Philips S5013-28 Operating Instructions
Series S5000
1
10
1
19
20
2
18
21
3
4
22
23 24
5
6
7
8
9
17
16
15
14
25
26
27
13
11
12
ENGLISH 4
БЪЛГАРСКИ 36
ČEŠTINA 72
EESTI 104
HRVATSKI 137
MAGYAR 170
ҚАЗАҚША 204
LIETUVIŠKAI 239
LATVIEŠU 272
МАКЕДОНСКИ 305
POLSKI 342
ROMÂNĂ 376
РУССКИЙ 410
SLOVENSKY 447
SLOVENŠČINA 480
SHQIP 512
SRPSKI 545
УКРАЇНСЬКА 578
Series S5000
4
ENGLISH
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benet from the support that Philips
offers, register your product at
www.philips.com/welcome.
General description (Fig. 1)
1 Protection cap for nose trimmer attachment
(specic types only)
2 Click-on nose trimmer attachment
(specic types only)
3 Comb for beard styler attachment
(specic types only)
4 Click-on beard styler attachment
(specic types only)
5 Click-on trimmer attachment
(specic types only)
6 Protection cap for shaving unit
(specic types only)
7 Click-on shaving unit
8 On/off button
9 Turbo button (specic types only)
10 Handle
11 Socket for small plug
12 Battery charge indicator with 1 light
13 Battery charge indicator with 3 lights
14 Travel lock symbol
15 Replacement reminder
16 Cleaning reminder
17 Cleaning cartridge for SmartClean system
18 SmartClean system (specic types only)
19 Cap of SmartClean system
20 On/off button
21 Battery symbol
22 Cleaning symbol
ENGLISH 5
23 Replacement symbol
24 Ready symbol
25 Adapter
26 Small plug
27 Pouch (specic types only)
Note: The accessories supplied may vary for different
products. The box shows the accessories that have been
supplied with your appliance.
Important safety information
Read this important information carefully before you
use the appliance and its accessories and save it for
future reference. The accessories supplied may vary
for different products.
Danger
- Keep the adapter dry.
Warning
- The adapter contains a transformer. Do not cut
off the adapter to replace it with another plug, as
this causes a hazardous situation.
- This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use
of the appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not
be made by children without supervision.
- Always unplug the shaver before you clean it
under the tap.
- Always check the appliance before you use it. Do
not use the appliance if it is damaged, as this may
cause injury. Always replace a damaged part with
one of the original type.
ENGLISH6
Caution
- Never immerse the cleaning system or the
charging stand in water and do not rinse it under
the tap.
- Never immerse the shaver in water. Do not use
the shaver in the bath or in the shower.
- Never use water hotter than 80°C to rinse the
shaver.
- Only use this appliance for its intended purpose as
shown in the user manual.
- Do not use the adapter in or near wall sockets
that contain or have contained an electric air
freshener to prevent irreparable damage to the
adapter
- For hygienic reasons, the appliance should only be
used by one person.
- Never use compressed air, scouring pads, abrasive
cleaning agents or aggressive liquids such as petrol
or acetone to clean the appliance.
- If your shaver comes with a cleaning system,
always use the original Philips cleaning uid
(cartridge or bottle, depending on the type of
cleaning system).
- Always place the cleaning system on a stable, level
and horizontal surface to prevent leakage.
- If your cleaning system uses a cleaning cartridge,
always make sure that the cartridge compar tment
is closed before you use the cleaning system to
clean or charge the shaver.
- When the cleaning system is ready for use, do not
move it to prevent leakage of cleaning uid.
- Water may drip from the socket at the bottom
of the shaver when you rinse it. This is normal
ENGLISH 7
and not dangerous because all electronics are
enclosed in a sealed power unit inside the shaver.
Electromagnetic elds (EMF)
- This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic elds.
General
- This shaver can be safely cleaned under the tap.
- The appliance is suitable for mains voltages ranging
from 100 to 240 volts.
- The adapter transforms 100-240 volts to a safe
low voltage of less than 24 volts.
- Maximum noise level: Lc = 69dB(A)
The display
Charging
Battery charge indicator with 3 lights
- Charging takes approx. 1 hour
- Quick charge (specic types only): When the
appliance is connected to the mains, the lights of
the battery charge indicator light up one after the
other continuously. When the appliance contains
enough energy for one shave, the bottom light of
the battery charge indicator ashes slowly.
