Philips DVD/VCR Home Theater System

MX5100VR

Total Immersion in Movies

Bothered by the various boxes under your TV? With Philips DVD/VCR home theater system solutions, you can now record & play movies & music entertainment from practically any disc format at the very comfort of your home.

Ultimate convenience

• VCR Plus+ for quick and easy programming

• Front AV input ensures easy connection to external devices

• One Touch Recording

Superb audio and video performance

• Cinema Center Speaker™ for realism cinematic experience

• DTS Digital Surround for multi-channel surround sound

• Dolby Digital for movies or concerts in full surround sound

• Progressive Scan component video for optimized image quality

• Advanced Class D Amplifier™for compact, powerful sound

Plays practically any disc format

• Movies: DVD, DVD+R/RW, DVD-R/RW, (S)VCD, VHS Tapes

• Music: CD, CD-R/RW and MP3-CD

• Photos: Picture CD (JPEG)

Page 2

DVD/VCR Home Theater System


Highlights

MX5100VR/37

VCR Plus+

With the VCR Plus+ system, all you need to do to program your video recorder is to enter the ‘Pluscode’ – a single code of up to nine digits (but usually less) that is printed next to each TV program in most TV guides.

Front AV Input

Front AV Input makes it much more c

onvenient to connect external devices like audio equipment, games and video cameras. It's the easy way to enjoy an extra audio sensation or a totally immersive gaming experience.

One Touch Recording

Simply pressing the REC/OTR key will start a rec

ording. If ‘Direct Record’* is activated, the (DVD) Video Recorder will automatically look up the channel to which the TV set is tuned and record from the same channel.* available in Europe only.

sensation of being not just in the cinema but in the movie itself.

DTS Digital Surround

DTS delivers superior surround sound with your DVD movies.

Dolby Digital Surround

Because Dolby Digital and DTS, the world's l

eading digital multi-channel audio standards, make use of the way the human ear naturally processes sound, you experience superb quality surround sound audio with realistic spatial cues.

Progressive Scan

6x Class D Digital Amplifier

When it comes to perfect audio there is no roo

m for distortion. Digital amplifiers generate far less heat than standard analog amplifiers, allowing for smaller set enclosures. Philips Class D Amplifiers™ provide dramatically enhanced sound quality over digital amplifiers used by competitors as they are designed to control and reduce EMI (Electro Magnetic Interference). In addition, the Class D Amplifiers™ use a closed loop design which suppresses distortion and loss of audio quality. The overall result is enhanced audio performance from a much smaller package.

Multi-format Movies and VHS

Multi-format playability allows you to play m

ost disc formats and VHS tapes for maximum

compatibility and viewing pleasure.

Multi-format Music

Multi-format playability allows you to play m

ost disc formats for maximum disc

compatibility and listening pleasure.

Picture CD (JPEG)

Multi-format playability allows you to view i

mages in the comfort of your living room and play most disc formats for maximum disc compatibility and viewing pleasure.

Cinema Center Speaker™

Recreate and experience realism cinematic e

xperience right in your environment with Cinema Center Speaker™. With a wider sweet spot delivered by four multi-directional woofers and a high frequency tweeter positioned precisely at different angles, more sound depths are distinguished from front and background and action from dialogue. Natural and crystal clear sound reproduction are created through the revolutionary new 2" full range woofers to give an incredible 'through the screen' experience which creates the

Progressive Scan doubles the vertical resolution of the image resulting in a noticeably sharper picture. Instead of sending a field comprising the odd lines to the screen first, followed by the field with the even lines, both fields are written at one time. A full image is created instantaneously, using the maximum resolution. At such a speed, your eye perceives a sharper picture with no line structure.

Quick Start Guide

To guide you through the initial set-up of your s

ystem, Philips delivers a Quick Start Guide that uses an easy approach with clearly defined graphics and colors to guide you through the basic steps of connection and obtaining picture and sound. These basic steps are clearly described on one page in the packaging box, making setup quick and simple.

