Series S5000
XZ5800, S5230,
S5210, S5095,
S5091, S5090,
S5082, S5081,
S5080, S5079,
S5078, S5077
14
15
1
13
16
2
12
3
4
5
11
10
9
8
17
6
7
18
English 6
简体中文 31
English
6
Introduction
Congratulations on your purchase and welcome
to Philips! To fully benet from the support that
Philips oers, register your product at
www.philips.com/welcome.
General description
1 Click-on trimmer attachment (S5230/04,
S5210/04, S5082/61, S5081/04, S5079/04,
S5078/04 only)
2 Protection cap for shaving unit
3 Click-on shaving unit
4 Shaving unit release button
5 On/o button
6 Handle
7 Socket for small plug
8 Battery charge indicator with 1 light
9 Unplug for use symbol
10 Travel lock symbol
11 Replacement reminder
(S5210/04, S5230/04 only)
12 Cleaning reminder (S5210/04, S5230/04 only)
13 Click-on cleansing brush attachment
(XZ5800/69, S5095/58, S5091/50,
S5090/58 only)
14 Protection cap for cleansing brush attachment
(XZ5800/69, S5095/58, S5091/50,
S5090/58 only)
15 Protection cap for nose trimmer attachment
(S5091/50, S5082/61 only)
16 Click-on nose trimmer attachment
(S5091/50, S5082/61 only)
17 Supply unit (adapter)
18 Small plug
The accessories supplied may vary for dierent
products. The box shows the accessories that have
been supplied with your appliance.
Important safety information
Read this important information carefully before
you use the appliance and its accessories and save
it for future reference. The accessories supplied
may vary for dierent products.
Danger
- Keep the supply unit dry.
Warning
- To charge the battery, only use the detachable
supply unit (HQ8505) provided with the
appliance.
- The supply unit contains a transformer. Do not
cut o the supply unit to replace it with another
plug, as this causes a hazardous situation.
- This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning
and user maintenance shall not be made by
children without supervision.
- Always unplug the shaver before you clean it
under the tap.
- Always check the appliance before you use
it. Do not use the appliance if it is damaged,
as this may cause injury. Always replace a
damaged part with one of the original type.
English
7
English
8
Caution
- Do not open the appliance to replace the
rechargeable battery.
- Never immerse the cleaning system or the
charging stand in water and do not rinse it
under the tap.
- Never use water hotter than 80°C to rinse the
shaver.
- Only use this appliance for its intended purpose
as shown in the user manual.
- For hygienic reasons, the appliance should only
be used by one person.
- Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive
liquids such as petrol or acetone to clean the
appliance.
- If your shaver comes with a cleaning system,
always use the original Philips cleaning uid
(cartridge or bottle, depending on the type of
cleaning system).
- Always place the cleaning system on a stable,
level and horizontal surface to prevent leakage.
- If your cleaning system uses a cleaning
cartridge, always make sure the cartridge
compartment is closed before you use the
cleaning system to clean or charge the shaver.
- When the cleaning system is ready for use, do
not move it to prevent leakage of cleaning uid.
- Water may drip from the socket at the bottom
of the shaver when you rinse it. This is normal
and not dangerous because all electronics
are enclosed in a sealed power unit inside the
shaver.
- Do not use the supply unit in or near wall
sockets that contain an electric air freshener to
prevent irreparable damage to the supply unit.
Electromagnetic elds (EMF)
- This Philips appliance complies with all
applicable standards and regulations regarding
exposure to electromagnetic elds.
General
- This shaver is waterproof. It is suitable for use
in the bath or shower and for cleaning under
the tap. For safety reasons, the shaver can
therefore only be used without cord.
- The appliance is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
The display
Charging
Note: If you press the on/o button during
charging, the 'unplug for use' symbol ashes white
to remind you that you have to disconnect the
appliance from the wall socket.
Battery charge indicator with 1 light
Quick charge (XZ5800, S5230/04, S5210/04,
S5095/58, S5090/58, S5081/04 only): When the
battery is empty and you connect the appliance
to the wall socket, the battery charge indicator
ashes quickly. When the appliance contains
enough energy for one shave, the battery charge
indicator starts ashing slowly.
While the appliance continues to charge, the
battery charge indicator ashes slowly until the
appliance is fully charged.
English
9
English
10
Battery fully charged
Note: When the battery is full, the display switches
o automatically after 30 minutes.
Note: This appliance can only be used without cord.
Battery charge indicator with 1 light
When the battery is fully charged, the battery
charge indicator lights up white continuously.
Battery low
Battery charge indicator with 1 light
When the battery is almost empty, the battery
charge indicator ashes orange.
’Unplug for use’ reminder
The appliance is equipped with an ‘unplug for
use’ reminder. The ‘unplug for use’ symbol ashes
to remind you that you have to disconnect the
appliance from the supply unit before you can
switch it on.
Cleaning reminder
3 sec.
Clean the shaver after every shave for optimal
performance. When you switch o the appliance,
the cleaning reminder ashes to remind you to
clean the appliance.
Travel lock
You can lock the appliance when you are going to
travel. The travel lock prevents the appliance from
being switched on by accident.
Activating the travel lock
1 Press the on/o button for 3 seconds to enter
Deactivating the travel lock
1 Press the on/o button for 3 seconds.
English
the travel lock mode.
While you activate the travel lock, the travel
lock symbol lights up continuously. When the
travel lock is activated, the travel lock symbol
ashes.
The travel lock symbol ashes and then lights
up continuously. The appliance is now ready for
use again.
11
English
12
Replacement reminder
For maximum shaving performance, we advise
you to replace the shaving heads every two years.
