Philips Micro Jukebox
Quick start guide
1
2
3
4
SA9100
SA9200
Install
Connect
and charge
Transfer
Enjoy
Page 2
Need help?
Look up our Support Centre website
www.philips.com/usasupport
or
Call our Customer Care helpline in your country
Besoin d’aide ?
Visitez la page Web de notre centre
d’assistance à l’adresse
www.philips.com/usasupport
ou
Appelez le centre client de votre pays
Page 3
¿Necesita ayuda?
Consulte nuestro sitio Web de Soporte técnico,
www.philips.com/usasupport
o
Llame a nuestra Línea de atención al cliente de su país
Support?
Besuchen Sie unser Support Center auf
www.philips.com/usasupport
oder
wenden Sie sich einfach an den telefonischen Kundendienst
Ihres jeweiligen Landes
Page 4
Austria
Belgium
Czech Republic
Denmark
Finland
France
Germany
Greek
Hungary
Ireland
Italy
Luxemburg
Netherlands
Norway
Poland
Portugal
Russia
Slovakia
Spain
Sweden
Switzerland
UK
0820 901115
070 253 010
800142100
3525 8761
09 2290 1908
08 9165 0006
0180 5 007 532
0 0800 3122 1223
06 80 018544
01 601 1161
199 404 042
26 84 30 00
0900 0400 063
2270 8250
022 3491504
2 1359 1440
(495) 961-1111
8 800 200-0880
0800004551
902 888 785
08 632 0016
02 2310 2116
0906 1010 017
€0.20
€0.17
Místní tarif
Lokal tarif
Paikallinen hinta
€0.23
€0,12
1 a a
Helyi tarifa
Local tariff
€0.25
Tarification locale
€0.20
Lokal tariff
Cena połączenia
lokalnego
Preço local
по России звонок
бесплатный
Miestna tarifa
€0,15
Lokal kostnad
Ortstarif
£0.15
Das Kaufdatum. Modellnummer und Serial nummer
La date d’achat la référence et le numéro de série du produit
Datum zakoupení, číslo modelu a sériové číslo
Indkøbsdato, type-, model- og serienummer
Ostopäivä ja tarkka mallinumero ja sarjanumero
La date d’achat la référence et le numéro de série du produit
Das Kaufdatum. Modellnummer und Serial nummer
A vásárlás dátuma, modell szám és szériaszám
Date of Purchase. Model number and Serial number
La data di acquisto, numero di modello e numero di serie
La date d’achat, la référence et le numéro de série du produit
De datum van aankoop, modelnummer en serienummer
Datoen da du kjøpte produktet & modellnummer & serienummeret
Data zakupu, Numer modelu i numer seryjny
A data de compra, número do modelo e número de série
Дата покупки, Номер модели и Серийный номер
Dátum zakúpenia, číslo modelu a sériové číslo
Fecha de compra y número del modelo y número de serie
Inköpsdatum, modellnummer och serienummer
Das Kaufdatum. Modellnummer und Serial nummer
Date of Purchase, Model number and Serial number
Canada
USA
0820 901115
(Francophone)
1-888-744-5477
(English / Spanish)
1-888-744-5477
€0.20
€0.17
Date of Purchase, Model number and Serial number
Date of Purchase, Model number and Serial number
Argentina
Brazil
Chile
Mexico
11 4544 2047
0800 701 02 03
(Except Sao Paulo)
2121 0203
(Sao Paulo)
600 744 5477
01 800 504 6200
Tarifa local
Grátis
Preço local
Tarifa local
Gratis
Fecha de compra y número del modelo y número de serie
A data de compra, número do modelo e número de série
Fecha de compra y número del modelo y número de serie
Fecha de compra y número del modelo y número de serie
China
Hong Kong
Korea
4008 800 008
2619 9663
02 709 1200
Europe
North America
South America
Asia
Pays Assistance Tarification / mn Soyez prêt
Page 5
1
EN
Contents
2 Is there a manual?
2 Register your product
2 Don’t forget about upgrades
3 What’s in the box
4 Connect and charge
4 Install
5 Transfer
5 Music transfer
6 Photo transfer
8 Enjoy
8 Power on and play
9 Use the vertical touch strip
10 Other features
10 Troubleshooting
10 How do I reset my player?
10 How do I repair my device?
10 Disposal of your old product
Page 6
2
Is there a manual?
You have a detailed user manual and FAQ on the CD by-packed with your GoGear. You can also
download the same file from this website: www.philips.com/support or
www.philips.com/usasupport (for US residents).
Register your product
Since it is possible for you to upgrade your product, we recommend that you register your
product on www.philips.com/register or www.philips.com/usasupport (for US residents) so we can
inform you as soon as new free upgrades become available.
Don’t forget about upgrades
We know you will enjoy your product for a long time. For best performance, we recommend that
your regularly check in to www.philips.com/support or www.philips.com/usasupport for free
upgrades of the latest software and Device Plug-in for your product. These downloads will help
you to optimize your product's performance and to take advantage of our future support of new
audio formats.
Enjoy your new music experience.
Page 7
3
EN
What’s in the box
Computer with:
Windows XP (SP2 or above)
Pentium Class 300MHz processor or higher
CD-ROM drive
128 MB RAM
500MB Hard Disk space
USB Port
Internet connection (preferable)
Microsoft Internet Explorer 6.0 or later
What else you’ll need?
