Philips PET712-12, PET712-05 User Manual

© 2007 Koninklijke Philips Electronics N.V.

All rights reserved.

Document order number:

Register your product and get support at

000000000000

PET712/12

EN User manual 4

Contents

1 Important 6

Safety 6
Notice 14

2 Your Portable DVD player 17

Introduction 17
What’s in the box
Overview of the main unit
Overview of the displays
Overview of the remote control

3 Get started 26

Preparation 26
Connect audio/video cables
Connect power
Install remote control batteries
Connect headphones
Select display language

4 Use your player 34

18
19
21
23

28
29
31
32
32

Turn on 34
Play discs
Adjust volume
Adjust display
Play options

34
35
36
37

5 Adjust settings 41

Playback control options
DivX Video-on-Demand code
Restrict access
Return to default settings
Select TV display aspect ratio
Select video output format
Select audio output
Select digital audio output

41
41
42
44
44
45
46
46

6 Troubleshooting 47

7 Product information 50

1 Important

Safety

a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
f Clean only with dry cloth.
g Do not block any ventilation openings.

Install in accordance with the
manufacturer’s instructions.

h Do not install near any heat sources such

as radiators, heat registers, stoves, or

other apparatus (including ampliers) that

produce heat.

i For countries with a polarized mains, do not

defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has
two blades with one wider than the other.
A grounding type plug has two blades and
a third grounding prong. The wide blade
or the third prong are provided for your

safety. If the provided plug does not t

into your outlet, consult an electrician for
replacement of the obsolete outlet.
Caution: To prevent electric shock, match
the wide blade of the plug to the wide slot,
fully insert.

j Protect the power cord from being

walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.

k Only use attachments/accessories specied

by the manufacturer.

l Use only with the cart, stand, tripod,

bracket, or table specied by the

manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.

m Unplug this apparatus during lightning

storms or when unused for long periods of
time.

n Refer all servicing to qualied service

personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.

o Battery usage CAUTION – To prevent

battery leakage which may result in bodily
injury, property damage, or damage to the
unit:

Install all batteries correctly, + and - as

•
marked on the unit.
Do not mix batteries (old and new or

•
carbon and alkaline, etc.).
Remove batteries when the unit is not

•
used for a long time.

p Apparatus shall not be exposed to dripping

or splashing.

q Do not place any sources of danger on the

apparatus (e.g. liquid lled objects, lighted
candles).

r This product may contain lead and

mercury. Disposal of these materials
may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local
authorities or the Electronic Industries
Alliance: www.eiae.org.

Warning

Never remove the casing of this player.

•

Never lubricate any part of this player.

•

Never place this player on other electrical equipment.

•

Keep this player away from direct sunlight, naked ames

•

or heat.
Never look into the laser beam inside the player.

•

Ensure that you always have easy access to the power

•

cord, plug or adaptor to disconnect the player from the
power.

How to connect a plug

The wires in the mains lead are coloured with the
following code: blue = neutral (N), brown = live
(L).
As these colours may not correspond with the
colour markings identifying the terminals in your
plug, proceed as follows:

Connect the blue wire to the terminal

•
marked N or coloured black.
Connect the brown wire to the terminal

•
marked L or coloured red.
Do not connect either wire to the earth

•
terminal in the plug, marked E (or e) or
coloured green (or green and yellow).

Before replacing the plug cover, make certain
that the cord grip is clamped over the sheath
of the lead - not simply over the two wires.

Mains plug

This apparatus is tted with an approved 13 Amp

plug. To change a fuse in this type of plug proceed
as follows:

a Remove fuse cover and fuse.
b Fix new fuse which should be a BS13625

Amp, A.S.T.A. or BSI approved type.

c Ret the fuse cover.

If the tted plug is not suitable for your socket

outlets, it should be cut off and an appropriate

plug tted in its place.

If the mains plug contains a fuse, this should have
a value of 5 Amp. If a plug without a fuse is used,
the fuse at the distribution board should not be
greater than 5 Amp.
The severed plug must be disposed off to avoid a
possible shock hazard should it be inserted into a
13 Amp socket elsewhere.

Norge

Typeskilt nnes på apparatens bakside.

Observer : Nettbryteren er sekunder t innkoplet.
Den innebygde netdelen er derfor ikke

fraktoplet nettet så lenge apparatet er tilsluttet

nettkontakten.

