Page 1
Recumbent stepper
ReActiv
PTE4000CS
Low impact for all users
Upper or lower body and total-body exercise
The ReActiv 4.0 S allows upper-body-only, lower-body-only and total-body exercise in semi-recumbent
position. The linear resistance is especially helpful for users to improve the strength and the balance of their
arms and legs.
Delivers total-body exercise
The resistance is equal for arms and legs
The step ranges from 1 to 12.5 inches
Innovative programmes
Maintain your desired heart rate
Intensity-based programme using METs as the benchmark
Relieves impact and stress on joints
The 4.0 S is accessible for even deconditioned users
Relieve lower-body stress on the semi-recumbent seat
Intuitive and easy-to-use console design
Bluetooth-based receiver is compatible with HR straps
LED display and clear overlay enhance user interaction
Accommodating to a variety of users
Adjust handles forwards and backwards
Page 2
Recumbent stepper
PTE4000CS/37
Highlights Specifications
HR Auto pilot
Heart rate-based programming is available at
the touch of a button. Cli nicians can assign
their patients a targeted heart rate zone and
the programme adjusts the resistance
accordingly to stay in the zone. A variety of
preset programmes gives users a number of
choices for the type of exercise they are
looking for.
METs-based programme protocol
The ReActiv series features an innovative METs
programme that not only displays your
metabolic equivalent, but also helps you
maintain your desired METs by automated
resistance adjustments. Resi stance
adjustments occur according to user's real-time
watt input.
1:1 Linear resistance
This stepper offers 1:1 resistance, which allows
a stronger arm or leg to help train another arm
or leg. Equal resistance is beneficial for a
variety of users, including those with a wider
range of motion or those with imbalance
between left and right legs or arms.
Low start-up resistance
The 4.0 S is an excellent choice to build up
user confidence and efficiency by allowing
users to exercise at different levels of physical
activity. A low starting resistance with just
5 watts reduces impact on joints and
contributes to better motivation towards
recovery.
Semi-recumbent design
Highly versatile, the semi-recumbent design
relieves stress on hips, knees and ankles while
providing a challenging workout. The seat fits
many users of all ages and mobility
limitations.
Step range
The step depth ranges from 1 to 12.5 inches,
which allows for shallower steps as well as far-
reaching steps. Step range of depth is equal
and reciprocal from one foot to the other.
Built-in heart rate receiver
The ReActiv series incorporates state-of-the-
art user interface and Bluetooth. Heart rate can
be tracked in real time via Bluetooth with
heart-rate-monitoring chest straps.
New appearance and interface
The new LED console features easy-to-read
dot matrix display, two windows at the bottom
and one message window on top for readouts.
This includes calories, distance, pulse and
many indicators according to users' programme
selections. Users can take in all of the
information at one glance. The overlay enables
intuitive operation with easy-to-identify colour
contrast and quick buttons to switch between
Fitness, METs, HR programmes and more.
Adjustable handgrips
The accommodating handles are adjustable in
length to fit a variety of users. Handle
positioning is easily secured for legs-only,
arms-only or total-body workout.
Compliance
Certifications: CE Class SA, EN957, UL
(Commercial grade)
Power AC
Volts: Adapter (DC12 V/1.5 A), AC 100-240 V
Brake
Type: Magnetic resistance system
Max. user weight
lbs: 396
kg: 180
Applicable connectivity
ANT+
Bluetooth (FTMS)
USB port
Charging: N o
Accessory set
Adjustable crank arm: Optional
Built-in HR receiver
Type: ANT+, Bluetooth
CSAFE
Yes: -
Fan
Yes: 3 speed levels
Hand pulse
Yes: -
Programmes
include: Custom, Hill, H R Auto pilot, Interval,
Manual, METs, Plateau, HR 65%, HR 80%, HR
Interval
Resistance
level: 1 to 20
Start resistance
watts: 10
Work rate
watts: 10 to 750
© 20 19 Koninklijke Philips N.V.
All Right s reser ved.
Specifications are subject to change
without notice. Trademarks are the
property of Koninklijke Philips N.V. or
their respective owners.
Issue date 2019‑0 9‑18
Version: 13.2. 3
12 NC: 8670 001 61285
EAN: 87 12581 76126 4
www.phili ps.com
