Page 1

PM435 Universal Remote

Page 2

Table of Contents

Introduction

Introduction ...................................................... 3

Setup ............................................................... 4

Battery Installation ....................................... 4

Battery Saver ............................................... 4

Code Saver ................................................. 4

Power-On default ........................................ 5

TV Punch Through ....................................... 5

VCR Punch Through .................................... 5

Code Setup ................................................. 5

Button Functions ............................................... 6

Advanced DVD and SAT Button Functions ....... 8

TV/VCR Punch-Through ..................................9

TV/VCR and TV/DVD Combo units ................ 9

Code Entry ..................................................... 10

Direct Code Entry ...................................... 10

Code Search ............................................. 11

Code Identification ..................................... 12

Sleep Timer .................................................... 13

Code List ....................................................... 13

Product Operation .......................................... 18

Troubleshooting .............................................. 19

Congratulations on your purchase of Philips Magnavox Universal Remote Control. Philips Magnavox Universal Remotes let you replace a broken or lost remote or combine more than one remote into one.

This remote control operates the common features of most but not all models and brands of IR Infrared Controlled Video Equipment. This remote may provide functions that are not available on your equipment. Some functions of your particular equipment (e.g. menu functions) may not be controlled by this remote. In such cases, use the original remote control for your equipment. Please use this manual to become familiar with your Philips Magnavox Universal Remote. After you are familiar with your remote the first thing you need to do is to install batteries and setup your remote for your particular product and brand.

Thank you for buying a Philips Magnavox remote and we hope it will give you many years of service.

Page 3

Setup

Battery Installation

1. On the back of the remote,

push down on the tab and

lift the cover off.

2. Match the batteries to the

+ and - marks inside the

battery case, then insert 2

AAA Alkaline batteries.

3. Press the battery cover

back into place.

Battery Saver

Your remote automatically times out if the buttons are depressed more than 30 seconds. This will save your batteries should your remote get stuck in a place where the buttons remain depressed (e.g., between the sofa cushions).

Power-On Default

The remote powers on in TV mode.

TV Volume/Mute Punch-Through

The TV Volume/Mute punch-through feature lets you control the Volume and Mute function of your TV in any mode programmed to be a VCR, DVD, or SAT device, without needing to change to TV mode.

VCR Punch-Through

Punch-through to VCR mode is only allowed in TV, and VCR modes. SAT is dedicated for satellite mode.

Code Setup

The Code Search button is used to setup the remote. You can either setup the remote using the code for your brand of product, from the code tables, or you can search through the library of codes until you find a code that works for your product.

Code Saver

You will have up to 10 minutes to change the batteries in your remote without losing codes you have programmed. However, do not press any buttons until batteries are installed in the remote. If buttons are pressed without batteries in the remote, all codes will be lost.

NOTE: You can store any kind of code under any mode (except TV). I.E. you can store a VCR code under the SAT key, or a DVD code under the VCR key, etc. However, you can only store TV codes under the TV key.

DVD

DVDDVD

VCR

Code Search.

CODE

CODECODE

SEARCHSEARCH

SLEEP

SLEEPSLEEP

VCRVCR

TVTV

CHAN

CHANCHAN

MUTE

MUTEMUTE

CCCCHHHHAAAANNNN

POWER

POWERPOWER

PIP

PIPPIP

TOGGLE

TOGGLETOGGLE

SAT

SATSAT

++++

PREVPREV

CHAN

CHANCHAN

V OO

OL LL

L ++

REPEAT

REPEATREPEAT

SUBTITLE

SUBTITLESUBTI TLE

CCCCCCCC

Page 4

Button Functions

Some buttons on the remote might have functions that are referred to by different names on the device you are controlling. E.G. Prev. Ch. may be called RECALL, or ENTER may be called DISPLAY. These differences depend on the brand and model of your product. Also, this remote can only operate features that exist on your product. E.G., your product must be equipped with Prev. Ch. ability for the Prev. Ch. button to operate this feature.

MUTE Turns off the TV sound while the picture remains.

TV, VCR, DVD, SAT Selects

product to be operated.

Code Search

For setup.

POWER Turns

TVTV

product On or Off.

SLEEP Turns off the TV after a period of 1

CODE

CODECODE

SEARCHSEARCH

to 99 minutes.

PIP TV Picture-in-

SLEEP

SLEEPSLEEP

Picture control.

NUMBERS

Enter numbers for direct channel selection. Some products require Enter to be pressed after channel selection.

ENTER

Used after direct channel number

INFO/

INFO/INFO/

SELECT

SELECTSELECT

entry to immediately change to the

MENUMENU

selected channel.

INFO/Select

SSSSCCCCAAAANNNN

displays/selects on-screen channel information, etc.

MENU Access the Menu functions of the device you are controlling.

Selects menu items for the device you are controlling.

Note: The REC button must be pressed TWICE to record from your VCR. For some brands of VCRs, you might need to press the REC button once, then press it again for three seconds.

Indicator light

Lights when any button is pressed.

