Lumea
SC1994, SC1997,
SC1998, SC1999
Skin tone table / Tabla de tonos de piel /
Cuadro de tono de piel /
Tabela de tons de pele / Cilt rengi tablosu
2
Hair color table / Tabla de colores de vello /
Cuadro de color del pelo /
Tabela de cores dos pelos / Tüy rengi tablosu
3
6
10
9
2a 3
5
4
5
14
SC1994 (2a)
SC1997 (2a, 2b)
SC1998 (2a, 2b, 2c)
SC1999 (2a, 2b, 2c)
15
4
2b
5
4
2c
8
7
12
11
1
13
1
English 6
Español 26
Español 48
Português do Brasil 69
Türkçe 90
6
English
Welcome
Welcome to the beauty world of Lumea! You are only a few weeks away
from silky-smooth skin.
Philips Lumea uses Intense Pulsed Light (IPL) technology, known as one of
the most effective methods to continuously prevent hair regrowth. In close
cooperation with licensed dermatologists we adapted this light-based
technology, originally used in professional beauty salons, for easy and
effective use in the safety of your home. Philips Lumea is gentle and offers
convenient and effective treatment at a light intensity that you find
comfortable. Unwanted hairs are finally a thing of the past. Enjoy the feeling
of being hair-free and look and feel amazing every day.
To fully benefit from the support that Philips offers, register your product at
www.philips.com/welcome. For further information, please go to
www.philips.com/lumea to find our experts' advice, tutorial videos and
FAQs and make the most of your Lumea.
Device overview (Fig. 1)
1 Light exit window with integrated UV filter
2 Attachments
a Body attachment
b Facial attachment (SC1997, SC1998 and SC1999)
c Bikini attachment (SC1998, SC1999)
3 Reflector inside the attachment
4 Integrated safety system
5 Skin tone sensor
6 Electronic contacts
7 Flash button
8 Opening for electronic contacts
9 On/off button
10 Intensity lights (1-5)
11 'Ready to flash' light
12 Air vents
13 Device socket
14 Adapter
15 Small plug
16 Pouch (not shown)
Who should not use Lumea? Contraindication
General conditions
-
Never use the device if you have skin type V or VI (You rarely to
never sunburn, very dark tanning). In this case you run a high risk of
developing skin reactions, such as hyperpigmentation and
hypopigmentation, strong redness or burns.
English
Note: To check if your skin type allows usage of the device, consult
the skin tone table with number 2 on the foldout page.
-
Never use the device if you are pregnant or breastfeeding as the
device was not tested on pregnant or breastfeeding women.
-
Never use the device if you have any active implants such as a
pacemaker, neurostimulator, insulin pump etc.
Medications/History
Never use the device if you take any of the medications listed below:
-
If your skin is currently being treated with or has recently been
treated in the past week with Alpha-Hydroxy Acids (AHAs), BetaHydroxy Acids (BHAs), topical isotretinoin and azelaic acid.
-
If you have taken any form of isotretinoin Accutane or Roaccutane
in the last six months. This treatment can make skin more
susceptible to tears, wounds and irritations.
-
If you are taking photosensitizing agents or medications, check the
package insert of your medicine and never use the device if it is
stated that it can cause photo-allergic reactions, photo-toxic
reactions or if you have to avoid sun when taking this medicine.
-
If you take anticoagulation medications, including heavy use of
aspirin, in a manner which does not allow for a minimum 1-week
washout period prior to each treatment.
7
Never use the device:
-
If you have received radiation therapy or chemotherapy within the
past 3 months.
-
If you are on painkillers which reduce the skin's sensitivity to heat.
-
If you take immunosuppressive medications.
-
If you have had surgery in the areas to be treated in the last 3
weeks.
8
English
Pathologies/Disorders
Never use the device:
-
If you have diabetes or other systemic or metabolic diseases.
-
If you have congestive heart disease.
-
If you have a disease related to photosensitivity, such as
polymorphic light eruption (PMLE), solar urticaria, porphyria etc.
-
If you have a history of collagen disorder, including a history of
keloid scar formation or a history of poor wound healing.
-
If you have epilepsy with flashlight sensitivity.
-
If your skin is sensitive to light and easily develops a rash or an
allergic reaction.
-
If you have a skin disease such as active skin cancer, you have a
history of skin cancer or any other localized cancer in the areas to
be treated.
-
If you have a history of vascular disorder, such as the presence of
varicose veins or vascular ectasia in the areas to be treated.
-
If you have any bleeding disorder.
