Philips SACD1000 User Manual

Instructions for use Mode d'emploi Instrucciones de manejo

SACD1000

General information

Safety precautions

USA C

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK ,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

Laser safety

This unit employs a laser. To prevent possible eye injury, only a qualified service person should remove the cover or attempt to service this device.

USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN

HAZARDOUS RADIATION EXPOSURE.

LASER

Type Semiconductor laser GaAlAs Wavelength 650 nm (DVD)

Output Power 7 mW (DVD)

Beam divergence 60 degrees

CAUTION VISIBLE AND INVISIBLE LASER RADIATION. WHEN OPEN AVOID

EXPOSURE TO BEAM. (WARNING LOCATION: INSIDE ON LASER COVERSHIELD)

NEVER MAKE OR CHANGE CONNECTIONS WITH THE POWER SWITCHED ON.

For Customer Use:

780 nm (VCD/CD)

10 mW (VCD/CD)

CLASS 1

LASER PRODUCT

Read carefully the information located on the back of your SACD player and entered below the Serial N° Retain this information for future reference.

Model N° is SACD 1000 Serial N° is __________________________

Return your Warranty Registration card today to ensure

Hurry!

you receive all the benefits you’re entitled to.

Once your PHILIPS purchase is registered, you’re eligible to receive all the privileges of owning a PHILIPS product. So complete and return the Warranty Registration Card enclosed with your purchase at once, and take advantage of these important benefits.

Warranty

Verification

Registering your product within 10 days confirms your right to maximum protection under the terms and conditions of your PHILIPS warranty.

Congratulations

and welcome to the

on your

“family!”

purchase,

Owner

Confirmation

Your completed Warranty Registration Card serves as verification of ownership in the event of product theft or loss.

Model

Registration

Returning your Warranty Registration Card right away guarantees you’ll receive all the information and special offers which you qualify for as the owner of your model.

Dear PHILIPS product owner:

Thank you for your confidence in PHILIPS. You’ve selected one of the best-built, best-backed products available today. And we’ll do everything in our power to keep you happy with your purchase for many years to come.

As a member of the PHILIPS “family,” you’re entitled to protection by one of the most comprehensive warranties and outstanding service networks in the industry.

What’s more, your purchase guarantees you’ll receive all the information and special offers for which you qualify, plus easy access to accessories from our convenient home shopping network.

And most importantly you can count on our uncompromising commitment to your total satisfaction. All of this is our way of saying welcome–and thanks for investing in a PHILIPS product.

Sincerely,

Robert Minkhorst President and Chief Executive Officer

Know these

safetysymbols

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

P.S. Remember, to get the most from your PHILIPS

product, you must return your Warranty Registration Card within 10 days. So please mail it to us right now!

This “bolt of lightning” indicates uninsulated material within your unit may cause an electrical shock.

For the safety of everyone in your household, please do not remove product covering.

The “exclamation point” calls attention to features for which you should read the enclosed literature closely to prevent operating and maintenance problems.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.

CAUTION: To prevent electric shock, match wide blade of plug to wide slot, and fully insert. ATTENTION: Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la borne

correspondante de la prise et pousser jusqu’au fond.

Visit our World Wide Web Site at http://www.philipsusa.com

Important safety instructions

1. Read Instructions - All the safety and operating instructions should be read before the appliance is operated.

2. Retain Instructions - The safety and operating instructions should be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to.

4. Follow Instructions - All operating and use instructions should be followed.

5. Cleaning - Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

Exception: A product that is meant for uninterrupted service and that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6. Attachments - Do not use attachments not recommended by the video product manufacturer as they may cause hazards.

7. Water and Moisture - Do not use this video product near water - for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8. Accessories - Do not place this video product on an unstable cart, stand, tripod, bracket, or table. The video product may fall, causing serious injury to a child or adult, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the video product. Any mounting of the appliance should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer.

8A. An appliance and cart combination should be

moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

9. Ventilation - Slots and openings in the cabinet are provided for ventilation, to ensure reliable operation of the video product, and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the video product on a bed, sofa, rug, or other similar surface. This video product should never be placed near or over a radiator or heat register. This video product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10. Power Sources - This video product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance supplier or local power company. For video products intended to operate from battery power, or other sources, refer to the operating instructions.

11. Polarization - This product may be equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12. Power-Cord Protection - Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

13. Outdoor Antenna Grounding - If an outside antenna or cable system is connected to the video product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. See Fig.A.

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE (NEC)

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT

(NEC SECTION 810-20)

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM

(NEC ART 250, PART H)

14. Lightning - For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power surges.

15. Power lines - An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16. Overloading - Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

17. Object and Liquid Entry - Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

18. Servicing - Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19. Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions a. When the power-supply cord or plug is damaged. b. If liquid has been spilled on, or objects have fallen into the product. c. If the product has been exposed to rain or water. d. If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation. e. If the product has been dropped or the cabinet has been damaged. f. When the product exhibits a distinct change in performance

- this indicates a need for service.

20. Replacement Parts - When replacement parts are required, be sure the service technician has used replacement parts specified by the manufactu-rer or which have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.

21. Safety Check - Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

22. Carts and Stands - The appliance should be used only with a cart or stand that is recommended by the manufacturer.

23. Heat - The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products that produce heat.

4 GENERAL INFORMATION

WARNING:

This device complies with Part 15 of the FCC (U.S.A.) Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation! This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the supplier or an experienced radio/TV technician for help.

NOTE TO CATV SYSTEM INSTALLER:

This reminder is provided to call the CATV (CableTV) system installer’s attention to Article 820-40 of the NEC (National Electrical Code) that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

IMPORTANT:

This product was FCC verified under test conditions that included use of shielded cables and connectors between system components. It is important that you use shielded cables to reduce the possibility of causing interference to radios, television sets, and other electronic devices. If you have any problems, contact your supplier.

Any change or modifications to the equipment by the user not expressly approved by the grantee or manufacturer could void the user's authority to operate such equipment.

THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS B LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL APPARATUS AS SET OUT IN THE RADIO INTERFERENCE REGULATIONS OF THE CANADIAN DEPARTMENT OF COMMUNICATIONS.

CET APPAREIL NUMÉRIQUE N'ÉMET PAS DE BRUITS RADIOÉLECTRIQUES DÉPASSANT LES LIMITES APPLICABLES DANS LA RÈGLEMENT SUR LE BROUILLAGE RADIOÉLECTRIQUES ÉDICTÉ PAR LE MINISTÈRE DES COMMUNICATIONS DU CANADA.

