SCF862

4241 354 01944

100% recycled paper

S R

3 4

MAX.

8 9

11 12 13

14 15 16

MAX.

18 19 20 21

b c

22 23 24

ENGLISH 6 ESPAÑOL 28 FRANÇAIS 54 ITALIANO 80 PORTUGUÊS 106

SCF862

6 ENGLISH

Refer to the pictures on the folded pages at the front and

back of the user manual.

Table of Contents

Important 7 Introduction 11 General description 11 Before rst use 12 Using the appliance 12 Cleaning and descaling 21 Storage 22 Recycling 23 Guarantee and service 23 Troubleshooting 23 Technical specications 27

Important

Read this user manual carefully before you use the appliance and save it for future reference.

Danger

- Never immerse the main unit in water or any other liquid. Do not rinse it under the tap.

Warning

- Check that the voltage indicated on the appliance corresponds to the local mains voltage before you connect the appliance.

- Do not use the appliance if the plug, the power cord or the appliance itself is damaged. If the power cord is damaged, you must have it replaced by Philips; a service center authorised by Philips or similarly qualied persons in order to avoid a hazard.

- This appliance shall not be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved.

- Children shall not play with the appliance (including the accessories).

- This appliance shall not be used by children. Keep the appliance and its cord out of reach of children (including the accessories).

- Cleaning and user maintenance shall not be made by children.

- Do not touch the blades, especially when the appliance is plugged in. The blades are very sharp.

- Take care in handling the sharp blades when emptying the jar and during cleaning. Always disconnect the device from supply if it’s left unattended.

- If the blades become stuck, unplug the appliance before you remove the ingredients blocking the blades.

7ENGLISH

8 ENGLISH

- The appliance including jar lid gets hot during or shortly after steaming (especially surfaces with this symbol “ ”) and may cause burns when touched. The jar lid should only be opened by using the lid tab. To lift the basket, spatula must be used. To lift the jar, hold the jar by its handle.

- Be aware that hot steam comes out of the jar during steaming and when its lid is removed.

- Be aware of hot steam that comes out of the water tank when you open its lid.

- Do note that hot steam will continue coming out from the steam vent on jar lid for some time when steam cycle is completed. Be careful when you open the jar lid.

- If the appliance is not assembled properly, hot steam could escape from the edge of the water tank lid. Refer to the “Troubleshooting” chapter for preventing or resolving this.

- Do not use this appliance to chop hard and sticky ingredients.

- Never use bleach or chemical sterilizing solutions/ tablets on the appliance.

- Never use scouring pads, abrasive cleaners or aggressive liquids such as gasoline, acetone or alcohol to clean the appliance.

- Always let the appliance cool down for 10 minutes after one steaming cycle before you start steaming again.

- Do not let the appliance blend for more than 30 seconds at a time. If you have not nished blending after 30 seconds, release the knob to stop blending and wait a few seconds before you continue. If the main unit becomes hot, let it cool down for a few minutes before you continue.

- Never pour any liquid into the jar for steaming.

Caution

- Never use any accessories or parts from other manufacturers or that Philips does not specically recommend. If you use such accessories or parts, your guarantee becomes invalid.

- Do not place the appliance on or near an operating or still hot stove or cooker.

- Switch o the appliance and disconnect from supply before changing accessories or approaching parts that move in use.

- Always unplug the appliance and let it cool down before you clean it.

- Turn the control knob to the o position every time after steaming.

- Never use the jar or any other part of the appliance in a microwave, as the metal parts of the jar handle and blade unit are not suitable for this use.

- Never sterilize the jar or any other part of the appliance in a sterilizer or in a microwave, as the metal parts of the blade unit are not suitable for this use.

- This appliance is intended for household use only. If the appliance is used improperly or for professional or semiprofessional purposes or if it is not used according to the instructions in the user manual, the guarantee becomes invalid and Philips refuses any liability for damage caused.

- Place the appliance on a stable, horizontal, and level surface. The appliance emits hot steam during use. Make sure there is enough free space around it to prevent damage to cabinets or other objects.

- Do not use the appliance if it has fallen or is damaged in any way. Take it to an authorized Philips service center for repair.

- Never use the steam function without water in the water tank.

- Make sure that the water in the tank does not exceed 180ml.

9ENGLISH

10 ENGLISH

- Make sure the water tank lid is correctly locked before steaming.

- When blending, do not exceed the MAX food blending volume level indicated on the jar (400 ml).