The appliance is equipped with a replacement
reminder which reminds you to replace the shaving
heads. The shaving unit symbol and arrows light
up to indicate that you have to replace the shaving
heads.
Note: After replacing the shaving heads, you need
to reset the replacement reminder by pressing the
on/o button for 7 seconds.
(S5210/04, S5230/04 only)
Charging
Charge the shaver before you use it for the rst
time and when the display indicates that the
battery is almost empty.
Charging takes approx. 1 hour (XZ5800, S5230/04,
S5210/04, S5095/58, S5090/58, S5081/04) or
8 hours (S5091/50, S5082/61, S5080/03,
S5079/04, S5078/04, S5077/04).
Note:You cannot use the appliance while it is
charging.
Charging with the supply unit
1 Make sure the appliance is switched o.
2 Put the supply unit in the wall socket and put
the small plug in the appliance.
3 After charging, remove the supply unit from the
wall socket and pull the small plug out of the
appliance.
Using the appliance
Note: This appliance can only be used without
cord.
Switching the appliance on and o
1 To switch on the appliance, press the on/o
button once.
2 To switch o the appliance, press the on/o
button once.
Shaving
Skin adaptation period
Your rst shaves may not bring you the result you
expect and your skin may even become slightly
irritated. This is normal. Your skin and beard need
time to adapt to any new shaving system. To allow
your skin to adapt to this new appliance, we advise
you to shave regularly (at least 3 times a week)
and exclusively with this appliance for a period of
3 weeks.
Dry shaving
1 Switch on the appliance.
2 Move the shaving heads over your skin in
circular movements to catch all hairs growing in
dierent directions. Exert gentle pressure for a
close comfortable shave.
Note: Do not press too hard, this can cause skin
irritation.
English
13
3 Clean the appliance after use (see 'Cleaning
and maintenance').
Wet shaving
You can also use this appliance on a wet face with
shaving foam or shaving gel.
14
English
To shave with shaving foam or shaving gel,
follow the steps below:
1 Apply some water to your skin.
2 Apply shaving foam or shaving gel to your skin.
3 Rinse the shaving unit under the tap to ensure
that the shaving unit glides smoothly over your
skin.
4 Switch on the appliance.
5 Move the shaving heads over your skin in
circular movements to catch all hairs growing in
dierent directions. Exert gentle pressure for a
close comfortable shave.
Note: Do not press too hard, this can cause skin
irritation.
Note: Rinse the shaving unit regularly to ensure
that it continues to glide smoothly over your
skin.
6 Dry your face.
7 Clean the appliance after use
(see 'Cleaning and maintenance').
Note: Make sure you rinse all foam or shaving
gel o the appliance.
Using the click-on attachments
Note: The accessories supplied may vary for
dierent products. The box shows the accessories
that have been supplied with your appliance.
Removing or attaching the click-on
attachments
1 Make sure the appliance is switched o.
2 Pull the attachment straight o the appliance.
Note: Do not twist the attachment while you
pull it o the appliance.
3 Insert the lug of the attachment into the slot in
the top of the appliance. Then press down the
attachment to attach it to the appliance (‘click’).
Using the trimmer attachment
You can use the trimmer attachment to groom
your sideburns and moustache.
(S5230/04, S5210/04, S5082/61, S5081/04,
S5079/04, S5078/04 only)
1 Attach the attachment to the appliance ('click').
2 Switch on the appliance.
3 Hold the trimmer attachment perpendicular to
the skin and move the appliance downwards
while you exert gentle pressure.
4 Clean the attachment after use
(see ‚Cleaning and maintenance‘).
English
15
16
English
Using the cleansing brush attachment
Use the rotating cleansing brush attachment with
your daily cleansing cream. The cleansing brush
attachment removes oil and dirt, contributing to a
healthy and oil-free skin.
(XZ5800/69, S5095/58, S5091/50,
S5090/58 only)
1 Attach the attachment to the appliance ('click').
2 Moisten the attachment with water.
Note: Do not use the appliance with a dry brush
attachment, as this can irritate the skin.
3 Moisten your face with water and apply a
cleanser to your face.
4 Place the attachment on your cheek.
5 Switch on the appliance.
20 sec.
6 Gently move the attachment across your skin
from the nose towards the ear. Do not push the
attachment too hard onto the skin to make sure
the treatment remains comfortable.
Note: Do not cleanse the sensitive area around
your eyes.
20 sec.
20 sec.
English
7 After approx. 20 seconds move the appliance
to your other cheek and start cleansing this part
of your face.
8 After approx. 20 seconds move the appliance
to your forehead and start cleansing this part of
your face. Gently move the brush head from left
to right.
Note: We advise you to not overdo the
cleansing and to not cleanse any zone longer
than 20 seconds.
9 After the treatment, rinse and dry your face.
Your face is now ready for the next step of your
daily skincare routine.
10 Clean the attachment after use
(see 'Cleaning and maintenance').
Using the nose trimmer attachment
You can use the nose trimmer attachment to trim
your nose and/or ear hair.
(S5091/50, S5082/61 only)
Trimming nose hair
When trimming nose hair, make sure your nostrils
are clean.
1 Attach the attachment to the appliance ('click').
2 Switch on the appliance.
3 Carefully insert the attachment into one of your
nostrils.
Do not insert the attachment more than 0.5cm
into your nostrils.
17
English
18
4 Slowly move the attachment around to remove
all unwanted hairs in your nostrils.
5 Clean the attachment after use
(see 'Cleaning and maintenance').
