Philips SE735 User Manual

8VHUPDQXDO

Contents

4 Important Information

4 For your safety 4 Installation requirements 4 Need Help?

5 What’s in the box?

6Your SE735

6 Overview of the handset 9 Overview of the base station 10 Main features of your SE735

12 Connect

13 Install

17 USB Connection

21 Call

26 Phonebook

31 Call log

33 SMS

41 Clock & Alarm

43 Personal Settings

49 Advanced Settings

55 Network Services

58 Games

59 Telephone Answering Machine (TAM)

66 Troubleshooting

69 Information

70 Index

Important Information

For your safety

This equipment is not designed to make emergency calls in the event of a power failure. Alternative arrangements should be made for access to emergency calls.

To avoid damage or malfunction:

- Do not allow the product to come into contact with liquid.

- Do not open it as you could be exposed to high voltages.

- Never use any battery type other than the one supplied.

- Do not hold the handset too close to your ear when the phone is ringing or when activating the loudspeaker as it may damage your hearing.

- Do not expose the phone to excessive heat caused by heating equipment or direct sunlight.

- Do not drop your phone or allow objects to fall on your phone.

- Do not use any cleaning agents containing alcohol, ammonia, benzene, or abrasives as these may harm the set.

- Active mobile phones in the vicinity may cause interference.

About operating and storage temperatures

- Operate in a place where temperature is always between 0 and 35º C (32 to 95º F).

- Store in a place where temperature is always between -20 and 45º C (-4 to 113º F).

- Battery life may be shortened in low temperature conditions.

Installation requirements

This product requires an electrical supply of 220-240 volts, alternating monophased power, excluding IT installations defined in standard EN 60-950. In case of power failure, the communication can be lost.

The electrical network is classified as hazardous according to criteria in the standard EN 60-950. The only way to power down this product is to unplug the power supply unit from the electrical outlet. Ensure the electrical outlet is located close to the apparatus and is always easily accessible.

The voltage on the network is classified as TNV-3 (Telecommunication Network Voltages), as defined in the standard EN 60-950.

Need Help?

For more information on troubleshooting:

Troubleshooting: page 66

Please refer to the following website for more information on Philips web support:

Online Support

www.philips.com/support

What’s in the box?

The following accessories are included with your SE735:

Handset

Belt clip

Warranty card

The line adaptor may not be attached to the line cord. In this case, you have to connect the line adaptor to the line cord first before plugging the line cord to the line socket.

In multihandset packs, you will find one or more additional handsets, chargers with power supply units and additional rechargeable batteries.

Base station

Battery door

User Guide

Power supply for

base station

Headset USB cable

Quick Start

Guide

Line cord

Installation CD

2 AAA

rechargeable

batteries

Your SE735

Overview of the handset

Earpiece

LCD Screen

Event LED

Up/Down Navigation keys

Left Soft key

Talk key

Keypad lock

Loudspeaker

key

Right Soft key

headset jack

Hang-up key

Alphanumeric keypad

Case key / Pause key / Ringer off key

Intercom key

Microphone

USB socketUSB socket

Handset keys

Press To

(Left soft key)

(Right soft key)

r e

c v #

Your SE735

Enter the main menu from stand-by mode. Select the function displayed on the handset screen directly above it. Activate mute function during a call. Switch on the backlight.

Go to redial list from stand-by mode. Select the function displayed on the handset screen directly above it. Initiate a second call, call transfer or consult the phonebook during a call. Switch on the backlight.

Answer an incoming external or internal call. Insert R for operator services when on the line.

Hang up a call. Return to stand-by mode. Long press in stand-by mode to switch off the handset, short press to switch on the

handset again.

Access call log from stand-by mode. Scroll up a menu list or go to the previous phonebook or call log record. Increase earpiece volume during a call. Go to the previous character in editing mode.

Access phonebook from stand-by mode. Scroll down a menu list or go to the next phonebook or call log record. Decrease earpiece volume during a call. Go to the next character in editing mode.

Initiate an internal call.

Answer an incoming call in handsfree mode. Activate and deactivate the loudspeaker* during a call.

Dial # in stand-by mode.

Long press to mute the ringer in stand-by mode. Long press to insert a pause in dialling mode. Long press to switch between upper and lower case in editing mode.

Dial * in stand-by mode. Long press to activate and deactivate keypad lock.

