Page 1
Philips
Internal Drive
CD-ROM
52x
PCCD4852K
Top Class CD-ROM drive
Top performance and reliabilty combined
Top class CD-ROM drive with state of the art performance and reliability
Convenience
• Set-up and use in minutes on any PC or Laptop
Ultimate Convenience
• Step by step guidance for installation and applications
Page 2
Internal Drive
CD-ROM 52x
PCCD4852K/35
Specifications
Storage Media
• Access time (typical): 120ms
• Disc capacity: 650/700 MB CD-R/R
• Disc size: 80,120 mm mm
• Mass storage class compliant
• Reading speeds: 52x on CD-ROM
• Supported formats: CD-Audio,
Recordable, CD-Rewritable, CD-ROM, CD-Text,
Photo CD
Connectivity
• Interface: ATAPI/ E-IDE (UDMA-2)
• Other connections: Analog audio Left/Right out
Convenience
• Ease of Use: How to manual, step by step
Accessories
• Included accessories: User Manual, Warranty
certificate
CD-Extra, CD-
System Requirements
• Hard disk space: 50 MB
• PC OS: Win 98 SE, 2000, ME, XP
• Processor: Intel Pentium MMX200 or higher
•RAM memory: 64 MB
Dimensions
• Product dimensions (WxDxH): 20x15x4.1 cm
• Product weight: 0.093 kg kg
Power
• Adaptor type: DC 5V/12V
• Power consumption: 25 W W
Technical specifications
• Humidity: 5 - 90 %RH (no condensation)
• Operating temperature range: 5 - 45 °C °C
• Safety standards: EN60950, EN60825,UL1950
• EMC standards: EN55022, EMS55024,FCC Part 15
•
Highlights
Ease of use
Ease of use means every customer is able to install
and operate even complex products.
How to.. manual
Photo guided step by step tour through both
installation process and applications
Issue date 2014-02-07
Version: 1.0.4
12 NC: 9082 100 03804
EAN: 87 10895 86299 8
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