-
If you have a history of immunosuppressive disease (including HIV
infection or AIDS).
Skin condition
Never use the device:
-
If you have infections, eczema, burns, inflammation of hair follicles,
open lacerations, abrasions, herpes simplex (cold sores), wounds
or lesions and haematomas in the areas to be treated.
-
On irritated (red or cut), sunburned, recently tanned or faketanned skin.
-
On the following areas without consulting your doctor first: moles,
freckles, large veins, darker pigmented areas, scars and skin
anomalies. This can result in a burn and a change in skin color,
which makes it potentially harder to identify skin-related diseases.
-
On following areas: warts, tattoos or permanent make-up.
English
Location/areas
Never use the device on the following areas:
-
Around the eyes and on or near the eyebrows.
-
On the lips, nipples, areolas, labia minora, vagina, anus and the
inside of the nostrils and ears.
-
Men must not use the device on the face and neck including all
beard-growing areas, nor on the whole genital area.
-
On areas where you use long-lasting deodorants. This can result in
skin reactions.
-
Over or near anything artificial like silicone implants, subcutaneous
injection ports (for instance an insulin dispenser) or piercings.
Note: This list is not exhaustive. If you are not sure whether you can
use the device, we advise you to consult your doctor.
9
Important
Danger
-
Keep the device and the adapter dry.
-
If the device is broken, do not touch any inner part to avoid electric
shock.
-
Water and electricity are a dangerous combination. Do not use this
appliance in wet surroundings (e.g. near a filled bath, a running
shower or a filled swimming pool).
10
English
Warning
-
This device is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, unless they
have been given supervision or instruction concerning use of the
device by a person responsible for their safety.
-
Children should be supervised to ensure that they do not play with
the device.
-
The device is not intended for children under the age of 15 years.
Teenagers aged between 15 and 18 years can use the device with
the consent and/or assistance of their parents or the persons who
have parental authority over them.Adults of 18 years and older can
use the device freely.
-
Always check the device before you use it. Do not use the device
or adapter (including the cord) if it is damaged.
-
Do not use the device if the UV filter of the light exit window is
broken.
-
Do not modify or cut off any part of the adapter or the cord, as this
causes a hazardous situation.
-
Do not use any pencil or pen to mark the areas to be treated. This
may cause burns on your skin.
-
Hair removal by intense pulsed light sources can cause increased
hair growth in some individuals. Based upon currently available
data, the highest risk groups for this response are females of
Mediterranean, Middle Eastern and South Asian heritage treated
on the face and neck.
-
The light exit window can become very hot after use. Do not touch
the inner part of the light exit window before it has cooled down.
-
This appliance runs on electric power. You need to leave the
adapter connected to a wall socket to operate the appliance. This
adapter provides extra features to ensure safe operation and shall
not be replaced by another type of adapter. Only use the
detachable supply unit (S036Nx2400150, where x depends on the
plug type) provided with this appliance (see symbol). The reference
number can be found on your adapter.
English
11
Note: If you notice a skin tone has changed since the last treatment
(e.g. due to tanning), we recommend that you perform a skin test and
to wait 30 minutes before your next treatment.
To prevent damage
-
Make sure that nothing obstructs the airflow through the
ventilation slots of the device.
-
Never subject the device to heavy shocks and do not shake or
drop it.
-
If you take the device from a very cold environment to a very warm
environment or vice versa, wait approximately 3 hours before you
use it.
-
Store the device in a dust free and dry place.
-
Do not use the device at a temperatures lower than 15 °C or higher
than 35 °C.
-
Store the device in temperatures between -25 °C to 60 °C to avoid
reduced device lifetime.
-
In order to prevent damage avoid unnecessary prolonged
exposure to direct sunlight or other UV light.
Caution
-
This device is only intended for removing unwanted body hair from
areas below the cheekbone. Do not use it for any other
purpose.Doing so may expose you to a hazardous situation.Men
must not use it on the face and neck including all beard-growing
areas and the whole genital area.
-
This device is not washable. Never immerse the device in water
and do not rinse it under the tap.
12
English
-
For hygienic reasons, the device should only be used by one
person.
-
Use the device only at settings suitable for your skin type. Use at
higher settings than those recommended can increase the risk of
skin reactions and side effects.
-
Never use compressed air, scouring pads, abrasive cleaning agents
or aggressive liquids such as petrol or acetone to clean the device.
-
The scattered light produced by the device is harmless to your
eyes. Do not look at the flash while using the device. It is not
necessary to wear goggles during use. Use the device in a well-lit
room so that the light is less glaring to your eyes.
