ENGLISH 6 DEUTSCH 11 FRANÇAIS 16 NEDERLANDS 21
6

ENGLISH

Introduction

Congratulations on your purchase and welcome to Philips! To fully benet
from the support that Philips offers, register your product at www.philips. com/welcome.
This juicer is developed to condently handle a broad variety of ingredients
and recipes and delivering a long-lasting performance. Its unique micro-mesh
lter with high extraction ribs squeezes every drop from your fruits and
vegetables.

General description (Fig. 1)

A Pusher B Feeding tube C Lid D Filter E Juice collector F Driving shaft G Pulp container H Motor unit I Control switch J Cord storage facility K Locking arm L Detachable spout with drip stop M Cleaning brush N Juice jug lid O Foam separator P Juice jug

Important

Read this user manual carefully before you use the appliance and save it for future reference.
Danger
- Do not immerse the motor unit in water or any other liquid, nor rinse it under the tap.
Warning
- Check if the voltage indicated on the base of the appliance corresponds to the local mains voltage before you connect the appliance.
- Do not use the appliance if the plug, the mains cord or other components are damaged.
- If the mains cord is damaged, you must have it replaced by Philips, a
service centre authorised by Philips or similarly qualied persons in order to avoid a hazard.
- This appliance is intended for household use only. If the appliance is used improperly or for professional or semi-professional purposes or if it is not used according to the instructions in the user manual, the guarantee becomes invalid and Philips refuses any liability for damage caused.
- This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
- Children should be supervised to ensure that they do not play with the appliance.
- Never let the appliance operate unattended.
- If you detect cracks in the lter or if the lter is damaged in any way, do not use the appliance anymore and contact the nearest Philips service centre.
- Never reach into the feeding tube with your ngers or an object while the appliance is running. Only use the pusher for this purpose.
- Do not touch the small cutting blades in the base of the lter. They are very sharp.
Caution
- Only connect the appliance to an earthed wall socket.
- This appliance is intended for household use only.
- Never use any accessories or parts from other manufacturers or that
Philips does not specically recommend. If you use such accessories or
parts, your guarantee becomes invalid.
- Make sure all parts are correctly mounted before you switch on the appliance.
ENGLISH 7
- Only use the appliance when the locking arm is in locked position.
- Only unlock the locking arm after you have switched off the appliance
and the lter has stopped rotating.
- Do not remove the pulp container when the appliance is operating.
- Always unplug the appliance after use.
Electromagnetic elds (EMF)
This Philips appliance complies with all standards regarding electromagnetic
elds (EMF). If handled properly and according to the instructions in this user manual, the appliance is safe to use based on scientic evidence
available today.
Preparing for use
1 Wash all detachable parts (see chapter ‘Cleaning’).
2 Unwind the cord from the bottom of the appliance (Fig. 2).
3 Place the juice collector on the motor unit (1). To place the pulp
container, tilt it forwards slightly (2). Insert the top end of the pulp
container rst and then push home the bottom end (Fig. 3).
To empty the pulp container while you are juicing, switch off the appliance and carefully remove the pulp container.
Note: Reassemble the empty pulp container before you continue juicing.
4 Put the lter in the juice collector (1). Hold the lid over the lter and
lower it into position (2) (Fig. 4).
Make sure the lter is tted securely onto the driving shaft (‘click’).
Always check the lter before use. If you detect any cracks or damage, do
not use the appliance. Contact the nearest Philips service centre or take the appliance to your dealer.
5 Lift the locking arm to locked position (‘click’). Align the groove in the
pusher with the small protrusion on the inside of the feeding tube and slide the pusher into the feeding tube (Fig. 5).
Make sure the locking arm is in the locked position.
6 Put the lid on the juice jug to avoid splattering. Place the juice jug
under the spout (Fig. 6).
7 Push the spout downwards before you start juicing.
Note: When the spout is in upward position, it functions as a drip stop when the appliance is switched off. However, if you leave the spout in upward position during juicing, juice splashes out the spout.
Using the appliance
The appliance only functions if all parts are assembled properly and the lid is properly locked in place with the locking arm.
1 Wash the fruit and/or vegetables and if necessary cut them into
pieces that t into the feeding tube. (Fig. 7)
2 Slide the foam separator into the juice jug (1) and place the lid on the
juice jug (2). In this way, the foam stays behind in the jug when you pour out the juice. (Fig. 8)
Note: If you want your drink to have a foamy layer, do not use the foam separator.
Note: If you want to store the juice in the refrigerator, make sure the lid is on the juice jug.
3 Make sure the juice jug is placed under the spout and the spout is in
downward position.
4 Turn the control switch to setting 1 (low speed ) or 2 (high speed) to
switch on the appliance. (Fig. 9)
- Speed 1 is especially suitable for soft fruits and vegetables such as watermelons, grapes, tomatoes, cucumbers and raspberries.
- Speed 2 is suitable for all other kinds of fruits and vegetables.
5 Put the pieces of fruit or vegetables in the feeding tube and gently
press them down towards the rotating lter with the pusher (Fig. 10).
Do not exert too much pressure on the pusher, as this could affect the
amount of juice output.
Tip: The slower you press, the more juice output you get.
ENGLISH8
Never insert your ngers or an object into the feeding tube.
After you have processed all ingredients and the juice ow has stopped, switch off the appliance and wait until the lter has stopped rotating.