- Do not lift and move the appliance while it is in operation.

- Do not insert any objects into the water tank steam outlet, jar lid steam inlet and steam path on basket.

- Never rell the water tank during steaming, as hot water and steam may come out of the appliance.

- Always make sure that the jar lid of the water tank has cooled down before you open it.

- Never run this appliance’s power supply through an external switching device, such as a timer, or connect it to a circuit that is regularly switched on and o.

- Always check the temperature of the cooked food on the back of your hand to make sure it is safe for your baby.

- Always check the consistency of the food for your baby. For guidance on what food consistencies are appropriate for dierent ages, refer to weaning guide available for download on Philips website, or seek advice from a doctor or consultant.

- Only use the spatula provided for lifting the basket and emptying food from jar as instructed (g. o).

- Regular descaling prevents damage to the appliance.

- Make sure that the amount of food in the steaming basket does not exceed the top edge of steam path on basket, otherwise the path may be blocked.

Safety systems

For your safety during use, this appliance is equipped with a built-in safety lock. This appliance will only function if all parts have been assembled correctly. Assembling all parts correctly will disarm the built-in safety lock.

This appliance is also equipped with an overheat safety stop function. Overheating can occur if the time between two steaming cycles is too short. If the appliance’s overheat safety stop activates during a steaming cycle, let the appliance cool down for a few minutes. After this, you can use the appliance again.

Electromagnetic elds (EMF)

This Philips appliance complies with all applicable standards and regulations regarding exposure to electromagnetic elds.

Introduction

Congratulations on your purchase and welcome to Philips Avent! To fully benet from the support that Philips Avent oers, register your product at www.philips.com/welcome.

This Essential baby food maker help parents to prepare nutritious meals for their babies with steaming and blending functions combined in one appliance.

General description

Product overview (g. a) A Spatula

B Water tank lid C Water tank steam outlet D Water tank E Main unit F Control knob

a “Steam” position b “O” position c “Blend” position d Power indicator (steaming)

G Jar lock switch H Power cord I Water level and Food volume indication J Jar handle K Steaming and blending jar L Blade unit M Blade shaft seal N Steam path on basket O Steaming basket P Jar lid steam inlet Q Lid tab R Jar lid S Jar lid steam vent

11ENGLISH

12 ENGLISH

Before rst use

1 Remove all packaging materials from the appliance. 2 Clean all parts thoroughly before rst use. Refer to the “Cleaning and

descaling” chapter.

3 We recommend running one steaming cycle with an empty steaming

basket and empty jar before using the appliance for the rst time. Refer to the “Filling the water tank” and “Steaming” chapters.

Using the appliance

Caution

• Always check the temperature and consistency of the cooked food on the back of your hand to make sure it is safe for your baby.

This appliance is intended for steaming fresh, solid ingredients before blending to the consistency required for babies. Normally, you would steam the ingredients rst and blend them afterwards. However, you can also use the appliance for steaming only or blending only. When using the appliance for blending only, you can skip the “Filling the water tank” and “Steaming” sections and follow the instructions in the “Blending only” section.

This appliance is NOT intended for the following purposes.

- Steaming the same ingredients for more than 30 minutes

- Steaming frozen raw ingredients

- Blending rst, then steaming

- Heating liquids such as soup, sauces or water

- Reheating food

- Defrosting food

- Cooking rice or pasta

- Cutting hard ingredients such as ice cubes and sugar cubes, or sticky ingredients like cheese

Filling the water tank

Caution

• Before using the jar to measure water, please rinse the jar and make sure it is clean.

• Before using jar to measure water, ensure the blade unit including the blade shaft seal is assembled correctly. The at side of the blade shaft seal should face upwards (g. x).

Note

• Ensure the water in the tank does not exceed 180 ml. The water level indication can be found on the blending jar.

• We recommend using soft or puried water, as the minerals in mineral water or tap water may cause limescale buildup to occur more quickly inside the water tank.

• Except for using white vinegar for descaling, never put any liquids other than water in the water tank.

1 Push the handle of the steaming and blending jar backwards to

remove it from the main unit (g. b). Fill with water to the right volume according to the “Ingredients and steaming time” chapter in the user manual (g. d).

2 Turn the water tank lid counterclockwise to open it (g. e), then ll

with water using the blending jar (g. f). Do not exceed the MAX 180 ml (g. d).

3 Put the water tank lid back on and turn the lid clockwise to lock it

securely in place (g. g).