GENERAL INFORMATION 5

English ___________________________________________________8

Français ________________________________________________40

Español _________________________________________________74

English

Français

Español

INDEX 7

English

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only, unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Manufactured under license from Dolby Laboratories. “Dolby,” “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories. Confidential Unpublished Works. ©1992-1997 Dolby Laboratories, Inc. All rights reserved.

TRUSURROUND,

SSRRSS

, and symbol are trademarks of SRS Labs, Inc. TRUSURROUND technology is manufactured under license from SRS Labs, Inc.

Introduction

Reality reproduced: Super Audio CD __________________________10 The next standard: hybrid disc________________________________10 SACD 1000: reality in sound... and vision _______________________10 Digital video ______________________________________________11 Unpacking ________________________________________________12 Placement ________________________________________________12

Functional summary

Front of player ____________________________________________13 Rear of player _____________________________________________14 Display___________________________________________________15 Remote control ___________________________________________16

On-screen display information

Preparation

General notes _____________________________________________18 Connecting to audio equipment - analogue______________________18 Connecting to audio equipment - digital ________________________19 Connecting to a TV ________________________________________20 6 Channel settings - DVD only _______________________________20 Delay times - DVD only _____________________________________21 Connecting the power supply ________________________________21 Infrared remote control _____________________________________22 Remote control device code _________________________________22

English

Operation

General explanation ________________________________________23 Switching on ______________________________________________23 Personal preferences _______________________________________24 Loading an SACD or Audio disc ______________________________27 Playing an SACD or Audio disc _______________________________27 FTS (Favorite Track Selection) - Audio CD only _________________28 Access control; disc lock (DVD and VCD) ______________________29 Access control; parental control (DVD-video only) _______________30 Loading DVD or VCD discs __________________________________31 Playing a DVD-video disc ____________________________________31 Playing a Video CD_________________________________________31 General features ___________________________________________32 Special DVD features _______________________________________35 Special VCD features _______________________________________35 Enhanced use _____________________________________________36

Before requesting service

Trouble-shooting checklist ___________________________________37 Cleaning discs _____________________________________________38 Diagnostic program ________________________________________38

CONTENTS 9

English

Introduction

Reality reproduced:

SACD 1000: reality in sound...

Super Audio CD

The future in digital sound reproduction is no longer limited to a closely simulating of reality. The new audio standard IS reality! The human ear is no longer capable of distinguishing audible reality from digital reproduction. At Philips the future starts today with the SACD 1000 Super Audio Compact Disc player. This Super Audio CD player combines superior sound quality with the possibility of playing almost all existing audio and video formats with a single player. Your precious CD collection retains its value!

The Super Audio standard is based on Direct Stream Digital (DSD) technology. This new direct-stream digital format comprises a 1-bit system that has a digital sampling frequency that is 64 times higher than that of conventional audio CD. The results are spectacular: a frequency response of over 50k Hz and a 120 dB dynamic range over the entire audible spectrum. Mixed with as many of the original frequencies as possible, the audio information audible for human ears sounds much more natural. All audible frequencies are, after all, embedded in the frequency range as emitted by the sound source. A better reproduction does not exist! For the first time your ears will relive reality.

The next standard: hybrid disc

The Super Audio CD is the evolution of the CD that provides ultra-high-quality sound. Additional features, including multi-channel, can be offered. On the high density (HD) Super Audio CD you may have access to separate areas, containing two-channel stereo and multichannel.

But that is not all! The hybrid version of the SACD guarantees backward compatibility with the installed base of CD and DVD players. In addition to the HD layer, the hybrid disc contains a standard density CD layer with conventional two-channel stereo CD audio information. The two layers are read from the same side of the disc. The HD layer is read by an DVD laser. The bottom reflective layer with conventional CD sound is read by the CD laser through the second, semi-transmissive HD layer.

and vision

The SACD 1000 will not only surprise you with its superior reproduction of almost all existing audio formats. Connected to your TV, your SACD 1000 presents VCD and DVD video information as perfect digital studio-quality images with truly 3-dimensional digital multi-channel audio. Story sequences can be screened from your own choice of camera angle. You can break down language barriers with sound tracks in as many as eight languages, plus - if available on disc - as many as 16 subtitling languages. Video becomes a new experience. That makes the SACD 1000 an essential component in a state-of-the-art audio-video system.

Super Audio CD

You will recognize Super Audio CDs by the logo. There are three types of Super Audio CDs: single-layer, dual-

layer and hybrid discs. Each type may contain two areas of recorded information: a High Quality Stereo area and a High Quality Multi-channel area.

- The single layer disc may contain both information areas.

- The dual layer disc may contain both information areas but a double amount of information can be stored on the disc thanks to the second layer.

- The hybrid disc may contain not only both information areas but also a second, standard CD layer, making it playable on standard CD players. Recorded information may vary per area. This is indicated in the disc inlay. Areas can be selected separately before or during playback. When playing Super Audio CDs, the player can be operated via the keys on the player front and the remote control or via the On-Screen Display on your TV.

1 CD layer that plays on any

of your existing CD players

High-Density layer containing:

2 - High-Quality DSD Stereo 3 - High-Quality DSD Multi-channel

SACD Disc Types

Single-layer Disc

HD layer HD layer HD layer

10 INTRODUCTION

Dual-layer Disc Hybrid-layer Disc

CD layer

Audio CD (CDDA)

Video CD

Audio CDs contain music tracks only. You will recognize these CDs by their logo. You can play them in conventional

style through a stereo system, using the keys on the remote control and/or front panel, or via the TV using the On-screen Display (OSD).

Note: Please note that the DTS audio format on the SACD 1000 is only supported on DVD. This product does not support the playback of DTS encoded CDs.

Digital video

DVD-Video uses state-of-the-art MPEG 2 data compression technology to register an entire movie on a single 5-inch disc. DVD’s variable bitrate compression, running at up to 9.8 Mbits/second, captures even the most complex images in their original quality. The crystal-clear digital images have a horizontal resolution of over 500 lines, with 720 pixels (picture elements) to each line. This resolution is more than double that of VHS, superior to Laser Disc, and entirely comparable with digital masters made in recording studios. DVD-Video discs conform to either the PAL or NTSC video standard. This dual-standard player can play both types, and presents them in the best possible way on your multi-standard TV screen. As the universal video system of the future, DVD-Video offers optimal images on any TV screen.

You will recognize Video CDs by the logo. Depending on the material on the disc

(a movie, video clips, a drama series, etc.), these discs may have one or more tracks, and tracks may have one or more indexes, as indicated on the disc case. To make access easy and convenient, your player lets you move between tracks and between indexes.