Trimming ear hair
When trimming ear hair, make sure your outer ear
channels are clean and free from wax.
1 Attach the attachment to the appliance ('click').
2 Switch on the appliance.
3 Slowly move the attachment along the rim of
the ear to remove hairs that stick out beyond
the rim.
4 Insert the attachment into the outer ear
channel.
Do not insert the attachment more than 0.5cm
into your ear channel, as this could damage the
eardrum.
5 Slowly turn the attachment around to remove
all unwanted hairs from your outer ear channel.
6 Clean the attachment after use
(see 'Cleaning and maintenance').
Cleaning and maintenance
Note: The accessories supplied may vary for
dierent products. The box shows the accessories
that have been supplied with your appliance.
Cleaning the shaver under the tap
Clean the shaver after every shave for optimal
performance.
Caution: Be careful with hot water. Always check
if the water is not too hot, to prevent burning
your hands.
English
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
1 Switch on the appliance.
2 Rinse the shaving unit under a warm tap.
3 Switch o the appliance. Press the release
button to open the shaving unit.
4 Rinse the hair chamber under the tap.
5 Rinse the shaving head holder under a warm
tap.
6 Carefully shake o excess water and let the
shaving head holder dry.
19
7 Close the shaving head holder ('click').
English
20
Cleaning the click-on attachments
Never dry trimmer or beard styler attachments with
a towel or tissue, as this may damage the trimming
teeth.
The accessories supplied may vary for dierent
products. The box shows the accessories that have
been supplied with your appliance.
Cleaning the trimmer attachment
Clean the trimmer attachment every time you have
used it.
(S5230/04, S5210/04, S5082/61, S5081/04,
S5079/04, S5078/04 only)
1 Switch on the appliance with the trimmer
attachment attached.
2 Rinse the attachment under a warm tap.
3 After cleaning, switch o the appliance.
4 Carefully shake o excess water and let the
attachment dry.
Tip: For optimal performance, lubricate the teeth of
the attachment with a drop of sewing machine oil
every six months.
Cleaning the cleansing brush attachment
Clean the cleansing brush attachment every time
you have used it.
(XZ5800/69, S5095/58, S5091/50, S5090/58 only)
1 Switch o the appliance.
2 Detach the brush head from the brush base.
3 Clean the parts thoroughly with warm water
and soap.
4 Dry the cleansing brush attachment with a
towel.
Storage
English
21
Cleaning the nose trimmer attachment
Clean the nose trimmer attachment every time you
have used it.
(S5091/50, S5082/61 only)
1 Make sure the appliance is switched o.
2 Rinse the cutting element of the nose trimming
head with hot water.
3 Switch on the appliance and rinse the cutting
element once more to remove any remaining
hairs. Then switch o the appliance again.
4 Carefully shake o excess water and let the
nose trimmer attachment dry.
Tip: For optimal trimmer performance, lubricate the
trimmer teeth with a drop of sewing machine oil
every six months.
We advise you to let the appliance and its
attachments dry before you put the protection
caps on the attachments or store the shaver in the
pouch.
Note: The accessories supplied may vary for
dierent products. The box shows the accessories
that have been supplied with your appliance.
Put the protection cap on the shaver to protect it
from any dirt accumulation.
Put the protection cap on the cleansing brush
attachment to protect it from dirt accumulation.
English
22
Place the protection cap on the nose trimming
head.
Replacement
Replacing the shaving heads
2yrs
For maximum shaving performance, we advise
you to replace the shaving heads every two years.
Replace damaged shaving heads immediately.
Always replace the shaving heads with original
Philips shaving heads (see 'Ordering accessories').
Replacement reminder (S5230/04,
S5210/04 only)
The replacement reminder indicates that the
shaving heads need to be replaced.The shaving
unit symbol and arrows light up when you switch
o the appliance.
1 Switch o the appliance.
2 Press the release button to open the shaving
unit.
3 Pull the shaving head holder o the bottom part
of the shaving unit.
English
23
2
1
4 Turn the retaining rings anticlockwise and
remove them. Place them aside in a safe place.
5 Remove the shaving heads from the shaving
head holder.
Throw away the used shaving heads
immediately to avoid mixing them with the new
shaving heads.
6 Place the new shaving heads in the shaving
head holder.
Note: Make sure that the projections of the shaving
heads t exactly into the recesses of the shaving
head holder.
1
7 Place the retaining rings back onto the shaving
heads and turn them clockwise to reattach the
retaining ring.
2
Each retaining ring has two recesses and two
projections that t exactly in the projections and
recesses of the shaving head holder.
English
24
- Turn the ring clockwise until your hear a click to
indicate that the ring is xed.
Note: Hold the shaving head holder in your
hand when you reinsert the shaving heads and
reattach the retaining rings. Do not place the
shaving head holder on a surface when you do
this, as this may cause damage.
8 Reinsert the hinge of the shaving head holder
into the slot of the shaving unit. Close the
shaving head holder (‘click’).
9 S5230/04, S5210/04 only: To reset the
7 sec.
replacement reminder, press and hold the
on/o button for approx. 7 seconds.
Replacing the cleansing brush attachment
The brush head should be replaced every
3 months or earlier if the brush hairs are deformed
or damaged (see 'Replacing the cleansing brush
attachment').
Ordering accessories
To buy accessories or spare parts, visit
www.shop.philips.com/service or go to your
Philips dealer. You can also contact the Philips
Consumer Care Centre in your country (see the
international warranty leaet for contact details).