Soft key

BACK

*WARNING Handsfree activation can suddenly increase the volume in the earpiece to a very high

level. Make sure the handset is not too close to your ear.

Short press from menu browsing to return to the previous menu.

Your SE735

Display icons & symbols

In stand-by mode, several icons & symbols may be displayed on the handset.

The handset is registered and within range of the base station. It blinks when the handset is out of range or is searching for a base.

Battery symbol indicating 3 different battery levels.

The ringer volume is set to zero.

The keypad is locked.

There is an external incoming call, an external call is connected or an external call is held.

There is an internal incoming call, an internal call is connected or an internal call is held.

The loudspeaker is ON.

Alarm clock is activated.

SMS reception is activated. It blinks when the memory for SMS is full.

Telephone answering machine (TAM) is activated. It blinks when the memory for answering machine messages is full.

Do not Disturb mode is activated.

When there are new events, such as new missed calls, new SMS, voicemail or answering machine messages received, the following icons, together with the number of occurrences are displayed in the middle of the handset screen.

If you have not subscribed to Caller Line Identification service, there will not be any alerts for the new events except for new messages recorded on the answering machine. Hence, no missed call, SMS, or voicemail event icons will appear in the middle of the handset screen.

There are new SMS messages received. The number of new SMS messages received is also displayed on the left of the icon.

There are new missed calls. The number of new missed calls is also displayed on the left of the icon.

There are new voicemail messages received. The number of new voicemail messages received is also displayed on the left of the icon.

There are new answering machine messages received. The number of new messages received is also displayed on the left of the icon.

Your SE735

Overview of the base station

Volume keys

Time

Message number

Delete key

Paging key

Answer Machine

On/Off key

Base station keys

c o v x

p l

Next message key

SIM card tray

Previous message/

Replay message key

Page handset.

Long press to start registration procedure.

Short press to turn the answering machine On/Off.

Increase speaker volume during message playback. Reduce speaker volume during message playback.

Delete current message during message playback. Long press to delete all messages when TAM is in stand-by mode

(unread messages will not be deleted).

Play phone messages (the first recorded will be played first). Stop message playback.

Go to previous message if pressed within 1 second of current message playback.

Replay current message if pressed after 1 second of current message playback.

Skip to the next message during message playback.

Play/Stop key

Your SE735

LCD Message counter Displays current time when the answering machine is switched off

or in stand-by mode.

Displays date & time of recording and message number during playback.

Blinking: Indicates number of new messages.

Steady: Indicates number of old messages.

2 bars flashing: Indicates that there is no more memory left.

Indicates the volume level (L0 - L9) when

Indicates the current message number during playback.

Main features of your SE735

The following is an overview of the menu options that are available in your SE735. For detailed explanation of the menu options, please refer to the corresponding sections in this User Guide.

Menu To Page

SMS Setup, write/read SMS, etc. 33

v is pressed.

PHONEBOOK Add, edit, manage phonebook entries and copy phonebook

entries from SIM card.

CLOCK &

ALARM

PERSONAL SET Set Handset tone, Wallpaper, View Foto Pic, Contrast, Handset

ADVANCED

SET

NET. SERVICE Set Call forwarding, Voice mail, Call back and Caller ID. 55

GAMES Play games 58

ANSWER

MACHINE

Set date and time, alarm, alarm tone and Do not Disturb mode.

name, Auto Pick-up/Hang-up, Languages, Babysit mode, Backlight time and Theme Colour.

Set Recall time, Dial mode, Call barring, Baby call mode, Register/Unregister handset, Select Base, Change PIN, Reset phone, Auto prefix, Conference mode and Demo mode.

Setup, play, delete phone messages, record memo, etc. 59

Your SE735

Menu navigation

The basic steps of navigating through the menus and options are as follows:

Task Action Illustration

Enter main menu/menu options Choose

MENU by pressing the key

directly below it (left soft key

Philips

• Go to a specific menu/option

• Confirm your selection

In this example, the alarm is On

Once.

• To change your selection.

• To confirm your selection.

• Return to previous menu level or stand-by screen

1. Press

2. Choose

1. Press

2. Choose

3. Choose

: key to scroll to your

desired menu/option

SELECT by pressing the

key directly below it (left soft key

: key to scroll to your

desired option

SELECT by pressing the

key directly below it (left soft

key

BACK by pressing the

key directly below it (right soft

key

08-08

Off

On Once

On Daily

SELECT

Alarm

 

18:00

REDIAL

BACK

Connect

The location of your base station can have an effect on the range and performance of your SE735 (see TIP below).