13ENGLISH

Note

• Always make sure that you have locked the water tank lid before the appliance starts operating.

14 ENGLISH

Steaming

Caution

• Ensure the blade unit including the blade shaft seal is assembled correctly. The at side of the blade shaft seal should face upwards (g. x).

• Hot steam or hot water can burn your ngers. Do not touch, and never let children touch any hot parts of the appliance or the steam coming from the top of the appliance, as this may cause scalding.

Note

• Ingredients need to be washed, peeled and cut into small cubes no bigger than 1cm before you steam.

• Always defrost frozen raw ingredients before placing them in the steaming basket for steaming. Shake o any excess water from the defrosted ingredients before placing them in the jar.

• The appliance will not start steaming if the jar and jar lid are not assembled and positioned correctly on the main unit (g. j & k).

1 Push the lid tab clockwise to remove the lid from the blending jar

(g. c).

2 Put solid ingredients (cut into cubes of around 1 cm) into the

steaming basket. The ingredients should not exceed the top edge of the steam path on the basket (g. h).

3 When placing the basket back into the jar, make sure the steam path

is on the opposite side to the handle. You will hear a gentle “click” when the basket slots into the correct position (g. i).

4 Place the jar lid on the jar and turn it counterclockwise to lock it

securely (g. j).

5 Lock the jar back onto the main unit by sliding it clockwise (g. k).

Note

• The main unit has grooves that help smoothly guide the locking pins and lock the jar in place. Make sure that jar is securely locked on the main unit before steaming or blending.

6 If you have not yet lled the water tank with water for steaming, refer

to the “Filling the water tank” chapter and add water to it before getting started.

Note

• Make sure the water tank lid is correctly locked in place.

7 Plug in the appliance. 8 Turn the control knob to steam setting (g. l). Refer to the table in

the “Ingredients and steaming time” chapter for the recommended water volume for steaming.

» The yellow light will turn on, indicating the appliance is steaming. » When the steaming cycle is nished, the appliance will

automatically turn o and the indicator light will go out.

9 After steaming, turn the control knob back to the “o” position

(g. m). Wait 2 minutes or until there is no more steam coming from the top of the jar before removing it.

Caution

• If you intend to start another steaming cycle, let the appliance cool down for 10 minutes and empty any remaining water out of the water tank before you rell and start a new steaming cycle.

Note

15ENGLISH

• Do not turn the control knob to “o” position before the steaming cycle nished, so as to avoid insucient steaming and water left in the tank.

Blending after steaming

Caution

• Ensure the blade unit including the blade shaft seal is assembled correctly. The at side of the blade shaft seal should face upwards (g. x).

• The jar and jar lid will become hot after the steaming cycle. Only hold the jar by the handle.

• Only use the lid tab for opening the jar lid.

• Only use the spatula to lift the basket after steaming.

• Always ensure the lid and jar are assembled and positioned correctly on the main unit (g. j & k) when the appliance is in use.

16 ENGLISH

1 To remove the blending jar from the main unit, hold the handle and

push backwards to unlock the jar (g. b).

2 Push the lid tab to open the jar lid (g. c). 3 Use the spatula provided to take the steaming basket out of the jar.

Insert the spatula through the holes on the basket (with the word “Avent” facing upwards) and lift it up (g. o).

4 Pour the steamed food into the blending jar by holding the spatula

(g. p).

Note

• No need to pour out the water collected in the jar. Mix it with the steamed food for blending.

5 Put the blending jar lid back and lock it in place (g. q). Do not put

the steaming basket back in the jar when preparing for blending.

6 Shake the blending jar to evenly distribute the ingredients. 7 If needed, remove the jar lid and add additional ingredients for

blending (e.g. water for purees or additional cooked ingredients like rice or pasta). Do not exceed the MAX food volume of 400 ml.

8 Place the blending jar back on the main unit. Turn the jar to lock into

position. Ensure the jar is secure and the handle is positioned directly above the jar lock switch. Make sure the handle is on the right-hand side (g. k).

9 To start blending, turn the knob to “blend” position until the

ingredients are blended to the consistency of your choice (g. r).

Caution

• Do not let the appliance blend for more than 30 seconds at a time. If you have not nished blending after 30 seconds, release the knob to stop blending and wait a few seconds before you continue. If the main unit becomes hot, let it cool down for a few minutes before you continue.

