Page 1
Upright bike
ReCare
PTE7000MU
Builds lower-body strength and conditioning
Designed with comfort
Patients can enjoy the oversized, padded seat with precise positioning for a comfortable ride. Adjustable crank
lengths for limited ranges of motion, METs measurements and downloadable workout data help clinicians
provide better aid to users.
Custom fit for function
Adjust crank length to fit range of motion
Adjust the seat up, down, forwards or backwards
Innovative programmes
The console displays workout data
Console measures strength input on left and right sides
User friendly
The console features an easy-to-read display
Numbered seat and pedal adjustments are available
Page 2
Upright bike
PTE7000MU/37
Highlights Specifications
Console
The console displays essential, real-time
patient performance feedback. Patient data can
be streamed at the same time. Windows
display time, rotations per minute, watts,
calories, METs, heart rate and power.
Console
Large, bright LE D windows make it easy for
users and clinicians to monitor important
workout data at a glance.
Crank adjustment
To help patients with limi ted mobility or
injuries, the pedals can be moved along the
crank to accommodate a range of motion as
small as 15 degrees. Smaller degrees render
smaller circular lower-body motions, so that
patients can complete a full 360 degree stroke
during rehabili tation. Cranks are indexed for
keeping track of how far you have improved, as
well as for precise repetition.
Indexed adjustments
By documenting numbered adjustments,
patients can quickly and easily set up the bike
with indexed seat distance and crank settings.
Seat adjustment
For the best body positioning and comfort, the
seat adjusts vertically and horizontally and is
secured via locking pop-pins. Settings are
indexed for consistent setup for each workout.
Symmetry programme
The symmetry programme allows clinicians to
measure improvement for patients who are
working on strengthening a weaker leg.
Compliance
Certifications: CAN/CSA-C22.2 N o. 60601-
1:14, AN SI/AAMI, ES60601-1:2005+A2 (R2012)
+A1, IEC 60601-1-2:2014, EN 60601-1-2:2015,
IEC 60601-1:2015+A1:2012, EN 60601-1:2006,
+A1:2013, +A12:2014, EN ISO 20957:2013,
MDD 93/42/E EC Class Im,, NB: 0123
Max. user weight
lbs: 440
kg: 200
Net weight
lbs: 142.2
kg: 65
Overall dimensions
inches: 47.7 x 25 x 55
cm: 121 x 64 x 140
Power AC
Volts: AC 100-240 V
Drive train
Heavy-duty: 8-groove poly-V belt, with
spring-loaded idlers
CSAFE
Yes: -
Hand pulse
Yes: -
Programmes
include: Custom, Hill, HR, Interval profiles,
Isokinetic, Manual, Plateau, Symmetry, VO2
Resistance
level: 1 to 50
type: Magnetic resistance system
Start resistance
watts: 5
Work range
watts: 5 to 750
© 20 20 Koninklijke Philips N.V.
All Right s reserved.
Specifications are subject to change
without notice. Trademarks are the
property of Koninklijke Philips N.V. or
their respective owners.
Issue date 2020 ‑07‑12
Version: 13.5.1
12 NC: 8670 001 57737
EAN: 87 12581 75665 9
www.phili ps.com