DVD

DVDDVD

VCR

VCRVCR

++++

CHAN

CHANCHAN

V OO

OL LL

MUTE

MUTEMUTE

CCCCHHHHAAAANNNN

POWER

POWERPOWER

PIP

PIPPIP

TOGGLE

TOGGLETOGGLE

INPUT

INPUTINPUT

TV/VCR

OKOK

CHAPTE R

CHAPTE RCHAPTE R

PLAY

PLAYPLAY

STOP

STOPREC

STOPSTOP

TV/VCRTV/VCR

++++

SCAN

SCANSCAN

PAUSE

PAUSEPAUS E

ENT ER

ENT EREN TER

REC PAUSE

RECREC

GUI DE

GUI DEGUI DE

QUI T

QUI TQUIT

CCCCCCCC

++++

SAT

SATSAT

PREVPREV

CHAN

CHANCHAN

REPEAT

REPEATREPEAT

SUBTITLE

SUBTITLESUBTI TLE

Button Functions, cont.

CHANNEL Up/ Down Changes

the channels.

VCR

VCRVCR

TVTV

CODE

CODECODE

SEARCHSEARCH

SLEEP

SLEEPSLEEP

PIP

PIPPIP

ENT ER

ENT EREN TER

INFO/

INFO/INFO/

SELECT

SELECTSELECT

MENUMENU

SSSSCCCCAAAANNNN

REC PAUSE

RECREC

CHAPTER +/- controls DVD track selection i.e. DVD Track Skip Up/Down (in DVD and SAT modes). Note the VCR Transport keys also control DVD when in DVD Mode.

VOLUME Up/ Down Changes the

volume level of the product, normally the TV.

DVD

DVDDVD

++++

CHAN

CHANCHAN

V OO

OL LL

MUTE

MUTEMUTE

CCCCHHHHAAAANNNN

POWER

POWERPOWER

TOGGLE

TOGGLETOGGLE

INPUT

INPUTINPUT

TV/VCR

TV/VCRTV/VCR

OKOK

QUI T

QUI TQUIT

++++

CHAPTE R

CHAPTE RCHAPTE R

SCAN

PLAY

SCANSCAN

PLAYPL AY

STOP

STOPREC

PAUSE

STOPSTOP

PAUSEPAUS E

CCCCCCCC

GUI DE

GUI DEGUI DE

++++

SAT

SATSAT

PREVPREV

CHAN

CHANCHAN

REPEAT

REPEATREPEAT

SUBTITLE

SUBTITLESUBTI TLE

Prev. Ch.

Returns to the previously selected channel, or DVD repeat toggle.

CC (Subtitle)

TV Closed Caption (if your TV has this feature) or DVD Subtitle toggle.

TOGGLE Swaps TV PIP screens.

TV/VCR/input toggle

For some TVs, press repeatedly to select from available viewing sources (antenna, VCR, etc.).

GUIDE displays on-screen program guide.

QUIT Used to exit menu functions.

RECORD, PLAY, STOP, REW, FF, PAUSE VCR control

buttons operate your VCR even when the remote is set to operate the TV. Also operates DVD Scan -/+.

Page 5

Advanced Button Functions

DVD

Scan+ and Scan- buttons control the speed of Fast

Forward and Reverse Playback respectively. Chapter+ and Chapter- buttons respectively locate the succeeding or preceding Chapters or Tracks on a disc. Subtitle button brings up DVD Subtitle Menu for Subtitle selection and display. Repeat button performs DVD players “A-B Repeat” (or RPT A.B) function for repeat play of current Chapter or Track. Info/Select button brings up DVD Display or Control Menu for Chapter/Track/Title number, Time remaining/ elapsed indication, system information, etc. Menu brings up the DVD disc Menu screen - use with the Up, Down, Left & Right navigation buttons. OK button is used for on-screen Menu selection. Note some DVD players require the Play button to be used. Quit button is used to Exit or Clear on-screen Menu displays. Play button is used to start Disc playback and for Menu selection on some DVD players.

Stop button stops Disc playback. Pause button will pause Disc playback - press Play to

resume. Note - in DVD Mode the INPUT button activates the DVD Players SETUP Menu.

SAT

Guide button displays on-screen Satellite Channel

Guide. Chapter+ and Chapter- buttons perform the “Page+” and “Page-” function for on-screen Guide Menus used by some Satellite systems. Info/Select button brings up Satellite Display screen for current Channel and system information. Menu brings up the Satellite Menu screen - use with the Up, Down, Left & Right navigation buttons.

OK button is used for on-screen Menu selection. Quit button is used to Exit or Clear on-screen Menu

displays.

Input button performs the Satellite TV/SAT function.

TV/VCR Punch-Through

VCR Punch-through is only available in TV mode, i.e. the 6 VCR keys (Play, Pause, Stop, Record, FF and Rewind) will punch-through to the device programmed under VCR when in TV mode.

The TV/VCR/INPUT button performs the TV/VCR antenna switch function when in VCR Mode.

The TV/VCR/INPUT button performs the TV/SAT switch function when in SAT Mode.