For å redusere faren for brann eller elektrisk støt,

skal apparatet, ikke utsettes for regn eller fuktighet.

Hearing safety

Listen at a moderate volume.

Using headphones at a high volume can

•
impair your hearing. This product can
produce sounds in decibel ranges that may
cause hearing loss for a normal person, even
for exposure less than a minute. The higher
decibel ranges are offered for those that may
have already experienced some hearing loss.
Sound can be deceiving. Over time your

•
hearing “comfort level” adapts to higher
volumes of sound. So after prolonged
listening, what sounds “normal” can actually
be loud and harmful to your hearing. To
guard against this, set your volume to a safe
level before your hearing adapts and leave it
there.

To establish a safe volume level:

Set your volume control at a low setting.

•
Slowly increase the sound until you can hear

•
it comfortably and clearly, without distortion.

Listen for reasonable periods of time:

Prolonged exposure to sound, even at

•
normally “safe” levels, can also cause hearing
loss.
Be sure to use your equipment reasonably

•
and take appropriate breaks.

Be sure to observe the following guidelines
when using your headphones.

Listen at reasonable volumes for reasonable

•
periods of time.
Be careful not to adjust the volume as your

•
hearing adapts.
Do not turn up the volume so high that you

•
can’t hear what’s around you.
You should use caution or temporarily

•
discontinue use in potentially hazardous
situations. Do not use headphones while
operating a motorized vehicle, cycling,

skateboarding, etc.; it may create a trafc

hazard and is illegal in many areas.

Notice

This product complies with the radio interference
requirements of the European Community.
This product complies with the requirements of
the following directives and guidelines: 73/23/EEC
+ 89/336/EEC + 93/68/EEC

Any changes or modications made to this

device that are not expressly approved by
Philips Consumer Electronics may void the user’s
authority to operate the equipment.

The making of unauthorized copies of copy­protected material, including computer programs,

les, broadcasts and sound recordings, may be

an infringement of copyrights and constitute a
criminal offence. This equipment should not be
used for such purposes.
Recording and playback of material may require
consent. See Copyright Act 1956 and The
Performer’s Protection Acts 1958 to 1972.

Disposal of product and packing material

Your product is designed and manufactured with
high quality materials and components, which can
be recycled and reused.

When this crossed-out wheeled bin symbol is
attached to a product, it means the product is
covered by the European Directive 2002/96/EC.
Please be informed about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and do
not dispose of your old product with your normal
household waste. The correct disposal of your
old product will help prevent potential negative
consequences to the environment and human
health.
All redundant packing material has been omitted.
We have done our utmost to make the packaging
easily separable into mono materials.

Please observe the local regulations regarding the
disposal of packing materials.

This player includes this label:

2 Your Portable

DVD player

Congratulations on your purchase, and welcome

to Philips! To fully benet from the support that

Philips offers, register your product at www.Philips.
com/welcome.

Introduction

Your portable DVD player plays digital video discs
conforming to the universal DVD Video standard.
With it, you can play movies with true cinema
picture quality and stereo or multi-channel sound
(depending on disc and playback set-up).
You can also select sound track, subtitle languages,
and different angle of view (again depending on
DVD disc). Besides, you can set parental control
to prevent your children to see certain discs.
You can play the following discs on the DVD
player:

DVD video disc

a

b
ce

f

h
i

k

m
n

d

g
j

l

a

b
ce

f

h
i

k

m
n

d

g
j

l

Video CDs

CD with JPEG les

What’s in the box

Check and identify the contents of your package:

Portable DVD player

•
7” LCD screen x 2

•
Remote control

•
AC power adaptor

•
Car adaptor (12V)

