Philips SCB4055NB User Manual

SCB4055NB

User Manual
Manuel d’utilisation
Guía de usuario
Bedienungsanleitung
Gebruikershandleiding
Manuale d'uso
Manual do utilizador

OdËÁfi˜ ¯Ú‹Û˘

Kullanım kılavuzu

Brugervejledning

Använderhandbok

Käyttöohje

Instrukcja obsługi
Uživatelská příručka
Návod na použitie
Felhasználói kézikönyv

Руководство по
эксплуатации

RU

HU

SK

CS

PL

FI

SV

DK

TR

GR

PT

IT

NL

DE

ES

FR

EN

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.

2008 © Koninklijke Philips Electronics N.V. All rights reserved.

www.philips.com

1

0682

Additional information (including warranty conditions)
available at our website:

www.philips.com/support

Specifications subject to change without notice.
All dimensions shown are approximate.

SCB4055NB 200 min travel charger EN

Important Safety Instructions:

Save these instructions - this manual contains important safety and operating
instructions for this charger.Before using your charger read all instructions and
cautionary markings on the charger,the batteries to be charged and the
products that use the batteries.

Warning:

• Use to charge Ni-MH batteries only.Do not charge Alkaline, Zinc Carbon,
Lithium or any other type of battery not specified on the charger.
Other types of batteries might burst or leak causing personal injury.

• For proper battery insertion, please observe pole indications (+/-).

See fig.A.

• Do not dispose of in fire, short circuit or open.

• Charge new batteries before using.

• Never alter the AC plug.

• Do not operate the charger if it has been subjected to shock or if it is
damaged.

• Do not disassemble the charger.

• To avoid risk of electric shock,unplug the charger from the electrical outlet
before cleaning or when not in use.

• This battery charger is for indoor use only. Do not expose the charger to rain
or excessive moisture. Keep the charger away from dust and dirt, which can
cause premature wear of parts or harm its normal operation.

• Never use the charger as a power source for any electrical equipment.

• Do not incinerate, disassemble or short circuit batteries since they may burst
or release toxic materials.

• This charger is not intended for use by young children or infirm persons
without supervision.

• To reduce the risk of damage to the AC plug, disconnect the charger by pulling
the plug.

• Do not operate the charger if cord or plug is damaged.

• Do not charge damaged or leaking batteries.

Care:

• Wipe the charger with a damp cloth occasionally without harsh chemicals,
cleaning solvents or strong detergents.

• Charger and batteries must be disposed of separately.Inform yourself about
the separate collection system for electrical and electronic products.

Operating Instructions

General charging guidelines

• At the same time you can charge 2 or 4 AA/AAA batteries.

• For long battery life, only charge empty batteries.

• When charging, ambient temperature should be between 0°C and 40°C

(32 °F and 104 °F).

• You can only charge batteries of the same size and type (AA/AAA).

Note: It is normal for the unit and the batteries to become warm while charging.

Charging batteries
1

First select the appropriate plug (supplied) for your country and attach the
plug to the adapter pins.

2 Open the cover.
3 To charge batteries,pull out the battery terminals and insert the batteries in

the charging channels respecting the polarity (+/-) marked inside.

See fig.A.

4 Plug the charger into a household electric outlet. See fig. B.

> A green LED (charging indicator) will illuminate indicating that the charging is in

progress.

> If any of the batteries is not installed correctly, the LED will not light and the

charger will not start charging.

> If any of the batteries is not suitable for charging (i.e. a bad battery), the LED will

flash green and the battery/batteries will not be charged.

> When the batteries are fully charged, the green LED will turn off.The charger will

now switch over to trickle charge to keep your batteries fully charged for use.

5 When you are going to use the batteries, disconnect the plug from the outlet

and remove the batteries.

See fig. C. Always unplug between charges!

Battery charging times: See fig.D.

Visit our website at: www.philips.com

A)

B)

C)

Battery Battery Approx.
size capacity (mAh) charging time

AA Ni-MH 2600 mAh 3 hrs
AA Ni-MH 2300 mAh 2 ½ hrs
AA Ni-MH 1800 mAh 2 hrs
AA Ni-MH 1300 mAh 1 ½ hrs
AAA Ni-MH 700 mAh 2 hrs

Battery charging times:

D)