The TV/VCR/INPUT button performs the INPUT source switch function when in TV Mode.

The TV/VCR/INPUT button performs the DVD Setup function when in DVD Mode.

Misc.

SELECT means same as OKAY - some manufacturers

use OKAY label and others use SELECT label on their remotes.

CC will activate the Closed Caption feature if your device has that feature.

PIP (Picture-in-Picture) and TOGGLE buttons operate your television’s Picture-in-Picture features. Use PIP to activate the feature and TOGGLE to swap between the displayed pictures on your TV.

TV/VCR and TV/DVD Combo units

Note that for some TV/VCR and TV/DVD combo units you might need to set up two different buttons to control both parts of the combo unit. E.G., (referring to the Direct Code Entry section on the following page) you might need to set up a code under the TV button to control the TV part of the combo unit AND a separate code for the VCR or DVD under any other button you

choose.

Page 6

Code Entry

Direct Code Entry

1. Press and hold the Code Search button until the red

indicator stays on. Release the Code Search button.

2. Press and release the desired mode button (TV, VCR,

etc.).

The red indicator blinks, then stays lit.

3. Enter the 3 digit code from the code tables. Note:

after a valid code entry, the red indicator turns off.

For an invalid code, the red indicator flashes.

4. With your device on, press CHANNEL Up. If the

device responds, no further programming is

required. Note: If some buttons do not operate your

equipment, try one of the other codes for your

brand.

TVTV

CODE

CODECODE

SEARCHSEARCH

SLEEP

SLEEPSLEEP

Write your codes down here for easy reference later.

ENT ER

ENT EREN TER

VCR

VCRVCR

PIP

PIPPIP

DVD

DVDDVD

CHAN

CHANCHAN

MUTE

MUTEMUTE

CCCCHHHHAAAANNNN

POWER

POWERPOWER

TOGGLE

TOGGLETOGGLE

SAT

SATSAT

++++

V OO

OL LL

L ++

INPUT

INPUTINPUT

TV/VCR

TV/VCRTV/VCR

CCCCCCCC

PREVPREV

CHAN

CHANCHAN

REPEAT

REPEATREPEAT

SUBTITLE

SUBTITLESUBTI TLE

Programming with Code Search

If your device does not respond after you have tried all the codes for your brand, or if your brand is not listed, try searching for your code by following these steps.

1. Manually turn on the device (TV, VCR, etc.) to be controlled.

2. Press and hold Code Search button until the red indicator stays on. Release the Code Search button.

3. Press and release the desired mode button (TV, VCR, etc.). The red indicator blinks, then stays lit.

4. Press the Channel Up button repeatedly (up to 300 times) until the device to be controlled changes channel. The red indicator blinks, then stays lit. If you accidentally overshoot the code required, press the Channel Down button to backtrack through the library until the device changes channel. Pressing Channel Up changes direction to forward again. Press and release Mute to install the code.

The above assumes that you want to store VCR codes under the VCR button, DVD codes under DVD, etc. If you want to store a VCR code under DVD, etc., first follow the procedure on page 10 and try ANY DVD code from the code tables, e.g. press DVD in step 2, page 10, and then enter ANY VCR code. Then follow the steps above.

Note: If the device does not have a Channel Up button, use Play (VCR only) or Power instead. Code Search starts from the currently stored three digit number

under that mode.

TVTV

VCR

VCRVCR

DVD

DVDDVD

SAT

SATSAT

Type Type stored Code

TV TV

VCR

DVD

SAT

++++

CHAN

ENT ER

ENT EREN TER

CHANCHAN

MUTE

MUTEMUTE

CCCCHHHHAAAANNNN

POWER

POWERPOWER

PIP

PIPPIP

TOGGLE

TOGGLETOGGLE

V OO

OL LL

L ++

INPUT

INPUTINPUT

TV/VCR

TV/VCRTV/VCR

CCCCCCCC

PREVPREV

CHAN

CHANCHAN

REPEAT

REPEATREPEAT

SUBTITLE

SUBTITLESUBTI TLE

CODE

CODECODE

SEARCHSEARCH

SLEEP

SLEEPSLEEP

1110

Page 7

Code Identification

Sleep Timer

Code Identification

1. Press and hold Code Search button until the red indicator stays on. Release the Code Search button.

2. Press and release the desired mode button (TV, VCR, etc.). The red indicator blinks, then stays lit.

3. Press and release the Code Search button. The indicator light blinks off.

4. To find the first digit for the code stored under the mode key pressed in step 2, press each numeric key from 0-9 in turn. When the indicator light blinks off the number you pressed is the first digit for the code you are searching for.

5. To find the second digit, repeat step 4, this time when the indicator light blinks off this is the second digit.

6. Repeat step 4 again to find the third digit.

DVD

DVDDVD

VCR

1, 3.