- If you leave the appliance connected to the
mains, the charging process continues. To indicate
that the appliance is charging, rst the bottom
light ashes and then lights up continuously.
Then the second light ashes and then lights up
continuously, and so on until the appliance is fully
charged.
ENGLISH8
Battery charge indicator with 1 light
- Charging takes approx. 1 hour.
- Quick charge (specic types only): When the
appliance does not contain enough energy for one
shave, the battery charge indicator ashes quickly.
When the battery charge indicator starts ashing
slowly, the appliance contains enough energy for
one shave .
- If you leave the appliance connected to the mains,
the charging process continues. To indicate that
the appliance is charging, the battery charge
indicator ashes slowly.
Battery fully charged
Note: You can also use this appliance directly from the
mains.
Note: When the battery is full, the display switches off
automatically after 30 minutes.
When the battery is fully charged, all lights of the
battery charge indicator light up continuously.
- Battery charge indicator with 3 lights
- Battery charge indicator with 1 light
ENGLISH 9
Battery low
When the battery is almost empty, the battery
charge indicator ashes orange.
- Battery charge indicator with 3 lights
- Battery charge indicator with 1 light
Remaining battery capacity
Battery charge indicator with 3 lights
- The remaining battery capacity is indicated by the
lights of the battery charge indicator that light up
continuously.
Cleaning reminder
For optimal shaving performance, we advise you to
clean the shaver after every use.
- When you switch off the shaver, the cleaning
reminder ashes to remind you to clean the
shaver.
3 sec.
ENGLISH10
Travel lock
You can lock the shaver when you are going to
travel. The travel lock prevents the shaver from being
switched on by accident.
Activating the travel lock
1 Press the on/off button for 3 seconds to enter
the travel lock mode.
- While you activate the travel lock, the travel lock
symbol lights up continuously. When the travel
lock is activated, the travel lock symbol ashes.
Deactivating the travel lock
1 Press the on/off button for 3 seconds.
- The travel lock symbol ashes and then lights up
continuously.
The shaver is now ready for use again.
Replacing shaving heads
For maximum shaving performance, we advise
you to replace the shaving heads every two years.
- The appliance is equipped with a replacement
reminder which reminds you to replace the
shaving heads. The replacement reminder lights up
white continuously.
Note: After replacing the shaving heads, you need to
reset the replacement reminder by pressing the on/off
button for 7 seconds.
ENGLISH 11
Turbo setting (specic types only)
- The appliance is equipped with a Turbo or Turbo+
setting. This setting is intended for quicker and
more intense shaving and makes hard-to-reach
areas easier to shave.
Activating the Turbo setting
1 To activate the Turbo setting, press the Turbo
button once.
Deactivating the Turbo setting
1 To deactivate the Turbo setting, simply press
the Turbo button once again.
Charging
Charging takes approx. 1 hour.
Note: You can also use this appliance directly from the
mains.
Charge the shaver before you use it for the rst
time and when the display indicates that the battery
is almost empty.
Charging with the adapter
1 Insert the small plug into the appliance and put
the adapter in the wall socket.
ENGLISH12
Charging in the SmartClean system
(specic types only)
1 Put the small plug in the SmartClean system.
2 Put the adapter in the wall socket.
3 Press down the top cap to be able to place the
shaver in the holder (‘click’).
4 Hold the shaver upside down above the holder.
Make sure the front of the shaver points
towards the SmartClean system.
5 Place the shaver in the holder, tilt the shaver
backwards and press down the top cap to
connect the shaver (‘click’).
- The battery symbol ashes slowly to indicate the
shaver is charging.
Using the shaver
Switching the appliance on and off
1 To switch on the appliance, press the on/off
button once.
2 To switch off the appliance, press the on/off
button once.
- Battery charge indicator with 3 lights: The display
lights up for a few seconds to show the remaining
battery status.
ENGLISH 13
Shaving
Skin adaptation period
Your rst shaves may not bring you the result you
expect and your skin may even become slightly
irritated. This is normal. Your skin and beard need
time to adapt to any new shaving system.
We advise you to shave regularly (at least 3 times
a week) with this shaver for a period of 3 weeks to
allow your skin to adapt to the new shaver.
Note: You can also use the shaver directly from the
mains.
1 Switch on the appliance.
2 Move the shaving heads over your skin in
circular movements.
Note: Do not make straight movements.
3 Clean the shaver after use (see chapter
‘Cleaning and maintenance’).
