Philips SCF875 User Manual [ru]

Always there to help you

SCF875

www.philips.com/welcome

User manual

4241 354 00222

100% recycled paper

사용 설명서

22 23 24

Refer to the pictures on the folded pages at the front and back of the user manual.

Contents

Important 6 Introduction 10 General description 11 Before rst use 12 Using the appliance 12 Ingredients and steaming time 20 Cleaning and descaling 21 Storage 22 Recycling 22 Guarantee and service 23 Troubleshooting 23 Technical specications 27

5ENGLISH

6 ENGLISH

Important

Read this user manual carefully before you use the appliance and save it for future reference.

Danger

- Never immerse the main unit in water or any other liquid. Do not rinse it under the tap.

Warning

- Check that the voltage indicated on the appliance corresponds to the local mains voltage before you connect the appliance.

- Do not use the appliance if the plug, the power cord or the appliance itself is damaged. If the power cord is damaged, you must have it replaced by Philips; a service center authorised by Philips or similarly qualied persons in order to avoid a hazard.

- This appliance can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

- Children shall not play with the appliance.

- Keep the appliance and its cord out of the reach of children (including accessories).

- Cleaning and user maintenance shall not be made by children.

- Do not touch the blades, especially when the appliance is plugged in. The blades are very sharp.

- Take care when handling the sharp blades, emptying the jar, and during cleaning.

- If the blades become stuck, unplug the appliance before you remove the ingredients blocking the blades.

- The appliance gets hot during or shortly after steaming (especially surfaces with this symbol “ ”) and may cause burns when touched. Only lift the jar by its handle.

- Hot steam comes out of the jar during steaming and when its lid is removed.

- Beware of hot steam that comes out of the water tank when you open its lid.

- When the steaming cycle is nished, hot steam will continue to come out of the steam outlet on the water tank lid and the steam hole in the jar for some time. Be careful when you lift the jar o the water tank.

- If the appliance is used improperly, hot steam could escape from the edge of the water tank lid. Refer to the “Troubleshooting” chapter for preventing or resolving this.

- Take extra caution when pouring hot liquid into the jar as the liquid may splash.

- Always put previously blended food in the storage pot if you want to reheat or defrost food with this appliance.

- Do not use this appliance to chop hard and sticky ingredients.

- Never use bleach or chemical sterilizing solutions/tablets in the appliance.

- Never use scouring pads, abrasive cleaners or aggressive liquids such as gasoline, acetone or alcohol to clean the appliance.

- Always let the appliance cool down for 10 minutes after one steaming cycle before you start steaming again.

- Do not let the appliance blend for more than 30 seconds at a time. If you have not nished blending after 30 seconds, release the button to stop blending and wait a few seconds before you continue. If the main unit becomes hot, let it cool down for a few minutes before you continue.

- Never put water or any other liquid in the jar for steaming to avoid damaging the appliance.

- Always remove the storage pot lid before using the pot to heat up food in a microwave.

7ENGLISH

Caution

- Never use any accessories or parts from other manufacturers or that Philips does not specically

8 ENGLISH

recommend. If you use such accessories or parts, your guarantee becomes invalid.

- Do not place the appliance on or near an operating or still hot stove or cooker.

- Always switch o the appliance and disconnect from supply when it is left unattended and before assembling, disassembling, changing accessories, cleaning or approaching parts that move in use.

- Always unplug the appliance and let it cool down before you clean it.

- Always turn the control knob to the o position (OFF) every time after steaming, reheating, or defrosting.

- Never use the jar or any other part of the appliance (except the storage pots) in a microwave, as the metal parts of the jar handle and blade unit are not suitable for this use.

- Never sterilize the jar or any other part of the appliance (except the storage pots) in a sterilizer or in a microwave, as the metal parts of the jar handle and blade unit are not suitable for this use.

- This appliance is intended for household use only. If the appliance is used improperly or for professional or semiprofessional purposes or if it is not used according to the instructions in the user manual, the guarantee becomes invalid and Philips refuses any liability for damage caused.

- Place the appliance on a stable, horizontal, and level surface. The appliance emits hot steam during use. Make sure there is enough free space around it to prevent damage to cabinets or other objects.

- Do not use the appliance if it has fallen or is damaged in any way. Take it to an authorized Philips service center for repair.

- Never use the steam function without water in the water tank.

- Make sure that the water in the tank does not exceed the MAX water level marking on the side of the water tank (250 ml) or the MAX water level indication in the water tank.

9ENGLISH

- Make sure the water tank lid is correctly locked before putting the jar on the water tank.

- When you steam ingredients, make sure that you do not ll the jar beyond the top of the gray blade unit (g b).

- When you blend liquids, do not exceed the maximum ll level indicated on the jar (720 ml) (g. c).

- Do not lift and move the appliance while it is in operation.