•
AV cable x 2

•
Car pouch x 2

•
Y-type power cord

•

MP3s

Audio CDs

Overview of the main unit

a

Move cursor up / down•

b /

a

b

c

e

f

h

d

g

a

b

c

e

f

h

d

g

•

•

c

•

d MENU

•

e

•

f SETUP

•

g

•

h – VOL +

•

i POWER

•

j POWER/IR

•

Skip to previous/next chapter, track or
title
Move cursor to left/right

Start or interrupt play

Enter or exit DVD menu

Stop play

Enter or exit system setup menu

Headphones jack

Adjust headphone volume

Turn DVD player on/off

Power/Remote sensor indicator

k OPEN

Open disc door to insert or remove

•
disc

l AV out 1 and 2

Audio/Video output jacks

•

m DC OUT

DC power output to the two screens

•

n DC IN

Power supply socket

•

Overview of the displays

a DISPLAY

2

5

3

4

1

6

7

8

9

10

11

12

13

14

15

16

DVD MENU

OSD

MUTE

TITLE

2

5

3

4

1

6

7

8

9

10

11

12

13

14

15

16

DVD MENU

OSD

MUTE

TITLE

Setup screen display

•

b POWER ON/OFF

Turn the screen on/off

•

c

Adjust display value of the screen

•

d

Headphone jack

•

e – VOL +

Adjust volume

•

f DC IN

Power supply from the DVD player

•

g Audio In L(left) and R(right)

Audio/Video input jacks

•

h VIDEO IN

Video input jack

•

Overview of the remote control

a SETUP

Enter or exit system menu

•

b , OK

Move cursor up / down / left / right.

•

Conrms selection.

•

c OSD

Access available functions

•

d

Skip to previous chapter, track or title.

•

e PLAY/PAUSE

Start / pause / resume play

•

f MUTE

Turn off sound

•

g Numeric Keypad 0 - 9

Input numbers.

•

h SUBTITLE

Select a subtitle language for DVD disc.

•

i RETURN

Return to the PBC (playback control)

•
menu of VCD disc

j A-B

Setup repeated play of a specic section

•

k DVD MENU

Return to main menu of DVD disc

•

l TITLE

Return to title menu of DVD disc

•

m

Skip to the next chapter, track or title

•

n STOP

•

Stop play

o AUDIO

Select an audio language when playing

•
a DVD isc or select an audio mode
(Stereo, Mono-Left or Mono-Right)
when playing a VCD/CD disc

p ZOOM

Enlarge or reduce picture or active

•
image size

3 Get started

A

B

B

A

B

B

Caution

Use the controls only as stated in this user manual.•

Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial numbers. Find the model
number and serial number of this player at the
back or the bottom of your player. Write these
numbers here:
Model No. __________________________
Serial No. ___________________________

Preparation

To use the player in a car, attach the player and
the two screens to the back of the front seat
headrests.

1 Strap the car pouches over your car seat

headrest.

2 Insert the DVD player and the two screens

into the pouches.

3 Close the buckle and adjust the belt until it

ts tightly around the headrest.

Connect audio/video cables

Connect power

Note

Match the color of the AV cable with the jacks: the yellow

•

cable is for the yellow video jack, the red/white cable is for
the red/white audio jacks.

1 Connect AV cable to the main unit and to

the screen.

Caution

Risk of product damage! Ensure that the power supply

•

voltage corresponds to the voltage printed on the back or
the underside of the player.
Risk of electric shock! When you unplug the AC adaptor,

•

always pull the plug from the socket. Never pull the cord.

1 Connect the single-connector end of the

power cord to the
main unit.

2 Connect one end of the double-connector

end of the power cord to the
one screen.

3 Repeat step 2 with the other screen.

DC OUT jack of the

DC IN jack of

4 Connect the power:

To connect power from inside a car:

Car Cigarette Lighter SocketCar Cigarette Lighter Socket

•
Connect the car adaptor cable to the
DC IN jack of the main unit and to the
car cigarette lighter socket.

Install remote control batteries

Caution

Risk of explosion! Keep batteries away from heat, sunshine

•

or re. Never discard batteries in re.

Risk of decreased battery life! Never mix different brands

•

or types of batteries.
Risk of product damage! When the remote control is not

•

used for long periods, remove the batteries.
Perchlorate Material - special handling may apply. See

•

www.dtsc.ca.gov/hazardouswaste/perchlorate.

To connect power from household

•
power sources: Connect the AC adaptor
cable to the
and to the power outlet.

DC IN jack of the main unit

For rst-time use:

1 Remove the protective tab to activate the

remote control batteries.

To replace the remote control batteries:

1 Open the battery compartment.
2 Insert 1 CR2025 3V lithium battery batteries

with correct polarity (+/-) as indicated.

3 Close the battery compartment.

Connect headphones

Caution

Philips guarantees compliance with the maximum sound

•

power of its audio players as determined by relevant
regulatory bodies only with the original model of provided
headphones. In case this one needs replacement, we
recommend that you contact your retailer to order a
model identical to that of the original provided by Philips.

