IMPORTANT SAFETY INSTRUCTIONS

Some of the following information may not apply to your particular product; however, when using baby monitor equipment, basic safety precautions should always be followed to reduce the risk of

re, electric shock and injury to persons, including the following:

1 Read these instructions. 2 Keep these instructions. 3 Heed all warnings. 4 Follow all instructions. 5 Do not use this apparatus near water. 6 Clean only with dry cloth. 7 Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8 Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus

(including ampliers) that produce heat.

9 Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has

two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided

plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.

10 Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

11 Only use attachments/accessories specied by the manufacturer.

12 Unplug this appliance during lightning storms or when not used for long periods of time.

13 Refer all servicing to qualied ser vice personnel. Servicing is required when the apparatus has

been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

14 This baby monitor is intended as an aid. It is not a substitute for responsible and proper adult

supervision and should not be used as such. 15 Use this appliance only for its intended use as described in this manual. 16 Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol

cleaners. 17 Products should not be used while you are in a bathtub, shower or pool. Immersion of the

product in water could cause an electrical shock. 18 This product should be operated only from the type of power source indicated on the type

plate of the adapters (A15,B9). If you are not sure of the type of power supply to your home,

consult your dealer or local power company.

19 Do not overload wall outlets and extension cords as this can result in the risk of re or electric

shock.

20 Never push objects of any kind into this product through casing slots as they may touch

dangerous voltage points or short out par ts that could result in a risk of re or electric shock.

Never spill liquid of any kind on the product. 21 To reduce the risk of electric shock, do not disassemble this product, but call 1-800-54-AVENT

(1-800-542-8368) for assistance. Opening or removing covers (except battery compartment

lids) may expose you to dangerous voltage or other risks. Incorrect reassembly can cause

electric shock when the appliance is subsequently used. 22 To prevent strangulation with power cord, never place monitor within reach of child. Do not use

with extension cords.

If your product utilizes batteries, the following additional precautions should be

observed:

1 Use only the type and size of batteries specied in the user manual. 2 Do not dispose of batteries in re. They may explode. Check with local regulations for possible

special disposal instructions.

3 Exercise care in handling batteries in order not to short out the batteries with conducting

materials such as rings, bracelets and keys. Overcharging, short circuiting, reverse charging, mutilation, or incineration of batteries must be avoided to prevent one or more of the following

occurrences: release of toxic materials, release of hydrogen and/or oxygen gas, rise in surface

temperature.

4 Do not attempt to recharge batteries provided with or identied for use with this product that

are not intended to be charged. The batteries may leak corrosive electrolyte or explode.

5 Do not attempt to rejuvenate the batteries provided with or identied for use with this product

by heating them. Sudden release of battery electrolyte may occur, causing burns or irritation to eyes or skin.

6 If and when necessary, the batteries must be replaced with identical new ones from the same

manufacturer. If a battery to be replaced is connected with other batteries in series, it is recommended that the other batteries be replaced with new ones at the same time.

7 Reverse polarity installation of the batteries in the end product must be avoided. Reverse

insertion of batteries can cause charging, and that may result in leakage or explosion.

8 Remove batteries from this product if you store the product over 30 days because the batteries

could leak and damage the product.

9 Discard ‘dead’ batteries as soon as possible since ‘dead’ batteries are more likely to leak in a

product. If a battery has leaked or vented, it should be replaced immediately using protective gloves.

10 Do not store this product, or the batteries provided with or identied for use with this product,

in high-temperature areas. Batteries that are stored in a freezer or refrigerator for the purpose of extending shelf life should be protected from condensation during storage and defrosting. Batteries should be stabilized at room temperature prior to use after cold storage.

11 If your product uses rechargeable batteries, charge the batteries only in accordance with the

instructions and limitations specied in the user manual.

12 There is a risk of explosion if batteries are replaced with an incorrect type. For the

unit, always use the SCD530 Li-Ion rechargeable battery pack as supplied with the appliance.

SAVE THESE INSTRUCTIONS

CAUTION:THE SYMBOL SHOWN IN FIGURE 1 MEANS THAT THERE IS A RISK OF EXPLOSION OF THE BATTERIES AND/OR OF SERIOUS DAMAGE TO THE BABY MONITOR IF THE BATTERIES OR THE ADAPTER ARE REPLACED WITH AN INCORRECT TYPE. (Fig. 1)

Adapter for baby unit:

Input: 120 VAC 60 Hz

Output: 7.5 VDC 400 mA

Adapter no. UD075040B

Adapter for charger:

Input: 100-240 VAC 50/60Hz

Output: 7.5VDC 500mA

Adapter no. SSA-5W-09 US 075050F

The socket-outlet shall be installed near the equipment and shall be easily accessible.

For the baby unit, only use 1.5V AA alkaline batteries (batteries not supplied).

For the parent unit, only use the SCD530 Li-Ion rechargeable battery pack as supplied with the appliance. Dispose of used batteries according to the instructions.

Compliance information

The FCC ID number is located on the casing bottom of the parent unit and in the battery compartment of the baby unit.
