Philips MX3691C User Manual

36" Stereo Remote Color Monitor/Receiver

(screen size measured diagonally)

• Two-tuner PIP

• MagnaVue™ Plus

• MagnaGlo™ remote control

• Remote Locator™

• Dynamic comb filter

• Video DNR

• Audio/video jack panel

• dbx

hi-fi stereo sound system with surround sound jacks

• Incredible Stereo™

Color Television

MX3691B

• SmartSound™

• SmartPicture™

• Surf™

• SmartMute™

• First Time Setup

• Onscreen Clock

Universal TV/VCR/Cable Remote

(Remote # RCU81E)

Color Television

MX3691B


MagnaVue™ Plus

A unique combination of contrast enhancement, color enrichment technologies, and LTI™ that produces deeper, more vibrant colors with an unrivaled picture that’s larger than life.

Luminance Transience Improvement (LTI™)

A new generation of edge enhancement technology applied directly to the video processing circuitry creates a remarkable increase in clarity and sharpness at the point of transition from dark to light areas of the video image. When coupled with other recent advancements, LTI™ produces a picture so sharp and well defined that you’ll never want to go to the movies again.

Green Stretch

Advanced chroma processing circuitry takes automatic flesh-tone correction to a new level, making flesh-tones more true-to-life for eye-popping realism in your TV picture.

Two-Tuner PIP Dynamic Comb Filter Improved Image Definition (IID™) Video DNR (Dynamic Noise Reduction) SmartPicture™ 36'' Invar Mask Picture Tube Black Stretch Blue Stretch

Remote Control

MagnaGlo™ Remote Control

No more fumbling in the dark to access TV and VCR functions. Just press the button on the remote control and all buttons on the remote control glow.

Remote Locator™

Lost or misplaced remotes are easy to find! Simply press the POWER button on the TV. The words “Locating Remote” appear on the screen and the remote control beeps–leading you right to it. Press any key on the remote to stop the beeping.

Universal TV/VCR/Cable Remote

Controls all features and functions of this monitor/receiver with direct menu access, including the Two-Tuner A/B Switch, Smart Window™ PIP with On/Off, Position, Freeze, Swap, Source, and PIP CHANNEL ; Multimedia Mode, Incredible Stereo™, Surf™, and the dual A/V input/ tuner switch. It also activates the exclusive SmartSound™, SmartClock™, and SmartPicture™ options. In addition, this remote controls all important operating features and functions of virtually all infrared VCRs, most brands of DVD Video players, virtually all brands of DBS receivers, and on/off as well as CHANNEL functions on most cable converter/decoders. (Remote # RCU81E)

Convenience

Multimedia Mode

Simply press the MULTIMEDIA button on the remote control and sequentially scroll through the various inputs. The SmartPicture™ option is automatically set to MULTIMEDIA for optimal adjustment of customer controls. The third time the MULTIMEDIA button is pressed, the TV returns to the original tuner source and all settings revert to their previous condition…automatically!

SmartSurf™

Eliminates the frustration of trying to remember what channels had programs of interest while channel surfing. After establishing the SmartSurf™ configuration with the user-friendly menu, store up to ten stations in the SmartSurf™ memory and then surf only those channels at the touch of a button. The versatility of this feature is enhanced by the availability of an onscreen list of the channels stored and offers the option of adding or deleting channels in the list by remote control.

UP DN

SmartClock™ SmartMute™ Easy First Time Setup Alternate Channel Onscreen Clock with Sleep Timer and Alarm Timer Parental Control Trilingual Onscreen Display Auto Programming Closed Caption Onscreen Volume Bar

Sound

Surround Sound

Experience the full three-dimensional effect of a live musical performance or theater with four or more speakers. The front left and right speakers contain directional sounds creating stereo spread or what’s known as the “wall of sound” as well as other important effects that help “steer” the audio more realistically to the listener’s ears. The rear speakers help to recreate the reflective ambience of the original room in which the audio was recorded. They generate short echoes and delays that help make the entire audio experience more lifelike.

SmartSound™ dbx®Hi-Fi Stereo Sound System with Surround Sound Jacks Incredible Stereo™ Tone Controls

Audio/Video Jack Panel

Audio/Video Jack Panel (J834)

The A/V jack panel on the back of this set includes dual audio/video inputs for connection of a VCR, DVD Video player, Web browser, or other accessory equipment; variable audio outputs which allow sound from TV or accessories to be routed through a home audio system; standard video output for connection to a VCR; S-Video input for connection of a highresolution video accessory, and dual RF inputs for tuner “A” and tuner “B”.

Surround Sound Jacks

Additional Features Include:

• Channel edit

• Total remote menu format tuning with multicolor onscreen graphics

• 181-channel capability

• 4-way cursor control

• Random channel access

• Programmable scan tuning

• Status recall

• Mono/stereo/SAP select

• Cable/normal select

• Two 5" oval, full-range speakers with menu-selectable speaker switch

UPC: 037849865415 Product dimensions: 33"W x 29"H x 24.2"D Product weight: 181 lbs. Carton dimensions: 37.1"W x 32.6"H x 27.1"D Carton weight: 185 lbs. Master pack: 1

Carton Contains: 36" Stereo Remote Color Monitor/Receiver, MagnaGlo Universal TV/VCR/CBL Locator Remote Control w/Batteries, Operating Instructions, Warranty Information

Subject to modification without notice

* MagnaVue, MagnaGlo, Incredible Stereo, Remote Locator, SmartSound,

LTI, IID, SmartPicture, SmartClock, SmartMute, and SmartSurf are trademarks of Philips Consumer Electronics Company. dbx is a registered trademark of dbx , Inc, Sunnyvale, CA.