- Do not insert any object into the steam outlet on the water tank lid or the steam inlet on the jar lid.

- Never rell the water tank during steaming, as hot water and steam may come out of the appliance.

- Always make sure that the jar lid has cooled down after steaming before you open it to add more ingredients for blending.

- Never run this appliance’s power supply through an external switching device, such as a timer, or connect it to a circuit that is regularly switched on and o.

- Always check the temperature of the cooked food on the back of your hand to make sure it is safe for your baby.

- Always check the consistency of the food for your baby. For guidance on what food consistencies are appropriate for dierent ages, refer to the professional weaning advice that comes with this appliance, or seek advice from a doctor or consultant.

- Only use the provided spatula for taking food out of the jar.

- Regular descaling prevents damage to the appliance.

- The storage pot provided with this appliance is not a children feeding utensil. Do not feed children directly from the storage pot.

- Before using the storage pot, clean it thoroughly, and then sterilize it with a Philips Avent sterilizer or place the storage pot in boiling water for 5 minutes. This is to ensure hygiene. Make sure that there is enough water in the container when using boiling water to sterilize the storage pot, and that the pot does not contact the container for too long, to avoid heat deformation.

10 ENGLISH

- Make sure that the amount of food in the storage pot does not exceed the maximum scale marked on the side of the pot, otherwise the pot may leak.

- When reheating or defrosting food, make sure that the storage pot lid is closed tightly before putting the storage pot in the jar, otherwise the pot may leak when you take it out of the jar.

- Heating food with the provided storage pot in a microwave may produce localized high temperatures in the food and may aect its nutritional value. Always stir heated food to ensure even heat distribution and test the temperature before serving.

- Do not select the grill function if you use a combination microwave (with grill function) to reheat or defrost food with the storage pots. If you have just nished a grilling process, wait until the microwave has cooled down before putting the storage pots in it, as the residual heat can cause damage to the storage pots.

Safety systems

For your safety during use, this appliance is equipped with a built-in safety lock. This appliance will only function if all parts have been assembled correctly. Assembling all parts correctly will disarm the built-in safety lock.

This appliance is also equipped with an overheat safety stop function. Overheating can occur if the time between two steaming cycles is too short. If the appliance’s overheat safety stop activates during a steaming cycle, turn the control knob back to the o position (OFF) and let the appliance cool down for a few minutes. After this, you can use the appliance again.

Electromagnetic elds (EMF)

This Philips appliance complies with all applicable standards and regulations regarding exposure to electromagnetic elds.

Introduction

Congratulations on your purchase and welcome to Philips Avent! To fully benet from the support that Philips Avent oers, register your product at www.philips.com/welcome.

This 4-in-1 healthy baby food maker helps all parents in preparing nutritious meals for their babies with steaming and blending functions combined in one appliance. You can also use the baby food maker to defrost and warm up baby food.

General description

Product overview (g. a)

A Lid tab B Connector on the jar lid C Jar lid D Sealing ring E Locking pin F Sieve G Blade unit H Blade unit holder I Jar J Water tank lid K Water level markings L MAX water level indication M Water tank (not detachable) N Boiler O Main unit P Control knob Q Blending button R Power cord S Locking area on the water tank

11ENGLISH

Controls overview (g. a)

T Defrost setting U Reheat setting for the 240 ml storage pot V Reheat setting for the 120 ml storage pot W Steaming light

Accessories (g. a)

X Storage pot Y Storage pot lid Z Spatula

Before rst use

1 Remove all packaging material from the appliance. 2 Clean all parts thoroughly before rst use. Refer to the chapter “Cleaning

and descaling”.

12 ENGLISH

3 We recommend running one steaming cycle with an empty jar before using

the appliance for the rst time. Refer to chapters “Filling the water tank” and “Steaming”.

Using the appliance

Caution

• Always check the temperature of the cooked food on the back of your hand to

make sure it is safe for your baby.

This appliance is intended for steaming fresh, solid ingredients and blending them to the consistency of your choice. Please refer to the enclosed recipe booklet for some tasty and nutritious recipe ideas. The appliance can also be used for just steaming or blending only. For blending only, refer to the chapter “Blending without steaming”. This appliance can also be used to defrost or reheat cooked food that has been stored in the specially designed storage pots. Always use these storage pots to defrost or reheat blended foods. Defrosting or reheating without the storage pots will cause the food to drop through the sieve into the jar lid. Never put the jar with blended food inside in the steaming position on the main unit. Never steam the same batch of raw ingredients for longer than 30 minutes or more than once.

This appliance is NOT intended for the following purposes.