VCRVCR

TVTV

CODE

CODECODE

SEARCHSEARCH

SLEEP

SLEEPSLEEP

PIP

PIPPIP

ENT ER

ENT EREN TER

INFO/

INFO/INFO/

SELECT

SELECTSELECT

MENUMENU

SSSSCCCCAAAANNNN

REC PAUSE

RECREC

CHAN

CHANCHAN

MUTE

MUTEMUTE

CCCCHHHHAAAANNNN

POWER

POWERPOWER

TOGGLE

TOGGLETOGGLE

OKOK

CHAPTE R

CHAPTE RCHAPTE R

PLAY

PLAYPL AY

STOP

STOPREC

STOPSTOP

SAT

SATSAT

++++

V OO

OL LL

L ++

INPUT

INPUTINPUT

TV/VCR

TV/VCRTV/VCR

CCCCCCCC

GUI DE

GUI DEGUI DE

QUI T

QUI TQUIT

PREVPREV

CHAN

CHANCHAN

REPEAT

REPEATREPEAT

SUBTITLE

SUBTITLESUBTI TLE

++++

SCAN

SCANSCAN

PAUSE

PAUSEPAUS E

The Sleep feature enables the remote to turn off the TV after a period of 1 to 99 minutes. Remote is to be in TV mode to set a Sleep Timer. This feature works even if your TV does not have this feature.

1. Press and release the TV Mode key.

2. Press and hold the Sleep button until LED remains on (occurring after approx. 2-3 seconds).

3. Release Sleep button.

4. Press and release the numeric keys (01-99) for the time required. The LED will blink off to indicate keypress acceptance and remain off after second keypress.

5. TV Sleep Timer now set.

6. Leave the Remote pointing towards the TV with an unobstructed path.

To cancel the Sleep Timer, press and hold the Sleep key until the LED blinks or press and release the Power key

in TV Mode.

