Page 1
Baby Monitor
SBCSC463
System check for more reliability
Wireless baby monitor that includes the unique feature of system check. This functionality checks if the baby
monitoring system is working reliably.
Reliability & Piece of mind
More transmission channels lowers the risk of interference
Analog Pi lot Tone minimizes i nterference from other devices
System check ensures the monitor is working reliably
System check alarm Informs of malfunction or out-of-range
System check li ght reassures you that the monitor is working
Flexibility in monitoring your child
Take the parent unit with you in and around the house
Maximum operating distance between units with no obstacles
Convenience for you and your child
Simplifies the selection of the volume you prefer
High-quality microphone has adjustable sensitivity
Page 2
Baby Monitor
SBCSC463/16
Highlights Specifications
Number of channels
A choice of channels significantly reduces the
risk of interference or sounds from other baby
monitors in the neighbourhood.
Analogue Pilot Tone
A special tone that is transmitted along with
the audio signal minimizes the chance of
interference from other wireless appliances.
System check
When interference is detected in the
communication li nk between the baby unit and
parent unit or if the signal is too weak, the
visual and audible alarms will be activated.
System check alarm
The parent unit gi ves an audible alarm when it
is outside the communication range of the
baby unit or when the communication link is
not reliable.
System check light
Green light on the parent unit lights when the
connection between the baby and the parent
unit is reliable and flashes when the parent
unit is outside the range of the baby unit or
when the communication link is not reliable.
Use in & around the house
Rest assured that as you take the parent unit
with you as you move in and around your
house, the parent unit will stay in touch with
the baby unit. It keeps you reassuringly
informed and able to respond quickly when
baby calls.
Range in open air
In the open air with no obstacles, the safe
distance between the baby unit and parent unit
is greater than indoors, so you can take the
parent unit with you into the garden or to the
neighbour's house without loosing contact.
Volume control
A handy rotary control sets the volume to the
ideal level to suit your preference.
Adjust Microphone sensitivity
Possibili ty to set the sensitivity of the
microphone so you only hear the sounds you
want to hear.
Tuner/Reception/Transmission
Frequency band: 40.675 - 40.690 MHz
Number of pilot tones: 4
Pilot tone: Analogue
Maximum range: 250 m
Number of channels: 2
Convenience
Auto out-of-range warning
Battery low indication
Power on indication
Volume control
Accessories
AC/DC Adaptor: 2x 9V DC 200mA
Batteries: 4 x AA baby unit not incl.
Belt clip: Belt clip on parent unit
User Manual
Power
Battery voltage: 4.8 V
Operating time on battery: 12 hr
© 20 19 Koninklijke Philips N.V.
All Right s reser ved.
Specifications are subject to change
without notice. Trademarks are the
property of Koninklijke Philips N.V. or
their re spective owners .
Issue date 2019‑0 4‑0 8
Version: 1.0.2
12 NC: 9082 100 00 669
EAN: 87 10101 69650 8