- Steaming frozen raw ingredients

- Steaming previously blended food without the storage pot

- Steaming the same ingredients for more than 30 minutes

- Cooking rice and pasta

- Blending rst, then steaming

- Heating or reheating liquids such as soup, sauces or water

- Keeping food warm for several hours

- Cutting hard ingredients such as ice cubes and sugar cubes, or sticky ingredients like cheese

Filling the water tank

Note

• Make sure that the water in the tank does not exceed the MAX water level marking on the side of the water tank (250 ml) or the MAX water level indication in the water tank.

• We recommend using soft or puried water, as the minerals in mineral or tap water cause limescale buildup to occur more quickly inside the water tank.

• Except for materials needed for descaling, never put any liquids other than water in the water tank.

13ENGLISH

1 Turn the water tank lid counterclockwise to open the water tank (g d), then

follow the water level markings on the water tank and ll with water to the required level according to the chapter “Ingredients and steaming time” in the user manual or the enclosed recipe booklet (Fig. e).

2 Put the water tank lid on the water tank and turn the lid clockwise to lock it

securely in place (Fig. f).

» When the water tank lid is correctly locked in place, the icon on the

water tank lid will line up with the icon on the water tank.

Note

• Always make sure that you have locked the water tank lid before the appliance starts operating.

Steaming

Caution

• Hot steam or hot water can burn your ngers. Do not touch, and never let children touch any hot parts of the appliance or the steam coming from the top of the appliance, as this may cause scalding. (Fig. g).

Note

• Always defrost frozen raw ingredients before placing them in the jar for steaming. Shake o any excess water from the defrosted ingredients before placing them in the jar.

• Do not ll past the top edge of the gray blade unit when adding ingredients.

• Never put water or any other liquid in the jar for steaming to avoid damaging the appliance.

• The appliance will not start steaming if the jar is not correctly locked in place.

• Make sure that the sealing ring is assembled around the jar lid before steaming, and that the at side of the sealing ring is facing out.

1 Push the lid tab counterclockwise to release the lid from the jar (Fig. h). 2 If the blade unit is not in the jar, put it on the blade unit holder in the jar

(Fig. i).

3 We recommend cutting solid ingredients into small pieces (cubes not bigger

than 1cm).

4 Put the ingredients in the jar (Fig. j). 5 Press the sieve into the jar lid (Fig. k). 6 Place the jar lid on the jar and turn it clockwise to close it securely (Fig. l).

Note

• The jar has grooves that help smoothly guide the locking pins and lock the lid in place. Make sure that the lid tab slides into the handle of the jar (Fig. m).

14 ENGLISH

7 If you have not yet lled the water tank with water for steaming, refer to

the chapter “Filling the water tank” and add water to the water tank before putting the jar on the main unit.

Note

• Make sure the water tank lid is correctly locked in place before placing the jar on the main unit.

8 Flip the jar over with the jar lid on the bottom (Fig. n). 9 Align the connector on the jar lid to the locking area on the water tank, and

then place the jar on the main unit with the jar lid on the bottom (Fig. o). Press the jar downwards to lock it rmly on the main unit, and make sure the handle is on the right-hand side.

10 If the control knob is not in the o position (OFF), turn it to the o position

rst.

11 Plug in the appliance. 12 Turn the control knob to select the steaming time you need (Fig. p). Refer

to the table in the chapter “Ingredients and steaming time” and the recipe booklet for the recommended steaming time.

» The steaming light will turn white to indicate that the appliance is

steaming.

» When the steaming cycle is nished, the appliance will beep and the

steaming light will go out.

13 Turn the control knob back to the o position (OFF) (Fig. q). Wait 2 minutes,

or until there is no more steam coming from the top of the appliance before removing the jar.

Caution

• If you intend to start another steaming cycle, let the appliance cool down for 10 minutes, and empty any remaining water out of the water tank before you rell and start a new steaming cycle.

14 To blend the steamed ingredients, refer to chapter “Blending after steaming”. 15 There may still be some water remaining in the water tank after a steaming

cycle. This is normal. Wait until the appliance cools down to room temperature, then empty the water tank of all residual water. To empty or clean the water tank, refer to the chapter “Cleaning and descaling”.

15ENGLISH

Blending after steaming

Caution

• The jar and the lid will become hot after the steaming cycle. Only hold the jar by the specially designed heat-resistant handle. (Fig. r).

• Always make sure that the lid of the jar is correctly closed and locked in place while the appliance is in use.

• Always make sure that the jar lid has cooled down after steaming before you open it to add more ingredients (do not ll past the top edge of the gray blade unit), or to remove the remaining water from the jar.

• If you have added additional liquids, never put the jar in the steam position, as the liquid will go through the sieve.

1 From the steaming position, lift the jar by the handle and turn it upside

down (Fig. s). Shake the jar to allow the steamed ingredients to move to the bottom of the jar where the blending blades are.

