Philips SC5371 User Manual

SC5371

EN User manual

FR Guide d’utilisation

ES Manual del usuario

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, especially when children are present, basic safety precautions should always be followed, including the following:

READ ALL INSTRUCTIONS BEFORE USING

DANGER

To reduce the risk of electrocution:

1. Always unplug the charging stand immediately after use, except when facial brush is (re)charging.

2. Do not place or store the charging stand where it can fall or be pulled into a tub or sink.

3. Do not place charging stand in or drop into water or other liquid.

4. Do not reach for a charging stand that has fallen into water. Unplug immediately.

5. Unplug and remove power supply cord from charging stand before cleaning.

6. The batteries used in this device may present a

re or chemical burn hazard if mistreated. Do not

disassemble, heat above 100°C (212°F) or incinerate.

7. Keep the adapter dry (Fig. 2).

ENGLISH

WARNING

To reduce the risk of burns, electrocution, re,

or injury to persons:

1. Charging stand should never be left unattended when plugged in.

2. Close supervision is necessary when this facial brush/ charging stand is used by, on, or near children or invalids.

3. Use this facial brush/charging stand only for its intended household use as described in this manual. Do not use attachments not recommended by Philips North America LLC or Philips Electronics Ltd.

4. Never operate this facial brush /charging stand if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water while plugged in. For assistance, call 1-800-243-7884 (in US only) or 1-866-800-9311 (in Canada only).

5. Keep the facial brush, charging stand, cord, plug and any attachments away from heated surfaces.

6. Never use while sleeping or drowsy.

7. Never drop or insert any object into any opening.

8. Do not use the adapter in or near a power outlet that contains an electric air freshener to prevent damage to the adapter.

9. Do not operate or plug in charging stand outdoors

or where aerosol (spray) products are being used or where oxygen is being administered.

10. Do not use this facial brush with a damaged or broken brush. Replace brush head immediately.

11. Use only the cord and charging stand provided to

charge and (re)charge the facial brush.

12. Always attach plug to charging stand rst, then to

outlet. To disconnect, turn the facial brush ‘OFF’, then remove plug from outlet.

13. To prevent possible damage to the cord, do not wrap cord around the charging stand. Do not use an extension cord.

14. Never put facial brush or charging stand in direct sunlight or charge, use and store at a temperature below 50°F (10°C) and above 140°F (60°C).

15. A facial brush should never be left unattended while plugged in.

16. Do not insert metal-containing material into the socket for the facial brush plug.

17. Only use the power plug and other accessories supplied with the facial brush.

SAVE THESE INSTRUCTIONS

IMPORTANT: The power plug contains a transformer. Do not cut off the power plug to replace it with another plug as this will cause a hazardous condition.

ENGLISH

1 Introduction

Thank you for choosing Philips VisaPure Advanced. Cleansing is an essential part of the daily skincare routine, but traditional methods do not always leave your skin as clean and radiant as it could be. That’s why we developed VisaPure Advanced - our exciting new approach to facial cleansing with VisaPure Advanced, you can enjoy healthy-looking, radiant skin, quickly and easily every day. VisaPure Advanced combines gentle rotations and sonic pulses that cleanse deeply, remove impurities and makeup, leaving skin feeling soft and fresh. Designed to complement your current routine, you can use VisaPure Advanced together with your current

cleanser and it can also help your favorite moisturizer

absorb better into your skin. A Deep Pore brush head,

a Precision brush head and a Revitalizing Massage head

are included for all skin types. Additional brush heads for different skin types are available separately. Use VisaPure Advanced twice daily to enjoy healthy-looking, soft skin and reveal your natural radiance.

2 General description

(g. 1)

1 Handle 2 Charging light and battery low indicator 3 Speed indicator

• Speed one: gentle cleansing

• Speed two: deep cleansing 4 On/off button 5 Connection pin 6 Charging pins 7 Anti-roll ridge 8 Deep Pore brush head 9 Protective cap

10 Revitalizing Massage head

11 Precision Brush head 12 Socket for the appliance plug 13 Charging stand 14 Adapter 15 Appliance plug 16 Storage caddy 17 Travel pouch

This symbol on the appliance

indicates that the facial brush can be used in both the bath and shower.

ENGLISH

3 IMPORTANT

INFORMATION

• Fully charge the facial brush before using and at least every 3 months to sustain battery life.