The following accessories and spare parts are
available:
- SH50 Philips shaving heads
- HQ110 Philips shaving head cleaning spray
- RQ111 Philips beard styler attachment
- RQ585 Philips cleansing brush attachment
- RQ560, RQ563 Philips cleansing brush heads
- JC301, JC302, JC303, JC304, JC305 cleaning
cartridge
- HQ8505 supply unit
Note: The availability of the accessories may dier
by country.
Recycling
- Do not throw away the product with the
normal household waste at the end of its life,
but hand it in at an ocial collection point for
recycling. By doing this, you help to preserve
the environment.
- This product contains a built-in rechargeable
battery which shall not be disposed of with
normal household waste. We strongly advise
you to take your product to an ocial collection
point or a Philips service centre to have a
professional remove the rechargeable battery.
- Follow your country’s rules for the separate
collection of electrical and electronic products
and rechargeable batteries. Correct disposal
helps prevent negative consequences for the
environment and human health.
English
25
English
26
Removing the rechargeable appliance battery
Only remove the rechargeable battery
when you discard the appliance. Before
you remove the battery, make sure that the
appliance is disconnected from the mains
and that the battery is completely empty.
Take any necessary safety precautions
when you handle tools to open the
appliance.
Be careful, the battery strips are sharp.
1 Remove the screw in the back panel with a
screwdriver. Then remove the back panel.
2 Bend the hooks aside and remove the power
unit.
3 Break the snap hooks and remove the front
panel of the power unit.
4 Take out the battery holder and cut the battery
tags with a pair of cutting pliers.
Warranty and support
If you need information or support, please
visit www.philips.com/support or read the
international warranty leaet.
Warranty restrictions
The shaving heads (cutters and guards) are not
covered by the terms of the international warranty
because they are subject to wear.
Troubleshooting
This chapter summarizes the most common
problems you could encounter with the appliance.
If you are unable to solve the problem with the
information below, visit www.philips.com/
support
contact the Consumer Care Center in your country.
for a list of frequently asked questions or
English
27
English
28
Shaver
Problem Possible cause Solution
The appliance
does not work
when I press the
on/o button.
The appliance does not
shave as well as
it used to.
The appliance is
still attached to the
wall socket. For
safety reasons, the
appliance can only
be used without
cord.
The rechargeable
battery is empty.
The travel lock is
activated.
The shaving unit is
soiled or damaged
to such an extent
that the motor
cannot run.
The shaving heads
are damaged or
worn.
Hairs or dirt obstruct
the shaving heads.
Unplug the appliance and
press the on/o button to
switch on the appliance.
Recharge the battery
(see 'Charging').
Press the on/o button for
3 seconds to deactivate the
travel lock.
Clean the shaving heads
thoroughly or replace
them. Also see 'Hairs or dirt
obstruct the shaving heads'
for a detailed description of
how to clean the shaving
heads thoroughly.
Replace the shaving heads
(see 'Replacement').
Clean the shaving heads
in the regular way or clean
them thoroughly.
Problem Possible cause Solution
To clean the shaving heads
thoroughly,
remove the shaving heads
from the shaving head
holder one by one (see
'Replacement'). Then
separate the cutter from
its guard and rinse each
matching set under the
tap. After rinsing, place
the cutter back into its
corresponding guard.
Finally, put the shaving
heads back into the
shaving head holder
(see 'Replacement').
I replaced
the shaving
heads, but the
replacement
reminder is still
showing.
A shaving
head symbol
has suddenly
appeared on the
display.
Water is leaking
from the bottom
of the appliance.
The nose
trimmer
attachment pulls
at the hairs.
You have not reset
the appliance.
This symbol is
a replacement
reminder.
During cleaning,
water may collect
between the inner
body and the
outer shell of the
appliance.
You move the
appliance too fast.
Reset the appliance by
pressing the on/o button
for approx. 7 seconds.
Replace the shaving heads
(see 'Replacement').
This is normal and not
dangerous because all
electronics are enclosed in
a sealed power unit inside
the appliance.
Slowly move the
attachment around to
remove all unwanted hairs
in your nostrils.
English
29
English
30
Problem Possible cause Solution
The nose
trimmer
attachment does
not work.
The cutting element
of the attachment
is very dirty, for
instance because
some nasal mucus
has dried inside the
cutting element.
Clean the cutting element
by rinsing it under the tap
with hot water. Switch on
the appliance and rinse the
cutting element once more
to remove any remaining
hairs
If rinsing the nose trimmer
under the tap does not
unblock the cutting
element, then immerse it in
a glass with warm water for
a few minutes. Then switch
on the appliance and rinse
it under the tap.