-
Always return the device to a service center authorized by Philips
for examination or repair. Repair by unqualified people could
cause an extremelyhazardous situation for the user.
-
Never leave the device unattended when it is switched on. Always
switch off the device after use.
-
Do not use the device if any of the conditions mentioned in
chapter ‘Who should not use Lumea? Contraindication' apply to
you.
-
Tanning with natural or artificial sunlight might influence the
sensitivity and color of your skin. Perform a skin test to determine
the appropriate light intensity setting.
-
Before you use Lumea, you should clean your skin and make sure
it is hair-free, entirely dry and free from oily substances.
-
Do not treat the same skin area more than once during a session.
This does not improve the effectiveness of the treatment, but
increases the risk of skin reactions.
-
Lumea should never be painful. If you experience discomfort,
reduce the light intensity setting.
Electromagnetic fields (EMF)
This Philips device complies with all applicable standards and regulations
regarding exposure to electromagnetic fields.
How IPL works
With IPL technology, gentle pulses of light are applied to the skin and
absorbed by the hairroot. The darker the hair, the better the pulses of light
are absorbed.
The pulses of light stimulate the hair follicle to go into a resting phase. As a
consequence, the hair sheds naturally and hair regrowth is prevented,
leaving your skin continuously silky-smooth.
The cycle of hair growth consists of different phases. IPL technology is only
effective when the hair is in its growing phase.Not all hairs are in the
growing phase at the same time. This is why we recommend an 8-week
treatment schedule followed by touch-ups to make sure all hairs are
effectively treated in the growing phase.
Note: Treatment with Lumea is not effective if you have blond or light blond
hairs, as light hairs do not absorb enough light. Below you can see the hair
colors for which Lumea is suitable and effective.
English
13
Suitable body hair colors
Note: To check if your body hair color allows usage of the device, consult the
hair color table with number 3 on the foldout page.
What to expect
Immediately after the 1st treatment
Afterthe first treatment, it can take 1 to 2 weeks for the hairs to fall out. In
the first weeks following the initial treatments, you still see some hairs
growing.These are likely to be hairs that were not in their growing phase
during the first treatments.
14
English
After 2-3 treatments
After 2-3 treatments, you should see a noticeable reduction in hair growth.
However, to effectively treat all hairs, it is important to keep on treating
according to the recommended treatment schedule.
After 4-5 treatments
After 4-5 treatments, you should see a significant reduction of hair growth in
the areas that you treated with Lumea. A reduction of hair density should be
visible as well. Keep on treating with frequent touch-ups (every 4-8
weeks)to maintain the result.
Tanning advice
Tanning with natural or artificial sunlight
Intentionally exposing your skin to natural or artificial sunlight with the aim
of developing a tan influences the sensitivity and color of your skin.
Therefore the following is important:
-
After each treatment, wait at least 48 hours before tanning. Even after 48
hours, make sure that the treated skin does not show any redness from
the treatment anymore.
-
In case of exposing your skin to the sun (without tanning intentionally) in
the 48 hours after treatment, use a sunblock SPF 50+ on the treated
areas. After this period, you can use a sunblock SPF 30+ for two weeks.
-
After tanning, wait at least 2 weeks before you use Lumea. Perform a skin
test to determine the appropriate light intensity setting.
-
Do not use Lumea on sunburned body areas.
Note: Occasional and indirect sun exposure does not qualify as tanning.
Tanning with creams
If you have used an artificial tanning lotion, wait until the artificial tan has
disappeared completely before you use the device.
Before you use your Lumea
Pretreating your skin
Before you use Lumea, you should pretreat your skinby removing hairs on
the surface of your skin. This allows the light to beabsorbed by the hair
parts below the skin surface to ensure effective treatment. You can either
shave, short-trim, epilate or wax. Do not use hair removal creams, as
chemicals may cause skin reactions.
Skin test
English
If you chose to wax, please wait 24 hours before using Lumea to let your
skin rest.We recommend that you take a shower before the treatment to
ensure that all possible residue of wax has been removed from your skin.
1 Pretreat the areas you intend to treat with Lumea.
2 Clean your skin and make sure it is hair-free, entirely dry and free from
oily substances.
Note: Once the hairs stop growing back, which usually happens after 4-5
treatments, you no longer have to pretreat your skin before you use the
device.
When you use Lumea for the first time or after recent tanning, perform a skin
test on each area to be treated. The skin test is necessary to check your
skin's reaction to the treatment and to determine the correct light intensity
setting for each bodyarea.