6 Push the spout upwards to prevent juice from dripping out of the
spout.
Tips
- Use fresh fruit and vegetables, as they contain more juice. Pineapples, beetroots, celer y stalks, apples, cucumbers, carrots, spinach, melons, tomatoes, pomegranates and grapes are particularly suitable for processing in the juicer.
- You do not have to remove thin peels or skins. Only remove peels which you would not eat, e.g. those of oranges, pineapples, kiwis, melons and uncooked beetroots.
- When you prepare apple juice, remember that the thickness of the apple juice depends on the kind of apple you use. The juicier the apple, the thinner the juice. Choose a kind of apple that produces the type of juice you prefer.
- Apple juice turns brown very quickly. To slow down this process, add a few drops of lemon juice.
- Fruits that contain starch, such as bananas, papayas, avocados, gs and mangoes are not suitable for processing in the juicer. Use a food processor, blender or bar blender to process these fruits.
- Leaves and leaf stalks of e.g. lettuce can also be processed in the juicer.
- Drink the juice immediately after you have extracted it. If it is exposed to air for some time, the juice loses its taste and nutritional value.
- To extract the maximum amount of juice, always press the pusher down slowly.
- The juicer is not suitable for processing very hard and/or brous/starchy fruits or vegetables such as sugar cane.
- Citrus fruits can also be processed with the juicer, remove the white pith of citrus fruits because it has a bitter taste.
Cleaning
Never use scouring pads, abrasive cleaning agents or aggressive liquids such as alcohol, petrol or acetone to clean the appliance.
The appliance is easier to clean if you do so immediately after use.
1 Switch off the appliance. Remove the plug from the wall socket and
wait until the lter has stopped rotating.
2 Remove the dirty parts from the motor unit. Disassemble the juicer
in the following order:
- Remove the pusher;
- Lower the locking arm to unlocked position;
- Remove the lid;
- Remove the pulp container.
3 Remove the juice collector together with the lter (Fig. 11).
4 Clean the detachable spout with the small side of the brush. Clean all
parts except the motor unit with the cleaning brush in warm water with some washing-up liquid and rinse them under the tap.
Note: All detachable parts are dishwasher-safe. Place the detachable plastic parts on the top tray of the dishwasher. Make sure they are placed well away from the heating element.
5 Clean the motor unit with a damp cloth.
Never immerse the motor unit in water nor rinse it under the tap.
Storage
1 Store the mains cord in the cord storage facility by winding it round
the base of the motor unit.
Environment
- Do not throw away the appliance with the normal household waste at
the end of its life, but hand it in at an ofcial collection point for
recycling. By doing this, you help to preserve the environment (Fig. 12).
ENGLISH 9
Guarantee & service
Exceptional guarantee & service
You have bought a culinary tool for life and we want to ensure that
you remain satised. We would like you to register your purchase, so
that we can stay in contact with you and you can receive additional
services and benets from us. Register within 3 months of purchase to receive benets including:
- 5 year product guarantee (and 15 year motor guarantee).
- Fresh ideas for recipes via e-mail
- Tips and tricks to use and maintain your Robust product
- All the latest news on Robust Collection
The only thing you need to do to register your new product is visit www. philips.com/kitchen or call your local Freephone Philips consumer care
hotline (United Kingdom: 0800 331 60 15). If you have questions about
your culinary tool (usage, maintenance, accessories etc) you can either consult our on line support at www.philips.com/kitchen or call your local hotline.
We have put all the maximum effort in developing, testing and designing this
high quality product. However in the unfortunate case that your product needs repair, please call your local Philips consumer care hotline. They will help you with arranging any necessary repairs in a minimum time
with maximum convenience - they can arrange a courier to come to your
home to collect your product and bring it back when it is repaired. This way you can continue to enjoy your delicious homemade cooking.
Troubleshooting
This chapter summarises the most common problems you could encounter with the appliance. If you are unable to solve the problem with the information below, contact the Consumer Care Centre in your country.
Problem Solution
The appliance does not work.
The motor unit gives off an unpleasant smell
the rst few times
the appliance is used.
The appliance makes a lot of noise, gives off an unpleasant smell, is too hot to touch, gives off smoke etc.
The lter is blocked. Switch off the appliance, clean the feeding tube
The lter touches
the feeding tube or vibrates strongly during processing.
Juice splashes out of the spout during juicing.
The appliance is equipped with a safety system. If the parts have not been assembled properly, the appliance does not work. Check whether the parts have been assembled in the right way, but switch off the appliance before you do so.
This is not unusual. If the appliance continues to give off this smell after a few times, check the quantities you are processing and the processing time.
Switch off the appliance and unplug it.Go to the nearest Philips service centre or your dealer for assistance.
and the lter and process a smaller quantity.
Switch off the appliance and unplug it. Check if the
lter is placed properly in the juice collector. The ribs in the bottom of the lter have to t properly onto the driving shaft. Check if the lter is damaged. Cracks, crazes, a loose grating disc or any
other irregularity may cause malfunction.
If you detect any cracks or damage in the lter, do
not use the appliance anymore and contact the nearest Philips Service Centre.
The spout is in upward position. Make sure the spout is in downward position during juicing.