Code List

ABEX ................................. 1 2 0

ADMIRAL ................. 701 918

ADVENTURA .................. 0 1 9

AIKO ................................. 407

AI WA ..........................121 221

ALLERON ........................ 206

AMARK ............................. 603

AMTRON.......................... 90 6

AKAI ................................. 801

AMSTRAD ........................ 5 2 0

ANAM NATIONAL .104 805

............................. 901 906 920

AOC ............ 002 003 102 119

..................... 217 302 502 814

ARCHER ........................... 6 0 3

AUDIOVOX ...................... 906

BANG & OLUFSEN ......... 62 0

BELCOR ............................ 002

BELL & HOWELL .......... 5 0 6

..................................... 601 701

BRADFORD ...................... 9 0 6

BROKSONIC ..............215 316

BROKWOOD .................... 002

CANDLE .... 002 019 402 502

CAPEHART...................... 11 9

CELEBRITY ..................... 8 0 1

CENTURION .................... 502

CETRONIC ....................... 8 0 5

CITIZEN ....002 112 319 402

..... 407 502 512 701 805 906

CLAIRTONE .................... 0 0 3

CLASSIC ............................ 8 05

CL P .................................... 0 2 1

CLP CLASSIC .... 018 004 002

COLORTYME ... 002 502 602

CONCERTO ...............002 502

CONCIERGE ..................... 713

CONTEC/CONY ....... 003 802

............................. 805 902 906

CRAIG ......................... 805 906

CROWN ...................... 805 906

CURTIS MATHES ............ 0 0 2

..................... 103 112 502 506

..................... 512 601 701 704

CXC .............................805 906

DAEWOO .......... 002 102 110

..................... 214 303 311 314

............. 403 407 415 502 503

............. 611 614 805 809 909

DAYTRON .................002 502

DIMENSIA .................601 704

DUMONT ..................002 713

DYNASTY ........................ 8 0 5

ELEKTRA ........................ 70 1

ELECTROBAND ...... 003 801

ELECTROHOME .....002 502

............................. 803 901 914

1312

Page 8

EMERSON ......... 002 003 004

..... 005 104 105 106 115 204

..... 205 206 213 304 305 316

..... 319 405 502 505 506 519

..... 604 605 705 804 805 903

............................. 904 905 906

ENVISION ..................002 502

FISHER 506 522 606 619 902

FUJITSU .....................206 321

FUNAI ................ 206 805 906

FUTURETEC ............805 906

GE ........ 002 006 007 018 107

..... 114 310 312 502 601 704

..... 719 803 806 810 901 911

GIBRALTER .............. 002 713

GOLDSTAR 002 102 117 207

............. 217 307 502 818 914

GRUNDY ....................206 906

HALLMARK ............. 002 502

HARVARD ......................... 9 0 6

HITACHI.... 002 016 116 216

............. 315 410 502 507 515

............. 519 607 615 622 701

..... 707 710 715 815 902 915

IMA .................................... 9 0 6

INFINITY ......................... 8 0 7

INTEQ ............................... 713

JANEIL .............................. 0 1 9

JBL ..................................... 8 0 7

JCB ..................................... 80 1

JC PENNY ......... 002 007 102

..................... 107 112 310 312

............. 402 502 512 601 704

............. 719 803 806 818 907

JENSEN ......................002 502

JVC ...................... 007 107 108

..................... 308 510 607 902

KAWASHO ......... 002 502 801

KAYPANI .......................... 119

KEC .................................... 80 5

KENWOOD ....... 002 502 914

KLOSS NOVABEAM ....... 019

..................................... 408 508

KONKA ......................203 208

..................... 219 306 317 417

KTV .................... 003 213 319

..................... 608 703 805 906

LODGENET .............. 601 701

LOEWE ......................722 807

LOGIK ........................ 601 701

LUXMAN ................... 002 502

LX I .............. 002 312 502 506

............. 512 601 704 719 807

MAGNAVOX ..... 002 009 109

............. 118 209 309 402 408

..... 502 508 510 807 914 917

MAJESTIC ................. 601 701

MARANTZ ........ 002 502 807

MEGATRON ......002 502 507

ME I .................................... 0 0 3

MEMOREX 002 115 206 502

..................... 506 601 701 706

MGA .................... 002 102 206

..................... 502 619 803 914

MIDLAND ......... 007 107 312

............................. 713 719 818

MINUTZ ........................... 80 6

MITSUBISHI ............. 002 102

..................... 206 502 510 619

..................... 709 803 814 914

MONTGOMERY WARD 60 1

............................................ 70 1

MOTOROLA .............901 918

MTC ....................002 003 102

............................. 112 502 512

MULTITECH ................... 9 0 6

MULTIVISION ................. 0 1 0

NAD ............ 002 120 502 512

NEC ............. 002 102 110 111

..................... 502 510 602 901

NIKEI ................................ 8 05

NIKKO ............... 002 407 502

NT C ................................... 407

ONKING ............................ 8 0 5

ON WA ........................ 805 906

OPTIMUS ..................120 618

OPTONICA ...............111 918

ORION ................105 115 713

PANASONIC ...... 007 107 416

..... 516 608 618 718 807 901

PHILCO ...... 002 009 102 109

..................... 309 402 408 502

..................... 508 807 901 914

PHILIPS ..... 002 009 020 109

............. 122 202 209 210 222

............. 310 322 402 408 422

............. 508 510 807 822 901

..................... 914 917 919 922

PHILIPS/MAGNAVOX ... 020

............................. 422 919 922

PILOT ............................... 00 2

PIONEER ...................002 120

............................. 502 519 610

PORTLAND ..............002 102

..................................... 407 502

PRECISION ....................... 2 1 8

PRICE CLUB .................... 11 2

PRISM ................................ 1 0 7

PROSCAN .. 312 601 704 719

PROTON ............ 002 119 220

............................. 502 820 910

PULSAR ............................ 713

PULSER ............................. 0 0 2

QUASAR .... 007 107 416 516

............. 608 618 718 807 901

RADIO SHACK/REALISTIC .

............. 002 021 111 117 406

............. 502 506 601 618 704

............. 705 805 818 906 914

RCA ..... 002 021 011 102 211

..... 302 312 318 320 406 409

..... 411 420 502 511 514 519

..... 601 702 711 719 809 811

............. 901 909 911 912 914

RHAPSODY ...................... 0 0 3

RUNCO .............................. 7 1 3

SAMPO ....... 002 119 502 818

SAMSUNG .. 002 012 102 103

..... 112 212 502 512 818 914

SAMSUX ........................... 50 2

SANSUI .......................115 215

SANYO ............... 002 412 506

..................... 522 612 619 902

SCOTCH .....................002 502

SCOTT ............... 002 004 105

..................... 206 502 805 906

SEARS . 002 112 206 312 502

............. 506 512 520 601 612

............. 619 704 719 902 914

SHARP 002 013 014 111 502

..... 509 712 812 813 913 918

SHOGUN ........................... 00 2

SIGNATURE ...... 601 701 903

SIMPSON .......................... 4 0 2

SONIC ................................ 00 3

SONY .......... 202 414 708 801

SOUNDESIGN ... 002 206 402

............................. 502 805 906

SPECTRAVISION ............ 92 1

SQUAREVIEW ................. 5 2 0

SSS ....................... 002 805 906

STARLITE ........................ 9 0 6

SUPREMACY ................... 019

SUPREME ......................... 8 0 1

SYLVANIA ......... 002 009 109

............. 209 309 402 408 502

............. 508 717 807 914 917

SYMPHONIC .....520 904 906

TANDY ............................. 9 1 8

TATUNG ........................... 90 1

TECHNICS .................007 107

TECHWOOD............. 002 007

..................................... 107 502

TEKNIKA .. 002 019 102 112

..... 206 209 402 407 502 512

..... 601 618 701 805 902 906

TELECAPTION .............. 3 1 3

TELERENT ............... 601 701

TERA .......................... 002 220

TM K ...........................002 502

TOSHIBA ...112 313 413 419

..... 506 510 512 517 613 902

UNIVERSAL .............. 310 806

VICTOR ............................. 607

VIDTECH ........... 002 102 502

VIKING .............................. 0 1 9

WARDS ....... 002 004 009 102

............. 109 111 206 209 310

............. 408 502 508 513 601

............. 701 704 806 807 914

WHITE WESTINGHOUSE ...