Page 3

DVD/VCR Home Theater System

Specifications

MX5100VR/37

Picture/Display

• Aspect ratio: 4:3, 16:9

Sound

• D/A converter: 24 bit, 96 kHz

• Distortion and Noise (1kHz): 90 dB

• Equalizer settings: Digital,

• Frequency response: 30-20000 Hz

• Signal to noise ratio: >120 dB (A-weighted)

• Sound Enhancement: Digital Sound Control 4 es

mod

• Sound System: Dolby Digital (AC-3), DTS, Matrix

rround

• Total Sound Power (RMS): 450 W

Jazz, Optimal, Rock

Loudspeakers

• Satellite Speaker: 2 way, Magnetically shielded front

• Satellite speaker freq range: 120-20000 Hz

• Satellite speaker impedance: 4 ohm

• Satellite speaker drivers: 1 piezo, 3" full range fer

woo

• Center Speaker: 2 way, Cinema Center speaker,

Magnetical

• Center freq range: 120-20000 Hz

• Center speaker impedance: 4 ohm

• Center speaker drivers: 1.75" tweeter, 4x 2" mid

rang

• Subwoofer freq range: 30-120 Hz

• Subwoofer impedance: 4 ohm

• Subwoofer driver: 6.5" high efficiency woofer

ly shielded

e woofers

Video Playback

• Compression formats: MPEG1, MPEG2

• Playback Media: DVD+RW, DVD+R, DVD-RW

(Video mode), DVD-R, DVD-Video, SVCD, Vid CD

• Disc Playback Modes: A-B Repeat, Repeat

• Head Cleaner: Auto

•Loader Type: Tray

• Number of Discs: 1

• Video disc playback system: NTSC, PAL

• Video tape playback system: PAL

• Videotape Enhancements: Turbo Drive Deck

Video Recording

• Max recording time on DVD: 0 hr

• Recording enhancements: Direct R

One Touch Record (OTR)

• Recording system: PAL

ecord, Erase,

Audio Playback

• Compression format: Dolby Digital, DTS, MP3,

PCM

• Playback Media: CD, CD-R, CD-RW, MP3-CD

• Disc Playback Modes: Fas

Next/Previous Album Search, Next/Previous Track Search, Repeat one/album/all, Shuffle Play

• MP3 bit rates: 112-320 kbps

t Forward/Backward,

Storage Media

• Recording media: VHS

Tuner/Reception/Transmission

• Aerial Input: 75 ohm coaxial (IEC75)

• Auto digital tuning

• Auto store

• Number of Preset Channels: 40

• Tuner Bands: AM, FM Stereo

• TV system: NTSC

Connectivity

•Front / Side connections: Audio L/R in, CVBS in

• Other connections: Analog audio Left/Right in, mponentVideo out Progressive, Composite

Co video (CVBS) input, Composite video (CVBS) out, Digital coaxial out, FM Antenna, MW Antenna, SVideo out, TV in (antenna cable)

Convenience

• Child Protection: Parental Control

• Display Type: FTD, On Screen (OSD)

• Pre-set Channels: 99

• Programmable Events: 6

• Programming Period: 1 month

• Programming/Timer Enhancements: Daily/Weekly

peat Program, Manual Timer, One Touch

Re Recording, VCR Plus+

• Remote Control: Multi-functional

Accessories

• Included Accessories: 1x center speaker, 1x

subwoofer, 2x front satellite speakers, 2x rear satellite speakers, AC Power Cord, AM/FM Antenna, Audio Cable, Coax RF antenna cable, Quick Use Guide, Remote Control, User Manual, Video Cable, Warranty certificate

• Included batteries: 2x Longlife AA

Dimensions

• Center speaker dimensions (W x H x D):

435 x 72 x 63.5 mm

• Center Speaker Weight: 1.3 kg

• Packaging dimensions (W x H x D):

0 x 469 x 540 mm

•Set dimensions (W x H

• Set weight: 7.4 kg

• Subwoofer dimensions (W x H x D):

6 x 391 x 432 mm

• Subwoofer Weight: 5.72 kg

• Surround Speaker dimensions (W x H x D):

94 x 155 x 89 mm

• Surround speaker Weight: 0.65 kg

• Weight incl. Packaging: 18.22 kg

x D): 435 x 99 x 362 mm

Power

• Power supply: 110V, 50/60 Hz

• Standby power consumption: < 5 W

•

Issue date 2009-05-08

Version: 3.0.4

12 NC: 9073 100 11603 UPC: 0 37849 93961 1

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.