1 Choose an area close to the area you intend to treat.
2 Switch on the device. Make sure you select setting 1.
3 Put the device against your skin and press the flash button to release a
flash.
4 Slide the device over the skin to the next area to be treated.
5 Increase the setting by one level, apply a flash and slide the device to the
next area. Repeat this for all levels within the recommended range for
your skin type.
6 After the skin test, wait 24 hours and check your skin for any reaction. If
your skin shows reactions, choose the highest setting that did not result
in any skin reaction for subsequent use. The skin test should be
performed in all the areas you want to treat.
15
Using your Philips Lumea
Skin tone sensor
For extra safety the integrated skin tone sensor measures the skin tone at
the beginning of each session and occasionally during the session. If it
detects a skin tone that is too dark for treatment with Lumea, the device
automatically disables to prevent you from developing skin reactions. This
means that it does not emit pulses when you press the flash button.
16
English
Attachments
Placing and removing
To place the attachment, simply snap it onto the light exit window.
To remove the attachment, pull it off the light exit window.
Body attachment
You can use the body attachment to treat unwanted hair on several body
areas below the neckline. You can use it for example forfast treatment of
larger areas like legs.
Facial attachment (SC1997, SC1998, SC1999)
The facial attachment includes an additional integrated light filter for extra
safetyand you can therefore use it to treat unwanted facial hair on the
upper lip, chin and sideburns.
Caution:
-
Do not treat your eyebrows with Lumea.
-
When you treat the area above your upper lip, be careful that you do not
flash on the lip.
Bikini attachment (SC1998, SC1999)
The bikini area attachment has a special filter for treating the coarser hair in
the bikini area.
Selecting the right light intensity
Lumea provides 5 different light intensities. Depending on your skin type
and the light intensity level you find comfortable, you can select the right
light intensity setting.
1 Consult the table below to select the right setting.
2 To adjust the light intensity setting,press the on/off button one or more
times until you have reached the required setting. The corresponding
intensity light lights up white.
Note: Thedevice automatically disables when your skin tone is too dark,
to prevent you from developing skin reactions. The integrated skin tone
sensor does not tell you which light intensity setting to use, as Philips
Lumea gives you the freedom to select the light intensity that you find
most convenient.
3 Lumea should never be painful. If you experience discomfort, reduce the
light intensity setting.
4 After recent tanning, perform a skin test to determine the right light
intensity setting.
Skin type
I White; You always sunburn, never tan. 4/5
II Beige; You easily sunburn, tan minimally. 4/5
Skin tone Light intensity setting
English
17
III Light brown; You sunburn easily, tan slowlyto light
brown.
IV Mid brown; You rarely sunburn, tan easily. 3/4
V Dark brown; You rarely sunburn, tan very easily. You cannot use the device
VI Brownish black or darker; You rarelyor never sunburn,
very dark tanning.
Note: To check if your skin type allows usage of the device, consult the skin
tone table with number 2 on the foldout page.
Note:Your skin may react differently on different days/occasions for a
number of reasons.
4/5
You cannot use the device
Handling the device
1 Before use, clean the attachments and the light exit window.
18
English
2 Put the small plug in the device and put the adapter in the wall socket.
3 Switch on the device and select the right light intensity for your skin tone.
4 Place the device at a 90° angle on the skin and press firmly so that the
attachment and the integrated safety system are in contact with your
skin.
The integrated safety system prevents unintentional flashingwithout skin
contact.
5 Press the devicefirmly onto your skin to ensureproper skin contact. The
device then automatically performs a skin tone analysis and the ‘ready to
flash light’ lights up white to indicate that you can proceed with the
treatment.
Note: When the ‘ready to flash’ light lights up orange, your skin is not
suitable for treatment. In this case, the device automatically disables. You
can try to use the device on other areas with a lighter skin tone.
6 Press the flash button to release a flash.You should feel a warm
sensation because of the flash.
Note: The light produced by the device is harmless to your eyes. It is not
necessary to wear goggles during use. Use the device in a well-lit
roomso that the light is less glaring to your eyes.
7 Place the device on the next area to be treated. After each flash, it takes
up to 3.5 seconds until the device is ready to flash again. You can release
a flash when the 'ready to flash' light lights up again.
8 To make sure that you have treated all areas, release the flashes close to
each other. Effective light only comes out of the light exit window,
therefore there should be some overlap.However, make sure you flash
the same area only once. Flashing the same area twice doesn't improve
the effectiveness of the treatment, but increases the risk of skin reactions.
