Page 1
Philips
Portable DVD Player
•18cm/ 7" digital LCD
•3hr playtime
•DTV
PET749
Enjoy portable DVD and digital TV
with built-in HDTV tuner
The Philips Portable DVD player PET749 has a built-in digital TV receiver so you can enjoy
free-to-air digital TV programs. The 18 cm/7" , crystal-clear, TFT LCD delivers DTV picture
quality and the rechargeable battery lasts up to 3 hours.
Play your movies, music and photos on the go
• DVD, DVD+/-R, DVD+/-RW, (S)VCD, CD compatible
• MP3-CD, CD and CD-RW playback
• View JPEG images from picture disc
Enjoy portable TV entertainment in real-time
• 17.8 cm (7") high density (800x480 pixels) LCD display
• 180-degree swivel screen for improved viewing flexibility
• Free-to-air digital TV channel reception
• Easy installation and automatic channel search
For ultimate convenience
• Enjoy up to 3 hours playback with a built-in battery*
• Car adaptor and slim remote control
• Stereo headphone jack for better personal music enjoyment
• Detachable antenna design lets you connect to other antennas
Page 2
Portable DVD Player
18cm/ 7" digital LCD 3hr playtime, DTV
Highlights
PET749/37
3 hours built-in battery*
This Philips player comes with a compact builtin rechargeable battery for long-lasting power.
Up to 3 hours of continuous movie, photo and
music playback enjoyment can be achieved on a
single charge. Just plug in the power cable to
recharge the player - it's that simple.
DVD, DVD+/-RW, (S)VCD, CD
The Philips Portable DVD player is compatible
with most DVD and CD discs available in the
market. DVD, DVD+/-R, DVD+/-RW, (S)VCD,
and CD – all of them can play on the DVD
player. DVD+/-R is a shorthand term for a DVD
drive that can accept both of the common
recordable DVD formats. Likewise, DVD+/-RW
handles both common rewritable disc types.
180-degree swivel screen
The screen swivels 180? to give you the
optimum viewing angle for watching movies and
photos. Rotate the screen or adjust it up and
down to cut down on glare and get the best
viewing angle possible.
17.8 cm (7") HD LCD display
The high resolution (800 x 480 pixel) color LCD
display brings images to life, showing off your
treasured photos, favorite movies and music
with the same 'real life' rich detail and vibrant
colors as high quality prints.
Detachable antenna design
The antenna on the Philips portable TV is
com
pletely detachable, allowing you to easily
connect the TV up to an alternate (e.g., indoor
or rooftop) antenna as needed. By doing so, you
can be sure of reaching the best TV signal
available wherever you are.
Free-to-air digital TV
Expand your entertainment experience and
enjoy digital channel programs - for free. With
digital TV broadcasting, you can receive free
digital TV programs in your country. The signal
is kept digital without any analog steps in
between, to preserve the highest quality.
Page 3
Portable DVD Player
18cm/ 7" digital LCD 3hr playtime, DTV
Specifications
PET749/37
Picture/Display
• Display screen type: LCD TFT
• Diagonal screen size (inch): 7 inch
• Resolution: 800(w)x480(H)x3(RGB)
Sound
• Output Power: 250mW RMS(built-in speakers)
• Output power (RMS): 10mW RMS(earphone)
• Signal to noise ratio: >80dB(earphone), >62dB(builtin speake
rs)
Video Playback
• Playback Media: DVD, Picture CD, SVCD, Video
CD, DVD-R/-RW, MP3-CD, CD-R/CD-RW,
DVD+R/+RW, CD
• Disc Playback Modes: Disc Menu, Fast Backward,
t Forward, OSD, Repeat, Shuffle Play, Slow
Fas
Backward, Slow Forward, Zoom
• Video disc playback system: NTSC, PAL
Audio Playback
• Compression format: Dolby Digital, MP3
• MP3 bit rates: 32 - 320 kbps
• Playback Media: CD, CD-R, CD-RW, MP3-CD
• File systems supported: ISO-9660, Jolliet
Connectivity
• DC in: 9V ~ 12V
• AV output: Composite (CVBS) x1
• Headphone jack: 3.5mm Stereo Headphone x 1
• TV connection: F-type connector
Convenience
• Battery charging indication
• Favorite list TV programs
• User Interface: Multiple su
Screen Display on TV
btitles supported, On
Tuner/Reception/Transmission
• Cable: Unscrambled Digital Cable QAM
• Terrestrial: ATSC (8VSB)
• TV system: ATSC
Video Decoding
• Aspect Ratio: 16:9, 4:3
Accessories
• AC/DC Adaptor: DC 9V, 1A, 110-240v, 50/60Hz
• Cables: 1 x AV Cables
• Car kit: cigarette outlet adaptor, 12vDC
• Remote control: AY5523 slim remote
• User Manual: Multi lanaguage
• Included accessories: Aerial antenna
Power
• Battery Type: Built-in battery
• Battery lifetime: Up to 3 hrs*
• Rechargeable
Dimensions
• Packaging dimensions (W x H x D):
235 x 255 x 70 mm
• Master carton dimensions: 225 x 270 x 245 mm
• Master carton quantity: 3
• Master carton weight: 4.35 kg
• Packaging type: D-box
• Product dimensions (W x H x D):
199 x 41 x 159 mm
• Product weight: 0.6 kg
•
Issue date 2013-06-23
Version: 1.1.3
12 NC: 8670 000 58384
UPC: 6 09585 18057 4
© 2013 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject t
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
o change without notice.
* Rechargeable batteries have a limited number of charge cycles and may
eventually need to be replaced. Battery life and number of charge
cycles vary by use and settings.
* Battery life varies by use and settings.
* Battery life of playtime is approximate and may vary depending on
appl
ication condition. To optimize battery life, user should turn LCD
backlight to minimum, connect to headphones (not built-in speakers)
and listen at medium volume level, and use the product at room
temperature.
