Philips Medical Systems
NEWSLETTER
Issued by : PMSN Best Reference No. : XRD-BEST 231
Date : May 2003
Service
Service Tools Newsletter
No. 44
Subject: ScopeMeter
R
R
EECCOOMMMMEENNDDAATTIIOONN AANNDD WWOORRLLD
S
S
PPMMSS--119999C
CCOOPPE
FFRROOMM
E
M
M
C
OOLLOOR
F
F
EETTEERR
R
E
LLUUKKE
0
//CC0
D
-
-
WWIIDDEE CCOONNTTRRAACCT
XX
T
::
The Tools Newsletter is for internal Philips use only. Issued by Customer Lead Office Tools. Best,
The Netherlands. E-mail: helpdesk.pmstools@philips.com
XRD-BEST 231 (03.0) 1
(c) 2003 Koninklijke Philips Electronics N.V.
ALL RIGHTS RESERVED
1 INTRODUCTION........................................................................................................................... 3
2 THE FLUKE PMS-199COL OR/C0X SCOPEMETER FOR PHILIPS MEDICAL SYSTEMS ................3
2.1 Configuration:................................................................................................................................ 3
2.2 Ordering information ......................................................................................................................4
2.3 Prices:.......................................................................................................................................... 5
2.3.1 Euro currency prices ...................................................................................................................5
2.3.2 USD currency prices ...................................................................................................................5
2.4 Special price and trade -in offer! ...................................................................................................... 5
2.5 What do I need to know further? .....................................................................................................6
3 SPECIFICATIONS ........................................................................................................................ 7
4 PROBE 1:1 ...................................................................................................................................8
5 PROBE CLIP HC200..................................................................................................................... 8
6 FLUKE VIEW SOFTWARE ............................................................................................................9
7 SPECIAL PMS COMMON S ETTINGS............................................................................................9
8 ANY QUESTIONS.......................................................................................................................10
APPENDIX 11
2 (03.0) XRD-BEST 231
(c) 2003 Koninklijke Philips Electronics N.V.
ALL RIGHTS RESERVED
1 INTRODUCTION
The recent introduction of the new Fluke color scopemeter triggered the PMS Tool Committee to investigate
and compare this new instrument with the actual recommended model PMS-199.
In close coorparation with the Professor Holst Training Centre both instruments have been compared.
Compare results:
• The Fluke 199Color is more sensitive (2mV/div) than the actual 199 model (5 mV/div). It is therefore
more useful for measuring video signals.
• The full -color display Fluke199Color) makes identification of individual waveforms easier, particularly
when displaying large amplitude or multiple overlapping waveforms on screen. On -screen color labels,
measurements and warnings are clearly linked to specific waveforms.
• The Digital Persistence mode (Fluke 190Color) helps to find anomalies and to analyze complex dynamic
signals by showing the waveforms amplitude distribution over time.
• One of the new features with the Fluke190Color is the waveform pass/fail testing. Waveform reference
allows an acquired trace to be stored and designated “reference trace” for visual comparisons.
• Improved trigger response for video measurements compared to the model 199.
• Faster response of keys à Cursors and Move button
2 THE FLUKE PMS-199COLOR/C0X SCOPEMETER FO R PHILIPS
MEDICAL SYSTEMS
New contract:
As a result of the recommendation a special package, the “Fluke PMS-199Color/C0x” will be made available
for Philips Medical Systems and a new contract has been agreed upon with Fluke.
This contract offers a considerable discount on the standard listprice (world-wide coverage).
The contract for the actual model PMS-199 will remain and this model can still be ordered.
2.1 CONFIGURATION:
FLK-199Color: ScopeMeter 190C series: 200MHz - 2.5_GS/s real time sampling -
dual channel digital oscilloscope with Color display and Digital Persistence and
integrated protective holster. “Waveform Compare” mode included.
Standard accessories:
- Mains adapter (country specific line voltage adapter / battery charger)
- Voltage Probe Set 10:1, 1 red, 1 gray (VPS200) including hook clip, ground
leads and 4 mm add-on probe tips
- Test Leads Set, 1 red, 1 black (TL 75)
SCC190 kit: PC cable PM9080 - Optically isolated RS -232 adapter/cable
FlukeView - ScopeMeter software for Windows
Hard shell carrying case - rugged, shock proof with integrated protective holster
PMS User
Manual:
Full set of user manuals on CD -rom, printed ‘Getting Started’ manual (English)
XRD-BEST 231 (03.0) 3
(c) 2003 Koninklijke Philips Electronics N.V.