10 Unplug the appliance. 11 Remove the jar from the main unit and open the jar lid (g. n). 12 Use the spatula to transfer the food from the jar to your bowl or plate

(g. s).

Blending only

Caution

• Ensure the blade unit including the blade shaft seal is assembled correctly. The at side of the blade shaft seal should face upwards (g. x).

• Always make sure that the lid of the blending jar is correctly locked in place while the appliance is in use.

Note

• Ingredients need to be washed, peeled and cut into small cubes no bigger than 1cm before you blend.

1 Remove the blending jar from the main unit and push the lid tab to

open the jar. (g. b & g. c).

2 Pour the chopped food into the blending jar without the steaming

basket. Do not exceed the MAX amount of 400 ml.

3 Put the blending jar lid back and lock it in place (g. q). Shake the

blending jar to ensure the ingredients are evenly distributed.

4 Place the blending jar back on the main unit and lock it securely in

place.

5 To start blending, turn the knob to “blend” position until the

ingredients are blended to the consistency of your choice (g. r).

17ENGLISH

Note

• If the ingredients stick to the wall of the jar, or if the blended ingredients are still too solid, release the blending knob, remove the jar from the main unit, and loosen the ingredients with the spatula, add some drinking water until the blended food has the right consistency for your baby’s age.

Caution

6 Unplug the appliance. 7 Remove the jar from the main unit and open the jar lid (g. n).

18 ENGLISH

8 Use the spatula to transfer the food from the jar to your bowl or plate

(g. s).

Ingredients and steaming time

Type of food

Fruit Apple 20 120

Vegetables Asparagus 20 120

Meat Chicken, beef, lamb,

Fish Salmon, whiting, sole,

Ingredient Approximate

steaming time (min.)*

Orange/mandarin 20 120 Peach 10 60 Pear 20 120 Pineapple 30 180 Plum 10 60 Strawberry 20 120

Broccoli 20 120 Carrot 30 180

Cauliower 20 120 Celery 20 120 Eggplant 20 120 Fennel 30 180 French beans 30 180 Leek 20 120 Onion 20 120 Peas 20 120 Bell pepper 20 120 Potato 30 180 Pumpkin 20 120 Spinach 20 120 Swede 20 120 Sweet corn 20 120 Sweet potato 20 120 Tomato 20 120 Turnip 30 180 Zucchini 20 120

30 180

pork etc.

20 120

cod, trout etc.

Water level in the water tank (ml)

* All food must be cut into small cubes of no bigger than 1 cm. The

steaming time estimation is based on 200 g of food. Adjust the steaming time according to the actual food quantity.

* Steam times may vary due to voltage uctuation.

Recipe examples

19ENGLISH

(1) Precious puree of potato and broccoli*

(2) Bananas about avocado*

(3) Veggie heaven*

(4) Meat mates*

(5) My rst muesli*

Ingredient Water volume

and steaming

time

• 140 g potato 70 g broccoli

• 50 g banana

• 50 g avocado

• 80 g cauliower

• 90 g potato

• 60 g carrot

• 250 g beef / lamb / chicken breast / pork

• 100 g peach

• 100 g pear

• 50 g blueberries

• Add 120 ml water and steam for about 20 min

• No need to steam

• Add 180ml water and steam for about 30 min

• Add 120ml water and steam for about 20 min

Blending

• Blend 3-5 times for 15 seconds each

• Add 60 ml milk

• Blend 3-5 times for 15 seconds each

• Blend 2-3 times for 15 seconds each

• Blend 3-5 times for 15 seconds each

• If required, mix 1 tablespoon of meat puree with 3 tablespoons of pureed vegetables [refer to the veggie heaven recipe (3)]

• Blend 2-3 times for 5 seconds each

• After blending, divide the puree into 5 portions. Mix 1 portion with 100 g rolled oats for each serving

20 ENGLISH

(6) Cod and potato party*

(7) Happy broccoli ever after *

(8) Sunny asparagus *

Ingredient Water volume

and steaming

time

• 100 g cod

• 150g potato

• Add 180ml water and steam for about 30 min

• 120 g salmon

• 120 g broccoli

• Add 120ml water and steam for about 20 min

• 240 g asparagus

• Add 120 ml water and steam for about 20 min

Blending

• Blend 2-3 times for 5 seconds each

• After blending, divide the puree into 5 portions. Mix 1 portion with 100 g well cooked rice porridge for each serving

• Blend 2-3 times for 5 seconds each

• After blending, divide it into 4 portions. Mix 1 portion with 140 g well-cooked pasta shells for each serving

• No need to blend

• After steaming, divide the asparagus into 3 portions. Mix 1 portion with 100 g cooked new potato wedges and 20 g minced parmesan cheese for each serving

* Ingredients need to be washed, peeled and cut into small cubes no

bigger than 1 cm before processing. * Always check the food temperature and consistency before feeding. * The above recipes are designed for babies at dierent weaning stages.