3.1 CAUTION

• Only use this facial brush on the face, neck and low neckline, excluding the sensitive area around the eyes. Do not use this facial brush for any other purpose.

• Do not use the facial brush more than twice a day.

• For hygienic reasons, it is recommended the facial brush be used by only one person.

• Do not use this facial brush if you have dry, chapped or sunburned skin, open wounds, suffer from skin diseases or skin irritations or if you are taking steroidbased medication.

• Do not use this facial brush with self-made cleansers or cleansers containing harsh chemicals or rough particles.

• Do not clean the facial brush and accessories in a dishwasher.

3.2 General

• If you have sensitive skin select setting 1 the rst few times you use the facial brush.

• Facial skin can get dryer during colder months so you may want to reduce the frequency, depending on the condition of your skin.

• Using the facial brush to remove makeup may discolor or stain the bristles.

• Clean the facial brush and the accessories after each use.

• An adapter plug may be necessary for charging plug usage in some foreign countries. Use an attachment

plug adapter of the proper conguration for the

power outlet. The charging plug will automatically convert to work on 100V to 240V AC systems.

• To charge the battery, only use the detachable supply unit (SSW-2082 or SSW-2600) provided with the appliance (Fig. 3).

4 Preparing for use

ENGLISH

4.1 Charging the facial brush

Charging the facial brush takes approximately 6 hours. A fully charged facial brush has a cordless operating time of up to 30 minutes.

1 Make sure the facial brush is switched off. 2 Inser t the facial brush plug in the socket of the

charging stand (1), put the adapter in the wall socket (2), remove the protection cap (3) and put the facial

brush in the charging stand (4) (g. 4).

Make sure the charging pins on the facial brush are

connected properly with the contact points in the charging stand.

3 The charging light blinks white to indicate that

the facial brush is charging. When the battery is fully charged, the charging light lights up white

continuously (g. 3).

4.2 Battery-low indicator

• When the battery is almost empty, the charging light blinks amber for 15 seconds. The battery still contains

enough energy for a complete treatment (g. 6).

To charge the facial brush, follow the steps in section ‘Charging the facial brush’.

5 Using the facial brush

Make sure the facial brush is fully charged before you use it for the rst time.

Caution: Wear a headband or tie all your hair securely away from your face to ensure no loose hair gets caught in the brush head during use.

D Note:

You can use the facial brush in front of the sink, in the shower or bathtub.

5.1 Brush heads

• Deep pore brush head prevents and reduces the appearance of pores. Use daily.

• Precision Brush head for precision cleansing of hard to reach areas such as the nose area.

• Revitalizing Massage head for a relaxing and

revitalizing massage.

• Normal brush head for all skin types. Use daily. Sold separately.

• Exfoliation brush for all skin types. Use weekly. Sold separately.

• Sensitive brush head for normal to sensitive skin. Use daily. Sold separately.

• Fresh Eyes head for a boost of freshness to tired eyes. Sold separately.

5.2 Daily facial cleansing

5.2.1 Intelligent Head Recognition

VisaPure Advanced has Intelligent Head Recognition.

• The Precision brush head and the Revitalizing

Massage head have specic levels of rotation and

vibration.

ENGLISH

• When you attach a different intelligent attachment

and switch on the appliance, it recognizes the

intelligent attachment.

• You will hear a beep and the intensity setting

indications ash alternately.

• The appliance then activates a customized program for the intelligent attachment in use.

5.2.2 Intensity settings

You can choose between 2 different intensity settings depending on your personal preference.

• Intensity setting 1 for a gentle treatment.

• Intensity setting 2 for an intensive treatment.

The rst time you use the facial brush, we advise you to select

intensity setting 1. If you do not experience any skin reactions, you can start using the appliance at intensity setting 2.

D Note:

Your skin might need to adapt to the new treatment just like it does with a new skincare product.

5.2.3 Skin zones

• The face can be divided into three zones: right cheek, left cheek and T-zone. The cheek zones include the

chin, the area between nose and upper lip and the area between eyes and ears. The neck and lower neck can also be divided into three zones (g. 7).

Note:

Do not use the facial brush on the sensitive skin area around the eyes.

5.2.5 Skin zone timer

When you switch on the facial brush, it works for three periods of 20 seconds. Between these periods, there is a short pause to indicate you should move the brush

head to another skin zone.

5.2.6 Auto shut-off

The facial brush automatically switches off after one minute to prevent overtreatment.