English

DVD-Video

You will recognize DVD-Video discs by the logo. Depending on the material on the disc

(a movie, video clips, a drama series, etc.), these discs may have one or more Titles, and each Title may have one or more Chapters. To make access easy and convenient, your player lets you move between Titles and between Chapters.

INTRODUCTION 11

English

Unpacking

First check and identify the contents of your SACDplayer package, as listed below:

- SACD player

- Remote Control with batteries

- 2-core power cord

- Audio cable (4x)

- Digital coaxial cable

- Video cable

- YCBCRcable

- Instructions for use If any item is damaged or missing, please inform your supplier immediately. Save the packaging materials; you may need them to transport your player in the future.

Placement

● Place the player on a firm, flat surface.

● Keep away from domestic heating equipment and

direct sunlight.

● In a cabinet, allow about 2 inches of free space all

around the player for adequate ventilation.

● If the SACD player cannot read SACDs/CDs/DVDs

correctly, use a commonly-available cleaning CD/DVD to clean the lens before taking the SACDplayer to be repaired. Other cleaning methods may destroy the lens. Always keep the tray closed to avoid dust on the lens.

● When it is moved from a cold to a warm

environment, allow the SACD player to acclimatize for at least 2 hours in order to avoid damage. When suddenly placed in a warm environment, the lens may cloud over. Playing an SACD/CD/DVD will not be possible then. Wait until the moisture evaporates.

12 INTRODUCTION

Functional overview

Front of player

ON/OFF

SACD 1000

POWER ON/OFF

- switches the player on/off

Stand-by indicator

- lights up red when the player is in Stand-by mode

SOUND MODE selects required sound mode:

- for SACD: CD, Stereo or Multi-channel (if available)

- for DVD/VCD: Stereo, Dolby Surround, 3D Sound or Multi-channel

Display

- displays the current status of the player

; PAUSE

- interrupts audio/video play or moves to the next frame

2 PLAY

- starts audio/video play

9 STOP

- stops audio/video play

SOUND MODE STOP PLAY PAUSE

SVCD

SACD

STEREO MCH

TITLE

VIDEO

DTS MCH

SCANCHAPTERTRACK

DSUR ALLA-B REPEAT

SHUFFLE

TOTAL REM TRACK TIME CHAPTER TRACKTITLE

F S

REPEAT PREV NEXT

English

OPEN/CLOSE

TruSurround

with

DIGITAL OUT

SRS

SUPER AUDIO CD

Disc loading tray

/ OPEN/CLOSE

- opens/closes the disc tray

REPEAT

S PREV

- selects previous track/title/chapter/index or

returns to beginning of current track/tile/chapter/index

T NEXT

- selects next track/title/chapter/index

FUNCTIONAL OVERVIEW 13

English

Rear of player

VOLTAGE SELECT(or)

- For selecting 100/120V or 220/240V. If necessary, adjust the selector to match your local power supply.

POWER SUPPLY

- Power supply socket for connection to the power supply.

Filter switch

- See chapter ‘Operation - Enhanced use’.

GND

- Ground connector. For making grounding connection between the various components of your system in case of disturbance problems. Also see ‘System grounding’ of chapter ‘Operation - Enhanced use’.

MULTI-CHANNEL AUDIO OUT (For connection to a multi-channel receiver)

- SUBW(oofer) - subwoofer connection

- CENTER - center speaker connection

- RIGHT/LEFT SURR(ound) - surround speaker connections

- RIGHT/LEFT - front speaker connections

VOLTAGE SELECTOR

100-120V220-240V

MAINS

FILTER

123

RIGHT

GND

DIGITAL AUDIO OUT

Dolby Digital/

DTS/MPEG only

DIG OUTOPT OUT

DIGITAL AUDIO OUT

- OPT(ical) OUT - digital audio output connector for connection to digital (optical) equipment

- DIG(ital) OUT - digital audio output connector for connection to digital (coaxial) equipment

STEREO OUT

- Audio outputs for connection to an amplifier, receiver or stereo system

VIDEO OUT (CVBS)

- for connection to a TV with CVBS video inputs

STEREO OUT

AUDIO

LEFT

MULTICHANNEL AUDIO OUT

RIGHT SURR. LEFT SURR.

(CVBS)

VIDEO OUT

3104 127 1194.1

SUBW

( Y/C )

S-VIDEO

CENTER

- for connection to a TV with YUV inputs

- for connection to a TV with S-Video (Y/C) inputs

14 FUNCTIONAL OVERVIEW

YUV(YCBCR)

S-VIDEO OUT (Y/C)

Caution: Do not touch the inner pins of the rear panel connectors. Electrostatic discharge may cause permanent damage to the unit.

Display

SACD

Super Audio CD inserted

SACD

Audio CD inserted

SVCD

Video CD inserted

STEREO

indicate the current active sound mode

MCH

VIDEO

DVD video disc inserted

TITLE

- number of titles on DVD in Stop mode

- number of current title

English

ACK

TITLE

TRACK

INDECHAPTER

- number of tracks on SACD/CD/VCD in Stop mode

- number of current track

SCAN

SHUFFLE

SCAN

SHUFFLE

REM TIME remaining track time in hours, minutes and

SVCD

SACD

STEREO MCH

VGA

PIC

ALBUM TITLE

HDCDVIDEO AUDIO

GROUP

DTS MCH

DSUR SPOTLIGHT ALLA-B REPEAT

SCANINDEXCHAPTERTRACK

TOTAL REM TRACK TIME

SHUFFLE

CHAPTER TRACKTITLE

Number of current chapter

TOTAL REM TRACK TIME

track time in hours, minutes and seconds

disc/program time in hours, minutes and seconds

seconds when Display mode is set to

F S

DIGITAL

NATURAL

MOTION

Remaining time

playback temporarily interrupted (not active when setting Personal Preferences)

SCAN

first 10 seconds of each track/chapter are played

A-B REPEAT

SHUFFLE

F S

A passage (

A-B) is being repeated

tracks/chapters are played in random order

CHAPTER TRACKTITLE

ALLREPEAT

repeat Title/Chapter/Track/All active

FTS (Favorite Track Selection) program available for CD/DVD/ VCD inserted

remote control active (flashing)

