Philips PM335 User Manual
PM335
Universal
Remote
Insructions
Table of Contents
Introduction
Introduction ...................................................... 3
Setup ............................................................... 4
Battery Installation ....................................... 4
Battery Saver ............................................... 4
Code Saver ................................................. 4
Power-On default ........................................ 5
TV Punch Through ....................................... 5
DVD/VCR Punch Through .......................... 5
Code Setup ................................................. 5
Button Functions ............................................... 6
Advanced DVD and SAT Button Functions ....... 8
DVD/VCR Punch-Through ............................... 9
TV/DVD and TV/VCR Combo units ................ 9
Code Entry ..................................................... 10
Direct Code Entry ...................................... 10
Code Search ............................................. 11
Code Identification ..................................... 12
Sleep Timer .................................................... 13
Code List ....................................................... 14
Product Operation .......................................... 18
Troubleshooting .............................................. 19
Congratulations on your purchase of Philips
Magnavox Universal Remote Control. Philips
Magnavox Universal Remotes let you replace a
broken or lost remote or combine more than one
remote into one.
This remote control operates the common features
of most but not all models and brands of IR
Infrared Controlled Video Equipment. This
remote may provide functions that are not
available on your equipment. Some functions of
your particular equipment (e.g. menu functions)
may not be controlled by this remote. In such
cases, use the original remote control for your
equipment. Please use this manual to become
familiar with your Philips Magnavox Universal
Remote. After you are familiar with your remote
the first thing you need to do is to install batteries
and setup your remote for your particular product
and brand.
Thank you for buying a Philips Magnavox remote
and we hope it will give you many years of
service.
32
Setup
Battery Installation
1. On the back of the remote,
push down on the tab and
lift the cover off.
2. Match the batteries to the
+ and - marks inside the
battery case, then insert 2
AAA Alkaline batteries.
3. Press the battery cover
back into place.
Battery Saver
Your remote automatically
times out if the buttons are
depressed more than 30
seconds. This will save your
batteries should your remote
get stuck in a place where the
buttons remain depressed
(e.g., between the sofa
cushions).
Power-On Default
The remote powers on in TV mode.
TV Volume/Mute Punch-Through
The TV Volume/Mute punch-through feature lets you
control the Volume and Mute function of your TV in any
mode programmed to be a VCR, DVD, or SAT device,
without needing to change to TV mode.
VCR/DVD Punch-Through
Punch-through to VCR and DVD mode is only allowed
in TV mode. SAT/DBS is dedicated for satellite mode.
Code Setup
The Code Search button is used to setup the remote.
You can either setup the remote using the code for your
brand of product, from the code tables, or you can
search through the library of codes until you find a
code that works for your product.
Code Saver
You will have up to 10 minutes to change the batteries
in your remote without losing codes you have
programmed. However, do not press any buttons until
batteries are installed in the remote. If buttons are
pressed without batteries in the remote, all codes will be
lost.
NOTE: You can store any kind of code under any mode
(except TV). I.E. you can store a DVD code under the
SAT key, or a TV code under the DVD key, etc.
However, you can only store TV codes under the TV
key.
VCR
VCR
VCRVCR
DVD
DVD
PIP
PIP
PIPPIP
TOGGLE/TITLE
TOGGLE/TITLE
TOGGLE/TITLETOGGLE/TITLE
DVDDVD
CHAN
CHAN
CHANCHAN
MUTE
MUTE
MUTEMUTE
CCCCHHHHAAAANNNN
POWER
POWER
POWERPOWER
SAT
SAT
SATSAT
++++
VV
VO
V
OO
OL
LL
L
++
PREV
PREV
PREVPREV
CHAN
CHAN
CHANCHAN
+
+
REPEAT
REPEAT
REPEATREPEAT
SUBTIT LE
SUBTIT LE
SUBTIT LESUBTIT LE
CCCCCCCC
Code Search.
CODE
CODE
CODECODE
SEARCH
SEARCH
SEARCHSEARCH
SLEEP
SLEEP
SLEEPSLEEP
TV
TV
TVTV
54
Button Functions
Some buttons on the remote might have functions that
are referred to by different names on the device you are
controlling. E.G. Prev. Ch. may be called RECALL, or
ENTER may be called DISPLAY. These differences
depend on the brand and model of your product. Also,
this remote can only operate features that exist on your
product. E.G., your product must be equipped with Prev.
Ch. ability for the Prev. Ch. button to operate this
feature.
MUTE Turns off
the TV sound
while the
picture remains.
TV, DVD/VCR,
SAT Selects
product to be
operated.
Code Search
For setup.
POWER Turns
product On or Off.
SLEEP Turns off the
TV after a period of 1
to 99 minutes.
PIP TV Picture-inÂPicture control.