Connecting the Base Station

1. Place the base station in a central location near the telephone line socket and electricity sockets.

2. Connect the line cord and the power cable to the proper connector at the back of the base station.

Connect the

power supply

3. Connect the other end of the line cord to the telephone line socket and the other end of the power cable to the electricity socket.

The line adaptor may not be attached to the line cord. In this case, you have to connect the line adaptor to the line cord first before plugging the line cord to the line socket.

TIP Avoid placing the base station too close to large metal objects such as filing cabinets, radiators or electrical appliances. This can impair the range and sound quality. Buildings with thick internal and external walls may impair transmission of signals to and from the base.

WARNING The base station does not have an ON/OFF switch. Power is applied when the power adaptor is plugged into the unit and connected to the electricity socket. The only way to power down the unit is to unplug the power adaptor from the electricity socket. Therefore, ensure that the electricity socket is easily accessible.

The power adaptor and telephone line cord have to be connected correctly, as incorrect connection could damage the unit.

Always use the telephone line cord supplied with the unit. Otherwise, you may not get a dial tone.

Connect the line cord to the line socket

Install

Install battery

Your SE735 is supplied with 2 rechargeable batteries allowing approximately up to 12 hours of talk-time and up to 168 hours stand-by time. Before using the handset, the batteries have to be installed and fully charged.

1. Slide out the battery cover.

2. Place the batteries as indicated and replace the cover.

Charge battery

1. Place the handset on the charging cradle of the base station. A beep is emitted if the handset is placed correctly.

2. A charging animation on the handset indicates that the battery is charging.

18:00

REDIAL

Philips

08-08

3. Leave it there until the batteries are fully charged (at least 24 hours).

4. The handset is fully charged when the charging animation stops and is displayed.

The handset must be charged for at least 24 hours before using it for the first time.

Low battery warning

The battery level is shown at the top left of the handset screen. When the battery level becomes low, an empty battery icon is displayed on the screen.

If the battery level becomes exceedingly low, the phone automatically switches off and any function in progress will not be saved.

Install

Out of range warning

The indoor and outdoor range of the phone is up to 50 metres and 300 metres respectively. When the handset moves beyond operation range, the antenna icon will blink.

Attach/Remove belt clip

A belt clip allows you to carry your handset on your belt.

1. To attach the belt clip to your handset, fit the tabs on the belt clip into the slots at the back of the handset and push into place.

2. To remove the belt clip, simply pull the clip away from the handset.

Configure your SE735

Before you use your SE735, you need to configure it according to the country of use. After charging it for a few minutes, the word WELCOME appears in various languages. Follow these steps to configure your phone:

1. Scroll : to the word WELCOME in your preferred language and press mSELECT.

2. Scroll

3. Press

4. Scroll

5. Press

6. The default line settings and menu language for the selected country will be automatically configured.

: to your country.

mSELECT to confirm your selection.

: to your operator (if necessary).

mSELECT again to confirm your selection.

You cannot make outgoing calls or receive incoming calls without first defining your country selection.

Depending on your country, the WELCOME screen may not appear. In this case, you are not required to select your country/operator/language settings.

Set date and time

1. Press mMENU.

2. Scroll

: to Clock & Alarm and press mSELECT.

Install

3. Press mSELECT to enter Set Date/Time.

4. Enter current time (HH:MM) and current date (DD/MM/YY) and press

WARNING If your phone is connected to an ISDN line through an adaptor, the date & time may be updated after each call. The availability of date & time update is dependent on your network provider. Please check the date & time settings in your ISDN system or contact your network provider.

Now, you are ready to use your phone.

Basic operations of your SE735

Make a call

Enter the phone number (maximum 20 digits) and press r to dial the number.

For details, please refer to "Make a call" on page 21.

Answer or end a call

Press r key to answer a call.

e key to end a call.

Press

For details, please refer to "Answer a call" on page 21 and "End a call" on page 22.

Switch the handset on/off

Press and holde key for 3 seconds to switch off the handset in stand-by mode.

Short press

e key to switch on the handset again.j

mOK.

Keypad lock/unlock

Press and hold * key for 2 seconds to lock or unlock the keypad in stand-by mode.

Paging

The paging feature enables you to locate a missing handset if the handset is in range and contains charged batteries.