TIP: If you use Lumea on your bikini area and want to leave some hair in
place, make sure that the skin tone sensor is not placed on the remaining
hair during the treatment, as this can cause the device to block.
9 When you have finished the treatment, press and hold the on/off button
for 2 seconds to switch off the device.
Two treatment modes: Stamp & Flash and Slide & Flash
YourPhilips Lumea has two treatment modes for more convenient use on
different body areas:
-
The Stamp & Flash mode is ideal to treat small orcurvy areas like knees
and underarms. Simply press and releasethe flash button to release a
single flash.
-
The Slide & Flash mode offers convenient use on larger areas like legs.
Keep the flash button pressed while you slide the device over your
skinto release several flashes in a row.
Recommended treatment schedule
Initial phase
For the first 4 to 5 treatments, we advise you to use Philips Lumea once
every two weeks to ensure that all hairs are treated.
Touch-up phase
After the initial treatment phase (4-5 treatments), we recommend touch-ups
every 4 to 8 weeks,when you see hairs growing back. This is to maintain
results and enjoy smooth skin for months.The time between treatments
may vary based on your individual hair regrowth and also across different
body areas.
English
19
1 2 3
2
1
8 min.
1 min.
3
1 15 min.
1
1
4 min.
2 min.
SC1994 ( )
SC1997 ( , )
SC1998, SC1999 ( , , )
1
1 2
1 32
20
English
Recommended attachment & treatment time per area
After use
Common skin reactions
Your skin may show slight redness and/or may prickle, tingle or feel
warm. This reaction is absolutely harmless and disappears quickly.
English
Dry skin and itching may occur due to shaving or a combination of
shaving and light treatment. You can cool the area with an ice pack
or a wet face cloth. If dryness persists, you can apply a non-scented
moisturizer on the treated area 24 hours after the treatment.
Rare side effects
-
Burns, excessive redness (e.g. around hair follicles) and swelling:
these reactions occur rarely. They are the result of using a light
intensity that is too high for your skin tone. If these reactions do
not disappear within 3 days, we advise you to consult a doctor.
Wait with the next treatment until the skin has healed completely
and make sure you use a lower light intensity.
-
Skin discoloration: this occurs very rarely. Skin discoloration
manifests itself as either a darker patch (hyperpigmentation) or a
lighter patch (hypopigmentation) than the surrounding area. This is
the result of using a light intensity that is too high for your skin
tone. If the discoloration does not disappear within 2 weeks, we
advise you to consult a doctor. Do not treat discolored areas until
the discoloration has disappeared and your skin has regained its
normal skin tone.
-
Skin infection is very rare but is a possible risk following a
(micro)wound, a skin burn, skin irritation etc.
-
Epidermal heating (a sharply defined brownish area which often
occurs with darker skin tones and is not accompanied with skin
dryness): This reaction occurs very rarely. In case this reaction does
not disappear within 1 week, we advise you to consult a doctor.
Wait with the next treatment until the skin has healed completely
and make sure you use a lower light intensity.
-
Blistering (looks like small bubbles on the surface of the skin): this
occurs very rarely. In case this reaction does not disappear within 1
month or when the skin gets infected, we advise you to consult a
doctor. Wait with the next treatment until the skin has healed
completely and make sure you use a lower light intensity.
21
22
English
-
Scarring: often the secondary effect of a burn, which can take
longer than a month to heal.
-
Folliculitis (swelling around hair follicles combined with pustule
formation): this reaction occurs very rarely and is the result of
bacteria penetrating the damaged skin. In case this reaction
occurs, we advise you to consult a doctor as folliculitis may need
antibiotic ointment.
-
Pain: this can occur during or after treatment if you have used the
device on skin that is not hair-free, if you use the device at a light
intensity that is too high for your skin tone, if you flash the same
area more than once and if you use the device on open wounds,
inflammations, infections, tattoos, burns, etc.
Aftercare
After use, you can safely apply lotions, creams, deodorant, moisturizer or
cosmetics to the treated areas. If you experience skin irritation or skin
redness after treatment, wait until it disappears before applying any product
to your skin. If you experience skin irritation after applying a product to your
skin, wash it off with water.
Note: when following all instructions you may still get skin reactions. In this
case stop using the device and contact the consumer care center in your
country.
Cleaning & storage
After use, switch off the device, unplug it and let it cool down.