5.3 Using the Deep Pore brush head

D Note:

You can use the Deep Pore brush head twice a day.

1 Push the brush head onto the connection pin until it

locks into position with a click (g. 8).

2 Moisten your skin and the brush head with water.

Apply the liquid cleanser to your face or the brush head directly. Do not use the facial brush with a dry brush head, as this can irritate the skin.

3 Place the brush head on your skin. 4 Press the on/off button once to switch on the facial

brush. Press two times to switch off the facial brush or wait until it stops automatically after one minute

(g. 9).

5 Gently move the brush head across your skin while

making horizontal movements. Do not press the

brush head too hard onto the skin to make sure the

treatment remains comfortable (g. 10).

ENGLISH

6 After 20 seconds, the facial brush briey pauses to let

you know that you have to move to another zone.

Do not overdo the cleansing and do not cleanse any

zone longer than 20 seconds.

5.4. Revitalizing Massage head

The Revitalizing Massage head is suitable for all skin types.

We advise you to use it 2-3 times a week. Before you

massage the skin, rst cleanse your face with VisaPure

Advanced.

1414

5.4.1 The 3 minute Revitalizing Massage program

The 3 minute Revitalizing Massage program consists of

2 treatment periods of 1 1/2 minutes each. The

Revitalizing Massage head is intended to treat the right and left cheek. The cheek zones include the chin,

the area between the nose and upper lip and the areas between the eyes and ears.

Note:

Each treatment period has a specic rotation direction optimized for the skin zone treated. Do not use the Revitalizing Massage head on the sensitive area around

the eyes.

5.4.2 Using the Revitalizing Massage head

Use the Revitalizing Massage head on clean, dry skin or

after applying facial cream or oil to your skin.

1 Push the Revitalizing Massage head onto the

connection pin until it locks into position with a click (Fig. 11).

2 Press the on/off button to switch on the appliance

and choose your preferred setting.

Note:

When you attach a different head the appliance

recognizes it. You will hear a beep and the intensity setting indications ash alternately (Fig. 12).

3 Place the Revitalizing Massage head on your right

cheek. Gently move the head across your skin, from the nose towards the ear and repeat this movement (Fig. 13).

Note:

Do not push the head too hard onto the skin to make sure the treatment remains comfortable.

4 After 1 1/2 minutes, the appliance pauses briey to

let you know you should move it to the other cheek (Fig. 14).

5 When the program is nished, turn the appliance off.

ENGLISH

5.5 Precision Brush head

The Precision Brush head is suitable for all skin types. We advise you to use it once a day. If you use the brush head more than once a day, make sure it is dry before using it again. When using the Precision Brush head, the ideal sequence consists of the following steps:

Caution: Take off your glasses and remove any nose or lip piercings before you use the Precision Brush around your nose, lips or chin.

1 Remove make up. Use the Deep Pore brush head to

cleanse your cheeks and forehead, but not the nose or area around the mouth.

1616

2 Use the Precision Brush head to clean hard-to-reach

areas such as around your nose, mouth and chin area.

3 Finish with a massage treatment using the Revitalizing

Massage attachment.

5.5.1 The 30-second Precision Brush program

With the Intelligent brush head recognition, the VisaPure

Advanced handle recognizes the intelligent brush head and will run a customized program. The program consists

of 2 treatment periods of 15 seconds each. Start on the right side of your nose or mouth. When the appliance pauses after 15 seconds, move to the left side of your nose or mouth (Fig. 15).

D Note:

It is normal for your nose to feel slightly tender after

the rst treatment. If preferred reduce the treatment

intensity and duration.

5.5.2 Using the Precision Brush head

Make sure you only use the Precision Brush head on wet

skin or in combination with a facial cleanser.

1 First cleanse your face with a cleansing brush. Only

cleanse the cheeks and the forehead. You can leave the cleanser and water on your face, while you switch heads to the Precision Brush head.

2 Push the Precision Brush head onto the connection

pin until it locks into position with a click (Fig. 16).

3 Moisten the brush head and your face with water.

Do not use a dry Precision Brush head as this can irritate the skin. If preferred, you can put a bit of cleanser onto the brush head. Gently rub the cleanser in-between the bristles so it stays on the brush head. Do not apply too much cleanser onto the brush head to prevent cleanser from splashing when the treatment starts.

4 Press the on/off button to switch the appliance on

and choose your preferred setting.

