3121 235 20121

Your T elevision’s Directions for Use

Color

Television

Color

Television

Read this manual first!

Congratulations on purchasing this Philips product. We’ve included everything you need to get started. If you have any problems, Philips Representatives can help you get the most from your new product by explaining:

• Hookups,

• First Time Setup, and

• Feature Operation. Do not attempt to return this product to the store.

For fast help, call us first!

1-800-531-0039

Thank you for making Philips a part of your home!

Once your MAGNAVOX purchase is registered, you’re eligible to receive all the privileges of owning

a MAGNAVOX product. So complete and return the Warranty Registration Card enclosed with your

purchase at once. And take advantage of these important benefits.

Return your Warranty Registration card today to ensure you

receive all the benefits you’re entitled to.

Congratulations

on your

purchase,

and welcome to the

“family!”

Dear MAGNAVOX product owner:

Thank you for your confidence in MAGNAVOX. You’ve selected one of the best-built, best-backed products available today. And we’ll do everything in our power to keep you happy with your purchase for many years to come.

As a member of the MAGNAVOX “family,” you’re entitled to protection by one of the most comprehensive warranties and outstanding service networks in the industry.

What’s more, your purchase guarantees you’ll receive all the information and special offers for which you qualify, plus easy access to accessories from our convenient home shopping network.

And most importantly you can count on our uncompromising commitment to your total satisfaction. All of this is our way of saying welcome–and thanks for investing in a MAGNAVOX product.

Sincerely, Philips Consumer Electronics Company

Know these

safety

symbols

t This “bolt of lightning” indicates uninsulated material within your unit which may cause an

electrical shock. For the safety of everyone in your household, please do not remove product covering.

s The “exclamation point” calls attention to features for which you should read the enclosed lit-

erature closely to prevent operating and maintenance problems. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT

TO RAIN OR MOISTURE. CAUTION: To prevent electric shock, match wide blade of plug to wide slot, and fully insert. ATTENTION: Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la

borne correspondante de la prise et pousser jusqu’au fond.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Warranty

Verification

Registering your product within 10 days confirms your right to maximum protection under the terms and conditions of your MAGNAVOX warranty.

Owner

Confirmation

Your completed Warranty Registration Card serves as verification of ownership in the event of product theft or loss.

Model

Registration

Returning your Warranty Registration Card right away guarantees you’ll receive all the information and special offers which you qualify for as the owner of your model.

P.S. Remember, to get the most from your MAGNAVOX

product, you must return your Warranty Registration Card within 10 days. So please mail it to us right now!

Hurry!

Visit our World Wide Web Site at http://www.philipsusa.com

IMPORTANT SAFETY INSTRUCTIONS

Read before operating equipment

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any of the ventilation openings. Install in

accordance with the manufacturers instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. Apolarized plug has two blades with one wider than the other. A grounding type plug has two blades and third grounding prong. The wide blade or third prong are provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with a cart, stand, tripod, bracket, or table

specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid

injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15. This product may contain lead and mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance: www.eiae.org

16. Damage Requiring Service - The appliance should be serviced by qualified service personnel when:

A. The power supply cord or the plug has been damaged;

B. Objects have fallen, or liquid has been spilled into the

appliance; or

C. The appliance has been exposed to rain; or D. The appliance does not appear to operate normally or

exhibits a marked change in performance; or

E. The appliance has been dropped, or the enclosure

damaged.

17. Tilt/Stability - All televisions must comply with recommended international global safety standards for tilt and stability properties of its cabinet design.

• Do not compromise these design standards by applying excessive pull force to the front, or top, of the cabinet which could ultimately overturn the product.

• Also, do not endanger yourself, or children, by placing electronic equipment/toys on the top of the cabinet. Such items could unsuspectingly fall from the top of the set and cause product damage and/or personal injury.

18. Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer.

19. Power Lines - An outdoor antenna should be located away from power lines.

20. Outdoor Antenna Grounding - If an outside antenna is connected to the receiver, be sure the antenna system is grounded so as to provide some protection against voltage surges and built up static charges.

Section 810 of the National Electric Code, ANSI/NFPA No. 70-1984, provides information with respect to proper grounding of the mats and supporting structure grounding of the lead-in wire to an antenna discharge unit, size of grounding connectors, location of antenna-discharge unit, connection to grounding electrodes and requirements for the grounding electrode. See Figure below.

21. Object and Liquid Entry - Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings.

Example of Antenna Grounding as per NEC - National Electric Code

Note to the CATV system installer: This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides

guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

(NEC SECTION 810-20)

TABLE OF CONTENTS

NOTE: It is possible that this owner's manual may be used with several different television models. Not all features (and drawings) discussed in this manual will necessarily match those found with your television system. This is normal and does not require you contacting your dealer or requesting service.