USB cable
CD-ROM containing Windows
Media Player 10, Philips Device
Manager, Philips Device Plugin, User Manual, Tutorials and
Frequently Asked Questions
Protective
pouch
Quick start guide
Computer
Headphones
Philips Micro Jukebox
Quick start guide
SA9100
SA9200
Install
1
Connect
2
and charge
3
Transfer
Enjoy
4
Page 8
4
1
Install
1 Insert the CD supplied with your product into the CD ROM drive of your PC.
2 Follow the onscreen instructions to complete the installation of Windows Media
Player 10 and Philips Device Manager.
Connect and charge
2
Your player will be charged while connected to your computer via the USB connection.
1 Connect the player to your computer using the supplied USB cable.
> You will see the charging animation in the top right corner of your player’s display.
The player is fully charged when the charging animation stops and the above icon is displayed.
Page 9
5
EN
Transfer
Music transfer
3
5
6
4
Philips GoGear
A
1 Connect the player to your computer using the supplied USB cable.
2 Start Windows Media Player 10.
3 Choose Manual in Device Setup Wizard screen. (you can also do an automatic
synchronization, refer to user manual on the CD for instructions).
4 Select Sync tab. In the pull down menu on the right pane, select Philips or Philips
GoGear as the destination. If they are not in the list , press F5 to refresh and try
again.
5 Select the Library tab to access the media library.
Click to highlight a song you want to copy. Right click on the item and select
Add to > Sync List.
OR
Drag and drop the song into the Sync List on the right pane.
6 Click the Start Sync button to start synchronization. The progress will be displayed.
7 When the transfer is finished, you can disconnect your player from the computer.
Page 10
6
Photo transfer
Philips GoGear
B
Remember to install Philips Device Plug-in for Windows Media Player (can be
found in the supplied CD ROM) in your computer before transferring photos.
1 Connect the player to your computer.
2 Start Windows Media Player 10.
3 Select Sync tab.
4 In the pull-down menu on the right pane, select Philips or Philips GoGear as the
destination.
5 Select the Library tab to access the media library.
6 Click All Pictures on the left pane to display the list of photos.
7 Click to highlight the photo you want to copy to your player.
8 Drag and drop the photo into the Sync List on the right pane.
9 Click Start Sync button at the bottom of the screen to start synchronization.
> The progress will be displayed just above the Start Sync button.
34
57 8
9
6
8
Page 11
7
EN
IMPORTANT Photos can only be transferred using Windows Media Player 10. If
they were dragged and dropped using Windows Explorer, they will not show on your
player.
Photo transfer (continued)
B
A pop-up message will be displayed, notifying you of the synchronization progress.
When the pop-up disappears, the transfer is completed and you can disconnect your
player.
For more information and tips on transferring music and pictures with Windows Media
Player 10, please refer to the user manual on the supplied CD.
Page 12
8
Enjoy
4
A
Power on and play
1 To power on, slide down and hold ON/OFF LOCK slider to ON/OFF position until the
player powers on.
2 Use the VERTICAL TOUCH STRIP to scroll through the main menu.
3 Select Music, Pictures or Settings by pressing 2.
4 Use the VERTICAL TOUCH STRIP and 1/2 buttons to navigate.
5 Once you have found a song you would like to play, press 2;.
Reset hole
On/Off/Lock slider
(key lock)
Left/Back key
Rewind/Previous key
Menu key
Headphone plug
Left Side View Right Side view
Volume Up/Down bar
Right/Select key
Forward/Next key
Play/Pause key
Vertical touch strip
Cable/dock/adaptor
connector
Page 13
9
EN
B
Press
Slide down and hold ON/OFF LOCK
slider to ON/OFF position
Use the vertical touch strip
2
1
MENU
1
2;
)K
J(
Select or play a song, press MENU and
select add to playlist on the go
Press MENU, select Start slide show
and press 2
1
To
Power on/off
Scroll through lists
Select option
Return to previous menu/option
Access list of menu options
Go back to the library to browse
Play/Pause songs
Jump to next song
Move back to previous song
Add song to Playlist on the go
Start a slide show
Stop a slide show
General
Music
Pictures
Use the vertical touch strip
Your player has touch sensitive controls that respond to the touch of your fingers. The
VERTICAL TOUCH STRIP (see picture) is used to scroll through lists. It responds to the
following finger movements.
Tap Hold Stroke Swipe
Page 14
10
Troubleshooting
How do I reset my player?
In the unlikely event that your player hangs, do not panic. Insert a small pin or other sharp object into
the reset hole located at the back of the player. Hold until the player shuts down.
How do I repair my device?
In case of a device error, connect your player to the computer and use Philips Device Manager
to restore your player.
1 Launch Philips Device Manager from Start > Programs > Philips Device Manager.
2 Select your device.
3 Select Repair tab.
4 Click Repair.
5 After the repair process is completed , click OK and disconnect your player.
6 The player is ready for use again after restart.
Disposal of your old product
Your product is designed and manufactured with high quality materials and components, which can
be recycled and reused.
When this crossed-out wheeled bin symbol is attached to a product it means the product is
covered by the European Directive 2002/96/EC
Please inform yourself about the local separate collection system for electrical and
electronic products.
Please act according to your local rules and do not dispose of your old products with your
normal household waste. The correct disposal of your old product will help prevent potential
negative consequences for the environment and human health.
C
Other features
For other features, please refer to the user manual provided in the by-packed CD ROM for
details.
Page 15
Printed in China
Specifications are subject to change without notice.
Trademarks are the property of Ko ninklijke Philips Electronics N.V.
or their respective owners
2006 © Koninklijke Philips Electronics N.V. All rights reserved.
www.philips.com
wk6244