1 Remove the attachment.
2 Moisten the soft cloth supplied with the device with a few drops of water
3 Let all parts air dry thoroughly.
4 Store the device in a dust-free and dry place at a temperature between
and use it to clean the following parts:
-
the light exit window
-
the outside surface of the attachments
-
the reflector inside the attachments
-
the reddish filter glass inside thefacial attachment.
-25 °C and 60 °C.
Warranty and support
If you need information or support, please visit www.philips.com/support or
read the international warranty leaflet.
Recycling
-
Do not throw away the product with the normal household waste at the
end of its life, but hand it in at an official collection point for recycling. By
doing this, you help to preserve the environment.
-
Follow your country's rules for the separate collection of electrical and
electronic products. Correct disposal helps prevent negative
consequences for the environment and human health.
Technical specifications
SC1994, SC1997, SC1998, SC1999
Rated voltage 100 V - 240 V
Rated frequency 50 Hz - 60 Hz
Rated input 36 W
Protection against electric shock Class II
Protections rating IP 30 (EN 60529)
English
23
Operating conditions Temperature:+15 ºC to 35°C
Storage conditions temperature -25 °C to 60 °C
Storage conditions humidity Less than 90% (non condensing)
Operating pressure 700 hPa - 1060 hPa
Altitude Max. 2000 m
Emitted wavelengths 530 nm - 1400 nm
Optical exposure 2.5 - 5.0 J/cm², depending on chosen setting
Maximum optical energy 20 J
Pulse duration <1.5 ms
Repetition time 1-3.5 s, depending on chosen setting
Optical homogeneity Max. +/- 20% deviation from average optical exposure in
treatment area
Troubleshooting
This chapter summarizes the most common problems you could encounter
with the device. If you are unable to solve the problem with the information
24
English
below, visit www.philips.com/support for a list of frequently asked questions
or contact the Consumer Care Center in your country.
Problem Possible cause Solution
The device/adapter
becomes warm during use
When I place the device on
the skin it does not release
a flash. The 'ready to flash'
light blinks orange and
then lights up orange
continuously.
The 'ready to flash light'
doesn't light up when I
place the attachment on
my skin, but the cooling fan
works.
The 'ready to flash light'
lights up white but the
device does not produce a
flash when I press the flash
button.
The intensity lights are
blinking alternately, going
from 1 to 5, then 5 to 1.
The intensity lights are all
blinking.
The skin reaction after
treatment last longer than
usual.
This is normal. No action required.
You skin tone in the area to
be treated is too dark.
The device is not completely
in contact with your skin.
The device needs to be reset. To reset the device, switch it off and
The overheat protection has
been activated.
The device needs to be reset. To reset the device, switch it off and
You have used a light
intensity setting which is too
high for you.
Treat other body areas with lighter skin
tones with Lumea.
Place the device at a 90 degree angle on
the skin so that the integrated safety
system is in contact with your skin.
switch it on again.
Let the device cool down until the lights
stop blinking alternately. After approx. 5
minutes the device will automatically
turn off.
unplug the adapter from the mains.
Then, plug it in and switch it on again.
Select a lower intensity next
time.Seechapter 'Using your Philips
Lumea', section 'Selecting the right light
intensity'.
Problem Possible cause Solution
English
25
The results of the
treatment are not
satisfactory.
My body attachment does
not have an integrated
glass/filter/window.
You have used a light
intensity setting which is too
low for you.
You did not flash an area
adjacent to an area you
treated before.
The device is not effective on
your body hair color.
You do not use the device as
often as recommended.
You respond more slowly to
IPL treatment.
This is normal. The body attachment does not contain a
Select a higher setting next time.
You have to release the flashes close to
each other.
If you have white, grey, light blond,
blond, or red hair, the treatment is not
effective.
To remove all hairs successfully, we
advice you to follow the recommended
treatment schedule. You can reduce the
time between treatments, but do not
treat more often than once every two
weeks.
Continue using the device for at least 6
months, as hair regrowth can still
decrease over the course of this period.
glass/filter/window.
26
Español
Bienvenido
Bienvenido al mundo de belleza de Lumea. Está a solo unas pocas semanas
de disfrutar de una piel sueva y sedosa.
Philips Lumea usa una tecnología de Luz de pulsación intensa (IPL, del
inglés Intense Pulsed Light), conocida como uno de los métodos más
efectivos para prevenir de manera continua el crecimiento del vello.En
colaboración cercana con expertos dermatólogos adaptamos esta
tecnología basada en luz, originalmente creada para el uso profesional en
salones de belleza, para usarla de manera efectiva en la seguridad de su
hogar.Philips Lumea es delicado y ofrece un tratamiento efectivo y
conveniente a la intensidad de luz que le parezca cómoda.El vello no
deseado es por fin cosa del pasado. Disfrute la sensación de una piel libre
de vello, véase y siéntase increíble cada día.