We suggest: * Recipes 1-2 for the rst stage of weaning (around 4-6 months) * Recipes 3-4 for the second stage of weaning (around 6-8 months) * Recipes 5-6 for the third stage of weaning (around 9-12 months) * Recipes 7-8 for the fourth stage of weaning (above 12 months) * But because babies are individuals and grow at dierent paces, please

choose suitable recipes based on your baby’s development.

Cleaning and descaling

Cleaning

Caution

• Clean the appliance straight after every use.

• Never immerse the main unit and water tank in water or rinse it under the tap.

• Never use bleach or chemical sterilizing solutions/tablets in the appliance.

• Never use scouring pads, abrasive cleaners or aggressive liquids such as gasoline, acetone or alcohol to clean the appliance.

• You can clean the steaming basket, steaming and blending jar, blade unit and jar lid in the dishwasher. Before putting them in the dishwasher, please rinse these parts under tap water immediately after use. Do not immerse them in water with parts that have not been cleaned.

• Always reinsert the blade shaft seal back in the blending unit after you have removed it for cleaning. Make sure the at side of the blade shaft seal is facing upwards.

21ENGLISH

1 Unplug the appliance and remove the jar from the main unit. 2 Push the lid tab clockwise to release the jar lid (g. c). 3 Rinse the steaming basket, steaming and blending jar, jar lid and

spatula under tap water to remove food residues (g. u).

4 The blade unit can be disassembled for rinsing if need be (g. t). 5 Remove the blade shaft seal from the blending unit for cleaning if

necessary.

Caution

• Handle the blade unit very carefully to avoid injury as the cutting edges are sharp.

6 Turn the water tank lid counterclockwise and remove it from the

water tank.

7 Wash the water tank lid under the tap. 8 If necessary, pour fresh water into the water tank and ush it out.

Repeat as necessary until the water tank is clean. Do not leave water in the water tank (g. v).

9 Dry the main unit and all parts after cleaning (g. w).

22 ENGLISH

10 Assemble all the parts when they are dry.

Note

• Parts that come into contact with food such as the steaming basket and jar might be colored by food. This is normal. All parts are still safe to use and will do no harm to the cooked food.

Descaling the water tank

For optimum performance, we recommend descaling the appliance every 2-4 weeks. To reduce the buildup of limescale, we recommend using soft or puried water for steaming.

Do not turn on the appliance with descaling solution in the water tank. To descale the appliance, follow the descaling instructions below.

1 Make sure the appliance is switched o. 2 Mix 80 ml of white vinegar (6% acetic acid) with 80 ml of water.

Alternatively, you can use citric acid with warm water to descale the water tank.

3 Add the solution to the water tank. 4 Put the water tank lid on the water tank and turn the lid clockwise to

lock it securely in place.

5 Wait for 6 hours/overnight or until all limescale has dissolved. 6 Pour the used solution out of the water tank. 7 If the limescale buildup has not completely dissolved, repeat the

descaling process in this chapter from step 1 to 6.

8 Pour some fresh water into the water tank and ush it out. Repeat as

necessary until the water tank is clean.

9 Rinse the water tank lid thoroughly under the tap. 10 Fill the water tank with 180 ml of water and let the appliance

complete a steaming cycle with the jar empty before you use the appliance with food again.

Storage

1 Empty the water tank before you store the appliance. 2 Make sure all parts are clean and dry before you store the appliance

(refer to the “Cleaning and descaling” chapter).

3 Store the appliance with the blade unit in the jar to prevent damage.

23ENGLISH

4 Always make sure that the lids for both the water tank and the jar are

correctly locked in place for storage.

Recycling

This symbol means that this product shall not be disposed of with normal household waste (2012/19/EU).

Follow your country’s rules for the separate collection of electrical and electronic products. Correct disposal helps prevent negative consequences for the environment and human health.

Guarantee and service

If you need information or if you have any problems, please visit the Philips website at www. philips. com / avent or contact the Philips Customer Care Center in your country (refer to the enclosed worldwide guarantee leaet for details). If there is no Customer Care Center in your country, go to your local Philips dealer.