Turbo setting (specic types only)
The appliance is equipped with a Turbo or Turbo+
setting for easy shaving of hard-to reach areas.
1 Switch on the shaver.
2 Press the Turbo button once to switch on the
Turbo setting if you want to shave hard-toreach areas more quickly.
3 Move the shaving heads over your skin in
circular movements.
Note: Do not make straight movements.
4 To deactivate the Turbo setting simply press
the Turbo button once.
ENGLISH14
Using the click-on attachments
Note: The accessories supplied may vary for different
products. The box shows the accessories that have been
supplied with your appliance.
Removing or attaching the click-on
attachments
1 Make sure the appliance is switched off.
2 Pull the attachment straight off the appliance.
Note: Do not twist the attachment while you pull it off
the appliance.
3 Insert the lug of the attachment into the slot
in the top of the appliance. Then press down
the attachment to attach it to the appliance
(‘click’).
Using the trimmer attachment
You can use the trimmer attachment to groom
your sideburns and moustache.
1 Make sure the appliance is switched off.
2 Insert the lug of the attachment into the slot
in the top of the shaver. Then press down
the trimmer attachment to attach it to the
appliance (‘click’).
3 Switch on the appliance.
4 You can now start trimming.
5 Clean the attachment after use
(see chapter ‘Cleaning and maintenance’).
ENGLISH 15
Using the beard styler attachment
1 Make sure the appliance is switched off.
2 Insert the lug of the attachment into the slot
in the top of the appliance. Then press down
the attachment to attach it to the appliance
(‘click’).
Using the beard styler attachment with
comb
You can use the beard styler attachment with the
comb attached to style your beard at one xed
setting, but also at different length settings.
You can use it also to pre-trim any long hairs before
shaving to have a more comfortable shave.
The hair length settings on the beard styler
attachment correspond to the remaining hair length
after cutting and range from 1 to 5mm.
1 Slide the comb straight into the guiding
grooves on both sides of the attachment
(‘click’).
2
1
2 Press the length selector and then push it
to the left or right to select the desired hair
length setting.
3 Switch on the appliance.
4 You can now start styling your beard by
moving the attachment upwards with gentle
pressure making sure the front of the comb is
in full contact with the skin.
5 Clean the attachment after use (see chapter
‘Cleaning and maintenance’).
ENGLISH16
Using the beard styler attachment without
comb
You can use the beard styler attachment without the
comb to contour your beard, moustache, sideburns
or neckline to a length of 0.5mm.
1 Pull the comb off the attachment.
Note: Grab the comb in the centre to pull it off the
attachment. Do not pull at the sides of the comb.
2 Switch on the appliance.
3 You can now start contouring your beard,
moustache, sideburns or neckline by moving
the styler downwards with gentle pressure
while holding it perpendicular to the skin.
4 Clean the attachment after use
(see chapter ‘Cleaning and maintenance’).
Using the nose trimmer attachment
You can use the nose trimmer attachment to trim
your nose hair.
Make sure your nostrils are clean.
1 Insert the lug of the attachment into the slot
in the top of the appliance. Then press down
the attachment to attach it to the appliance
(‘click’).
2 Switch on the appliance.
3 Carefully insert the attachment into one of
your nostrils.
Do not insert the attachment more than 0.5cm
into your nostrils.
ENGLISH 17
4 Slowly move the attachment around to remove
all unwanted hairs in your nostrils.
5 Clean the attachment after use
(see chapter ‘Cleaning and maintenance’).
Trimming ear hair
You can use the nose trimmer attachment to trim
your ear hair. Make sure your outer ear channels are
clean and free from wax.
1 Insert the lug of the attachment into the slot
in the top of the appliance. Then press down
the attachment to attach it to the appliance
(‘click’).
2 Switch on the appliance.
3 Slowly move the attachment along the rim of
the ear to remove hairs that stick out beyond
the rim.
4 Insert the attachment into the outer ear
channel.
Do not insert the attachment more than 0.5cm
into your ear channel, as this could damage the
eardrum.
5 Slowly turn the attachment around to remove
all unwanted hairs from your outer ear
channel.
6 Clean the attachment after use
(see chapter ‘Cleaning and maintenance’).
ENGLISH18
Cleaning and maintenance
Note: The accessories supplied may vary for different
products. The box shows the accessories that have been
supplied with your appliance.
Cleaning the shaver in the SmartClean
system (specic types only)
Do n ot tilt the SmartClean system to prevent
leakage.
Note: Hold the SmartClean system while you prepare
it for use.
