Page 1
Philips
Flash audio player
512MB*
SA2300
Your digital music on the move
with MP3, WMA music playback
Enjoy your MP3 and WMA music on the move with the Philips SA2300. With direct USB
for fast and easy music and data transfer.
Ready to wear, Ready to go
• Plug and play data
• Direct USB – no cables needed
• Drag and drop your songs easily - no software needed
• Enjoy up to 10 hours music playback*
Easy, intuitive music experience
• Folder view helps you to find songs easily and quickly
• Equalizer for optimized sound to suit your music style
• Easy-to-read black and white LCD display
Your music, your data - on the go, everyday
• MP3 and WMA playback
• Voice recording to take notes or record anything, anytime
• Fast downloads from your PC via USB 2.0*
Page 2
Issue date 2009-11-06
Version: 1.2.6
12 NC: 8670 000 30195
UPC: 6 09585 13347 1
© 2009 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
Specifications
SA2300/37
Flash audio player
512MB*
Picture/Display
•Backlight
•Lines of text: 2
• Resolution: 32 x 128
•Type: LCD
Sound
• Channel separation: 35 dB
• Equalizer settings: Clas
sic, Jazz, Pop, Rock
• Frequency response: 80 - 18 000 Hz
• Output power (RMS): 2 x 3 mW
• Signal to noise ratio: > 80 dB
Audio Playback
• Compression format: MP3, WAV, Windows
Media™ Audio
• ID3 Tag support: Track title and artist name
• MP3 bit rates: 8-320 kbps and VBR
• MP3 sample rates: 8, 11.025, 16, 22.050, 24, 32,
44
.1, 48 kHz
• WMA bit rates: 64-320 kbps
• WMA sample rates: 8, 11.025, 16, 22.050, 32, 44.1,
48
kHz
Audio Capturing
• Audio file format: WAV
• Built-in microphone: mono
• Voice recording: ADPCM
Storage Media
• Built-in memory capacity: 512 MB
• Built-in memory type: NAND Flash
• Mass storage class compliant
• Music memory capacity, WMA: Up to 240 tracks*
Connectivity
• Headphone: 3.5 mm
•USB: High-speed USB 2.0
Convenience
• Firmware upgradeable
• Function: Keypad lock
Accessories
• Batteries: AAA Alkaline
• Headphones: AY3809
• User Guide on CD-ROM
Software
• Device manager: to restore and upgrade
Green Specifications
• Lead-free soldered product
System Requirements
•CD-ROM drive
• Internet connection: Yes (for access to updated
s
upport documents, manuals, future firmware and
PC software upgrades)
• PC OS: Windows 2000, Me, XP
• USB: Free USB port
Dimensions
• Blister dimensions (WxDxH): 135 x 38 x 195 mm
• Packaging type: Clamshell
• Product dimensions (WxDxH
): 31.5 X 23 X 77.8
mm
Power
•Batteries included
• Battery type: AAA / LR03 Alkaline
• Playtime on external batt
ery: Up to 10 hours
•