DTS

DTS (Digital Theater Sound) audio on the digital output

MCH

Sound mode button (for DVD) is set to Multi-channel

SUR

Sound mode button (for DVD/VCD) is set to Dolby Surround

D S

Sound mode button (for DVD/VCD) is set to 3D Sound

FUNCTIONAL OVERVIEW 15

English

Remote control

TV POWER

- switches the TV to power/standby

9 STOP

- stops playback

SOUND MODE

- selects required sound mode

• for SACD: CD, Stereo or Multi-channel (if available)

• for DVD/VCD: Stereo, Dolby Surround, 3D sound or Multichannel

2 PLAY

- starts audio/video play

5 REVERSE

- search backward

; PAUSE

- pause or still frame/step frame

H SLOW

- slow motion

6 FORWARD

- search forward

J PREVIOUS

- previous track/title/chapter/index

e RESUME

- resumes playback

K NEXT

- next track/title/chapter/index

POWER

SOUND MODE

REVERSE PAUSE SLOW FORWARD

PREVIOUS RESUME NEXT

ZOOM

VOL CH

ANGLE

MUTE

DISPLAY

SACD

POWER

PLAYSTOP

SACD POWER

- switches the player to power/stand-by

MENU DISC

- selects DVD-defined menu

MENU SYSTEM

- On-screen Display ON/OFF

v w t u

- up/down/left/right cursor movement in OSD mode

RETURN

- return to previous menu step

ZOOM

- enlarges video image

}}

ANGLE

- selects DVD camera angle

DISPLAY

- selects elapsed Time display or Remaining Time display

- acknowledge menu selection

VOL +/–

- volume up/down in TV mode

c MUTE

- mutes the sound in TV mode

CH +/–

- program up/down in TV mode

FTS

- switches FTS function ON/OFF

- displays FTS menu (FTS = Favorite Track Selection)

SHUFFLE

- playback in random order

SUBTITLE

- subtitle ON/OFF/selects subtitles (DVD/VCD only)

AUDIO

- language selection

TITLE

CHAPTER

FTS SHUFFLE SUBTITLE AUDIO

DIM REPEAT REPEAT SCAN

0-9

- numeric key pad

- selects titles

- selects chapters

PLAYER DISPLAY DIM

- adjusts display brightness

REPEAT

- repeats a track or complete disc (CD, VCD, SACD)

- repeats a chapter, title or complete disc (DVD)

REPEAT A-B

- repeats a particular passage (

A-B)

SCAN

- playback of the first 10 seconds of each track, chapter, title

16 FUNCTIONAL OVERVIEW

On screen display information

Menu bar/Status window

V User preference d Sound W Track/Title e Picture-by-picture X Chapter f Slow motion Z Subtitle language g Fast motion } Angle h Time search a Zoom Y Audio language b Color d Sound Mode c Video FTS

Status window icons

The status window displays the current status of the player and is displayed together with the first part of the menu bar if activated in the Features menu (see Personal Preferences).

Temporary Feedback Field icons

English

Scan

Repeat All

Repeat Title

Repeat Track

Repeat Chapter

Shuffle

Shuffle Repeat

Repeat A to end

Repeat A-B

Current camera angle/number of available camera angles

Child Lock On

General

Disc type

Tray status

Default screen

The default screen is displayed when the player is in STOP mode. It may contain a status window (see ‘Status Window’) and a ‘Temporary Feedback Field,’ which gives information concerning prohibited actions, playback modes, available angles, etc.

Child Safe

Resume

Action prohibited

off no off

ON SCREEN DISPLAY INFORMATION 17

English

Preparation

General notes

- Depending on your amplifier/receiver/Stereo System, there are various ways to connect the player. These are explained in the section below.

- For some connections, settings for digital and/or analogue output are required. These settings have to be made in the ‘Personal Preferences’ menu which is only accessible via your TV screen. In these cases you will need to connect the player to the TV as well.

- Please refer to your amplifier/receiver/Stereo System, TV and any other User Manual(s) as necessary to make the optimal connections.

Caution: Do not connect the player’s audio output to the phono input of your audio system.

Connecting to audio equipment analogue

Connecting to a Multi-channel Audio/(Video) receiver with 6 connectors

This SACD player contains a multi-channel decoder. This enables playback of SACDs recorded in Multi-channel. You only need to select Multi-channel using the Sound Mode key.

1 Connect the audio Left and Right outputs for Front

speaker connection (1) to the corresponding input sockets on your receiver using the audio cable supplied.

2 Connect the audio Left and Right outputs for

Surround speaker connection (2) to the corresponding inputs on your receiver using an optional audio cable.

3 Connect the audio outputs for Center speaker and

Subwoofer connection (3) to the corresponding inputs on your receiver using an optional audio cable.

Connecting to an amplifier/receiver equipped with two channel analogue stereo

● Connect the audio Left and Right outputs for Front

speaker connection (1) to the corresponding sockets on your amplifier, receiver or stereo system using the audio cable supplied.

AMPLIFIER

STEREO OUT

MULTICHANNEL AUDIO OUT

LEFT

RIGHT SURR. LEFT SURR.

(CVBS)

VIDEO OUT

AUDIO

SUBW

CENTER

( Y/C )

S-VIDEO

VOLTAGE SELECTOR

MAINS

100-120V220-240V

FILTER

123

DIGITAL AUDIO OUT

Dolby Digital/

DTS/MPEG only

RIGHT

GND

DIG OUTOPT OUT

Note: If the subwoofer is equipped with its own amplifier, the Subwoofer connection should be connected directly to the subwoofer.

AMPLIFIER

VOLTAGE SELECTOR

MAINS

100-120V220-240V

FILTER

123

DIGITAL AUDIO OUT

Dolby Digital/ DTS/MPEG only

GND

DIG OUTOPT OUT

LEFT

STEREO OUT

AUDIO

RIGHT SURR. LEFT SURR.

(CVBS)

VIDEO OUT

RIGHT

MULTICHANNEL AUDIO OUT

SUBW

CENTER

( Y/C )

S-VIDEO

18 PREPARATION

Connecting to an amplifier/receiver equipped with Dolby Pro Logic

For an amplifier/receiver with Dolby Surround, you can connect your SACD player in the same way as described for Dolby Pro Logic.

Dolby Pro Logic sound

1 Connect the audio Left and Right outputs for Front

speaker connection (1) to the corresponding inputs on the Dolby Pro Logic Audio/Video amplifier/receiver using the audio cable supplied.

2 Set Analogue Output to Dolby Surround in the

‘Personal Preferences’ menu.

If your amplifier/receiver is equipped with a Dolby Digital decoder

● Connect the player as described in the section

‘Connecting to an Audio/(Video) receiver with multichannel decoder’.