Note:

When you attach a different brush head, the

appliance recognizes it. You will hear a beep and the intensity setting indications ash alternately.

ENGLISH

5 Place the Precision Brush head on the right side

of your nose. Gently move the brush head up and down across the right side of your nose, and if preferred, also in the mouth area (Fig. 17).

Note:

Do not push the brush head too hard onto the skin, to make sure that the treatment remains comfortable.

Important: Do not use the Precision Brush head on dry skin, open wounds, around the eyes, on the lips, on or inside the ears or inside the nose.

181818

6 After 15 seconds, the appliance pauses briey to let

you know you have to move it to the other side of your nose (Fig. 18).

7 When the program is nished, turn the appliance off. 8 After the treatment, rinse and dry your face.

6 Cleaning and

maintenance

• Always turn the facial brush OFF and remove from charging stand before cleaning.

• Do not use scouring pads, abrasive cleaning agents or aggressive liquids such as alcohol or acetone to clean the facial brush and accessories.

6.1 Cleaning the facial brush,

Deep Pore brush head and charging stand

• For best results, clean the facial brush and brush heads with warm water after each use.

• Always remove the facial brush from the charging stand before cleaning.

• Never remove or replace brushes while the facial brush is turned on.

• Do not apply pressure or hard objects to brush heads as this may damage the brush heads and reduce cleansing effectiveness.

• Do not put the facial brush, brush heads or attachments in a dishwasher.

• Clean the charging stand and storage caddy with a soft, moist cloth. Allow to air dry thoroughly before attaching power cord.

• Always keep the power cord and adapter dry. Never rinse it under the tap or immerse in water.

1 Rinse the handle and brush head under the tap

thoroughly with warm water (max 104°F/40°C)

(g. 19).

2 Remove the brush head from the handle and clean

the back of the brush head and the connection pin

of the facial brush under the tap (g. 20).

3 Dr y the facial brush and brush head with a soft towel

being careful not to bend the brush bristles.

ENGLISH

1919

4 Unplug and remove cord from the outlet and

charging stand (g. 21).

5 Clean the charging stand and storage caddy with a

soft, moist cloth (g. 22). Allow to air dry thoroughly

before attaching power cord.

6.2 Cleaning the Revitalizing Massage head

1 Thoroughly clean the Revitalizing Massage head with

warm water and mild soap after each use. Shake off excess water.

2 Remove the Revitalizing Massage head from

the handle and clean the back of head and the connection pin of the product under the tap.

3 Dr y the Revitalizing Massage head with a soft towel

or allow to air dry thoroughly.

2020

6.3 Cleaning the Precision Brush head

1 Thoroughly clean the Precision Brush head with

warm water and mild soap after each use. Shake off excess water.

2 Remove the Precision Brush head from the handle

and clean the back of head and the connection pin of the appliance under the tap.

3 Dr y the Precision Brush head with a soft towel or

allow to air dry thoroughly.

4 You may let the brush head dry on the appliance in

the charging stand (without the protection cap), or on the storage caddy.

5 Once the brush head is dry, you can use the

protection cap to protect the bristles (during traveling or for storage). Do not cover the brush

head with other materials. Make sure the brush head

is dry before traveling.

Note:

Make sure you press the bristles back into shape, so

they can dry properly and remain straight.

7 Storage

• Be sure the facial brush is turned OFF. Remove cord from outlet and facial brush before storing in a safe, dry location where it will not be crushed, banged, or subject to damage.

• Do not wrap cord around the facial brush/charging stand when storing.

• Store the cord in a safe location where it will not be cut or damaged.

• Do not place or store the charging stand where it can fall or be pulled into a tub or sink, water or other liquid while plugged in.

ENGLISH

• Store the facial brush with the brush head attached

in the charging stand (g. 23).

• When traveling or not in use, place the protective

cap on the brush head (g. 24).

• Allow facial brush and brush heads to air dry thoroughly before storing.

Note:

Never store a wet brush head in the protective cap.

222222

7.1 Storing the Revitalizing Massage head and Precision Brush head

Store the attachments in a cool, dry place.

Note:

Never store a wet Revitalizing Massage head or Precision

Brush head.

Note:

You can store the Precision brush head on the storage caddy alongside the other attachments, or in the charging stand while attached to the VisaPure Advanced handle.