介绍
基本说明
简体中文
感谢您的惠顾，欢迎光临飞利浦！ 为了
让您能充分享受飞利浦提供的支持，
请在 www.philips.com/welcome 上注册
您的产品。
1 卡入式修剪器附件（仅限 S5230/04
、S5210/04、S5082/61、S5081/04
、S5079/04、S5078/04）
2 剃须刀头部件保护盖
3 卡入式剃须刀头部件
4 剃须刀头部件释放按钮
5 开/关按钮
6 手柄
7 小插头插座
8 电池充电指示灯（1 级指示）
9 “拔出插头即可使用”符号
10 旅行锁符号
11 更换提醒（仅限 S5210/04
、S5230/04）
12 清洗提示（仅限 S5210/04
、S5230/04）
卡入式洁面刷附件（仅限 XZ5800/69
13
、S5095/58、S5091/50, S5090/58）
14
洁面刷附件保护盖（仅限 XZ5800/69
S5091/50、S5095/58、S5090/58）
15 鼻毛修剪器附件保护盖
（仅限 S5091/50, S5082/61）
16 卡入式鼻毛修剪器附件
（仅限 S5091/50, S5082/61）
31
简体中文
32
重要安全信息
危险
警告
17 电源部件（适配器）
18 小插头
随附的附件可能因产品而异。 包装盒上
会显示随附于您产品的附件。
使用本产品及其附件之前，请仔细阅读本
重要信息，并妥善保管以供日后参考
。
随附的附件可能因产品而异。
- 保持电源部件干燥。
- 警告符号注释： 禁止在打开的水龙头
下进行清洗。
- 要给电池充电，请仅使用产品随附的
可拆卸电源部件 (HQ8505)。
- 电源部件中包含一个变压器。
请勿自行更换电源部件的插头，
否则将导致严重后果。
- 本产品适合由 8 岁或以上年龄的儿
童以及肢体不健全、感觉或精神上有
障碍或缺乏相关经验和知识的人士使
用，但前提是有人对他们使用本产品
进行监督或指导，以确保他们安全使
用，并且让他们明白相关的危害。
警告
简体中文
33
切勿让儿童玩弄本产品。 不要让儿童
在无人监督的情况下对本产品进行清
洁和保养。
- 将手持部分与电源软线分开后，才能
在水中清洗手持部分。
- 在自来水龙头下清洗剃须刀之前，
务必拔掉其电源插头。
- 使用前，请务必检查产品。 请勿使用损
坏的产品，否则可能对人体造成伤害。
请务必用原装型号更换损坏的部件。
- 切勿拆开本产品更换充电电池。
- 切勿将清洁系统或充电座浸入水中，
也不要在水龙头下冲洗。
- 警告符号注释：禁止用在打开的水龙
头下进行清洗。
- 切勿使用温度高于 80°C 的热水冲洗
剃须刀。
- 只能将本产品用于用户手册中所示的
原定用途。
- 出于卫生的目的，本产品只能供一个
人使用。
- 切勿使用压缩气体、钢丝绒、研磨性
清洁剂或腐蚀性液体
（例如汽油或丙酮）来清洁产品。
- 如果剃须刀随附清洁系统，应始终使
用原装飞利浦清洁液（滤芯或瓶，
取决于清洁系统类型）。
- 清洁系统必须放在稳定、平坦的水平
表面上，以防漏液。
简体中文
34
电磁场 (EMF)
概述
- 如果清洁系统采用清洁滤芯，在使用
清洁系统进行清洁或为剃须刀充电之
前，应始终确保滤芯仓已关闭。
- 清洁系统准备就绪时，切勿移动，
以免清洁液漏出。
- 冲洗剃须刀时，水可能从产品底部的
插口漏出。 这是正常的，而且没有危
险，因为所有电子元件都封闭在剃须
刀内部的密封电源部件中。
- 请勿在包含电动空气清新器的墙壁插
座上或其周围使用电源部件，以免电
源部件受到不可修复的损坏。
- 本 Philips 产品符合所有有关暴露于电
磁场的适用标准和法规。
- 符号注释：适合于在洗澡或淋浴时使
用。 允许在盛水的浴缸、淋浴、洗脸
盆或其他器皿附近使用本器具。
- 该剃须刀具有防水性能。 适合在沐浴
或淋浴时使用，也可以放在水龙头下
清洗。 出于安全原因，该剃须刀在使
用时不能连接电线。
- 本产品适合在 100 - 240 伏的电源电
压下工作。
- 该电源部件可将 100-240 伏的电压转
换为 24 伏以下的安全低电压。
显示屏
充电
注意： 充电期间按开/关按钮，“拔出
插头即可使用”符号会呈白色闪烁，
提醒您需断开产品与电源插座的连接。
电池充电指示灯（1 级指示）
快速充电（
S5230/04、S5210/04、S5095/58
、S5090/58、S5081/04
尽后，当您将产品连接到电源插座时，电
池充电指示灯会快速闪烁。
产品包含的电量足够完成一次剃须时，
电池充电指示灯开始缓慢闪烁。
如果产品继续充电，电池充电指示灯会
缓慢闪烁，直至产品充满电。
电池已完全充满
仅限 XZ5800,
）：
简体中文
电池电量耗
35
注意： 电池充满电后，显示屏会在
30 分钟后自动关闭。
注意： 本产品只能在不接电源的情况下
使用。
电池充电指示灯（1 级指示）
简体中文
36
电池充满电后，电池充电指示灯将呈白
色持续亮起。
电池电量不足
电池充电指示灯（1 级指示）
当电池的电量几乎耗尽时，
电池充电指示灯会呈橙色闪烁。
“拔出插头即可使用”提醒
产品配有“拔出插头即可使用”提醒。
“拔出插头即可使用”符号闪烁，提醒
您需先断开产品与电源部件的连接才能
启动产品。
清洗提示
每次剃须后请清洁剃须刀，以获得更好
性能。 关闭产品时，清洗提示符号闪
烁，提醒您需要清洁产品。
旅行锁
3 sec.