..................................... 311 611

YAMAHA ... 002 102 502 914

ZENITH .............002 008 115

..................... 215 405 407 507

............. 601 701 713 903 916

VCR

ADMIRAL ........................ 224

ADVENTURA .................. 7 2 6

AIKO ................................. 826

AI WA .......... 126 324 528 726

AKAI .......... 027 235 335 424

..................... 524 624 724 924

ALLEGRO ..........326 534 925

AMERICAN HIGH .... 130 226

ASHA ................................. 42 5

AUDIO DYNAMICS . 025 436

AUDIOVOX ...................... 525

DAEWOO ......................... 5 2 9

BELL & HOWELL .......... 428

BEAUMARK .................... 425

BROKSONIC ..............227 325

............................. 530 626 632

CALIX ............................... 52 5

CANDLE ............ 025 026 425

..................... 525 625 725 825

CANNON ... 130 226 535 635

CAPEHART............... 135 534

CARVER ............................ 3 3 0

CCE ............................. 230 826

CITIZEN ....025 026 425 525

..................... 625 725 825 826

COLORTYME .................. 0 2 5

CO LT ................................. 230

CRAIG ......... 230 425 426 525

CURTIS MATHES ............ 0 2 5

..................... 124 130 226 324

..................... 425 526 635 725

CYBERNEX ...................... 425

DAEWOO ..026 135 625 626

..................... 726 825 826 926

DAYTRON ........................ 135

DBX ............................ 025 436

DIMENSIA ........................ 1 2 4

DYNATECH .............. 324 726

ELECTROHOME .....027 525

ELECTROPHONIC ......... 5 2 5

EMERSON ......... 027 028 127

............. 128 130 226 227 228

............. 324 325 327 427 428

............. 525 526 527 528 625

..... 626 627 628 630 634 724

..... 726 727 735 827 828 927

FISHER ....... 025 029 129 328

..................... 330 426 428 928

FUJI .....................130 226 524

FUNAI ................ 324 726 924

GARRARD ........................ 7 26

GE ................ 124 130 136 226

..................... 425 429 635 835

GOLDSTAR ........ 025 236 525

GRADIENTE .................... 7 2 6

GO-VIDEO ......... 139 438 537

HARLEY DAVIDSON ..... 7 2 6

HARMAN KARDON 025 930

HARWOOD....................... 230

HEADQUARTER ............. 428

HITACHI.... 136 235 324 336

............. 538 629 638 829 834

HI-Q ................................... 4 2 6

INSTANT REPLAY ......... 13 0

..................................... 226 924

INTEQ ............................... 525

JCL .............................. 130 226

JC PENNEY .......025 130 235

..................... 425 428 436 525

..................... 629 635 834 935

JENSEN ...................... 235 629

JVC ...................... 025 235 239

..................... 326 339 428 436

1514

Page 9

KENWOOD ...............025 235

............................. 428 436 725

KLH ............................230 237

KODAK ..............130 226 525

LLOYD ....................... 324 726

LOGIK ............................... 23 0

LX I ..................................... 52 5

MAGNAVOX ..... 130 226 330

..................... 534 536 635 734

MAGNIN ........................... 42 5

MARANTZ ........ 025 130 226

..... 330 428 436 530 535 725

MARTA ............................. 525

MATSUSHITA ........... 130 226

ME I ............................. 130 226

MEMOREX ........ 130 224 226

..................... 324 335 425 426

..................... 428 525 534 726

MGA ............................ 027 630

MGN TECHNOLOGY ..... 42 5

MIDLAND ........................ 4 2 9

MINOLTA .................. 629 834

MITSUBISHI ..... 027 031 131

............. 229 231 329 431 436

............. 531 629 630 730 930

MONTGOMERY WARD 22 4

............................................ 63 1

MOTOROLA ..... 130 224 226

MTC ....................324 425 726

MULTITECH ............324 425

............................. 726 429 230

NEC ..... 025 235 428 526 530

............. 725 731 831 931 436

NIKKO .............................. 525

NOBLEX ........................... 4 2 5

OLYMPUS ................. 130 226

OPTIMUS .......... 035 224 525

..................... 537 737 837 937

OPTONICA ...............537 631

ORION ............................... 2 2 7

PANASONIC ...... 035 039 130

............. 226 635 636 937 938

PENTAX .... 136 629 725 834

PENTEX RESEARCH ..... 02 5

PHILCO ...... 130 226 330 635

PHILIPS ............. 130 226 330

..................... 430 434 439 536

............. 631 734 738 934 937

PHILIPS/MAGNAVOX ... 43 4

............................................ 93 4

PILOT ............................... 5 25

PIONEER ... 132 232 436 629

PORTLAND ..............026 135

..................................... 725 825

PROSCAN ......................... 124

PROTEC ........................... 23 0

PULSAR ............................ 53 4

QUARTER ........................ 4 28

QUARTZ ........................... 4 2 8

QUASAR .................... 039 130

............................. 635 636 937

