Page 1
TV station DVB-T
PicoPix
with Sound
PPA7301
Project your life
Connect your PicoPix to the PicoPix TV Station and enjoy free-to-air digital TV
Channels on a big screen. The PicoPix TV Station has 2 x 2-Watt stereo speakers
for improved sound and an inbuilt battery for up to 2 hours' more playtime.
Natural and clear sound
Premium Stereo Speaker inside for excellent sound
Extended playtime
Additional battery to last up to 3 more hours
Portable TV Entertainment
Enjoy free-to-air digital TV wherever you are
Page 2
TV station DVB-T
PPA7301/EU
Highlights Specifications
Premium Stereo speaker
Enjoy your videos and music with high quality
sound. The built-in 2 x 2 Watt premium
speakers offer a great sound experience as
well as the convenience of infinitely adjustable
volume.
Extended playtime
The PicoPix Sound station comes with a
compact built-in rechargeable battery for long-
lasting power. Up to 3 additional hours of
continuous film, photo and music playback
enjoyment can be achieved on a single charge.
This makes the PicoPix Sound station the
perfect accessory for your pocket projector.
Sound
Internal stereo speaker: 2 x 2 Watt
Connection
DC-IN: D C jack
Power Supply
Power adapter: 110-240V AC, 50-60 Hz,
12V@2A for EU and UK
Internal battery: 7.4V @ 3600mAh
Battery life: 3 hours
LED indicator: battery charge
Dimensions
packed (W x D x H): 190 x 190 x 48 mm
unpacked (W x D x H): 105 x 105 x 32 mm
Weight
packed: 550g
unpacked: 270g
Temperature range
Operation: 5-36°C
Storage packed: -25-60°C
Storage unpacked: 0-45°C
Relative humidity
Operation: 15-85% RH
Storage packed: 5-93% RH
Storage unpacked: 15-85% RH
Standard package includes
Quick start guide
Warranty card
Adapter for external Antenna
PPA7301
© 20 19 Koninklijke Philips N.V.
All Right s reser ved.
Specifications are subject to change
without notice. Trademarks a re the
property of Koninklijke Philips N.V. or
their re spective owner s.
Issue date 2019‑10 ‑2 4
Version: 2.0.1
12 NC: 8670 001 13 497
EAN: 34 2 5160 3 2091 6