更换提醒
简体中文
37
您可以在携带本产品旅行之前将其锁
住。 旅行锁可防止本产品被意外启动。
启用旅行锁
1 按住开/关按钮 3 秒钟以进入旅行锁模
式。
启用旅行锁后，旅行锁符号会持续亮
起。 旅行锁启用后，旅行锁符号将闪
烁。
解除旅行锁
1 按开/关按钮 3 秒钟。
旅行锁符号闪烁，然后持续亮起。
现在可以再次使用本产品。
为获得更好剃须效果，建议每两年更换
一次剃须刀头。 本产品配有更换提示，
它会提醒您更换剃须刀头。 剃须刀头部
件符号和箭头亮起，表示需要更换剃须
刀头。
注意： 更换剃须刀头后，您需要通过按
开/关按钮 7 秒来重置更换提醒。
（仅限 S5210/04、S5230/04）
简体中文
38
充电
首次使用剃须刀之前，或当显示屏指示电
池电量几乎耗尽时，请先为剃须刀充电。
充电大约需要 1 小时（XZ5800,
S5230/04、S5210/04、
S5095/58、S5090/58、S5081/04）或 8
小时（S5091/50, S5082/61、S5080/03、
S5079/04、S5078/04、S5077/04）。
注意：不能在充电时使用本产品。
用电源部件充电
1 确保产品电源已关闭。
2 将电源部件插入电源插座，
3 充电之后，从电源插座上拔下电源部
使用本产品
注意： 本产品只能在不接电源的情况下
使用。
然后将小插头插入本产品。
件，并从产品上拔下小插头。
打开或关闭产品
1 要打开本产品，请按一下开/关按钮。
2 要关闭产品，请按一下开/关按钮。
剃须
简体中文
39
皮肤适应期
前几次剃须可能不会带给您预期效果，
并且您的皮肤可能会受到轻度刺激。
这是正常的。 您的皮肤和胡须需要时间
适应任何新的剃须系统。 为了让您的皮
肤适应这款新产品，我们建议您在 3 周
时间内定期（至少每周 3 次）仅使用本
产品剃须。
干用剃须
1 启动产品。
2
将剃须刀头在您的皮肤上作迂回运动。
注意： 划圈动作比直线动作的剃须效
果更好。
3 使用 (请参见 '清洁和保养')后要清洁本
产品。
湿剃
您也可以先用剃须泡沫或剃须啫喱将脸
弄湿，然后再用本产品进行剃须。
要用剃须泡沫或剃须啫喱剃须，
请按照下面的步骤执行操作：
1 用水润湿皮肤。
40
简体中文
2 在皮肤上涂抹剃须泡沫或剃须啫喱。
3 在 水龙头下冲洗一下剃须刀头部件，
确保剃须刀头部件可以在您的皮肤上
顺畅滑动。
4 启动产品。
5 将剃须刀头在您的皮肤上作迂回运
动。
注意： 不要用力按压剃须刀，这样做
可能会导致皮肤疼痛。
注意： 定期冲洗剃须刀头部件，确保
其能够继续在您的皮肤上顺畅滑动。
6 擦干面部。
7 使用 (请参见 '清洁和保养')后要清洁
本产品。
使用卡入式附件
注意： 随附的附件可能因产品而异。
包装盒上会显示随附于您产品的附件。
拆卸或安装卡入式附件
1 确保产品电源已关闭。
注意： 确保冲洗干净本产品上的所有
泡沫或剃须啫喱。
简体中文
41
2 将附件竖直抽离产品。
注意： 将附件从产品上抽出时，
不要旋转。
3 将附件的凸缘插入本产品顶部的槽
内。 然后，按下附件将其安装到本产
品上（可听到“咔哒”一声）。
使用修剪器附件
您可使用修剪器附件修剪鬓角和须髭。
（仅限 S5230/04, S5210/04, S5082/61,
S5081/04, S5079/04, S5078/04）
1 将附件安装到产品上（可听到
“咔哒”一声）。
2 启动产品。
3 将修剪器附件垂直放在皮肤上，
向下移动产品，同时轻轻按压。
4 使用 (请参见 '清洁和保养')后要清洁
附件。
使用洁面刷附件
将旋转洁面刷与日常洁面产品一起使
用。 洁面刷可去除油脂和污垢，焕发健
康无油脂的肌肤。
（仅限 XZ5800/69, S5095/58,
S5091/50, S5090/58)
1 将附件安装到产品上（可听到
“咔哒”一声）。
42
简体中文
2 用水湿润附件。
注意： 切勿在洁面刷附件干燥的情况
下使用产品，否则可能会刺激皮肤。
3 用水润湿面部，并将洁面乳涂抹到脸
上。
4 将附件置于面颊上。
5 启动产品。
6 在鼻子至耳朵之间的皮肤上轻轻地移
动附件。 请勿过分用力地将附件压在
皮肤上，以确保舒适护理
。
20 sec.
20 sec.
20 sec.
