Page 1
Philips
Internal Drive
DVD
8x
ReWriter
PBDVD824B
Make your own DVDs at lightning speed
The highest speed DVD ReWriter
Enjoy the ultimate in speed and digital recording performance with the DVDRW824
internal DVD/CD writer Supports read and write on all recordable(+R/-R) and
ReWrirtable (+RW/-RW) discs
Top Performance
• Burn video, audio and images onto DVD or CD
• 4.7GB storage capacity
Convenience
• Set-up and use in minutes on any PC or Laptop
• Extensive software package for DVD and CD applications
Extreme Reliability and Robustness
• Safe and reliable re-writing with Seamless Link
• Dynamic Calibration ensures writing quality at high speed
• Optimum recording speed for any recordable disc
• Confidently play your DVDs on all drives and set-top devices
Page 2
Internal Drive
DVD 8x, ReWriter
PBDVD824B/30
Specifications
Storage Media
• Disc capacity: 4.7 GB DVD R/RW, 700 MB CD-R/R
• Disc size: 120 mm
• Mass storage class compliant
• Recording media: DVD+R, DVD+RW,
RW, 8cm CDs, 8cm CDs (only in hor. pos.), DVDR, DVD-RW
• Recording format: UDF and ISO 9660
• Access time (typical): 120ms on CD, 140 ms on
DVD
• Write modes: Track at once (TAO), Disc
(DAO), Multi Session (MS), Session at once (SAO),
Packet writing, Fixed packet, Variable packet, Raw
mode burning, Over-burn writing
• Supported formats: CD-Audio, CD-ROM, CD-
CD-Text, CD-Recordable, CD-Rewritable,
Bridge,
Video-CD, Photo CD, CD-Extra, DVD-ROM,
DVD+RW, DVD+R, DVD/R, DVD/RW
• Reading speeds: 12x on DVD-ROM, 7x on
R, 7x on DVD+RW, 40x on CD-R
DVD+
• Recording speeds: 8x on DVD+R, 4
24x on CD-R
• Rewriting speeds: 4x on DVD+RW, 2x on DVD-
W, 10x on CD-RW
R
Connectivity
• Other connections: 12 V DC in, Analog audio Left/
CD-R, CD-
at once
x on DVD-R,
Right out, Master/Slave select jumper, IDE
interface connector, DC power connector, Digital
audio out
• Interface: ATAPI/ E-IDE (UDMA-2)
System Requirements
• PC OS: Windows 98 SE, 2000, ME, XP
• Processor: Pentium III 500MHz or faster
• RAM memory: 128 MB
• Hard disk space: 500MB
Dimensions
• Product weight: 0.95 kg
• Product dimension (WxDxH) inch: 20x25x4 cm
Power
• Adaptor type: DC 5V/12V
• Power consumption: 16 W
Technical specifications
• Humidity: 5 - 90 %RH (no condensation)
• Operating temperature range: 5 - 45 °C
• EMC standards: EN55022, EMS55024,FCC Part 15
• Access time: CD: <120msec (typical), DVD:
0msec (typical)
<14
•
Highlights
High Speed ReWriting
Record your discs faster than ever before
4.7GB storage capacity
4.7GB storage capacity allows you to record 1 hour
of high-quality DVD video or to store data
equivalent to 7 CDs.
Ease of use
Ease of use means every customer is able to install
and operate even complex products.
Extensive Software Package
Complete software bundle offering all functionality in
a simple intuitive way.
Seamless Link
Seamless Link prevents loss of discs caused by
writing errors
Dynamic Calibration
Dynamic Calibration optimizes DVD writing quality
of high-speed DVD+RW drives.
Thermo Balanced Writing
Always the best and fastest recording of any of your
recordable discs
DVD compatibility
DVD Compatibility ensures playability of self-made
DVD discs on as many set-top players and DVDROMs as possible.
Issue date 2014-02-06
Version: 1.0.2
12 NC: 9082 100 03448
EAN: 87 10895 84577 9