If you connect the player to a TV equipped with a Dolby Pro Logic decoder

● Connect the player to the TV as described in the

section ‘Connecting to a TV’.

Connecting to an Audio/(Video) receiver with multi-channel decoder (Dolby Digital, MPEG 2 and DTS)

Digital Multi-channel sound (not for SACD)

For this you need a multi-channel A/V receiver that supports one or more of the DVD audio formats supported by your SACD player (MPEG 2, Dolby Digital and DTS). Check the receiver manual and the logos on the front of the receiver.

1 Connect the player’s digital audio output (optical 4

or coaxial 5) to the corresponding input on the receiver using the digital audio cable (coaxial) is supplied. Optical is optional.

AMPLIFIER

4 5

English

Connecting to audio equipment digital

The digital output of the SACD1000 does not provide PCM (Pulse Code Modulation) signals. If your amplifer/receiver can only decode PCM and not multichannel signals such as Dolby Digital, do not connect your SACD player using the digital input. This could damage your amplifier and/or speakers.

STEREO OUT

MULTICHANNEL AUDIO OUT

LEFT

RIGHT SURR. LEFT SURR.

(CVBS)

VIDEO OUT

AUDIO

SUBW

CENTER

( Y/C )

S-VIDEO

VOLTAGE SELECTOR

MAINS

100-120V220-240V

FILTER

123

DIGITAL AUDIO OUT

Dolby Digital/ DTS/MPEG only

RIGHT

GND

DIG OUTOPT OUT

Notes:

- If the audio format of the digital output does not match the capabilities of your receiver, the receiver will produce a strong, distorted sound. The audio format of the DVD disc in play is displayed in the Status Window when changing the audio format.

- 6 Channel Digital Surround Sound via digital connection can only be obtained if your receiver is equipped with a Digital Multi-channel decoder. If your receiver does not contain a decoder, you can make the analogue connections as described in the section‘Connecting to a Multi-channel Audio/(Video) receiver with 6 connectors’ to obtain 6 Channel Digital Surround Sound.

- SACD Multi-channel sound cannot be obtained via digital connection.

PREPARATION 19

English

Connecting to a TV

6 Channel settings - DVD only

Notes

- Depending on your TV, there are various ways to connect the player. These are shown in the illustration below.

- Please refer to your TV, VCR, and any other User Manual(s) as necessary to make the optimal connections.

- Do not connect your SACD-player via your VCR because the video quality could be distorted by the copy protection system.

S-Video (Y/C) connection

1 Connect the S-VIDEO OUT (Y/C) socket (7) to the

corresponding socket on the TV using an optional S-Video cable.

● If you wish to receive the sound via your TV,

connect the STEREO OUT Left and Right output sockets (1) to the corresponding sockets on the TV using the audio cable supplied.

Video CVBS connection

1 Connect the VIDEO OUT (CVBS) socket (8) to the

corresponding socket on the TV using the video cable supplied.

2 If you wish to receive the sound via your TV,

connect the STEREO OUT Left and Right output sockets (1) to the corresponding sockets on the TV using the audio cable supplied.

Front speaker

L (Large) : When the front speakers can reproduce low

frequency signals below 120Hz

S (Small) : When the front speakers cannot reproduce

low frequency signals below 120Hz

Center Speaker

L (Large) : When the center speaker can reproduce low

frequency signals below 120Hz

S (Small) : When the center speaker cannot reproduce

low frequency signals below 120Hz

Off : When the center speaker is not connected

Surround speakers

L (Large) : When the surround speakers can reproduce

low frequency signals below 120Hz

S (Small) : When the surround speakers cannot

reproduce low frequency signals below 120Hz

Off : When the surround speakers are not

connected

Subwoofer

On : When you connect a subwoofer Off : When a subwoofer is not connected

Center

speaker

VOLTAGE SELECTOR

Front speaker

left

781

MAINS

100-120V220-240V

FILTER

123

DIGITAL AUDIO OUT

Dolby Digital/ DTS/MPEG only

GND

DIG OUTOPT OUT

MULTICHANNEL AUDIO OUT

LEFT

RIGHT SURR. LEFT SURR.

RIGHT

STEREO OUT

(CVBS)

VIDEO OUT

AUDIO

SUBW

CENTER

( Y/C )

S-VIDEO

Rear speaker

(left surround)

Front speaker

Rear speaker

(right surround)

right

20 PREPARATION

Delay times - DVD only

Connecting the power supply

Your SACD player is set to correctly reproduce synchronized Digital Surround Sound in a listening area where the surround speakers are about 150cm nearer to the listening position than the front speakers and the center speaker is in line with the front speakers. To adjust for other listening-area arrangements, adapt delay times according to the following:

Digital Surround

Measure the distances in centimeters from the front speaker plane and from the surround speaker plane to the listening positioning plane. Substract the surround distance from the front distance and divide by 30. The result is the required Surround Channel delay time in milliseconds. If the center speaker is on the front speaker plane, no center speaker delay is needed. You can adjust the delay time in the “User Preference Settings”. See Personal preferences - Sound - Speaker Settings. If, however, it is nearer to the listening position, measure the distance in centimeters between the front and center speaker planes and divide by 30. The result is the required Center Channel delay time in milliseconds.

1 Check if the power voltage as shown on the type

plate (on the back of the player) corresponds to your local power voltage. If not, adjust the voltage selector (1) to match with your local power supply.

2 Plug the female end of the power cable supplied into

the Power connector POWER SUPPLY (2) on the rear of the player.

3 Plug the male end of the cord into an AC outlet.

Note: When the player is in the STANDBY or OFF position, it will still consume some power. If you wish to disconnect your player completely from the power supply, pull the plug from the AC Outlet.

Caution: Only qualified service personnel should remove the cover or attempt to service this device.

L E

English

Digital Surround Delay

10,5

7,5

0 ms

4,5

1,5

Distance from surround speakers (m)

0 ms

1,5 3 4,5 6 7,5 9 10,5 12

Distance from front speakers (m)

0 ms

5 ms

10 ms

15 ms

10ms5

0 ms

-5 ms

-10 ms

Differential arrival time

Preferred Acceptable Not recommended

Dolby Pro Logic

If the delay times for Surround Channel and Center Channel are set for Digital Surround mode, the delay times for Dolby Pro Logic mode will automatically be calculated and set.