RCA ..... 033 124 130 133 136

............. 226 233 332 424 425

............. 432 532 629 636 732

............. 832 834 835 837 932

RADIOSHACK .. 027 029 035

..... 124 129 130 224 226 324

..... 335 425 426 428 525 631

..... 635 726 737 835 837 937

RADIX ............................... 52 5

RANDEX ........................... 5 2 5

REALISTIC ........ 027 029 035

............. 124 129 130 224 226

..... 324 335 425 426 428 525

..... 631 635 726 737 837 937

REPLAY ............................ 9 3 8

RICOH ............................... 936

RUNCO .............................. 5 3 4

SAMSUNG .. 037 335 425 427

............. 429 537 624 625 629

SANKY ....................... 224 534

SANSUI ............... 235 333 436

SANYO ....... 328 425 426 428

SCOTT ....... 325 327 433 625

..................... 626 630 735 927

SEARS ......... 029 129 130 226

..................... 330 426 428 525

..................... 629 834 928 935

SHARP ........ 027 224 324 338

..................... 631 637 737 825

SHINTOM ..................230 337

............................. 524 629 936

SHOGUN ........................... 42 5

SIGNATURE ..................... 3 2 4

SINGER ............... 130 226 230

SONY .................. 034 038 138

..................... 238 524 838 936

STS .............. 130 226 629 834

SYLVANIA ......... 130 324 330

..................... 536 630 635 726

SYMPHONIC ..... 225 324 726

TANDY ......................324 428

TASHIKO .......................... 5 2 5

TATUNG ........................... 23 5

TEAC .................. 235 324 726

TECHNICS .........035 130 226

TEKNIKA .......... 130 134 226

............................. 324 525 726

TiVo ............................ 738 838

TOSHIBA ........... 029 330 433

..................... 625 629 630 735

TOTEVISION ............425 525

TM K ................... 425 526 828

UNITECH ......................... 4 2 5

VECTOR RESEARCH ..... 0 2 5

............................. 436 625 725

VICTOR ............................. 4 3 6

VIDEO CONCEPTS ..025 027

............................. 436 625 725

VIDEOSONIC ................... 42 5

WARDS ....... 027 130 224 226

..... 230 234 324 425 426 525

..... 625 629 631 726 735 834

WHITE WESTINGHOUSE ...

..................................... 324 924

XR-1000 ..... 130 226 230 726

YAMAHA...025 235 428 436

ZENITH ..... 030 036 125 326

..... 436 437 524 525 534 632

..... 638 729 824 925 929 936

DVD

AI WA ................................. 0 4 3

AKAI ................................. 141

APEX ................................. 044

DAEWOO .......... 046 645 745

DENON ...................... 641 743

ELTA .......................... 045 145

EMERSON ........................ 2 4 1

FISHER .............................. 24 3

GE ....................................... 644

GO-VIDEO ................. 244 342

HITACHI............ 042 543 545

HARMAN/KARDON ....... 3 4 4

JVC .............................. 242 443

INTEGRA .......................... 843

KENWOOD ...............544 641

KONKA ...... 642 742 842 942

MAGNAVOX ............. 441 442

MARANTZ ................441 442

MITSUBISHI .................... 841

MUSTEK ........................... 7 4 4

NAD ................................... 94 4

NAKAMICHI .................... 844

ONKYO ............................. 8 4 3

OPTIMUS ..................042 545

ORITRON ......................... 1 43

PANASONIC .............. 641 741

PHILIPS ............. 441 442 943

PIONEER ...................042 545

PROSCAN ......................... 941

RADIOSHACK .......... 835 945

RCA ............. 644 835 941 945

SAMSUNG ......................... 34 2

SAMPO .............................. 3 4 3

SEG ..................................... 44 4

SHARP ............................... 34 1

SHERWOOD ..................... 1 4 4

SHINCO ............................. 64 4

SONY ................................. 54 1

TEAC .......................... 042 545

THETA DIGITAL ..... 042 545

TOSHIBA ...................245 411

WHARFEDALE ............... 8 4 5

ZENITH .............142 241 345

YAMAHA ...................641 643

YAMAK AWA ................... 44 5

Laser Disc

DENON ............................. 13 2

PIONEER .......................... 1 3 2

PROSCAN ......................... 432

RCA .................................... 4 3 2

SANYO .............................. 82 4

SONY ................................. 93 3

ZENITH ............................ 8 2 4

SAT

AMPLICA ......................... 1 5 9

CHANNEL MASTER ...... 35 9

..................................... 459 559

CHAPPARAL .... 657 659 757

CHEYENNE ..................... 757

DRAKE ............... 059 360 857

DISH NETWORK .....067 366

..... 460 464 466 560 660 962

DX ANTENNA ......... 458 859

ECHOSPHERE ................. 464

ECHOSTAR........ 067 366 460

..................... 464 560 660 962

EXPRESSVU .............. 067 366

..................................... 464 962

FUJITSU .....................760 860

GE ................................265 863

GENERAL INSTRUMENTS .

