Page 1
Philips GoGEAR
MP3 player with
FullSound™
•Mix
•4 GB*
SA3MXX04DA
Enjoy your music on the go
Full colour display for easy navigation
The compact Philips GoGear Mix MP3 Player SA3MXX04DA with direct USB makes file
transfer simple - no cables required. Enjoy easy, intuitive navigation on the full colour
display and up to 13-hour music playback with its embedded battery.
Superb quality sound
• FullSound™ to bring your MP3 music to life
• MP3 and WMA playback
Complements your life
• Full colour display for intuitive and enjoyable navigation
• Up to 13-hour music playback
• Voice recording to take notes or record anything, anytime
Easy and intuitive experience
• Direct USB for easy file transfers—without cables
• Drag and drop your songs easily — no software needed
• Folder view to organise and view media files as you do on your PC
Page 2
MP3 player with FullSound™
Mix 4 GB*
Highlights
SA3MXX04DA/02
FullSound™
Philips' innovative FullSound technology
faithfully restores sonic details to compressed
MP3 music, dramatically enriching and
enhancing it, so you can experience CD music
without any distortion. Based on an audio
post-processing algorithm, FullSound
combines Philips' renowned expertise in music
reproduction with the power of the latest
generation Digital Signal Processor (DSP). The
result is fuller bass with more depth and
impact, boosted voice and instrument clarity,
and rich detail. Rediscover your compressed
MP3 music in true-to-life sound that will touch
your soul and move your feet.
MP3 and WMA playback
Audio compression technology allows large
digital music files to be reduced up to 10 times
in size without radically degrading their audio
quality. MP3 or WMA are two of the
compression formats that let you enjoy a
world of digital music on your GoGear player.
Download MP3 or WMA songs from
authorised music sites on the Internet or
create your own MP3 or WMA music files by
ripping your audio CDs and transferring them
onto your player.
Up to 13-hour music playback
This player's long-lasting power comes in the
form of 13 hours of continuous music playback
on just one single charge.
Voice recording
Voice recording converts your GoGear player
into a handy dictation machine. Besides playing
music or listening to the radio, you can also
record notes or reminders for work or school,
record shopping lists and phone numbers –
even song lyrics. By pressing the recording
button and speaking into the built-in
microphone, voice messages are compressed
and stored in the built-in internal memory.
Voice recording gives you a highly portable
voice recorder allowing you to record
anything, anytime and anywhere!
Direct USB
automatically recognise the device as a
removable USB mass storage device
(Windows 98 requires additional drivers),
allowing you to easily drag and drop files via
Windows Explorer (or Apple Folders)
between your computer and device. Simply
pack your device with music and data on the go
- every day.
Drag and drop your songs
You can quickly and easily copy your music
collection from your PC to your GoGear
player. Simply connect your GoGear to your
PC while in Windows® Explorer, select the
songs or the folders that you want to copy to
your player, then drag the selected files to the
GoGear's music folder. It is that simple. No
additional software installation is needed!
Folder view
Folder view is an optional directory view of the
GoGear player that lets you view all the files
on your player as if it were a computer. Once
you select Folder view, opening any supported
file (i.e. music, pictures or videos) is as easy as
selecting the file and hitting Play.
Full colour display
Full colour display for intuitive and enjoyable
navigation
Devices with direct USB can be plugged
directly into the USB port of your PC without
the need for a cable. Your computer will
Page 3
MP3 player with FullSound™
Mix 4 GB*
Specifications
SA3MXX04DA/02
Picture/Display
•Backlight
•Type: LCD
• Resolution: 128 x 64
•Lines of text: 3
Sound
• Equalizer customisable
• Equalizer settings: Funk, Hip Hop, Jazz, Rock,
echno, Classical
T
• Sound Enhancement: FullSound
• Channel separation: 40 dB
• Frequency response: 40 - 18,000 Hz
• Output power (RMS): 10 mW
• Signal to noise ratio: > 78 dB
Audio Playback
• Compression format: MP3, WMA, FLAC, APE
• ID3 Tag support: Song title, artist, album
• Digital Rights Management: No
• MP3 bit rates: 8-320 kbps and VBR
• MP3 sample rates: 16, 32, 44.1, 48, 11.025, 22.050,
, 8 kHz
24
• WMA bit rates: 10-320 kbps and VBR
• WMA sample rates: 8, 11.025, 16, 22.050, 32, 44.1,
kHz
48
Storage Media
• Built-in memory type: NAND Flash
• Mass storage class compliant
• Built-in memory (RAM): 4 GB
• Music memory capacity, MP3: Up to 900 tracks*
Connectivity
• Headphones: 3.5 mm
•USB: High-speed USB 2.0
Convenience
• Function: Keypad lock
•Superscroll
• Firmware upgradeable
• Battery charging indication: On user interface
• Charge and play: when connected to a PC
• Customisable volume limit
•Volume control
Accessories
• Headphones
•Quick start guide
• USB cable: built-in direct USB
Green Specifications
• Lead-free soldered product
System Requirements
• USB: Free USB port
• Internet connection: Yes (for access to updated
upport documents, manuals, future firmware and
s
PC software upgrades)
• PC OS: Windows XP (SP3)/Vista/7
Power
•Battery Type: LI-Polymer
• Rechargeable: Yes, via USB
• Battery capacity: 150 mAh
• Play time on internal battery: Up to 13 hours of
audio
Dimensions
• Packaging type: D-box
• D-box dimensions (WxDxH): 50 x 30 x 178 mm
• Product dimensions (WxDxH): 28.7 x 10.5 x 82
mm
• Product weight: 0.022 kg
Audio Capturing
• Built-in microphone: mono
• Voice recording
• Audio file format: WAV
Software
• Device manager: to restore and upgrade
•
Issue date 2013-09-03
Version: 1.0.3
12 NC: 8670 000 89571
EAN: 87 12581 64283 9
© 2013 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
* Storage capacity based on 4 minutes per song and 64 kbps WMA or
128 kbps MP3 encoding.
* Actual transfer speed may vary based on your operating system and
software configuration.
* 1 GB = 1 billion bytes; available storage capacity will be less.
* Rechargeable batteries have a limited number of charge cycles and
may eventually need to be replaced. Battery life and number of
charge cycles vary by use and settings.