Troubleshooting

This chapter summarizes the most common problems you may encounter with the appliance. If you are unable to solve the problem with the information below, contact the Consumer Care Center in your country.

Problem Possible cause Solution

The appliance does not work.

The steaming light does not turn on.

This appliance is equipped with a safety lock. This appliance will not work if the parts are not assembled correctly on the main unit.

The appliance is not connected to the power supply.

The jar is not placed on the main unit correctly.

Assemble all parts correctly. Before steaming, the jar lid should be placed on the jar and locked correctly by turning it counterclockwise. Put the jar back on the main unit vertically and lock the jar by turning it clockwise.

Insert the plug in the outlet.

Place and lock the jar on the main unit correctly.

24 ENGLISH

Problem Possible cause Solution

You have started a second steaming cycle immediately

Switch o the appliance and allow it to cool down for 10 minutes before

you start a second steaming cycle. after the previous one has nished.

The water tank gives o an unpleasant smell during the

You have not prewashed the water tank before use.

Refer to the "Cleaning and

descaling" chapter to clean the

water tank, then nish a steaming

cycle with an empty jar.

rst few uses. The appliance

does not generate steam.

You have not put water in the water tank.

There is too much limescale buildup in the water tank.

The steam path, water tank steam outlet and jar lid steam inlet have

Switch o and unplug the appliance,

then add water to the water tank.

Descale the water tank. Refer to the

"Descaling" section in the "Cleaning

and descaling" chapter.

Check the water tank steam outlet,

jar lid steam inlet and the steam

path and ensure there is nothing

blocking them. been blocked.

Steam is leaking from the water tank.

The water tank lid is not closed correctly.

The jar is not assembled

Close the water tank lid correctly

by turning it from unlock to lock

position.

Place the jar correctly on the main

unit. correctly on the main unit.

The jar lid steam

Clean the jar lid steam inlet. inlet is blocked.

The ingredients are not cooked

The pieces in the jar are too big.

Cut the food into smaller pieces

(cubes of around 1 cm).

thoroughly.

There is too much food in the jar.

Decrease the amount of food in the

jar.

The amount of food should not

exceed the top edge of the steam

path on the basket.

Problem Possible cause Solution

There is too little water in the water tank.

Add the correct amount of water

for the steaming time. Check the

"Ingredients and steaming time"

chapter to make sure that you

have added the correct amount of

water for the steaming time of the

ingredients you want to steam or the

recipe you want to prepare.

The food in the jar is spilling out.

Excessive steam vapor is leaking from the jar lid.

The blending function does not work.

There is too much limescale buildup in the water tank.

There is too much food in the jar.

The jar lid is not tted onto the jar correctly.

There is too much food in the jar.

Descale the water tank. Refer to the

"Descaling" section in the "Cleaning

and descaling" chapter.

Switch o the appliance and process

a smaller quantity.

Place the jar lid on the jar and

turn it counterclockwise to close it

securely.

Switch o the appliance and

process a smaller quantity. Never

put so much food in the jar that the

lid does not close. We advise that

the MAX food volume for blending

should not exceed 400 g. The jar is not

placed on the main unit correctly.

Place the jar on the main unit

with the lid on the top, align the

handle on the jar with the icon

on the main unit, and turn the jar

counterclockwise to securely lock it

in place on the main unit. The jar lid is not

locked onto the jar correctly.

You are using the appliance to blend sticky food such as cheese.

You have been using the blending function

Place the jar lid on the jar and

turn it counterclockwise to close it

securely.

Check the ingredients and steaming

time table or recipe examples

and choose ingredients that are

appropriate for blending.

Stop blending and let the appliance

cool down for a few seconds and

then start blending again. continuously for more than 30 seconds.

25ENGLISH

26 ENGLISH

Problem Possible cause Solution

Blended food result is not good enough.

Blending is not enough.

Ingredients are not suciently preprocessed.

Blend the ingredients for a few more

times. Do not blend continuously for

more than 30 seconds at a time.

Ingredients need to be washed,

peeled and cut into small cubes no

bigger than 1cm before you steam

and blend. Too few or too

much food volume

Increase or decrease food volume

for appropriately blending. to blend.

Steaming time is not sucient.

Add correct amount of water for

sucient steaming time. Refer to

the "Ingredients and steaming time"

chapter. The ingredients

are dry and stick to the wall of the jar during blending.