Note: If you clean the shaver in the SmartClean
system once a week, the SmartClean cartridge will last
approximately three months.
Preparing the SmartClean system for use
1 Put the small plug in the back of the
2
1
SmartClean system.
2 Put the adapter in the wall socket.
3 Press the button on the side of the SmartClean
system and lift the top part of the SmartClean
system.
4 Pull the seal off the cleaning cartridge.
5 Place the cleaning cartridge in the SmartClean
system.
ENGLISH 19
6 Push the top part of the SmartClean system
back down (‘click’).
Using the SmartClean system
Always make sure to shake excess water off the
shaver before you place it in the SmartClean
system.
1 Press down the top cap to be able to place the
shaver in the holder (‘click’).
2 Hold the shaver upside down above the holder.
Make sure the front of the shaver points
towards the SmartClean system.
3 Place the shaver in the holder, tilt the shaver
backwards and press down the top cap to
connect the shaver (‘click’).
- The battery symbol ashes slowly to indicate that
the shaver is charging.
ENGLISH20
4 Press the on/off button on the SmartClean
system to start the cleaning program.
- During the cleaning program (which takes approx.
10 minutes), the cleaning symbol ashes.
- When the cleaning program has been completed,
the ready symbol lights up continuously.
- The battery symbol lights up continuously to
indicate that the shaver is fully charged. This takes
approx. 1 hour.
Note: If you press the on/off button of the
SmartClean system during the cleaning program, the
program aborts. In this case, the cleaning symbol stops
ashing.
Note: If you remove the adapter from the wall socket
during the cleaning program, the program aborts.
Note: 30 minutes after the charging phase has been
completed, the SmartClean system switches off
automatically.
5 To let the shaver dry, you can leave it in the
SmartClean system until your next shave.
You can also remove the shaver from the
SmartClean system, shake off excess water,
open the shaving unit and let the shaver air dry.
Replacing the cartridge of the SmartClean
System
Replace the cleaning cartridge when the
replacement symbol ashes orange or when you are
no longer satised with the cleaning result.
If you clean the shaver in the SmartClean system
once a week, the SmartClean cartridge will last
approximately three months
ENGLISH 21
1 Press the button on the side of the SmartClean
2
1
system and lift the top part of the SmartClean
system.
2 Take the empty cleaning cartridge from the
SmartClean system and pour any remaining
cleaning uid out of the cleaning cartridge.
You can simply pour the cleaning uid down the sink.
3 Throw away the empty cleaning cartridge.
4 Unpack the new cleaning cartridge and pull the
seal off the cartridge.
5 Place the new cleaning cartridge in the
SmartClean system.
6 Push the top part of the SmartClean system
back down (‘click’).
Cleaning the shaver under the tap
Clean the shaver after every shave for optimal
shaving performance.
Be careful with hot water. Always check if the
water is not too hot, to prevent your hands from
getting burnt.
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
ENGLISH22
1 Rinse the shaving unit under a warm tap for
some time.
2 Press the release button and open the shaving
unit.
3 Rinse the shaving head holder under a warm
tap for 30 seconds.
4 Carefully shake off excess water and let the
shaving head holder dry.
5 Close the shaving head holder (‘click’).
Thorough cleaning method
Make sure the appliance is switched off.
1 Press the release button and open the shaving
unit.
2 Pull the shaving head holder off the bottom
part of the shaving unit.
ENGLISH 23
2
1
3 Turn the retaining rings anticlockwise and
remove them.
4 Remove the shaving heads from the shaving
head holder. Each shaving head consists of a
cutter and guard.
Note: Do not clean more than one cutter and guard
at a time, since they are all matching sets. If you
accidentally put a cutter in the wrong shaving guard,
it may take several weeks before optimal shaving
performance is restored.
5 Clean the cutter and guard under the tap.
6 After cleaning, place the cutter back into the
guard.
7 Put the shaving heads back into the shaving
head holder.
ENGLISH24
Note: Make sure the projections of the shaving heads
t exactly into the recesses of the shaving-head holder.
1
8 Place the retaining rings back onto the shaving
head holder and turn them clockwise.
2
- Each retaining ring has two recesses and two
projections that t exactly in the projections and
recesses of the shaving head holder.
- Turn the ring clockwise until your hear ‘click’ and
the ring is xed.
Note: Hold the shaving head holder in your hand
when you reinsert the shaving heads and reattach the
retaining rings. Do not place the shaving head holder
on a surface when you do this, as this may cause
damage.