1 Plug the headphones into the jack of the

main unit or screen.

Select display language

English is the default language for screen display.
You can change the display language.

1 Slide the POWER switch on the DVD player

to the

ON position.

2 Press the POWER ON/OFF button on one

of the screens.

3 Press SETUP.

4 Select [General] > [Language].
5 Select the language, then press OK.

4 Use your player

Turn on

1 Slide the POWER switch on the DVD player

to the

ON position.

2 Press the POWER ON/OFF button on the

screens.

To select the previous/next item, press

•
or .

To start search within video/audio, press

•

and hold

during search to adjust search speed.

For Video CDs or Super Video CDs:

•

Press

RETURN to return to the

previous menu.

Adjust volume

or . Briey press or

Play discs

1 Press OPEN on the main unit.
2 Insert the disc with label side facing up.
3 Push down to close the CD compartment.

Play starts automatically.

»

If a menu appears, select an item, then

•
press

OK to start play.

To stop play, press

•
To pause, press

•
again to resume play.

STOP .

PLAY/PAUSE . Press

For headphones connected to the player:

1 Adjust the volume control on the player.

For screen speakers:

1 Adjust the volume control on the screen.

Tip

When headphones are connected, no sound emits from

•

the screen speakers.

Adjust display

Play options

Select audio language

For DVDs that contain two or more audio
languages.

1 During play, press AUDIO repeatedly until

the language is selected.

1 Press DISPLAY on the screen repeatedly to

select:

[Brightness]: adjust the brightness ( )

•
of the screen
[Contrast]: adjust the contrast ( ) of

•
the screen
[Display ratio] : select 16:9 display

•
mode (

) or 6:9 display mode ( )

2 Press or to change value.

Select subtitle language

For DVDs that contain two or more subtitle
languages.

1 During play, press SUBTITLE repeatedly until

the language is selected.

Select DivX video subtitle

1 Press SETUP.
2 Select [Video] > [Mpeg-4 subtitles].
3 Select an option, then press OK to conrm.
4 Press SETUP to exit.

Select audio mode

When you play VCDs/CDs, you can select an
audio mode.

1 Press AUDIO repeatedly until the audio

mode is selected.

Zoom

For DVDs, VCDs and picture CDs, you can zoom
in and out for video images or pictures.

1 Press ZOOM repeatedly to zoom in and out.
2 When the video image or picture is enlarged,

press

Repeat a section

You can repeat a specic section of audio/video

within a title/chapter/track (repeat A-B).

to pan through it.

1 During play, press A-B to mark the start of

the section to repeat.

2 Press and hold or to search for the

end of the section.

3 Press A-B to mark the end of the section.

The selected section plays repeatedly.

»

4 Press A-B to cancel.

Repeat one/all

1 During play, press OSD.
2 Select [Repeat 1] or [Repeat all], then press

OK to conrm.

Random play

For audio CDs and MP3 CDs only.

1 Press OSD.
2 Select [Shufe], then press OK to conrm.
3 Select [On] or [Off], then press OK to

conrm.

Rotate pictures

For picture CDs only.

1 When you view the picture, press OSD.
2 Press to rotate clockwise.
3 Press to rotate counter-clockwise.

4 Press OSD again to exit.

5 Adjust settings

Playback control options

1 Press SETUP.
2 Select [General] > [PBC settings].
3 Select an option, then press OK to conrm.
4 Press SETUP to exit.

DivX Video-on-Demand code

DivX is a popular media technology created

by DivX, Inc.DivX media les contain highly

compressed video with high visual quality that

maintains a relatively small le size. DivX les can

also include advanced media features like menus,
subtitles, and alternate audio tracks. Many DivX

media les are available for download online, and

you can rent and purchase DivX videos with the
DivX VOD (Video on Demand) service. To use
this service, you need the DivX VOD registration

code of this player. For more information and
instructions, visit www.divx.com/vod.

1 Press SETUP.
2 Select [General] > [DivX (VOD)].

The DivX registration code appears

»

3 Write down the number for future reference.
4 Press SETUP to exit.

“DivX, DivX” Certied, and associated logos

are trademarks of DivX, Inc. and are used under
license.

Ofcal DivX® Certied product. Plays all versions
of DivX® video (including DivX® 6) with
standard playback of DivX® media les.