After steaming, no need to pour out

the water collected in the jar. Mix it

with the steamed food for blending.

If you use blending function only

(without steaming), add suitable

amount of drinking water in jar,

mix with food ingredients before

blending.

The appliance is noisy, produces an unpleasant smell, is hot to touch, emits smoke, etc.

There are white spots on the water tank and water tank lid.

There is too much food in the jar.

The jar lid is not closed properly.

You have been using the blending function for too long.

There is limescale buildup on these parts.

Switch o the appliance and process

a smaller quantity.

Place the jar lid on the jar and close

it securely.

Do not let the appliance blend

continuously for more than

30 seconds at a time.

This is normal. Remove the

limescale periodically. Clean the

water tank lid and jar lid with a moist

cloth. Descale the water tank. Refer

to the "Descaling" section in the

"Cleaning and descaling" chapter.

Problem Possible cause Solution

The surfaces of the appliance that come into contact with food are discolored.

The blending jar leaks.

Food colorings may discolor the parts that come into contact with food.

The blade unit is not assembled correctly.

Incorrect assembly of the blade shaft seal on the blade unit.

This is normal. This does not aect

the quality and the performance of

the appliance. All parts are still safe

to use and will do no harm to the

cooked food.

Tighten the blade unit.

Assemble the blade shaft seal

correctly (g. x).

Technical specications

- Voltage/wattage: See type plate on the bottom of the appliance

- Maximum water capacity of the water tank: 180 ml

- Maximum capacity of the blending jar: 400 ml

- Operating temperature: 10°C to 40°C / 50°F to 104°F

- Protection: Temperature-controlled heating system

27ENGLISH

28 ESPAÑOL

Consulte las imágenes de las páginas plegadas de la

parte delantera y trasera del manual de usuario.

Indice de contenidos

Importante 29 Introducción 33 Descripción general 34 Antes de utilizarlo por primera vez 34 Uso del aparato 35 Limpieza y eliminación de depósitos de cal 45 Almacenamiento 47 Reciclaje 47 Garantía y servicio 48 Solución de problemas 48 Especicaciones técnicas 53

Importante

Antes de usar el aparato, lea atentamente este manual de usuario y consérvelo por si necesitara consultarlo en el futuro.

Peligro

- Nunca sumerja la unidad principal en agua ni otros líquidos. No la enjuague bajo el grifo.

Advertencia

- Antes de enchufar el aparato, compruebe si el voltaje indicado en el mismo se corresponde con el voltaje de red local.

- No utilice el aparato si la clavija, el cable de alimentación o el propio aparato están dañados. Si el cable de alimentación está dañado, se debe sustituir en un centro de servicio autorizado por Philips o por parte de personal cualicado, con el n de evitar situaciones de peligro.

- Este aparato no debe ser usado por personas con su capacidad física, psíquica o sensorial reducida ni por quienes no tengan los conocimientos y la experiencia necesarios, a menos que sean supervisados o instruidos acerca del uso del aparato de forma segura y siempre que sepan los riesgos que conlleva su uso.

- Los niños no deben jugar con este aparato (incluidos los accesorios).

- Los niños no deben utilizar este aparato. Mantenga el aparato y el cable fuera del alcance de los niños (incluidos los accesorios).

- Los niños no deben llevar a cabo la limpieza ni el mantenimiento.

- No toque las cuchillas, sobre todo cuando el aparato esté enchufado. Las cuchillas están muy aladas.

- Tenga cuidado al manipular las cuchillas al vaciar la jarra y durante la limpieza. Desenchufe siempre el dispositivo de la fuente si se deja desatendido.

29ESPAÑOL

30 ESPAÑOL

- Si las cuchillas se bloquean, desenchufe el aparato antes de retirar los ingredientes que están bloqueándolas.

- El aparato, incluida la tapa de la jarra, se calienta durante la cocción al vapor o poco después (especialmente las supercies con el símbolo “ ”) y puede provocar quemaduras si se toca. La tapa de la jarra debe abrirse únicamente con la pestaña de la tapa. Para levantar la cesta, se debe utilizar la espátula. Para levantar la jarra, sujétela por el asa.

- Tenga cuidado, ya que durante la cocción al vapor y al retirar la tapa sale vapor caliente de la jarra.

- Tenga cuidado con el vapor caliente que sale del depósito de agua al abrir la tapa.

