Philips QG3330 User Manual
QG3340, QG3330
1-18
3-20
1
2
3
4
5
6
7 8
1112 10 9
1
English 5
Français (Canada) 14
English
Introduction
Congratulations on your purchase and welcome to Philips! To fully benefit
from the support that Philips offers, register your product at
www.philips.com/welcome.
General description (Fig.1)
1 Full size trimmer (32mm)
2 Attachment connector
3 On/off slide
4 Adapter
5 Small plug
6 Pouch
7 Beard and stubble comb (32mm)
8 Hair comb (32mm)
9 Detail comb (QG3340 only)
10 Nose trimmer rotary
11 Detail foil shaver (QG3340 only)
12 Detail trimmer (21mm)
Important safety information
Read this important information carefully before you use the appliance
and its accessories and save it for future reference. The accessories
supplied may vary for different products.
Danger
- Keep the adapter dry (Fig. 2).
Warning
- The adapter contains a transformer. Do not cut off the adapter to
replace it with another plug, as this causes a hazardous situation.
- This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
- Always unplug the appliance before you clean it under the tap.
5
6
English
- Always check the appliance before you use it. Do not use the
appliance if it is damaged, as this may cause injury. Always replace a
damaged part with one of the original type.
- Do not open the appliance to replace the rechargeable battery.
Caution
- Never immerse the appliance in water. Do not use the appliance in the
bath or shower.
- Never use water hotter than 80°C to rinse the appliance.
- Only use this appliance for its intended purpose as shown in the user
manual.
- For hygienic reasons, the appliance should only be used by one person.
- Do not use the adapter in or near wall sockets that contain or have
contained an electric air freshener to prevent irreparable damage to
the adapter.
- Never use compressed air, scouring pads, abrasive cleaning agents or
aggressive liquids such as petrol or acetone to clean the appliance.
Electromagnetic fields (EMF)
- This Philips appliance complies with all applicable standards and
regulations regarding exposure to electromagnetic fields.
General
- This appliance can be safely cleaned under the tap (Fig. 3).
- The appliance is suitable for mains voltages ranging from 100 to 240
volts.
- The adapter transforms 100-240 volts to a safe low voltage of less than
24 volts.
Charging
It takes approximately 10 hours to fully charge the appliance.
When the appliance is fully charged, it has an operating time of up to 60
minutes.
Switch off the appliance.
1
Insert the small plug into the appliance and put the adapter in the wall
2
socket (Fig. 4).
English
Using the appliance
Warning: Always check the appliance before you use it. Do not use the
appliance if it is damaged, as this may cause injury. Always replace a
damaged part with one of the original type.
Note: The appliance can only be used without cord.
Detaching and attaching cutting elements
To detach a cutting element, turn it anti-clockwise and pull it upwards
1
off the handle (Fig. 5).
To attach a cutting element, place it on the handle and turn it
2
clockwise (Fig. 6).
Detaching and attaching combs
To detach any type of comb from the cutting element, press the length
1
setting selector, grab the sides and pull it upwards off the cutting
element (Fig. 7).
To attach any type of comb onto a cutting element,slide it into the
2
guiding grooves on both sides of the handle (Fig. 8).
Switching the appliance on and off
To switch on the appliance, slide the on/off button up (Fig. 9).
1
To switch off the appliance, slide the on/off button down.
2
Precision attachments for use on face
Nose trimming
You can use the nose trimmer attachment to trim your nose hair and ear
hair.
- Make sure your nostrils are clean. Make sure your outer ear channels
are clean and free from wax.
- Do not insert the tip more than 0.5cm and make controlled
movements.
Nose trimmer rotary
Trimming nose hair:
- Gently move the tip in and out of your nose while turning it round to
remove unwanted hairs (Fig. 10).
Trimming ear hair:
- Slowly move the tip round the ear to remove hairs that stick out
beyond the rim of the ear.
7
8
English
- Gently move the tip in and out of the outer ear channel to remove
unwanted hairs (Fig. 11).
Detail trimmer (21mm)
You can use the detail trimmer without comb to create fine lines and
contours around your facial style, close to the skin (Fig. 12) (to a length of
0.5mm).
Eyebrow and detail comb
You can use the 21mm detail trimmer with thedetail comb attached for
tidying up your eyebrows or trimming your sideburns (Fig. 13).
Detail foil shaver
You can use the detail foil shaver to shave unwanted hairs on your cheeks
and chin with precision. Gently press the detail foil shaver onto the skin
and shave along contoured edges to remove any hairs (Fig. 14).
Attachments for use on beard
- We advise you to start at the highest length setting to familiarize
yourself with the appliance.
- Make controlled movements against the hair growth and move it over
the part that needs trimming.
Full-size trimmer 32mm
You can use the full-size metal trimmer without comb to get clean lines
around your beard, neck and sideburns close to the skin (Fig. 15) (to a
length of 0.5mm).
Beard and stubble comb
You can use the beard and stubble comb attached to the full size trimmer
to evenly trim your beard, stubble and moustache. You can choose any
setting between 1 and 18mm in steps of 1mm (Fig. 16).
Attachments for use on head
Hair clipping with comb
- Comb the hair in the growth direction.
- Slowly move the trimmer against the hair growth direction. Press
lightly.
- Since hair grows in different directions, you need to move the
appliance in different directions as well (upward, downward or across).
