Portable DVD player

demo for registered user.

User manual Guide d’utilisateur Manual del usuario Benutzerhandbuch

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips Electronics N.V.

or their respective owners

Printed in China wk7065

PET730 PET732

3 4 5

English

Content

1 Control elements

and functional components

1.1 Main unit controls

1.2 Front of player

1.4 Right of player

1.5 Back of the player

1.6 Remote Control

2 Introduction

2.1 Your portable DVD player

2.2 Unpacking

2.3 Placement

2.4 Playable disc formats

2.4.1 DVD-Video

2.4.2 Video CD

2.4.3 Audio CD / MP3 CD / WMA CD

2.4.4 CD with JPEG files

2.4.5 DivX video discs

2.5 Zero Bright DotTM

3 General information 4 Charging the units

1 Control elements and functional components

1.1 Main unit controls (see figure 1)

1 OPEN Open disc door to insert or remove disc 2 POWER Switch the player on / off 3 9 Press once to stop playback and store the stop

2; Start / pause / resume playback

4 J( / )K Search backward (J() or search forward ()K)

- VOL +

5 6 OPTION Access additional functions

MENU Display MENU page

7 3, 4, 1, 2 Up / down / left / right cursor

OK Confirm selection

position. Press twice to stop playback completely.

Volume control

1.2 Front of player (see figure 1)

POWER/IR/CHR

Power / Remote sensor / charging indicator

1.4 Right of player (see figure 1)

PHONE 1 & 2 10 AV OUT Audio/Video output 11 AV IN Audio video input 12 USB USB connector 13 COAXIAL Digital audio output 14 DC IN 9V Power supply socket

Headphones jack

1.5 Back of the player (see figure 1)

15 Reset Reset the player when it is hanged up 16 Car mounting screw hole

1.6 Remote Control (see figure 2)

1 MENU Display MENU page 2 3, 4, 1, 2 Up / down / left / right navigation key

OK Confirm selection

VOL+ / - Volume control 3 DISPLAY Adjust the display value of the system 4 J( Skip to previous chapter, track or title 5 2; Start / pause / resume playback 6 9 Press twice to stop playback 70- 9 Numeric keypad

SUBTITLE

8 9 RETURN For VCD menu page 10 A - B To repeat or loop a sequence in a title 11 SETUP Enter SETUP menu 12 OPTION Access additional functions 13 )K Skip to next chapter, track or title 14 s Mute player volume 15 AUDIO Audio language selector 16 ZOOM Enlarge video image

CAUTION Use of controls or adjustments or performance

of procedures other than herein may result in hazardous radiation exposure or other unsafe operation.

Subtitle language selector

2 Introduction

2.1 Your portable DVD player

Your portable DVD player plays digital video discs conforming to the universal DVD Video standard. With it, you will be able to enjoy full-length movies with true cinema picture quality, and stereo or multichannel sound (depending on the disc and on your playback set-up).

4.1 Charge the DVD player

4.2 Powering your remote control

5 Start up

5.1 Setup

5.2 Playback DVD

5.3 Playback VCD

5.4 Playback Super (S)-VCD

5.5 Playback Music CD

5.6 Playback Music MP3/WMA-CD

5.7 Playback Picture-CD

5.8 Playback from USB

6 Addition Functions

6.1 DISPLAY Menu

6.2 Connection

6.2.1 Headphone

6.2.2 TV

6.2.3 AV input

6.2.4 USB

6.2.5Coaxial

7 Troubleshooting 8 Technical data

3 General information

Power Sources

This unit operates on a supplied AC adaptor, car adapter, or a rechargeable battery pack.

• Make sure that the input voltage of the AC adaptor is in line with the local voltage. Otherwise, the AC adaptor and unit may be damaged.

• Do not touch the AC adaptor with wet hands to prevent electric shock.

• When connecting with car power (cigarette lighter) adaptor, be sure the input voltage of the adaptor is identical with car voltage.

• Unplug the AC adaptor from the outlet or remove the battery pack when the unit is not used for long periods of time.

• Hold the plug to disconnect the AC adaptor. Do not pull the power cord.

Please always use supplied AC/DC adaptor (AY4129)

Safety and maintenance

• Do not disassemble the unit for laser rays are dangerous to eyes. Any service should be done by qualified service personnel.

• Unplug the AC adaptor to cut the power if liquid or objects get inside the unit.

• Take care not to drop the unit or subject it to strong shocks, which may cause malfunction.

Hearing Safety Listen at a moderate volume.

• Using headphones at a high volume can impair your hearing. This product can produce sounds in decibel ranges that may cause hearing loss for a normal person, even for exposure less than a minute. The higher decibel ranges are offered for those that may have already experienced some hearing loss.

• Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes of sound. So after prolonged listening, what sounds “normal” can actually be loud and harmful to your hearing. To guard against this, set your volume to a safe level before your hearing adapts and leave it there.

To establish a safe volume level:

• Set your volume control at a low setting.

• Slowly increase the sound until you can hear it comfortably and clearly, without distortion.

Listen for reasonable periods of time:

• Prolonged exposure to sound, even at normally “safe” levels, can also cause hearing loss.

• Be sure to use your equipment reasonably and take appropriate breaks.

Be sure to observe the following guidelines when using your headphones.

• Listen at reasonable volumes for reasonable periods of time.

• Be careful not to adjust the volume as your hearing adapts.

• Do not turn up the volume so high that you can’t hear what’s around you.

• You should use caution or temporarily discontinue use in potentially hazardous situations.

• Do not use headphones while operating a motorized vehicle, cycling, skateboarding, etc.; it may create a traffic hazard and is illegal in many areas.

• Important (for models with by-packed headphones): Philips guarantees compliance with the maximum sound power of its audio players as determined by relevant regulatory bodies only with the original model of provided headphones. In case this one needs replacement, we recommend that you contact your retailer to order a model identical to that of the original provided by Philips.

• Traffic safety: do not use while driving or cycling as you may cause an accident.

• Do not expose to excessive heat caused by heating equipment or direct sunlight.

• This product is not waterproof: do not allow your player to be submersed in water. Water entering the player may cause major damage.

• Do not use any cleaning agents containing alcohol, ammonia, benzene, or abrasives as these may harm the player.

• Apparatus shall not be exposed to dripping or splashing. Do not place any sources of danger on the appartus (e.g. liquid filled objects,lighted candles)

• Do not touch the lens!

When the player is in use for a long period of time, the surface will be heated. This is normal.

Handling discs

• Do not attach paper or tape to the disc.

• Keep the disc away from direct sunlight or heat sources.

• Store the disc in a disc case after playback.

• To clean, wipe the disc outwards from the center with a soft, lint-free clean cloth.

On handling the LCD screen

The LCD is manufactured using high precision technology. You may, however, see tiny black points that continuously appear on the LCD. This is a normal result of the manufacturing process and does not indicate a malfunction.

Environmental information

We have reduced the packaging to its minimum and made it easy
