redial the
last number.
Press twice
2 short beeps
Switch caller
in a call.
Press and hold 1 long beep
Adjust
volume.
Press ●●/● Beep at max/
min level
Skip forward. Press and hold
●●
Skip
backward.
Press and
hold ●
Other status and indicators
Headset status Indicator
The headset is connected
to a Bluetooth device, while
the headset is in standby
mode or while you are
listening to music.
Blue LED
ashes every 6
seconds.
The headset is ready for
pairing.
LED ashes
whiteand
bluealternately.
The headset is on but not
connected to a Bluetooth
device.
Blue LED
ashes fast.
There is an incoming call. Blue LED
ashes twice
per second.
Low battery. White LED
ashes.
Battery is fully charged. White LED is
off.
Page 10
8 EN
Clip the headset
Note
• To keep high quality of the sound, clip the headset
within 20 cm from your mouth.
Clip the headset for your convenience.
Get the best t
1 Choose the exchangeable rubber ear caps
that best t for your ear canal.
2 Twist the earbuds to the right position for
best t and noise isolation.
Page 11
9
English
EN
5 Technical data
• Up to 9 hours of play time or talk time
• Up to 200 hours of standby time
• Normal time for a full charge: 3 hours
• Rechargeable Lithium-Polymer battery
(200 mAh)
• Bluetooth 3.0, Bluetooth mono support
(Headset Prole - HSP, Hands-Free
Prole - HFP), Bluetooth stereo supported
(Advanced Audio Distribution Prole
- A2DP; Audio Video Remote Control
Prole - AVRCP)
• Operating range: Up to 15 meters (50
feet)
• Digital echo & noise reduction
Specications are subject to change without
notice.
Page 12
10 EN
6 Frequently
asked questions
Bluetooth headset does not
switch on.
Battery is low.
• Charge the headset.
Fail to pair with a mobile phone.
Bluetooth disabled.
• Enable the Bluetooth feature on your
mobile phone and turn on the mobile
phone before you turn on the headset.
Pairing does not work.
The headset is not in pairing mode.
• Follow the steps described in this user
manual.
• Make sure that the LED light ashes
whiteand blue alternately before you
release . Do not stop holding the button
after seeing the blue LED only.
The mobile phone cannot
nd the headset.
The headset may be connected to another
previously paired device.
• Turn the connected device off or move it
out of range.
Pairings may have been reset or headset has
been previously paired with other device.
• Pair the headset with the mobile phone
again as described in the user manual.
Voice dialing or redialing does
not work.
Your mobile phone may not support this
feature.
The headset is connected to
a Bluetooth stereo enabled
mobile phone, but music will
play on the mobile phone's
speaker only.
The mobile phone may have the option to
listen to music via speaker or headset.
• Refer to the user manual of your
mobile phone on how to transfer the
music to the headset.
Audio quality is poor and
crackling noises can be heard.
The Bluetooth audio source is out of range.
• Reduce the distance between the headset
and the Bluetooth audio source, or
remove obstacles between them.
Audio quality is poor when
streaming from the mobile
phone is very slow, or audio
streaming does not work at
all.
The mobile phone may only support (mono)
HSP/HFP but not support A2DP.
• Refer to the user manual of the mobile
phone for detailed information on
compatibility.
Page 13
11
English
EN
I hear but cannot control
music on my device (e.g. skip
forward/backward).
The Bluetooth audio source does not support
AVRCP.
• Refer to the user manual of the audio
source for detailed information on
compatibility.
Please visit www.philips.com/support for
further support.
Page 14
Specifications are subject to change without notice
© 2013 Koninklijke Philips Electronics N.V.
All rights reserved.
SHB5000_UM_00_EN
0168
Loading...