..................... 058 066 158 166

............. 258 665 865 960 965

HITACHI DSS ............ 765 864

HUGHES SATELLITE DSS ...

............. 465 564 664 864 964

JANEIL .............................. 2 6 1

JERROLD .......................... 3 6 1

JVC ..................................... 466

KENWOOD ...................... 4 6 1

LUXOR .............................. 5 6 1

MAGNAVOX DSS ............ 259

..................................... 565 862

MACOM STATE .............. 661

NORSTAT ..................761 861

PACE .................. 063 163 266

PANASONIC DSS ......260 264

PRIMESTAR.............. 364 665

PHILIPS ............. 259 565 862

PHILIPS/MAGNAVOX ... 25 9

..................................... 565 862

PIONEER .......................... 0 6 0

PROSCAN .................. 265 863

RCA DSS ..... 265 566 866 966

REALISTIC ................ 358 961

SAMSUNG ......................... 06 1

SCIENTIFIC ATLANTA 362

SHARP ............................... 06 2

“SIERRA I II III” ............. 7 5 7

SONY DSS .................. 160 963

STARCHOICE ........... 364 665

STAR SIGHT..................... 96 4

STAR TRAK ..................... 4 6 2

STS .............. 458 558 658 758

SUPER GUIDE ................. 562

THOMSON ....................... 06 3

TOSHIBA .......................... 8 5 8

TOSHIBA DSS ...064 164 764

UNIDEN .....................762 958

UNIDEN DSS .................... 96 4

VIDEO CIPHER II ........... 05 9

ZENITH ..... 059 065 163 165

..................... 266 360 857 957

1716

Page 10

Product Operation

MENU MENUMENU

PLAY PLAYPLAY

PLAY

STOP STOPSTOP

STOP

REC RECREC

REC

PAUSE PAUSEPAUSE

PAUSE

PREV PREVPREV

CHAN CHANCH AN

CHAN

MUTE MUTEMUTE

MUTE

VO OO

OL LL

POWER

POWERPOWER

POWER

VCR VCRVCR

VCR

TV TVTV

CODE CODECOD E

CODE

SEARCH SEARCHSEARCH

QUIT QUITQUIT

QUIT

OK OKOK

SCAN SCANSCAN

SCAN

+ ++

S SS

SC CC

ENTER ENTERENTER

ENTER

TV/VCR TV/VCRTV/VCR

TV/VCR

SAT SATSAT

SAT

PIP PIPPIP

PIP

DVD DVDDVD

DVD

CHAN

CHANCHAN

CHAN

TOGGLE TOGGLETOGGLE

TOGGLE

REPEAT REPEATREPEAT

REPEAT

SUBTITLE SUBTITLESUBTITLE

SUBTITLE

SLEEP SLEEPSLEEP

SLEEP

CHAPTER CHAPTERCHAPTER

CHAPTER

INPUT INPUTINPUT

INPUT

INFO/ INFO/INFO/

INFO/

SELECT SELECTSELECT

SELECT

GUIDE GUIDEGUIDE

GUIDE

Troubleshooting

After the batteries are installed and you have programmed the remote for the codes that operate your products, you can use your remote to operate a TV, VCR, DVD, Satellite System, etc.

TV (Press TV First)

VCR (Press VCR First)

DVD Player (Press DVD first)

Remote does not operate your product.

• Press the mode button of the product you want to control.

• Program the remote with a new code.

• Install new batteries. (You might have to reprogram your remote after installing new batteries.)

• Remote may not be compatible with your product.

Remote does not operate some features of your product.

• Program remote with a new code.

• Remote may not be able to operate all features of your product or button names might be different than your product.

Indicator light blinks after you program a product code.

• Remote did not accept the code.

• Try to program the code again or try a different code.

Satellite System (Press SAT first)

CD Player (Press CD first)

To Operate:

1. Press the TV, VCR, DVD, SAT, etc. button (depending on which product you want to operate).

2. Aim the remote at the product.

3. Press POWER to turn on the product.

4. Press other buttons to operate the features of your product.

1918

Page 11

90 Day Warranty

This product is manufactured to PHILIPS MAGNAVOX specifications and is free from defects in material, workmanship and assembly. This warranty extends only to the original purchaser and is nontransferable. Should a defect occur under normal operating conditions within 90 days from the date of purchase, PHILIPS MAGNAVOX will provide a comparable replacement free of charge within the warranty period, to the original purchaser. Defective product must be returned, with the dated proof of purchase, to the place of purchase for replacement. This warranty does not extend to the product if it has been damaged or rendered defective as a result of accident, misuse, abuse, tampering with or modification. THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL PHILIPS MAGNAVOX BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, WHETHER IN CONTRACT, TORT OR NEGLIGENCE. Some States do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Some States do not allow exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific rights and you may also have other rights, which vary from State to State.

Made in China-TC, Quality Assured in USA Clifton, NJ 07014-1115

PM435 PM435S PM435P PM430G Back Cover Art