Para beneficiarse plenamente de la asistencia que Philips ofrece, registre el
producto en www.philips.com/welcome. Para obtener más información,
visite www.philips.com/lumea para consultar consejos de nuestros
expertos, videos tutoriales y preguntas frecuentes para aprovechar al
máximo su Lumea.
Visión general del dispositivo (Fig. 1)
1 Ventanilla de salida de luz con filtro UV integrado
2 Accesorios
a Accesorio corporal
b Accesorio facial (SC1997, SC1998 y SC1999)
c Accesorio para la zona del bikini (SC1998, SC1999)
3 Reflector dentro del accesorio
4 Sistema de seguridad integrado
5 Sensor de tono de piel
6 Contactos electrónicos
7 Botón de pulso de luz
8 Apertura para contactos electrónicos
9 Botón de encendido/apagado
10 Luces de intensidad (1-5)
11 Luz "Listo para el pulso de luz"
12 Rejillas de aire
13 Enchufe del dispositivo
14 Adaptador
15 Conector pequeño
16 Funda (no se muestra)
Español
Quién no debería usar Lumea Contraindicación
Condiciones generales
-
Nunca use el dispositivo si tiene el tipo de piel V y VI (rara vez o
nunca se broncea, tiene un bronceado muy oscuro). En este caso
corre un alto riesgo de desarrollar reacciones de la piel, tales como
hiperpigmentación o hipopigmentación, enrojecimiento severo o
quemaduras.
Nota: Para comprobar si su tipo de piel es el adecuado para usar el
dispositivo, consulte la tabla de tonos de piel con el número 2 en la
página desplegable.
-
Nunca use este dispositivo si está embarazada o amamantando ya
que no se probó el dispositivo en mujeres embarazadas o
amamantando.
-
Nunca use este dispositivo si tiene implantes activos tales como
un marcapasos, neuroestimulador, bomba de insulina, etc.
27
Medicamentos/Historial
Nunca use el dispositivo si toma cualquier medicamento que
aparezca en la siguiente lista:
-
Si su piel está siendo tratada actualmente o ha sido tratada
recientemente con alfa-hidroxiácidos (AHA, por sus siglas en
inglés), beta-hidroxiácidos (BHA, por sus siglas en inglés),
isotretinoína tópica y ácido azelaico.
-
Si ha tomado Accutane o Roaccutane isotretinoína en cualquier
forma en los últimos seis meses. Este tratamiento puede hacer
que su piel sea más susceptible a grietas, heridas o irritaciones.
28
Español
-
Si está tomando sustancias o medicamentos fotosensibilizadores,
lea el folleto en el paquete de su medicamento y nunca use el
dispositivo si se afirma que puede producir reacciones
fotoalergénicas, fototóxicas o si tiene que evitar el sol cuando
toma dicha medicina.
-
Si toma medicamentos anticoagulantes, incluso el uso intensivo
de aspirina cuyo curso no se puede interrumpir por un periodo de
limpieza de una semana previo a cada tratamiento.
Nunca use el dispositivo:
-
Si recibió radioterapia o quimioterapia en los últimos tres meses.
-
Si toma analgésicos que reduzcan la sensibilidad de la piel al calor.
-
Si toma medicamentos inmunosupresores.
-
Si ha tenido una cirugía en las zonas a tratar en las últimas tres
semanas.
Patologías/Trastornos
Nunca use el dispositivo:
-
Si tiene diabetes u otras enfermedades metabólicas o sistémicas.
-
Si tiene enfermedad cardíaca congestiva.
-
Si tiene una enfermedad relacionada a la fotosensibilidad, tal y
como erupción polimórfica leve (PMLE, por sus siglas en inglés),
urticaria solar, porfiria, etc.
-
Si tiene un historial de trastornos de colágeno, incluyendo un
historial de formación de cicatriz keloide o de mala curación de
heridas.
-
Si tiene epilepsia con sensibilidad a las luces de flash.
-
Si su piel es sensible a la luz y desarrolla salpullido o una reacción
alérgica fácilmente.
-
Si tiene una enfermedad de la piel tal y como cáncer activo, un
historial de cáncer de la piel o cualquier cáncer localizado en las
áreas a tratar.
Español
-
Si tiene un historial de trastornos vasculares, tal y como la
presencia de venas varicosas o ectasia vascular en las zonas a
tratar.