9 Reinsert the hinge of the shaving head holder
into the slot of the shaving unit. Close the
shaving head holder (‘click’).
ENGLISH 25
Cleaning the click-on attachments
Never dry the trimmer or beard styler
attachments with a towel or tissue, as this may
damage the trimming teeth.
Cleaning the trimmer attachment
Clean the trimmer attachment every time you have
used it.
1 Switch on the appliance with the trimmer
attachment attached.
2 Rinse the trimmer attachment under a hot tap
for some time.
3 After cleaning, switch off the appliance.
4 Carefully shake off excess water and let the
trimmer attachment dry.
Tip: For optimal trimmer performance, lubricate the
trimmer teeth with a drop of sewing machine oil every
six months.
Cleaning the beard styler attachment
Clean the beard styler attachment every time you
have used it.
1 Pull the comb off the beard styler attachment.
Note: Grab the comb in the centre to pull it off the
attachment. Do not pull at the sides of the comb.
2 Switch on the appliance.
3 Rinse the beard styler attachment and the
comb separately under a hot tap for some
time.
ENGLISH26
4 After cleaning, switch off the appliance.
5 Carefully shake off excess water and let the
beard styler attachment and comb dry.
Tip: For optimal trimmer performance, lubricate the
trimmer teeth with a drop of sewing machine oil every
six months.
Cleaning the nose trimmer attachment
Clean the nose trimmer attachment every time you
have used it.
1 Make sure the appliance is switched off.
2 Rinse the cutting element of the nose trimming
head with hot water.
3 Switch on the appliance and rinse the cutting
element once more to remove any remaining
hairs. Then switch off the appliance again.
4 Carefully shake off excess water and let the
nose trimmer attachment dry.
Tip: For optimal trimmer performance, lubricate the
trimmer teeth with a drop of sewing machine oil every
six months.
Storage
Note: The accessories supplied may vary for different
products. The box shows the accessories that have been
supplied with your appliance.
Note: We advise you to let the appliance and its
attachments dry before you put the protection caps on
the attachments and store the shaver in the pouch.
ENGLISH 27
- Place the protection cap on the nose trimming
head.
- Put the protection cap on the shaving head to
protect it from dirt accumulation.
- Store the shaver in the pouch supplied.
Replacement
Replacing the shaving heads
For maximum shaving performance, we advise you
to replace the shaving heads every two years.
Replacement reminder
The shaving unit symbol will light up to indicate that
the shaving heads need to be replaced. Replace
damaged shaving heads immediately. Only replace
the shaving heads with original Philips shaving heads
as specied in chapter ‘Ordering accessories’.
ENGLISH28
1 The shaving unit symbol lights up continuously
when you switch off the shaver to indicate that
the shaving heads need to be replaced.
2 Press the release button and open the shaving
unit.
3 Pull the shaving head holder off the bottom
part of the shaving unit.
2
1
4 Turn the retaining rings anticlockwise and
remove them.
5 Remove the shavings heads from the shaving
head holder and throw them away.
ENGLISH 29
6 Place new shaving heads in the holder.
Note: Make sure the projections of the shaving heads
t exactly into the recesses of the shaving head holder.
1
7 Place the retaining rings back onto the shaving
heads and turn them clockwise.
2
- Each retaining ring has two recesses and two
projections that t exactly in the projections and
recesses of the shaving head holder.
- Turn the ring clockwise until your hear ‘click’ and
the ring is xed.
ENGLISH30
Note: Hold te shaving head holder in your hand when
you reinsert the shaving heads and reattach the
retaining rings. Do not place the shaving head holder
on a surface when you do this, as this may cause
damage.
8 Reinsert the hinge of the shaving head holder
into the slot of the shaving unit. Close the
shaving head holder (‘click’).
7 sec.
9 To reset the replacement reminder, press and
hold the on/off button for approx. 7 seconds.
Ordering accessories
To buy accessories or spare parts, visit
www.shop.philips.com/service or go to your
Philips dealer. You can also contact the Philips
Consumer Care Centre in your country (see the
worldwide guarantee leaet for contact details).
The following parts are available:
- HQ8505 adapter
- SH50 Philips shaving heads
- HQ110 Philips Shaving Head Cleaning Spray
- RQ111 Philips beard styler attachment
- JC301, JC302, JC303, JC304, JC305 cleaning
cartridge
Note: Availability of the accessories may differ per
country.
Loading...