Magnavox™, SmartLock™, SmartPicture™, SmartSound™

are all registered trademarks of Philips Consumer Electronics Company.

Introduction

Welcome/Registration of Your TV . . . . . . . . . . . . . . . . . . .2

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Picture Menu

How to Use the Picture Adjustment Controls . . . . .5

How to use the DNR (Digital Noise Reduction) Control . . . .6

How to use the Contrast + (Black Stretch) Control . . . . . . .7

Sound Menu

Using the Treble, Bass, and Balance Controls . . . .8

How to Use the AVL Control . . . . . . . . . . . . . . . . . . . . . . .9

Setting the Incredible Surround Control . . . . . . . . . . . . . .10

Setting the TV for SAP (Secondary Audio Programs) . . . .11

Setting the TV to Receive Stereo Programming . . . . . . . .12

Features Menu

Using the Timer Controls . . . . . . . . . . . . . . . . . .13

Understanding the SmartLock Controls . . . . . . . . . . . . . .14

Setting Up the SmartLock Access Code . . . . . . . . . . . . . .15

How to Block Channels . . . . . . . . . . . . . . . . . . . . . . . . . .16

How to Clear All Channels at the Same Time . . . . . . . . . .17

How to Block All Channels at the Same Time . . . . . . . . .18

Blocking Programming Based on Movie Ratings . . . . . . .19

Blocking Programming Based on TV Ratings . . . . . . . . .20

Using the SmartLock Blocking Options . . . . . . . . . . . . . .21

How to Use the Closed Captioning Control . . . . . . . . . . .22

Audio/Video Connections

Using the A/V Inputs Jacks . . . . . . . . . . . . . . . . .23

Using the A/V Output Jacks . . . . . . . . . . . . . . . . . . . . . . .24

Using the S-Video Input Jack . . . . . . . . . . . . . . . . . . . . . .25

Remote Control Use

Setting up the Sleeptimer Option . . . . . . . . . . . . . .26

Setting the SmartPicture Control . . . . . . . . . . . . . .27

Setting the SmartSound Control . . . . . . . . . . . . . . . . . . . .28

Using the Surf Button (Alternate Channel) . . . . . . . . . . . .29

Remote Use with Accessory Devices (Direct Method) . . .30

Remote Use with Accessory Devices (Code Entry) . . . . .31

Remote Use with Accessory Devices (Search Method) . . .32

Remote Code Entry List . . . . . . . . . . . . . . . . . . . . . . .33-34

Remote VCR Related Buttons . . . . . . . . . . . . . . . . . . . . .35

General Information

Troubleshooting Tips . . . . . . . . . . . . . . . . . . . . . .36

Glossary of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Here are a few of the special features built into this new Color Television:

SmartLock™ feature allows you to block the viewing of certain channels or external audio/video connections where you might not want your children viewing inappropriate material.

Infrared Remote Control works your TV set, and allows you to program certain features with the press of one button. Can also be used with accessory devices such as VCRs, DVDs, Cable Boxes, and more.

Audio/Video Jackpanel for direct connections of accessory devices. Audio/Video Inputs and Outputs.

Standard broadcast (VHF/UHF) or Cable TV (CATV)

channel capability. Closed Captioning allows the viewer to read TV program

dialogue or voice conversations as on-screen text. Automatic Programming of Channels for quick and easy

selection of favorite stations available in your area. On-screen Features (in either English or Spanish) show

helpful messages for setting of TV controls. On Timer automatically turns the TV ON at a preset time,

and channel.

Sleeptimer automatically turns the TV OFF at preset times. SmartPicture™ allows you to set the picture color, tint, con-

trast, etc. for various types of programming such as Sports, Movies, Personal, Weak Signals or Multi Media with the push of one button.

SmartSound™ controls allow you to set the sound controls for various types of listening programs such as Personal (sound controls the way you set them), Theatre, Music, or Voice with the push of one button.

Treble, Bass and Balance controls to enhance the television’s sound.

Let's

Look

Inside!

HOW TO USE THE PICTURE ADJUSTMENT CONTROLS

o adjust your TV picture controls,

select a channel and follow the

steps shown below:

Press the MENU button on the

remote to display the on-screen menu.

Press the CURSOR UP 䊳 or

DOWN ■ buttons until the word PIC- TURE is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to display the PICTURE menu

features.

Press CURSOR UP 䊳 or DOWN

■ buttons to scroll the Picture features and highlight the control you wish to adjust (Brightness, Color, Picture, Sharpness, Tint, or Color Temp.).

Press the CURSOR RIGHT

䊳䊳

or the CURSOR LEFT 䊴䊴 buttons

to adjust the selected control or to make selections for the Color Temp. control (Normal, Warm, or Cool).

