Philips MultiLife
Battery charger
Quick
SCB4400NB
Quickly charge AA, AAA and 9 V batteries
With this Quick Charger
Philips Quick charger will charge your AA, AAA and 9 V batteries in as little as 5 hours.
This Quick charger has the flexibility to charge 2 to 4 batteries individually
Top Performance
• Quick power charging
• Reverse polarity protection for correct battery installation
• Bad or alkaline battery detection
• Minus dV Detection, zero slope Detection
• Automatic shutdown
• Worldwide voltage
Ease of Use
• Includes AA 2600 mAh NiMH rechargeable batteries
• Charge 2 to 4 AA, AAA and 9V
• LED light for charging indication
Page 2
Battery charger
Quick
SCB4400NB/12
Specifications
Power
• Batteries included
• Battery capacity: 4 x AA 2600 mAh
• Power supply: 100-240 VAC, 50/60 Hz
Green Specifications
• Heavy metals: Cd free, Hg free, Pb free
• Packaging material: PET
Charging and Control
• Charging indicators: LED
• Control functions: alkaline detection, bad battery
tion, -dV, no overcharging, short-circuit
detec
protection, temperature control, wrong polarity
Power Input
• Power supply: Corded
• Voltage: 100-240 V
Outer Carton
• Gross weight: 1.877 kg
• GTIN: 1 87 12581 60672 2
•Outer carton (L x W x H): 31.2 x 22.5 x 15.2 cm
• Net weight: 1.22 kg
• Number of consumer packages: 4
• Tare weight: 0.657 kg
Packaging dimensions
• Packaging dimensions (W x H x D):
10 x 25.2 x 7.5 cm
• EAN: 87 12581 60672 5
• Gross weight: 0.365 kg
• Net weight: 0.305 kg
• Number of products included: 1
• Packaging type: Blister
• Tare weight: 0.06 kg
•
Highlights
Automatic shutdown
The automatic shutdown feature has been designed
to provide peace of mind. When batteries are fully
charged, the charger will switch off, protecting them
from overcharging.
Bad/alkaline battery detection
This feature will notify when a bad or alkaline battery
is inserted, hence ensuring optimum safety
LED light indicates charging
The LED light will turn on to indicate when charging
is in progress, off when charging has been completed
and will flash if a bad battery is inserted
Reverse polarity protection
Reverse polarity protection ensures correct battery
installation in the charger preventing the batteries
from being charged or damaged.
Quick power charging
The Quick Charger enables you to be fully up and
running with maximum power in as little as 5 hours.
Issue date 2013-12-13
Version: 8.0.4
12 NC: 8670 000 77914
EAN: 87 12581 60672 5
© 2013 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