Short press

Once retrieved, press any key on the handset to end the paging.

c key on the base. The handset starts to ring.

Stand-by mode

If the handset is not used for 30 seconds in settings mode, review mode, edit mode, etc. it will automatically return to stand-by mode. It will also return to stand-by mode automatically when the handset is placed back on the base station.

Install

Screen and keypad backlight

The backlight remains on for 20 seconds after each activation such as an incoming call, key presses, lifting up the handset off the base station, etc. The colour of the LCD and keypad backlight is WHITE.

For setup details, please refer to "Backlight time" on page 48.

Event LED

The event LED on your handset blinks when there is a new message recorded on your telephone answering machine. If you have subscribed to Caller Line Identification, the event LED also blinks when there is a new call, a new SMS or a new voice mail message.

Default settings

Ringer Volume Medium

Earpiece Volume Volume 3

Speaker Volume Volume 3

Key Beep On

Wallpaper

Contrast Level 2

Auto Pick-up Off

Auto Hang-up On

Babysit mode Off

Alarm clock Off

Barring mode Off

SMS reception On

Master PIN 0000

Answering Machine

Answer Mode Answ. & Record

Ring delay 5

Outgoing Messages Predefined for Answ. & Record mode

Base station screening On with default speakerphone level

Handset screening Off

Base speaker Level 5

Remote access Deactivated

USB Connection

USB connection

Your SE735 is able to download melodies (maximum 20 KB, in MIDI format), wallpapers (128 x 160 pixels), as well as portrait pictures for fotocall (96 x 64 pixels) from your PC to your handset via USB connection. There are also a number of ring melodies, wallpaper and fotocall pictures pre-installed in your handset and the installation CD.

Before you can download PC files to your handset, you need to install the Download Software.

Install USB download software

1. Insert the CD supplied with your SE735 into the CD ROM drive of your PC.

2. Follow the onscreen instructions to complete the installation of the PC Download Software and USB driver.

3. During installation, the software will prompt you with dialogue boxes to accept or cancel the operations. You should choose to accept each operation and continue with your installation.

4. You may need to restart your PC after software installation.

If the installation program does not start automatically, browse the CD contents via Windows

Explorer and run the program by double clicking setup.exe.

System requirements:

CPU Pentium II 350MHz equivalent or better

Operating System Microsoft Windows 2000, Microsoft Windows XP or Windows ME

RAM 64MB or more

Minimum Hard Disk Space 150MB

Connection USB Type 1.1 or higher

CD ROM 8x CD-ROM drive or faster

Screen 800 x 600 pixels or higher

Display 16 bit high colour or higher

USB Connection

Connect the handset to your PC

USB connection can only be established when the handset is in stand-by mode and the backlight is switched on. If the handset is in menu mode or goes into screensaver mode, press any key to return to stand-by mode before you connect the handset to the PC.

To connect the handset to your PC, plug one end of the USB jack into the USB socket at the bottom of the handset, and then plug the other end of the USB jack to the USB port of your PC. When the USB cable is connected, the screen will display Waiting for about 12 seconds. After that, it will display USB Connected.

Plug the USB jack into the USB socket at the bottom of the handset.

USB socket

When the handset is in USB Download mode, all handset keys will be locked until the USB cable is removed from the handset.

When there is an incoming call during USB download, data transfer will stop. The handset will only emit a beep tone and display External Call on the screen. The caller identity of your correspondent will not be displayed. To answer the call, press

e key or

Download melodies

There are 16 ring melodies pre-installed on your SE735. KB) or replace it by downloading a new melody from your PC to your handset via USB connection

1. Launch Download Software by selecting Start > Programs > Download Software on your PC.

2. Click the Ringtone icon on the left of the windows to view the MIDI files that are available for use as ring melodies on your handset.USB Connection.

You can add an additional ring melody (maximum 20

USB Connection

Ringtone

icon

Play button

3. Select the MIDI file you wish to download from the selection window and click the PLAY button to listen to the MIDI file to make sure it is the correct ring melody you wish to download onto your handset.

4. Make sure that the handset is connected to the PC and click the Download button. A progress bar is displayed to indicate the download progress.

5. When the download is completed, safely remove your handset from your PC.

Selection window

Download button

Progress bar

Download wallpapers

There are 6 wallpapers pre-installed on your SE735. The 3rd wallpaper can be overwritten by downloading a new wallpaper from your PC to your handset via USB connection. The 4th wallpaper is a blank wallpaper.