Pro Logic Surround Delay

10,5

7,5

15 ms

0 ms

4,5

1,5

Distance from surround speakers (m)

15 ms

0 1,5 3 4,5 6 7,5 9 10,5 12

Distance from front speakers (m)

15 ms

20 ms

25 ms

30 ms

25ms20

15 ms

10 ms

5 ms

Differential arrival time

Preferred Acceptable Not recommended

PREPARATION 21

English

Infrared remote control

Selecting the remote control code

Loading the batteries

1 Open the battery compartment cover. 2 Insert two 'AA' (LR-6) batteries as indicated inside

the battery compartment.

3 Close the cover.

Caution: Do not mix old and new batteries. Also never mix different types of batteries (standard, alkaline, etc.)

Remote control device code

To operate the player via the remote control without response from a second DVD player, you can program both player and remote control to use a second set of remote control codes. The default system code is Code 1.

ZOOM

DISPLAY

ANGLE

VOL CH

MUTE

● Simultaneously press

DISPLAY and 1 or 2 on the remote control to select code 1 or 2.

➤ The remote control will now

be set to the remote control code of your choice.

➤ This action can be repeated whenever necessary.

Programming the player to respond to Code 2

1 Press ON/OFF to switch off the player. 2 Simultaneously press SOUND MODE and /

OPEN/CLOSE on the player for three seconds

and then press ON/OFF to switch the player on again.

➤ The player will now be programmed to respond

to Code 2.

➤ When steps 1 and 2 are repeated the system

code is set to Code 1 again.

22 PREPARATION

Operation

General explanation

About this manual

This manual gives basic instructions for operating this SACD player. When playing DVDs the player may not respond to all operating commands. Some DVDs are produced in a way that requires specific operation or allows only limited operation during playback. If this is the case, please refer to the instructions in the disc inlay. When a

appears on the TV screen, the operation is not

permitted by the player or the disc.

Remote control operation

- Unless otherwise stated, all operations can be performed with the remote control. Always point the remote control directly at the player, making sure there are no obstacles in the path of the infra-red beam.

- When there are corresponding keys on the front panel, these can also be used.

Switching on

English

1 If necessary, switch on the TV and select the video

input for your SACD player.

2 Press ON/OFF on the player front panel or

STANDBY on the remote control.

➤ The player display will light up. ➤ If the player is connected to the TV, the start-up

screen will appear.

Menu bar operation

- A number of operations can also be performed using the menu bar on the screen. The menu bar can be activated by pressing any of the following keys on the remote control: MENU SYSTEM, T, C, Angle, Audio Language, Subtitle Language, Zoom and FTS.

- The following functions can be operated via the menu bar:

- Personal Preferences;

- Track/title selection;

- Chapter selection;

- Audio language selection;

- Subtitle language selection;

- Angle selection;

- Zoom;

- Video FTS selection;

- Sound mode;

- Picture-by-picture;

- Slow motion;

- Fast motion;

- Time search.

- The various items can be selected using the tu (left/right cursor) keys or by pressing the relevant keys on the remote control.

- By pressing MENU SYSTEM the menu bar will disappear from the screen.

- When selecting an item in the menu bar, the selected item will be highlighted and the cursor keys (on the remote control) for operating the function are displayed below the icon.

- < or > indicates that more items are available at the left/right hand side of the menu bar. Press tu(left/right cursor) to select these items.

OPERATION 23

English

V Personal preferences

In this mode you can set your personal preferences for a number of player features. Some settings must always be selected.This depends on the type of audio equipment connected. For this see the section ‘Connecting to audio equipment.’

General operation

● Press MENU SYSTEM on

the remote control.

● Select V in the menu bar

and press w (down cursor).

➤ The Personal Preferences

menu will appear.

● Use the t u v w (left/right/up/down) keys to

toggle through the menus, sub-menus and sub-menu options.

➤ When a menu item is selected, the cursor keys

(on the remote control) for operating the item will be displayed next to the item.

● Press OK to confirm and return to the main menu.

Video shift

Factory setting is such that the video will be centered on your screen. Use this setting to personalize the position of the picture on your TV by scrolling it to the left or right.

TV shape

Black Level shift

Video shift

OK to exit

q Sound

The following items can be adapted:

p Picture

TV Shape

If you have a wide screen (16:9) TV, select 16:9. If you have a regular (4:3) TV, select 4:3. In this case you can also choose between: Letterbox for a ‘wide-screen’ picture with black bars top and bottom, or Pan Scan, for a full-height picture with the sides trimmed, provided these opations are available on the disc in play. If a disc has Pan Scan, the picture will then move (scan) horizontally to keep the main action on the screen.

VIEWING ON 16:9

LETTERBOX

VIEWING ON 4:3

PAN SCAN

Black level shift (NTSC only)

Adapts the color dynamics to obtain richer contrasts. Select ONor

OFF

Analogue output

Select Stereo, Dolby Surround, 3D Sound or Multichannel. See the section ‘Digital and Analogue output Settings for DVD/VCD’. Factory setting is Multi-channel. Multi-channel : Select this setting when using a Multi-

channel audio/(video) reciever with six inputs. In this mode, the player will perform Dolby Digital 5.1-channel decoding when applicable, and Dolby Pro Logic decoding on DVD-Video and Video-CD discs with 2-channel soundtracks. No Dolby Pro Logic decoding is done with (Super) Audio CD discs.

Dolby Surround : Select this setting when using a

equipment with a Dolby Surround Pro Logic decoder. In this setting, the

5.1 audio channels (Dolby Digital, MPEG-2) are downmixed to a Dolby Surround-compatible 2-channel output.

3D-Sound : In a setup without rear speakers

(analogue stereo output), 3D Sound remixes the six channels of digital surround into a two-speaker output while retaining all of the original audio information. The result is the listening sensation of being surrounded by multiple speakers.

Night Mode

Optimizes the dynamics of the sound with low-volume playback. This setting can only be used with discs that support the Night Mode feature.

24 OPERATION

Speaker settings

Allows you to select speaker settings, volume balance and delay time, and to test the speaker settings. Speaker settings are only active on the Multi-channel Audio Out Outputs. Speaker settings will not be used during playback in the SACD Stereo or Multi-channel Sound modes.