- Tenga en cuenta que seguirá saliendo vapor caliente por el oricio de salida del vapor de la tapa de la jarra un tiempo después de que se complete el ciclo de cocción al vapor. Tenga cuidado cuando abra la tapa de la jarra.

- Si el aparato se monta de forma incorrecta, podría salir vapor caliente del borde de la tapa del depósito de agua. Consulte el capítulo "Solución de problemas" para prevenir o solucionar este inconveniente.

- No utilice este aparato para picar ingredientes duros ni pegajosos.

- No utilice nunca soluciones ni pastillas con lejía o esterilizadores químicos en el aparato.

- No utilice estropajos, agentes abrasivos ni líquidos agresivos, como acetona, gasolina o alcohol, para limpiar el esterilizador.

- Deje siempre que el aparato se enfríe durante 10 minutos después de un ciclo de cocción para comenzar otro.

- No deje que el aparato bata durante más de 30 segundos seguidos. Si no ha terminado de batir después de 30 segundos, suelte el botón para detener el proceso de batido y espere unos segundos antes de continuar. Si la unidad principal se calienta, deje que se enfríe durante unos minutos antes de continuar..

- No vierta nunca líquidos en la jarra para cocer al vapor.

Precaución

- No utilice nunca accesorios ni piezas de otros fabricantes o que Philips no recomiende especícamente. Si lo hace, quedará anulada su garantía.

- No coloque el aparato sobre un horno o un fogón encendido o aún caliente, ni lo sitúe cerca de ellos.

- Apague el aparato y desenchúfelo de la fuente de alimentación antes de cambiar los accesorios o tocar alguna de las piezas que está en movimiento durante su funcionamiento.

- Antes de limpiarlo, desenchufe siempre el aparato y deje que se enfríe.

- Gire el botón de control hasta la posición de apagado después de la cocción al vapor.

- No introduzca nunca la jarra ni ninguna otra pieza del aparato en un microondas, ya que las piezas metálicas del asa de la jarra y la unidad de cuchillas no son adecuadas para este uso.

- No esterilice nunca la jarra ni ninguna otra pieza del aparato en un esterilizador o en un microondas, ya que las piezas metálicas de la unidad de cuchillas no son adecuadas para este uso.

- Este aparato es sólo para uso doméstico. Si se utiliza el aparato de forma incorrecta, con nes profesionales o semiprofesionales, o de un modo que no esté de acuerdo con las instrucciones de uso, la garantía quedará anulada y Philips no aceptará responsabilidades por ningún daño.

- Coloque el aparato sobre una supercie estable, horizontal y plana. El aparato emite vapor caliente durante el uso. Asegúrese de que haya suciente espacio libre alrededor para evitar que se produzcan daños en los armarios u otros objetos.

31ESPAÑOL

32 ESPAÑOL

- No utilice el aparato si se ha caído o está dañado de alguna forma. Llévelo a un centro de servicio Philips autorizado para su reparación.

- No utilice la función de cocción al vapor sin agua en el depósito.

- Asegúrese de que el agua del depósito no supera los 180 ml.

- Asegúrese de que la tapa del depósito de agua se ha jado correctamente antes de cocer al vapor.

- Al triturar, no supere el nivel de volumen de triturado de alimentos MAX indicado en la jarra (400 ml).

- No levante ni mueva el aparato mientras esté en funcionamiento.

- No introduzca objetos en la salida de vapor del depósito de agua, la entrada de vapor de la tapa de la jarra ni el conducto de vapor de la cesta.

- Nunca rellene el depósito de agua durante la cocción, ya que pueden salir vapor y agua caliente del aparato.

- Asegúrese siempre de que la tapa del depósito de agua se ha enfriado antes de abrirla.

- No ponga nunca en marcha la fuente de alimentación de este aparato a través de un dispositivo de conmutación externo, como un temporizador, ni lo conecte a un circuito que se encienda y se apague regularmente.

- Compruebe siempre la temperatura de la comida cocinada en el dorso de la mano antes de dar de comer a su bebé.

- Compruebe siempre la consistencia de los alimentos para su bebé. Para obtener indicaciones sobre qué consistencias de alimentos son adecuadas para las distintas edades, consulte la guía de introducción a los alimentos sólidos disponible para descargar en el sitio web de Philips, o busque el asesoramiento de un médico o especialista.

+ 100 hidden pages

Philips SCF862/02 User Manual [pr]

Specifications and Main Features

Frequently Asked Questions

User Manual