注意： 切勿清洁眼部周围的敏感区域
7 约 20 秒后，可将本产品移至另一侧
面颊，开始清洁这部分面部皮肤。
8 约 20 秒后，可将本产品移至前额，
开始清洁这部分面部皮肤。 轻轻将刷
头从左向右移动。
注意： 建议您不要过度清洁，任何部
位的清洁时间不要超过 20 秒钟。
。
简体中文
43
9 护理后，洗脸并擦干。现在您可以
进行日常面部护肤的下一步了。
10 使用 (请参见 '清洁和保养')后要清洁
附件。
使用鼻毛修剪器附件
您可以使用鼻毛修剪器附件修剪鼻毛和/
或耳毛。
（仅限 S5091/50, S5082/61）
修剪鼻毛
修剪鼻毛时，请确保鼻腔保持清洁。
1 将附件安装到产品上（可听到“咔
哒”一声）。
2 启动产品。
3 将附件小心地插入其中一个鼻孔。
附件插入鼻孔的深度不得超过
0.5 厘米。
4 缓缓地来回移动附件，以剃掉鼻孔中
所有多余的毛发。
5 使用 (请参见 '清洁和保养')后要清洁
附件。
修剪耳毛
修剪耳毛时，请确保外耳道保持清洁，
没有耳垢。
1 将附件安装到产品上（可听到
“咔哒”一声）。
2 启动产品。
简体中文
44
3 缓缓地沿着耳缘移动附件，以剃掉突
出耳缘的毛发。
4 将附件插入外耳道。
附件插入耳道的深度不能超过
0.5 厘米，否则可能损伤鼓膜。
5 缓缓地转动附件，以剃掉外耳道中所
有多余的毛发。
6 使用 (请参见 '清洁和保养')后要清洁
附件。
清洁和保养
注意： 随附的附件可能因产品而异。
包装盒上会显示随附于您产品的附件。
在水龙头下冲洗剃须刀
每次剃须后请清洁剃须刀，以获得更好
性能。
警告： 使用热水要当心。 切记先检查
水温是否太高，以防烫手。
不要用毛巾或纸巾擦拭剃须刀头部件，
因为这样可能会损坏剃须刀头。
1 启动产品。
2 用温水冲洗剃须刀头部件。
3 关闭产品。 按下释放按钮，打开剃须
4 在水龙头下冲洗胡茬储藏室。
5 用温水冲洗剃须刀头支架。
6 小心甩干多余的水，然后使剃须刀头
7 合上剃须刀头支架
清洁卡入式附件
简体中文
刀头部件。
支架干燥。
（可听到“咔哒”一声）。
45
注意： 切勿用毛巾或纸巾擦干修剪器或
胡须造型器附件，可能会损坏修剪齿。
清洁修剪器附件
每次使用后都要清洁修剪器附件。
(仅限 S5230/04, S5210/04, S5082/61,
S5081/04, S5079/04, S5078/04 )
1 打开装有修剪器附件的产品。
46
简体中文
2 在温水水龙头下冲洗附件。
3 清洁完成后，关闭产品。
4 小心地甩干多余的水，然后将附件晾
干。
提示： 为获得更好效果，请每隔六个月
用一滴缝纫机油润滑附件齿部。
清洗洁面刷附件
每次使用后都要清洗洁面刷附件。
(仅限 XZ5800/69, S5095/58, S5091/50,
S5090/58)
1 关闭产品。
2 从洁面刷基座上卸下刷头。
3 用温水和肥皂彻底清洗部件。
4 用毛巾擦干洁面刷附件。
清洁鼻毛修剪器附件
每次使用后都要清洁鼻毛修剪器附件。
(仅限 S5091/50, S5082/61)
1 确保产品电源已关闭。
2
用热水冲洗鼻毛修剪刀头的修剪部件。
3 打开产品，再次冲洗修剪部件，以清
除任何剩余的毛发。 然后再次关闭产
品。
4 小心地甩干多余的水份，然后将鼻毛
修剪器附件晾干。
提示： 为获得更好修剪器性能，每六个
月用一滴缝纫机油润滑修发器齿。
存放
简体中文
47
建议您将产品及其配件晾干后再将保护
盖放在配件上，或将剃须刀存放在收纳
袋中。
注意： 随附的附件可能因产品而异。
包装盒上会显示随附于您产品的附件。
将保护盖盖在剃须刀上，以防积聚灰尘。
将保护盖放在洁面刷附件上，以防产品
积聚灰尘。
将保护盖盖在鼻毛修剪刀头上。
更换
更换剃须刀头
2yrs
为获得更好剃须效果，建议每两年更换
一次剃须刀头。立即更换损坏的剃须刀
头。 务必使用原装飞利浦剃须刀头
(请参见 '订购配件')进行更换。
更换提醒（仅限S5230/04、S5210/04）
48
简体中文
更换提醒表示需要更换剃须刀头。
关闭产品时，剃须刀头部件符号和箭头
亮起。
1 关闭产品。
2 按下释放按钮，打开剃须刀头部件。
3 将剃须刀头支架从剃须刀头部件的底
部抽离。
2
1
4 逆时针旋转固定环并将其取下。
将其存放在安全的地方。
5 从剃须刀头支架上卸下剃须刀头。
立即扔掉用过的剃须刀头，以免与新
的剃须刀头混淆。
简体中文
6
将新的剃须刀头装到剃须刀头支架中。
49
注意： 确保剃须刀头凸起部位正好插入
凹陷部位。
1
7 将固定环放回剃须刀头上，然后顺时
针旋转以重新安装固定环。
各固定环均具有两个凹槽和两个凸
2
缘，正好装入剃须刀头支架的凸缘和
凹槽内。
- 顺时针旋转固定环，直至听到
“咔哒”一声，表明固定环已就位。
注意： 当您重新插入剃须刀头并重新安装
固定环时，请将剃须刀头支架握在手中。
当您执行此操作时，切勿将剃须刀头支架
放在平面上，否则可能会造成损坏。
简体中文
50
8 将剃须刀头支架的铰链重新卡入剃须
9
7 sec.
