Philips PET714/98 Leaflet

Page 1

Philips Portable DVD Player

PET714

Entertainment that travels with you

Sit back, relax and watch movies on the go on the 7” TFT LCD display of the Philips PET714. Enjoy your favorite DVD movies, MP3-CD and CD music, or admire your JPEG photos anytime, anyplace.

Immerse in AV entertainment on the go

• Play DVD, DVD+/-R, DVD+/-RW and (S)VCD

• Plays MP3-CD, CD and CD-RW music

• Share JPEG image files with Picture CD

For your viewing comfort

• 17.8 cm (7") TFT color LCD display for high quality viewing

• Enjoy movies in 16:9 widescreen format

• Built-in quality stereo speakers

For ultimate convenience

• Enjoy up to 2.5-hour playback with a built-in battery*

• Car adaptor and handy remote control included

• Share entertainment fun with dual headphone jacks

Page 2

Portable DVD Player

PET714/98

Specifications

Picture/Display

• Diagonal screen size (inch): 7 inch

• Display screen type: LCD TFT

• Resolution: 480(w)x234(H)x3(RGB)

• Brightness: 200 cd/m²

• LCD panel type: Anti

• Contrast ratio (typical): 250:1

• Effective viewing area: 154.1x86.6mm

• Pixel pitch: 0.107(w)x0.370(H)mm

• Response time (typical): 30 ms

Sound

• Output Power: 250mW RMS(built-in speakers)

• Output power (RMS): 10mW RMS(earphone)

• Signal to noise ratio: >80dB(line out), 76dB(earphone), >62dB(built-in speakers)

Video Playback

• Playback Media: DVD, DVD+R/+RW, CD-R/CD-

RW, SVCD, Video CD, CD, DVD-R/-RW, MP3CD, Picture CD

• Disc Playback Modes: OSD, A-B Repeat, Angle,

c Menu, Fast Backward, Fast Forward, Repeat,

Dis Shuffle Play, Slow Backward, Slow Forward, Zoom

• Video disc playback system: NTSC, PAL

Audio Playback

• Compression format: Dolby Digital, MP3

• MP3 bit rates: 32 - 320 kbps

• Playback Media: CD, MP3-CD, CD-R, CD-RW

• File systems supported: ISO-9660, Jolliet

-glare polarizer

Connectivity

• DC in: 9V

• Headphone jack: 3.5mm Stereo Headphone x 2

• AV output: Composite (CVBS) x1

Convenience

• Battery charging indication

•Shock proof

Accessories

• AC/DC Adaptor: AY4132 (110-240v, 50/60Hz)

• Car kit: AY4133 (cigarette outlet adaptor, 12vDC)

• Remote control: AY5508 slim remote

• Cables: 1 x AV Cables

• User Manual: English/ French/ Spanish

Power

• Battery Type: Built-in battery

Dimensions

• Master carton dimensions: 245 x 270 x 225 mm

• Master carton quantity: 3

• Master carton weight: 4.32 kg

• Packaging dimensions (W x H x D): 0 x 246 x 68 mm

• Product dimensions (W x H x D): 3 x 39 x 150 mm

• Packaging type: D-box

• Product weight: 0.8 kg

•

Highlights

MP3-CD, CD and CD-RW music

MP3 is a revolutionary compression technology by which large digital music files can be made up to 10 times smaller without radically degrading their audio quality. A singe CD can store up to 10 hours of music.

Share picture CD (JPEG)

Multi-format playability allows you to view images on the go and play most disc formats for maximum disc compatibility and viewing pleasure.

Issue date 2014-02-13

Version: 1.0.3

12 NC: 8670 000 34531 EAN: 87 12581 36976 7

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.