Karaoke vocal

Switch this setting to ON only when a multi-channel karaoke DVD is being played. The karaoke channels on the disc will then be mixed to a normal stereo sound.

r Language

Select the required Menu, Audio and Subtitle language. Menu language - The On-screen Menus will be displayed in the language you select. You can choose from 8 different languages. Audio language - The sound as well as the DVD menu will be in the language you select, provided it is available on the disc in play. If not, speech will revert to the first spoken language on the disc. You can choose from 16 different languages. Subtitle language - The subtitles will be in the language you select, provided it is available on the disc in play. If not, subtitles will revert to the first subtitle language on the disc. You can choose from 16 different languages.

s Features

Sound Mode (SACD only)

Selection of default SACD Sound Mode: Stereo or Multichannel. Sound Mode setting can be changed during playback with the Sound Mode leu on either the player or the remote control. When selecting Multi-channel, make sure your sound mode is set up for Multi-channel reproduction.

Access Control (DVD/VCD only)

Access Control contains the following features: Disc Lock - When Disc Lock is set to ON, a 4-digit PIN code must be entered in order to play discs. Parental control - Allows the conditional presentation of DVD discs containing Parental Control information.

Status Window

Displays the current status of the player and is displayed together with the menu bar. In STOP mode, it is displayed together with the ‘Temporary Feedback’ Field in the default screen. See ‘the section On-screen Display information'. Factory setting is ON. Select OFF to suppress display of the Status Window.

English

Audio language and Subtitle language can also be adapted via the Menu bar on the screen.

Low Power Stand-by

If this setting is set to ON, the player will go in lowpower stand-by when the Stand-by key (remote control) is pressed. While in low-power stand-by, scart AUX-I/O will no longer be available. All external equipment connected to it will be ignored.

PBC

This feature allows you to disable or enable the PBC (Playback Control) menu of VCD discs. See under ‘Special VCD features’: Factory settings is ON.

OPERATION 25

English

Display information

Display

Elapsed time - during playback the elapsed playing time will be displayed. Remaining time – during playback the remaining playing time will be displayed. Display setting can be changed during playback using the

DISPLAY key on the remote control.

off1no off

Access control

Status window

Low power standby

Sound mode

Display

PBC

Total time

Remaining time

Player Display Dim (via remote control)

This feature allows you to set the display brightness. By repeatedly pressing the DIM key on the remote control you can select.

26 OPERATION

Operation - Audio (Super Audio CD and CD)

Loading an SACD or Audio disc

STOP PLAY PAUSE

REPEAT PREV NEXT

OPEN/CLOSE

1 Press / OPEN/CLOSE on the front of the player.

The disc loading tray opens.

2 Lay the disc in the tray, label side up. Make sure it is

properly inserted in the correct recess.

3 Gently push the tray, or press / OPEN/CLOSE,

to close the tray.

➤ READING will appear on the player display and in

the status window (if TV is on). If a Super Audio CD is inserted, the Sound Modes available on the disc will be shown on the player display. The current Sound Mode is indicated on both player display (with a bullet) and screen (if TV is on).

Playing an SACD or Audio disc

➤ If a default Sound mode (Stereo/Multi-channel) is

selected in the Personal Preferences menu and this Sound mode is not availabale on the inserted disc, playback will start in the first available Sound mode on the disc.

➤ Playback will stop at the end of the disc.

● To stop play at any other time, press 9 STOP. ➤ The number of tracks and the total playing time

will be shown on the player display (and on the screen).

Sound mode - SACD playback

● Press SOUND MODE on the player or the

remote control to select the desired Sound mode:

Stereo - Super Audio Stereo reproduction. Multi-channel - Super Audio Multi-channel

reproduction. CD - normal CD stereo reproduction (press 9 STOP first, then press SOUND MODE).

The sound modes available on the disc will be indicated on the display. When selecting Multi-channel, make sure your speaker configuration is set up for Multi-channel reproduction.

English

● Press 2 PLAY to start playback. ➤ During playback of Super Audio CDs and audio

discs, all functions can be operated via the keys on the remote control and the player front.

➤ If the TV is on, the Super Audio CD or the

Audio CD screen will appear.

➤ During play, the current track number and its

elapsed playing time will be shown on the player display (and on the screen). If a default Display Time setting (Total Time/Remaining Time) is made in the Personal Preferences menu, the relevant time will be indicated during playback. With the DISPLAY key on the remote control other time indications can be selected.

➤ When playing a Super Audio CD, the currently-

selected Sound mode will be indicated on the display with a bullet.

➤ At the beginning of each track, the number of

front channels and surround channels will be displayed (e.g. 3/2). If a subwoofer channel is present this will also be displayed (+1).

Pause

● Press ; PAUSE during play.

● To return to play, press 2 PLAY.

● To search forward or backward through the disc at

4x normal speed, press 5 REVERSE or 6 FORWARD during play.

➤ Search will begin and sound will be muted.

● To step up to 8x normal speed, press 5 REVERSE

or 6 FORWARD again.

➤ Search will change to 8x speed.

● To return to 4x normal speed, press 5 REVERSE

or 6 FORWARD again.

● If the TV is on, search speed and direction will be

indicated on the screen each time 5 REVERSE or 6 FORWARD is pressed.

● To end the search, press 2 PLAY or 9 STOP as

desired.

➤ Sound will be muted in 4x and 8x search.

Moving to another track

SACD

STEREO MCH

DSD

● Press K NEXT briefly during play to move forward

to the next track.

● Press J PREVIOUS briefly during play to return to

the beginning of the current track. Press J PREVIOUS briefly again to smove back to the previous track.

● To go directly to any track, enter the track number

using the numeric keys 0-9.

OPERATION - AUDIO 27

English

Shuffle

Storing an FTS program

● Press SHUFFLE during play.

➤ The tracks will be played in random order.

● To return to normal play, press SHUFFLE again.

Repeat track/disc

● To repeat the currently-playing track, press

REPEAT.

➤ REPEAT TRACK will appear on the display.

● To repeat the entire disc, press REPEAT a second

time.

➤ REPEAT ALL will appear on the display.

● To exit Repeat mode, press REPEAT a third time.

Repeat A-B

To repeat or loop a sequence:

● Press REPEAT A-B at your chosen starting point;

➤ A will appear on the player display.

● Press REPEAT A-B again at your chosen end

point;

➤ A-B will appear on the display, and the repeat

sequence will begin.

● To exit from the sequence, press REPEAT A-B

again.

Scan

Plays the first 10 seconds of each track on the disc.

● Press SCAN.

● To continue play at your chosen track, press SCAN

again or press 2 PLAY.

FTS (Favorite Track Selection)

- Audio CD only

- The FTS feature allows you to store your favorite

tracks for a particular disc in the player memory.

- Each FTS program can contain up to 20 tracks.

- Each time an FTS program is played it will be placed at

top of the list. When the list is full and a new program is added, the last program on the list will be removed from the list.

- The selections can be called up and played at any time.