NUMBERS
Enter numbers for direct
channel selection. Some
products require Enter to
be pressed after channel
selection.
ENTER
Used after direct
channel number
entry to immediately
change to the
selected channel.
INFO/Select
displays/selects
on-screen channel
information, etc.
MENU Access the
Menu functions of
the device you are
controlling.
TV
TV
TVTV
CODE
CODE
CODECODE
SEARCH
SEARCH
SEARCHSEARCH
SLEEP
SLEEP
SLEEPSLEEP
INFO/
INFO/
INFO/INFO/
SELECT
SELECT
SELECTSELECT
MENU
MENU
MENUMENU
SSSSCCCCAAAANNNN
OK
Selects menu items for the
device you are controlling.
Indicator light
Lights when any
button is pressed.
VCR
VCR
VCRVCR
DVD
DVD
DVDDVD
CHAN
CHAN
CHANCHAN
MUTE
MUTE
MUTEMUTE
CCCCHHHHAAAANNNN
POWER
POWER
POWERPOWER
PIP
PIP
PIPPIP
TOGGLE/TITLE
TOGGLE/TITLE
TOGGLE/TITLETOGGLE/TITLE
ENT ER
ENT ER
ENT EREN TER
OK
OK
OKOK
CHAPTER
CHAPTER
CHAPTERCH APTER
PLAY
PLAY
PLAYPLAY
REC
REC
STOP
STOP PAUSE
RECREC
STOPSTOP
SAT
SAT
SATSAT
++++
VV
VO
V
OO
OL
LL
L
++
+
+
INPUT
INPUT
INPUTINPUT
TV/VCR
TV/VCR
TV/VCRTV/VCR
QUI T
QUI T
QUI TQUIT
CCCCCCCC
GUI DE
GUI DE
GUI DEGUI DE
PREV
PREV
PREVPREV
CHAN
CHAN
CHANCHAN
REPEAT
REPEAT
REPEATREPEAT
SUBTIT LE
SUBTIT LE
SUBTIT LESUBTIT LE
++++
++++
SCAN
SCAN
SCANSCAN
PAUSE
PAUSEPAUS E
Button Functions, cont.
CHANNEL Up/
Down Changes
the channels.
TV
TV
TVTV
CODE
CODE
CODECODE
SEARCH
SEARCH
SEARCHSEARCH
SLEEP
SLEEP
SLEEPSLEEP
PIP
PIP
PIPPIP
TOGGLE/TITLE
TOGGLE/TITLE
TOGGLE/TITLETOGGLE/TITLE
ENT ER
ENT ER
ENT EREN TER
INFO/
INFO/
INFO/INFO/
SELECT
SELECT
SELECTSELECT
MENU
MENU
MENUMENU
SSSSCCCCAAAANNNN
REC
REC
RECREC
CHAPTER +/- controls DVD
track selection i.e. DVD Track
Skip Up/Down.
VOLUME Up/
Down Changes the
volume level of
the product,
normally the TV.
VCR
VCR
VCRVCR
DVD
DVD
DVDDVD
++++
CHAN
CHAN
CHANCHAN
VV
VO
V
OO
OL
LL
L
MUTE
MUTE
MUTEMUTE
++
+
+
CCCCHHHHAAAANNNN
POWER
POWER
POWERPOWER
INPUT
INPUT
INPUTINPUT
TV/VCR
TV/VCR
TV/VCRTV/VCR
OK
OK
OKOK
QUI T
QUI T
QUI TQUIT
++++
CHAPTER
CHAPTER
CHAPTERCH APTER
SCAN
SCAN
PLAY
PLAY
SCANSCAN
PLAYPL AY
STOP
STOP PAUSE
PAUSE
STOPSTOP
PAUSEPAUS E
CCCCCCCC
GUI DE
GUI DE
GUI DEGUI DE
++++
SAT
SAT
SATSAT
PREV
PREV
PREVPREV
CHAN
CHAN
CHANCHAN
REPEAT
REPEAT
REPEATREPEAT
SUBTIT LE
SUBTIT LE
SUBTIT LESUBTIT LE
Prev. Ch.
Returns to the
previously
selected channel,
or DVD repeat
toggle.
CC (Subtitle)
TV Closed
Caption (if your
TV has this
feature) or DVD
Subtitle toggle.
TOGGLE Swaps
TV PIP screens.
TITLE brings up
the DVD Title
Menu screen (in
DVD Mode).
Input
For some TVs,
press repeatedly
to select from
available viewing
sources (TV, VCR,
SAT, etc.).
GUIDE displays
on-screen
program guide.
QUIT Used to exit
menu functions.
PLAY, STOP, REW,
FF, PAUSE, REC
DVD/VCR control
buttons operate your
DVD/VCR even when
the remote is set to
operate the TV.
76
