Philips SBCBA160 User Manual

Active speaker

SBC

BA160

AC/DC adapter

included

Trackball volume

control

4W output power

Integrated amplifier

Dynamic Bass Boost

Magnetic shielding

for PC applications

Philips Accessories

http://www.philips.com

Active speaker

SBC

BA160

Great sound, great style, and value for money!

The SBC BA160 is a high-quality, stylish speaker system that offers very good value for money. Compact and portable, these speakers have impact bumpers to protect them from damage when being carried around.The ideal set for all audio systems and multimedia applications.

Stylish speaker set with 4W output power

The SBC BA160 delivers 4W of high-quality sound through very stylish speakers.

Bass reflex system for punchy bass sounds

Bass reflex technology ensures plenty of punchy bass performance for full musical enjoyment.

Dynamic Bass Boost

Enhances bass performance at all volume levels by boosting the lower frequencies at lower volumes, and reducing the boost when the volume is increased.

Integrated amplifier

Can be powered from the audio source or from batteries to provide very good sound reproduction.

Active/Passive mode switch for conservation of battery power

When switched to the passive mode, the speakers will be powered from the audio source’s amplifier to conserve battery power.

Magnetic shielding for PC applications

Magnetic shielding in the speakers means they can be safely placed next to TVs and monitors. Ideal for PC use.

Trackball volume control for fingertip adjustment

Volume control can be precisely adjusted for personal preference.

AC/DC adapter included

To conserve batter y power, the speakers can be powered via the included AC/DC adapter.

Impact bumpers

Two reinforced and scratch-resistant side panels prevent the speakers from damage.

Standard product information

System information

• Type Active mini speaker system

• Speaker size 3 inch full range

• Frequency range 80 - 20000 Hz

• Impedance (passive) 4 Ohm

• Impedance (active) 150 Ohm

• PMPO 16W

• Max. music power 2 x 4W

• RMS value 2 x 2W

• Interlink cable length 1 M

• Source cable length 1 M

• Cable connection 3.5mm jack

• Power supply 6*1.5V Battery R6 (‘AA’) 9V/500 mA Adapter

• Operating time

(at 5mW + 5mW

output power) 40 hrs (alk batt)

• 12NC 9082 100 00177

• EAN 87 10101 65149 1

Packaging information

• Type Gift-box

• Material Carton

• Dimensions 255 x 148 x 270 mm

Inner carton

• Quantity 6 sets

• Dimensions 466 x 270 x 292 mm

• EAN 87 10101 98616 6

Outer carton

• Quantity 12 sets

• Dimensions 568 x 482 x 321 mm

• EAN 87 10101 98615 9

Country of origin China