Restrict access

1 Press SETUP.
2 Select [General] > [Parental].
3 Select a setting, then press OK to conrm.

4 Enter the password.

If this is the rst time you restrict access,

•
enter 9999 as the password.

5 Press SETUP to exit.

Set password

1 Press SETUP.
2 Select [General] > [Set password].
3 Enter the current password.

If this is the rst time you restrict access,

•
enter 9999 as the password.

4 Enter the new 4-digit password, then press

OK to conrm.

5 Enter the new password again, then press

OK to conrm.

6 Press SETUP to exit.

Return to default settings

Note

When you return to default settings, the access restriction

•

password will not be reset.

1 Press SETUP.
2 Select [General] > [Factory settings], then

press

OK.

The settings return to their default

»

setting.

3 Press SETUP to exit.

Select TV display aspect ratio

Set the screen format according to how you want
the picture to appear on your TV:

1 Press SETUP.
2 Select [Video] > [TV Display], then select an

option:

[16:9]: For widescreen TVs

•

[4:3 LB]: For normal TVs, for a wide-

•
screen picture. Black bars may appear
on the top and the bottom of the
screen.
[4:3 PS]: For normal TVs, for a full-height

•
picture. The sides of the picture may be
trimmed.

3 Press OK to conrm.
4 Press SETUP to exit.

Select video output format

The default video output format has been chosen
according to format that is broadcast in your
country. If the picture looks unusual, change the
video output.

1 Press SETUP.
2 Select [Video] > [TV Standard].
3 Select an option, then press OK to conrm.
4 Press SETUP to exit.

Select audio output

1 Press SETUP.
2 Select [Audio] > [Dolby].
3 Select an option, then press OK to conrm.
4 Press SETUP to exit.

Select digital audio output

If you connect the player to a sound system that
supports digital sound, select a compatible digital
audio output format.

1 Press SETUP.
2 Select [Audio] > [Digital (SPDIF)].
3 Select an option, then press OK to conrm.
4 Press SETUP to exit.

6 Troubleshooting

Warning

Never remove the casing of this player. •

To keep the warranty valid, never try to repair the
system yourself.
If you encounter problems when using this player,
check the following points before requesting
service. If the problem remains unsolved, go to
the Philips web site (www.Philips.com/support), or
contact Philips (see Contact information). When
you contact Philips, ensure that your player is
nearby and the model number and serial number
are availabl

No power

•

•

•

•

e (see ‘Get star ted’ on page 26).

Ensure that both plugs of the mains cord are
properly connected.
Ensure that there is power at the AC outlet.
Ensure that the battery is inser ted correctly.
Ensure that the car adaptor is connected
correctly.

‘No signal’ is displayed

Ensure that the player is turned on.

•

Ensure that the AV cable is connected.

•
Distorted picture

Clean the disc. With a clean, soft, lint-free

•

cloth, wipe the disc outwards from the
center.
Make sure that the video output format of

•

the disc is compatible with the TV.
Change the video output format to match

•

your TV or progra
format’ on page
The LCD is manufactured using high

•

precision technology. You may, however, see
tiny black points and/or bright points(red,
blue, green) that continuously appear on
the LCD. This is a normal result of the
manufacturing process and does not indicate
a malfunction.

No sound

Ensure that the AV cable is connected correctly.

Cannot play disc

Ensure the disc label is upwards.

•

m (see ‘Select video output

45).

Clean the disc. With a clean, soft, lint-free

•

cloth, wipe the disc outwards from the
center.
Check if the disc is defective by trying

•

another disc.

No response to the remote control

Ensure that the path between the remote

•

control and the player is clear from obstacles.
From a close distance, point the remote

•

control directly at the player.
Replace the remote control batteries.

•

The function does not work for this disc.

•

Refer to the disc instructions.

The player feels warm

When the player is in use for a long period

•

of time, its surface will be heated. This is
normal.

7 Product

information

Note

Product information is subject to change without prior

•

notice.

Dimensions (player) 204 x 168 x 33 mm

(8.0 x 6.6 x 1.3 inches)

Dimensions (screen) 204 x 168 x 33 mm

(8.0 x 6.6 x 1.3 inches)
Weight (player) 1.9 kg / 4.2 pounds
Weight (screen) 1.9 kg / 4.2 pounds
Power supply DC 12V 2.0A
Power Consumption
Operating temperature

range
Laser wavelength
Video system NTSC / PAL / AUTO

<20W

0 - 50°C

650nm