1. Launch Download Software by selecting Start > Programs > Download Software on your PC.

2. Click the Wallpaper icon on the left of the windows to view the picture files (BMP, JPG and GIF) that are available for use as wallpaper on your handset.

3. Select the wallpaper you wish to download from the selection window.

Selection window

Preview window

Wallpaper

icon


window

Download button

Progress bar

USB Connection

4. The image will appear in the Image window and the actual size will be displayed. You may resize the image in the Image window and select which part of the image to be used as wallpaper. You can also preview the image in the Preview window to make sure this is how you would like your wallpaper to appear on your handset.

5. Make sure that the handset is connected to the PC and click the Download button. A progress bar is displayed to indicate the download progress.

6. When the download is completed, safely remove your handset from your PC.

Download photo IDs

There are 20 fotocall pictures pre-installed on your SE735. You can download and overwrite any existing fotocall picture via USB connection.

1. Launch Download Software by selecting Start > Programs > Download Software on your PC.

2. Click the Fotocall icon on the left of the windows to view the photos that are available for use as fotocall pictures on your handset.

Selection window

Preview window


Fotocall

icon


window

selection box

Download button

Progress bar

3. Select the photo you wish to download from the selection window.

4. The photo will appear in the Image window and the actual size will be displayed. You may resize the photo in the Image window and select which part of the photo to be used as fotocall picture. You can also preview the photo in the Preview window to make sure this is how you would like your fotocall picture to appear on your handset.

5. In the Picture selection box, select the position number (1 to 20) of the fotocall picture you wish to overwrite on your handset. If you select 3, then the third fotocall picture on your handset will be replaced with the new picture.

6. Make sure that the handset is connected to the PC and click the Download button. A progress bar is displayed to indicate the download progress.

7. When the download is completed, remove your handset safely from your PC.

Call

Make a call

Predialling

1. Enter the phone number (maximum 20 digits).

2. Press

Direct dialling

1. Press r or v to take the line.

2. Enter the phone number.

Call from redial list

1. Press >REDIAL in stand-by mode.

2. Scroll

3. Press

Call from the call log

1. Press u in stand-by mode.

2. Press

3. Scroll

4. Press

r to dial the number.

: to an entry in the redial list.

r to dial the number.

TIP The handset stores the last 7 numbers dialled. The last number dialled will appear first in the redial list. If the redial number matches a phonebook entry, the name will be displayed instead.

mSELECT to enter call list.

: to an entry in the call list.

r to dial the number.

You need to subscribe to Caller Line Identification service to be able to see the caller’s number or name in the call log. See "Call log" on page 31 for details.

Call from the phonebook

1. Press d in stand-by mode.

2. Scroll

3. Press

: to a phonebook entry.

r to dial the number.

TIP Instead of scrolling : to browse the phonebook entries, press the numeric key corresponding to the first letter of the entry you wish to locate. For example, pressing starting with A. Pressing

2 again will show the entries starting with B, etc...

2 will show the entries

Answer a call

When the phone rings, press r key.

Call

Handsfree answering

When the phone rings, press v key.

Incoming call has priority over other events. Whenever there is an incoming call, other status in progress such as phone setting, menu navigation, etc will be aborted.

TIP If Auto Pick-up mode (see page 47) is activated, you can simply lift up the handset from its base station to answer the call. This feature is deactivated by default.

WARNING When the handset rings during an incoming call, please do not hold the handset too close to your ear as the volume of the ringing tone may damage your hearing.

End a call

Presse key.

The call duration will be displayed on the handset screen for about 5 seconds.

TIP If Auto Hang-up mode (see page 47) is activated, you can simply place the handset back to its base station to end the call. This feature is activated by default.

Calls in-progress

The following options are available during a call:

Adjust earpiece volume

1. Press : to select from Volume 1 to Volume 5.

Mute/unmute the handset

1. During a call, press mMUTE to turn off the microphone so that your correspondent cannot hear you.

2. Press

mUNMUTE to turn on the microphone.

Loudspeaker mode

1. Press v key to activate loudspeaker mode.

2. Press

v key again to return to normal mode.

WARNING Activation of loudspeaker can suddenly increase the volume in the earpiece to a very high level. Make sure the handset is not too close to your ear.

+ 49 hidden pages