-
Si tiene un trastorno hemorrágico.
-
Si tiene un historial de enfermedad inmunosupresora (incluyendo
la infección de VIH o SIDA).
Condición de la piel:
Nunca use el dispositivo:
-
Si tiene infecciones, eczema, quemaduras, inflamación de los
folículos pilosos, laceraciones abiertas, abrasiones, herpes simple
(úlceras bucales), heridas o lesiones y hematomas en las zonas a
tratar.
-
En piel irritada (roja o cortada), quemada al sol, recién bronceada
o con bronceado falso.
-
En las siguientes zonas sin consultar a un médico primero: lunares,
pecas, venas grandes, zonas de pigmentación oscura, cicatrices y
anomalías de la piel. Esto puede resultar en una quemadura y
cambio de color de la piel, lo cual hace que sea potencialmente
más difícil identificar las enfermedades relacionadas con la piel.
-
En las siguientes zonas: verrugas, tatuajes o maquillaje
permanente.
29
Ubicación/zonas
Nunca use el dispositivo en las siguientes zonas:
-
Alrededor de los ojos y en las cejas o cerca de las mismas.
-
En los labios, pezones, areolas, labios menores, vagina, zona anal
o dentro de las fosas nasales u oídos.
30
Español
-
Los hombres no deben usar este dispositivo en la cara ni en el
cuello, incluyendo todas las zonas donde crece la barba ni en toda
la zona genital.
-
En zonas donde ha usado desodorante de larga duración. Esto
puede producir reacciones en la piel.
-
Sobre o cerca de cualquier cosa artificial como implantes de
silicón, puertos de inyección subcutánea (por ej. un dispensador
de insulina) o perforaciones en la piel.
Nota: Esta no es una lista completa. Si no tiene la seguridad de
poder usar el dispositivo, le recomendamos que consulte a su
médico.
Importante
Peligro
-
Mantenga el dispositivo y el adaptador siempre secos.
-
Si el dispositivo está roto, no toque ninguna pieza interna para
evitar sufrir una descarga eléctrica.
-
El agua y la electricidad son una combinación peligrosa. No use
este dispositivo en entornos mojados (p. ej. cerca de una tina llena,
ducha abierta o piscina llena).
Advertencia
-
Este dispositivo no debe ser usado por personas (adultos o niños)
con su capacidad física, psíquica o sensorial reducida ni por
quienes no tengan los conocimientos ni la experiencia necesarios,
a menos que sean supervisados o instruidos acerca del uso del
dispositivo por una persona responsable de su seguridad.
-
Se debe supervisar a los niños para asegurarse de que no jueguen
con el dispositivo.
Español
-
El dispositivo no debe ser usado por niños menores de 15 años.
Los adolescentes de entre 15 y 18 años de edad pueden usar el
dispositivo con el permiso y ayuda de sus padres o de personas
que tengan patria potestad sobre ellos.Los adultos de 18 años de
edad o mayores pueden usar el dispositivo con libertad.
-
Revise siempre el dispositivo antes de usarlo.No use el dispositivo
ni el adaptador (incluyendo el cable) si están dañados.
-
No use el dispositivo si el filtro UV de la ventanilla de salida de luz
está roto.
-
No modifique ni corte ninguna parte del adaptador o del cable, ya
que podría provocar situaciones de peligro.
-
No use un lápiz ni una pluma para marcar las zonas a tratar. Esto
puede causar quemaduras en la piel.
-
La eliminación del vello por medio de fuentes de luz pulsante
intensa puede causar un aumento en el crecimiento del vello en
algunas personas. Con base en los datos disponibles actualmente,
los grupos de mayor riesgo para este tipo de resultado son
mujeres de origen mediterráneo, Oriente Medio y sur de Asia que
reciban tratamiento en la cara y el cuello.
-
La ventanilla de salida de luz puede calentarse mucho después
del uso.No toque la parte interior de la ventanilla de salida de luz
antes de que se haya enfriado.
-
Este dispositivo funciona a base de electricidad. Necesita dejar el
adaptador conectado a un enchufe de pared para que funcione.
Este adaptador proporciona funciones adicionales para asegurar
el funcionamiento seguro y no debe ser reemplazado por otro tipo
de adaptador. Use solamente la unidad de suministro
desprendible (S036Nx2400150, donde x depende del tipo de
enchufe) provista con este dispositivo (ver el símbolo). El número
de referencia se encuentra en el adaptador.
31
Loading...