- For storing an FTS program, On-screen Display

operation is required.

1 Load a disc and go to Stop mode.

Audio Disk Mode

CD 8 10321

stereo track

stop

fts On Off

track 1 2 3 4 5 6 7 8

program

Clear all

time

total tracks

total time

2 Use w (down cursor) to go to the list of available

tracks.

3 Use t and u (left/right cursor) to select tracks from

the list. To go directly to any track, enter the track number using the numeric keys 0-9.

4 Store each track by pressing OK.

➤ The track numbers will be added to the list of

selected tracks.

➤ The number of tracks and the playing time of the

program will be shown on the player display and the audio screen.

When your FTS program is complete, press 2 PLAY to start play; the FTS program will be automatically memorized.

● Press FTS or use the tu(left/right cursor) to set

FTS to ON or OFF.

Erasing a track from an FTS-program

1 Use w (down cursor) to go to the list of selected

tracks.

2 Use t and u (left/right cursor) to select the track

number you wish to erase. To go directly to any track, enter the track number using the numeric keys 0-9.

3 Press OK.

➤ The track number will be erased from the list of

selected tracks.

Erasing the complete program

● Use w (down cursor) to select

OK.

➤ The complete FTS program for the disc will be

erased.

Clear All

and press

28 OPERATION - AUDIO

Operation - Video (DVD and VCD)

Access control; disc lock (DVD and VCD)

Activating/deactivating the disc lock

1 In Stop mode, select

Features menu s using the w/v (down/up) keys and press u (right cursor).

2 Enter a 4-digit PIN code of your own choice. 3 Enter the code a second time to confirm. 4 Move to

Child lock

Acces control

Status window

Low power standby

Sound mode

Display

PBC

Access Control

in the

using the w/v (down/up) keys.

Child lock

Parental level

Change country

Change code

Authorizing discs

● Insert the disc. See ‘Loading a disc’. ➤ The Disc lock dialogue will appear. You will be

asked to enter your secret code for ‘Play Once’ or ‘Play Always’. If you select ‘Play Once’, the disc can be played as long as it is in the player and the player is in the ON position. If you select ‘Play Always’, the disc will become child safe (authorized) and can always be played even if the Disc lock is set to ON.

Notes: The player memory maintains a list of up to 80 authorized (‘Child safe’) disc titles. A disc will be placed on the list when ‘Play Always’ is selected in the ‘child protect’ dialogue. Each time a ‘child safe’ disc is played it will be placed at the top of the list When the list is full and a new disc is added, the last disc on the list will be removed from the list. Double sided DVD discs may have a different ID for each side. In order to make the entire disc ‘child safe’, each side must be authorized. Multi-volume VCDs may have a different ID for each volume. In order to make the complete set ‘child safe’, each volume must be authorized.

English

5 Move to Ç / É using the u (right cursor) key. 6 Select Ç using the w/v (down/up) keys. 7 Press OK to confirm or t (left cursor) to confirm

and press t (left cursor) again to exit from the menu.

➤ Now unauthorized discs will not be played unless

the 4-digit code is entered.

8 Select É to deactivate the disc lock.

Note: Reconfirmation of the 4-digit PIN code is necessary when: The code is entered for the very first time (see above); The code is changed (see ‘Changing the 4-digit code’); The code is cancelled (see ‘Changing the 4-digit code’); Both Disc lock and Parental Control are switched Off and the code is requested.

locked

Play once

Play always

Choose Play always for inserting disc in the

child safe list

Acces Control

Deauthorizing discs

● Insert the disc. See ‘Loading a disc’. ➤ Playback starts automatically.

● Press 9 STOP while { is visible. ➤ The | will appear and the disc will be now

deauthorized.

OPERATION - VIDEO 29

English

Access control; Parental control (DVD-Video only)

Movies on DVD discs may contain scenes not suitable for children. Therefore discs may contain ‘Parental Control’ information that applies to the complete disc or to certain scenes on the disc. These scenes are rated from 1 to 8 and alternative, more suitable scenes are available on the disc. Ratings are country-dependent. The ‘Parental Control’ feature allows you to prevent discs from being played by your children or to have certain discs played with alternative scenes.

Activating/Deactivating Parental Control

1 In Stop mode, select

Features menu s using the w/v (down/up) keys and press u (right cursor).

Access control

Status window

Low power standby

Sound mode

Display

PBC

Access Control

enter code

in the

Access control

Status window

Low power standby

Sound mode

Display

PBC

Child lock

Parental level

Change country

Change code

6 Press OK or t (left cursor) to confirm and press t

(left cursor) again to exit from the menu.

Country

1 In Stop mode, select

Features menu s using the w/v (down/up) keys and press u (right cursor).

2 Enter your 4-digit Pin code. 3 Move to

Change Country

4 Press the u (right) key. 5 Select a country using w/v (down/up cursor). 6 Press OK or t (left cursor) to confirm and press t

(left cursor) again to exit from the menu.

Access Control

in the

using the w (down) key.

2 Enter your 4-digit PIN code. If necessary enter the

code a second time.

3 Move to

Parental Level

using the w/v (down/up)

keys.

4 Move to the Value Adjustment bar using the u (right

cursor) key.

5 Then use the w/v (down/up) keys or the numeric

keys 0-9 on the remote control to select a rating from 1 to 8 for the inserted disc.

Rating 0 (displayed as ‘– –’):

Parental Control is not activated. The Disc will be played in full.

Ratings 1 (child safe) to 8 (adults only):

The disc contains scenes not suitable for children. If you set a rating for the player, all scenes with the same rating or lower will be played. Higher-rated scenes will not be played unless an alternative is available on the disc. The alternative must have the same rating or a lower one. If no suitable alternative is found, play will stop and the 4-digit code must be entered.

Changing the 4-digit code

1 In Stop mode, select

Features menu s using the w/v (down/up) keys and press u (right cursor).

2 Enter the old code. 3 Move to

Change Code

4 Press the u (right) key. 5 Enter the new 4-digit PIN code. 6 Enter the code a second time and reconfirm with OK. 7 Press t (left cursor) to exit from the menu.

Note: If you forgot your code, press while in the access control PIN code box and exit with OK. Access control is now switched off. You can then enter a new code (twice!) as described above.

Access Control

in the

using the w (down) key.

9 STOP

four times

30 OPERATION - VIDEO

+ 77 hidden pages

Philips SACD1000 User Manual

General information

Important safety instructions

English

Contents

Introduction

Functional overview

On screen display information

Preparation

Operation