更换洁面刷附件
每 3 个月应更换一次刷头，或当刷毛在
更短时间内出现变形或损坏时更换。
订购配件
要购买附件或备件，请访问
www.shop.philips.com/service 或联系
您的飞利浦经销商。 您还可以联系所在
国家/地区的飞利浦客户服务中心（请参
阅全球保修卡了解详细联系信息）。
可选配以下附件和备件：
- SH50 飞利浦剃须刀头
- HQ110 飞利浦剃须刀头清洁喷雾剂
- RQ111 飞利浦胡须造型器附件
- RQ585 飞利浦洁面刷附件
- RQ560、RQ563 飞利浦洁面刷头
刀头部件的槽内。 合上剃须刀头支架
（可听到“咔哒”一声）。
仅限 S5230/04、S5210/04： 要重置更
换提醒，请按住开/关按钮约 7 秒钟。
- JC301、JC302、JC303、
JC304、JC305 清洁滤芯
- HQ8505 电源部件
注意： 配件可用性可能因国家/地区而
。
异
回收
- 弃置本产品时，请不要将其与一般生
活垃圾放在一起，应将其交给政府指
定的回收中心。 这样做将有利于环
保。
- 此产品包含内置充电电池；请勿将充
电电池与一般生活垃圾一起弃置。 强
烈建议您将自己的产品送到官方收集
点或飞利浦服务中心，让专业人士移
除充电电池。
- 遵循您的国家/地区有关分类回收电子
电气产品和充电电池的规定。 正确弃
置产品有助于避免对环境和人类健康
造成不良后果。
取出可充电的产品电池
简体中文
51
警告： 仅在丢弃本产品时方可取出充电
电池。 卸下电池之前，请确保产品与电
源断开连接并且电池电量已耗尽。
警告： 当您使用工具打开产品时，
请采取必要的安全保护措施。
警告： 注意，电池带非常锋利。
简体中文
52
保修和支持
1 使用螺丝刀取出后面板中的螺钉。
拆除后面板。
2 将钩子向外掰，取出电源部件。
3 脱开安全钩，取下电源部件的前面
板。
4 取出电池舱，用一把钢丝钳剪下电池
标签。
如需信息或支持，请访问
www.philips.com/support 或阅读国际保
修卡。
保修条款
由于剃须刀头（刀片和网罩）属于易磨
损物品，因此不在国际保修条款的涵盖
范围之列。
故障种类和处理方法
本章归纳了使用本产品时最常见的一些
问题。如果您无法根据以下信息解决问
题，请访问 www.philips.com/support
查阅常见问题列表，或联系您所在国家/
地区的客户服务中心。
剃须刀
问题 可能的原因 解决方法
简体中文
53
按下开/关钮
时，产品不
工作。
产品仍然连接着
电源插座。 出
于安全原因，该
产品在使用时不
能连接电线。
充电电池的电量
已耗尽。
旅行锁已被激
活。
剃须刀头部件被
污染或损坏，导
致马达无法运
行。
产品 的剃须
效果没有以
剃须刀头已损坏
或磨损。
前好。
拔掉产品插头并按开/
关按钮打开产品。
给电池充电 (请参见
'充电')。
按住开/关按钮 3 秒钟
以禁用旅行锁。
彻底清洁剃须刀头或
将其更换。 有关如
何彻底清洗剃须刀头
的详细说明，另请参
阅“毛发或污垢堵塞
了剃须刀头”。
更换剃须刀头 (请参
见 '更换')。
简体中文
54
问题 可能的原因 解决方法
毛发或污垢堵塞
了剃须刀头。
对剃须刀头进行常规
或彻底清洁。
要彻底清洁剃须刀
头，请将剃须刀头从
剃须刀头支架上逐一
(请参见 '更换')卸下。
然后，分离刀片和网
罩，并在水龙头下冲
洗每个刀片和网罩套
装。 冲洗后，将刀片
放回对应的网罩中。
最后，将剃须刀头装
回到剃须刀头支架
(请参见 '更换')中。
我更换了剃
须刀头，但
产品尚未重置。 按住开/关按钮大约
7 秒钟以重置产品。
仍然显示更
换提醒。
显示屏上突
然出现剃须
此符号是更换提
醒。
更换剃须刀头 (请参
见 '更换')。
刀头符号。
水从产品底
部漏出。
在清洁过程中，
水可能聚集在产
品的机身内部与
外壳之间。
这是正常现象，而且
没有危险，因为所有
电子元件都封闭在产
品内部的密封电源部
件中。
问题 可能的原因 解决方法
简体中文
55
鼻毛修剪器
附件拉拔毛
发。
鼻毛修剪器
附件不工
作。
产品移动过快。 缓缓地来回移动附
件，以剃掉鼻孔中所
有多余的毛发。
附件的修剪部件
非常脏，因为修
剪部件内部沾有
一些干鼻涕（举
个例子）。
在热水龙头下冲洗修
剪部件，对其进行清
洁。 打开产品，再次
冲洗修剪部件，以清
除任何剩余的毛发
如果在水龙头下冲洗
鼻毛修剪器未能疏通
修剪部件，请将其浸
入盛有温水的玻璃杯
中几分钟。 然后启动
产品，并在水龙头下
冲洗。
56
简体中文
飞利浦多功能理容电动剃须刀
S5230, S5210, S5081
飞利浦多功能理容电动剃须刀 飞利浦电动剃须刀
S5082, S5079, S5078, S5077
保留备用
05/08/2016
飞利浦电动剃须刀
XZ5800, S5095, S5090
S5080, S5091
简体中文
产品中有害物质的名称及含量
部件名称
PCB’s
集成电路板
Electrical
contact pins
电接触片
Power plug
电源插头
本表格依据SJ/T 11364的规定编制。
O: 表示该有害物质在该部件所有均质材料中的含量均在GB/T 26572规定的限量要求以下。
X: 表示该有害物质至少在该部件的某一均质材料中的含量超出GB/T 26572规定的限量要求。
铅
(Pb)
汞
(Hg)镉 (Cd)
X O O O O O
X O O O O O
X O O O O O
有害物质
六价铬
(Cr (VI) )
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
57
Series S5000
XZ5800, S5230,
S5210, S5095,
S5091, S5090,
S5082, S5081,
S5080, S5079,
S5078, S5077
>75% recycled paper
>75%
4222.002.5772.4
Loading...