2 If needed, remove the jar lid and add additional ingredients for blending

(e.g. water for purees or additional cooked ingredients like rice or pasta). Place the jar lid back on the jar before you start blending.

3 Place the jar on the main unit with the lid on the top, align the icon on the

jar with the icon on the main unit, and turn the jar clockwise to securely lock it in place on the main unit (Fig. t). Make sure the handle is on the right-hand side.

» When the jar is correctly locked in place on the main unit, the icon on

the jar will line up with the icon on the main unit.

4 Push and hold the blending button to start blending until the ingredients are

blended to the consistency of your choice (Fig. u).

Caution

• Do not let the appliance blend for more than 30 seconds at a time. If you have not nished blending after 30 seconds, release the button to stop blending and wait a few seconds before you continue. If the main unit becomes hot, let it cool down for a few minutes before you continue.

5 When you have nished blending, release the blending button (Fig. v). 6 Unplug the appliance. 7 Remove the blended food from the jar. If necessary, use the spatula included

with this appliance.

Blending without steaming

This appliance is intended for the following purposes.

- Pureeing steamed and cooked ingredients

- Blending uids and fruits

16 ENGLISH

Caution

• The appliance is not intended for cutting hard ingredients such as ice cubes and sugar cubes or sticky ingredients like cheese.

• If you have added liquids to the jar, never put the jar in the steam position, as the liquid will go through the sieve.

Note

• When blending ingredients with uids, make sure you do not ll the jar past the MAX ll level indicated on the jar.

• Do not ll past the top edge of the gray blade unit when adding ingredients.

• Never put the jar with blended food inside in the steaming position on the main unit.

• If the ingredients stick to the wall of the jar, or if the blended ingredients are still too solid, release the blending button, remove the jar from the main unit, and loosen the ingredients with the spatula or add some liquid (e.g. drinking water) until the blended food has the right consistency for your baby’s age. When adding liquid in the jar, do not ll the jar past the MAX ll level indicated on the jar.

• Make sure that the blended baby food has the right consistency before you serve it. For guidance on what food consistencies are appropriate for dierent ages, refer to the professional weaning advice that comes with this appliance, or seek advice from a doctor or consultant.

• Do not process large quantities of solid ingredients at the same time. Process these ingredients in a series of small batches to get a ner texture.

1 Put the blade unit on the blade unit holder in the jar (Fig. i). 2 Cut solid ingredients into small pieces (cubes not bigger than 1 cm) before

you put them in the jar.

3 Put the ingredients in the jar (Fig. j). 4 Press the sieve into the jar lid (Fig. k). 5 Place the lid on the jar and turn it clockwise to close it securely (Fig. l).

Note

• The jar has grooves that help smoothly guide the locking pins and lock the lid in place. Make sure that the lid tab slides into the handle of the jar (Fig. m).

6 Place the jar on the main unit with the lid on the top, align the icon on the

jar with the icon on the main unit, and turn the jar clockwise to securely lock it in place on the main unit (Fig. t). Make sure the handle is on the right-hand side.

» When the jar is correctly locked in place on the main unit, the icon on

the jar will line up with the icon on the main unit.

7 Push and hold the blending button to start blending until the food is

properly blended (Fig. u).

17ENGLISH

Caution

8 When you have nished blending, release the blending button (Fig. v). 9 Unplug the appliance. 10 Remove the blended food from the jar. If necessary, use the spatula included

with this appliance.

Reheating

A 120 ml storage pot is included with the appliance. Use the storage pot to reheat the baby food you have made with the appliance.

Note

• A pack (SCF876) containing 2 storage pots with capacity of 120 ml and 240 ml can be purchased separately in some markets.

• Always put previously blended food in the storage pot to reheat.

• Make sure that the sealing ring is assembled around the jar lid before reheating, and that the at side of the sealing ring is facing out.

1 Pour the appropriate amount of water into the water tank.

» If you are using the 120 ml storage pot, pour 160 ml of water into the water

tank (i.e. to the water level marking for 10/15 min.) ; if you are using the 240 ml storage pot (purchased separately), pour water to the MAX water level marking indicated on the side of the water tank or the MAX water level indication in the water tank.

2 Put the water tank lid on the water tank and turn the lid clockwise to lock it

securely in place (Fig. f).

» When the water tank lid is locked correctly in place, the icon on the

water tank lid will line up with the icon on the water tank.

3 Take the blade unit out of the jar (Fig. w). 4 Flip the storage pot over and place it onto the blade unit holder in the jar

(Fig. x).

5 Place the jar lid on the jar and turn it clockwise to close it securely (Fig. y).

Note

• The jar has grooves that help smoothly guide the locking pins and lock the lid in place. Make sure that the lid tab slides into the handle of the jar (Fig. m).

6 Flip the jar over with the jar lid on the bottom (Fig. z).

+ 35 hidden pages
