Philips PET831/98 Quick Start Guide

1 Switch OFF the set.

2 Connect the supplied adaptor to the set

and the AC outlet.

3 The RED light comes on.

4 The battery pack will be fully charged in

approximately 4 hours.When the RED light

goes off, it means that the battery pack is

fully charged.

TIP Your battery will continue to charge while

the player is in use. However, the RED light

will not appear and it will take approximately 8

hours to fully charge the battery pack.

Charge

1

Quick start guide

Philips Portable DVD Player PET831 wk0801

IMPORTANT Do not load any 8-cm mini

DVD discs into the player. The DVD player

does not play mini DVD discs. If the disc gets

stuck inside the player, press 9 / twice to

eject the disc.Try the following steps if the

disc remains stuck inside the player.

1 Power off and then power on the player.

Press 9/ to eject the disc.

2 If this does not work, hold the player with

the slot facing down, gently shake the

player until the disc comes out.

1 Switch ON the set.

2 The GREEN light comes on.

3 Slide the disc into the slot on the right side

of the player with the label side of the disc

facing the front of the player.

4 The set will automatically start to play.

5 Use the control keys on the set or the

remote control.

6 To eject the disc, press 9 / twice.

2

Enjoy

15

6

2

3

1 Connect the set to the TV as shown.

2 Select an appropriate input or source on the TV.

You can consult the user’s guide of your TV. (If

your TV does not have Audio and Video inputs,

you will need to purchase a RF modulator. Please

consult your dealer for more information.)

Connect to TV

3

Y

PBP

R

Green

Blue

Red

TIP For better video quality, please use COMP.

OUT connection as shown below.

PET831_qsg.qxd 2008.1.4 13:31 Page 1
