Page 1
Philips
Internal Bulk Drive
PBDV16LSB
simply burn your disc & print your label
Burner & Printer in one
Dual format,double layer 8.5 GB burner with lightScribe technology to print labels direct
to disc with the same drive.
Superior Performance
• 16X top writing speed on DVD+R/-R
• Drive with lightScribe function
• 8.5GB storage capacity on a single sided double layer disc
Convenience
• CD and DVD Burner & Printer in one
•Dual Format
Extreme Reliability and Robustness
• Dynamic Calibration ensures writing quality at high speed
• Confidently play your DVDs on all drives and set-top devices
• Safe and reliable re-writing with Seamless Link
• Optimum recording speed for any recordable disc
Page 2
Internal Bulk Drive
PBDV16LSB/00
Specifications Product highlights
Storage Media
• Recording speeds: 16x on DVD+R, 40x CD-R,
2.4x on DVD+R DL, 8x on DVD-R
• Reading speeds: 16x on DVD-ROM, 10x on
DVD+R DL, 10x on DVD+R, 10x on DVD+RW,
10x on DVD-R, 10x on DVD-RW, 40x on CD-R,
32x on CD-RW
• Disc capacity: 8.5 GB DVD+R DL,4.7 GB DVD+R/
R
• Recording media: 8cm CDs (only in hor. pos.),
CD-R, CD-RW, DVD+R, DVD+R double layer,
DVD+RW, DVD-R, DVD-RW
• Rewriting speeds: 4x on DVD+RW, 4x on DVDRW, 24x CD-RW
• Supported formats: 8cm discs, CD-Audio, CDBridge, Stereo out (2 cinch), CD-I, CDRecordable, CD-Rewritable, CD-ROM, CD-Text,
DVD+R, DVD+RW, DVD-ROM, DVD/R, DVD/
RW, Photo CD, DVD+R DL
• Write modes: Disc at once (DAO), Fixed packet,
Multi session (MS), Over-burn writing, Packet
writing, Raw mode burning, Session at once
(SAO), Track at once (TAO), Variable packet
• Recording format: UDF and ISO 9660
• Access time (typical): 120ms on CD, 140 ms on
DVD
• Mass storage class compliant
Connectivity
• Other connections: 12 V DC in, Analogue audio
Left/Right out 2x, IDE interface connector,
Master/Slave select jumper
Convenience
• Ease of Installation: Plug & Play
• Ease of Use: How to manual, step by step
Accessories
• Included Accessories: 4 mounting screws, CDROM with software + manual, Quick install guide,
User Manual, LightScribe discs
System Requirements
• Hard disk space: 500MB
• PC OS: Windows® 2000 and XP
• Processor: Pentium III 500MHz or faster
• RAM memory: 128 MB
Dimensions
• Product dimension (WxDxH) inch: 20x15x4 cm
• Product weight: 0.95 kg
Power
• Adaptor type: DC 5V/12V
• Power consumption: 25 W
Technical specifications
• Humidity: 5 - 90 %RH (no condensation)
• Operating temperature range: 5 - 50 °C
• Safety standards: EN60950, EN60825,UL1950
• EMC standards: EN55022, EMS55024,FCC Part
15
• Access time: CD: <120msec (typical), DVD:
<140msec (typical)
•
16X write speed on DVD+R/-R
Top speed 16X recording on DVD+R and DVD-R discs
LightScribe
LightScribe Direct Disc Labelling makes messy marker
pens and awkward stick-on labels a thing of the past!
Simply flip over your specially coated recordable/
rewritable CD or DVD, re-insert it in the drive and 'burn'
fantastic labels with the look and quality of professional
silk-screened labels. You can mix text and personalized
gr aph ics usi ng t he s oft war e pr ovi ded and eve n ad d to the
label at a later date. It makes finding your archived
movies, music, photos and data files easier than ever
before.
8.5GB storage capacity
Single sided double layer disc with 8.5 GB storage
capacity
Burner & Printer in one
LightScribe technology adds the label printing function to
your CD and DVD burner.
Dual Format
Drive supporting both +R/+RW and -R/RW DVD formats
Dynamic Calibration
Dynamic Calibration optimizes DVD writing quality of
high-speed DVD+RW drives.
Seamless Link
Seamless Link prevents loss of discs caused by writing
errors
Issue date 2007-12-06
Version: 2.0
12 NC: 9082 100 05475
EAN: 87 10895 91881 7
© 2007 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