8 Replacement

8.1 Brush head replacement

Worn bristles could lead to skin irritation. The Deep Pore brush head and the Precision brush head should be

replaced every 3 months. The Revitalizing Massage Head

should be replaced after one year of use, or immediately if it is damaged. Replacement brush heads and additional brush head types are sold separately and may be purchased at a store near you, or on our website www.philips.com/store

• Replacement NORMAL Brush Head

Model SC5990/10 – For normal, combination or oily

skin. For daily use.

• Replacement EXFOLIATION Brush Head

Model SC5992/10 – For all skin types. For weekly use.

• Replacement SENSITIVE Brush Head Model SC5991/10 – For normal to sensitive skin. For daily use.

• Replacement DEEP PORE Brush Head

Model SC5996/10 – Prevents and reduces the

appearance of pores. For daily use.

• Replacement PRECISION Brush head Model SC6017/00 - for precision cleansing of hard-to-reach areas such as the nose area.

• Replacement FRESH EYES head

Model SC6040/00 - for a boost of freshness to tired eyes.

• Replacement REVITALIZING Massage head Model SC6060/00- for a relaxing and revitalizing massage.

ENGLISH

2323

This facial brush has no other user-serviceable parts. For assistance call 1-800-243-7884 (in US only) or 1-866-800-9311 (in Canada only).

9 Assistance

For assistance, visit our website:

www.philips.com/support or call toll free 1-800-2437884 (in US only) or 1-866-800-9311 (in Canada only).

Online information is available 24 hours a day, 7 days a week.

2424

10 Battery Recycling

• This Philips facial brush contains a lithium-ion battery

which must be disposed of properly (g. 25).

• Contact your local town or city ofcials for battery disposal information. You can also call 1-800-822-8837 or visit www.call2recycle.org for battery drop-off locations.

• For assistance, visit our website, www.philips.com/ support or call: 1-800-243-7884 (in US only) or 1-866-800-9311 (in Canada only).

• Your appliance is designed and manufactured with high quality materials and components, which can be recycled and reused. For recycling information, please contact your local waste management facilities or www.recycle.philips.com.

11 Full Two-Year Warranty

Philips North America LLC (USA) and Philips Electronics Ltd (Canada) warrant this new product (except brush heads) against defects in materials or workmanship for a period of two years from the date of purchase, and agree to repair or replace any defective product without charge.

IMPORTANT: This warranty does not cover damage

resulting from accident, misuse or abuse, lack of

reasonable care, the afxing of any attachment not

provided with the product or loss of parts or subjecting

the product to any but the specied voltage or

batteries.*

NO RESPONSIBILITY IS ASSUMED FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES.

In order to obtain warranty service, simply go to www.philips.com/support for assistance. It is suggested that for your protection you return shipments of product by insured mail, insurance prepaid. Damage occurring during shipment is not covered by this warranty.

NOTE: No other warranty, written or oral, is authorized

by Philips North America LLC. This warranty gives you

specic legal rights, and you may also have other rights

which vary from state to state, province to province or country to country. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above exclusion and limitations may not apply to you. * Read enclosed instructions carefully

ENGLISH

2525

In US only manufactured for: Philips Personal Health a division of Philips North America LLC P.O. Box 10313, Stamford, CT 06904

12 45-Day Money-Back

Guarantee

Canada only imported by: Philips Electronics Ltd. 281 Hillmount Road

Markham, ON L6C 2S3

2626

If you are not fully satised with your Philips VisaPure

Advanced send the appliance back and we’ll refund you the full purchase price. The VisaPure Advanced must be shipped prepaid by insured mail, insurance prepaid, have the original sales receipt, indicating purchase price and date of purchase,

and the money-back guarantee return authorization form

enclosed. We cannot be responsible for lost mail.

The VisaPure Advanced must be postmarked no later than 45 days after the date of purchase. Philips reserves the right to verify the purchase price of the appliance and limit refunds not to exceed suggested retail price.

To obtain money-back guarantee return authorization form, call 1-800-243-7884 (in US only) or 1-866-800-9311 (in Canada only) for assistance.

Delivery of refund check will occur 6–8 weeks AFTER

receipt of returned appliance.

13 FCC/ISED

Regulatory notices

Modication statement

Philips has not approved any changes or modications to this device by the user. Any changes or modications

could void the user’s authority to operate the equipment.

Interference statement

This device complies with Part 15 of the FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

ENGLISH

+ 61 hidden pages