ALL RIGHTS RESERVED
MA190 Medical Accessory Kit:
• 50-Ohms terminator (TR190 -50R)
• 50-Ohms terminator with 10:1 attenuation (TA190-50R)
• 1-Ohm current shunt = mAs-shunt (CS190-1R)
• 1.5m isolated BNC cable
• Male 4mm to BNC adapter (used to connect mAs-shunt)
• Two 4mm female to 4mm female adapters (used to connect mAs-shunt using test leads)
Additional features in PMS-199Color ScopeMeter
• mAs measurement using cursors. Dual channel operation is now supported, so that a secundary signal
can be used for determining the cursor position or timing reference.
• 1/T measurement with cursors
• Non interlaced video triggering also supporting high-resolution video systems
• Better video display (Smart Average)
• Better video display (Digital Persistence)
• Offset and dynamic range extended allowing extra vertical magnification (Resolution)
2.2 ORDERING INFORMATION
The Fluke PMS-199Color/C0x is ordered via your local purchase office directly at the nearest Fluke Sales
Office or at a selected Fluke representative .
An overview of the Fluke Sales Offices or selected Fluke representatives is given in the Appendix.
The PMS-199Color/C0x ScopeMeter(s) are shipped to the address indicated on the order.
Fluke code number: PMS-199Color/C0x
MAINS ADAPTER / BATTERY CHARGER :
The last digit (x) of the code number specifies the required mains adapter (see specifications, paragraph 3):
x = 1 Europe (BC190/801)
x = 3 North America (BC190/803)
x = 4 United Kingdom (BC190/804)
x = 7 Australia (BC190/807)
x = 8 Universal (BC190/808)
ORDERING EXAMPLE:
PMS-199Color/C04 : PMS-199Color/C0x 200MHz Color ScopeMeter with the UK type mains adapter.
USERS MANUAL:
The English ’Getting started’ manual is included with the ScopeMeter. Other languages and complete user
manuals ar e available on a CD Rom included with the ScopeMeter.
PHILIPS SERVICE LOGISTICS:
It is possible to order the PMS-199COLOR/C08 ScopeMeter at Philips Service Logistics but bear in mind that
the price will be higher than the one mentioned below!
12NC: 4522 300 20301 (= PMS-199COLOR/C08, no other versions possible!)
4 (03.0) XRD-BEST 231
(c) 2003 Koninklijke Philips Electronics N.V.
ALL RIGHTS RESERVED
2.3 PRICES:
Invoice currency:
The invoice to address from the corresponding Purchase Order determines the currency to be invoiced by
Fluke:
Invoice to address is Europe then invoice currency is EUR (€)
Invoice to address is Rest of World then invoice currency is USD ($)
2.3.1 EURO CURRENCY PRICES
PMS-199Color/C0x single unit: € 2.979
Special prices are offered for following minimum quantities:
PMS-199Color/C0x 5-units:
10-units: € 2.904 (price per unit)
25-units: € 2.851 (price per unit)
€ 2.957 (price per unit)
2.3.2 USD CURRENCY PRICES
PMS-199Color/C0x single unit: $ 2.979
Special prices are offered for following minimum quantities:
PMS-199Color/C0x 5-units:
10-units: $ 2.904 (price per unit)
25-units: $ 2.851 (price per unit)
IMPORTANT!!
The prices mentioned are valid if you order the Fluke PMS-199/C0x directly at the nearest Fluke sales
office or selected representative (world-wide coverage / see appendix). If you order the ScopeMeter at
Philips Service Logistics take into account that the prices you pay will be higher! There also is no
extra discount if you order 5 or more units.
Prices mentioned have a world-wide validity but does not include tr ansport costs, local taxes or
adders.
$ 2.957 (price per unit)
2.4 SPECIAL PRICE AND TRADE-IN OFFER!
When buying a PMS199Color/C0x before September 30 2003 you will pay €2851 / $2851 for a single unit!
An extra € 600/$600 discount is added when a Fluke 90 series or Fluke 105 ScopeMeter is traded in.
The trade -in rules:
• Offer only valid when buying a PMS199Color/C0x.
• Maximum of one ScopeMeter 90 series or Fluke 105 can be traded per PMS199Color/C0x purchased.
Independent of the model the discount will be €600/$600
• Unit traded in must be in a working condition.
• Specify the number of units to trade in on your order for PMS199Color/C0x
XRD-BEST 231 (03.0) 5
(c) 2003 Koninklijke Philips Electronics N.V.
ALL RIGHTS RESERVED