Press the CURSOR UP 䊳 or

DOWN ■ buttons to select and adjust

other Picture Menu controls.

When finished, press the STATUS

/EXIT button to remove the menu

from the TV’s screen.

BRIGHTNESS Press the 䊳䊳

or 䊴䊴 buttons until darkest parts of

the picture are as bright as you prefer.

COLOR

Press the 䊳䊳 or 䊴䊴 buttons to

add or eliminate color.


Press the 䊳䊳 or 䊴䊴 buttons

until lightest parts of the picture show good detail.

SHARPNESS

Press the 䊳䊳 or 䊴䊴 but-

tons to improve detail in the picture.

TINT

Press the 䊳䊳 or 䊴䊴 buttons to

obtain natural skin tones.

COLOR

TEMP Press the 䊳䊳 or 䊴䊴 but-

tons to select NORMAL, COOL, or WARM picture preferences. (NORMAL will keep the whites, white; COOL will make the whites, bluish; and WARM will make the whites, reddish.)

SMART HELP

Main

Picture Sound Features Install

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

Brightness Color Picture Sharpness Tint More...

POWER

TV/VCR

5 89 0

MUTE

SMARTSMART



Brightness Color Picture Sharpness Tint Color T emp.


Brightness

Color Picture Sharpness


Tint

Brightness

Color T emp.

Color

Picture Sharpness Tint


Color T emp.

Brightness Color


Sharpness Tint Color T emp.


Brightness Color Picture

Sharpness

Tint Color T emp.


Brightness Color Picture Sharpness

Tint

Color T emp.


Brightness Color Picture Sharpness Tint

Color T emp.

Normal

Warm

Cool

HOW TO USE THE DNR (NOISE REDUCTION) CONTROL

or reasons such as poor cable recep-

tion, the picture can sometimes appear slightly “speckled” (or has signal noise shown in the picture). The DNR (Dynamic Noise Reduction) control can help eliminate this type of interference and improve the quality of the picture.

Press the MENU button on the

remote to display the on-screen menu.

Press the CURSOR UP䊳or

CURSOR DOWN ■ button until the

word PICTURE is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to display the PICTURE menu

features.

Press the CURSOR UP 䊳

CURSOR DOWN ■ button

to scroll

the Picture menu features until the word

DNR is highlighted.

Press the CURSOR RIGHT

䊳䊳

button turn the DNR feature ON or OFF.

When finished, press the STATUS

/EXIT button to remove the menu

from the TV’s screen.

“Noise” Reduction is a video

adjustment feature that affects the

picture quality of the TV not the sound.

SMART HELP

Main

Picture Sound Features Install

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

Brightness Color Picture Sharpness Tint More...

POWER

TV/VCR

5 89 0

SMARTSMART



Brightness Color Picture Sharpness Tint Color T emp.


Color Picture Sharpness Tint Color T emp. DNR

VOL

MUTE


Color Picture Sharpness Tint Color T emp.

DNR


Color Picture Sharpness Tint Color T emp.

DNR

Off

HOW TO USE THE CONTRAST + (BLACK STRETCH) CONTROL

he Contrast + (Black Stretch) con-

trol helps to “sharpen” the picture quality. The black portions of the picture become richer in darkness and the whites become brighter.

Press the MENU button on the

remote to display the on-screen menu.

Press the CURSOR UP䊳or CUR-

SOR DOWN ■ button until the word PICTURE is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to display the PICTURE menu

features.

Press the CURSOR UP 䊳

CURSOR DOWN ■ button

to scroll

the Picture menu features until the word

CONTRAST + is highlighted.

Press the CURSOR RIGHT

䊳䊳

button turn the CONTRAST + feature ON or OFF.

When finished, press the STATUS

/EXIT button to remove the menu

from the TV’s screen.

Main

Picture Sound Features Install

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

Brightness Color Picture Sharpness Tint More...

POWER

TV/VCR

5 89 0

MUTE

SMARTSMART



Brightness Color Picture Sharpness Tint Color T emp.


Picture Sharpness Tint Color T emp. DNR Contrast +


Color Picture Sharpness Tint Color T emp.

Contrast +


Color Picture Sharpness Tint Color T emp.

Contrast +

Off

HOW TO ADJUST THE BASS, TREBLE, BALANCE CONTROLS

esides the normal volume level con-

trol, your TV also has Bass, Treble and Balance sound controls. The TREBLE control effects only the high frequency sound coming from the TV enhancing the highs; while the BASS control effects only the low frequency sound coming from the TV enhancing the lows. The Balance control adjusts the sound level being heard from each speaker.

Press the MENU button on the

remote to display the on-screen menu.

Press the CURSOR UP䊳or CUR-

SOR DOWN ■ button until the word

SOUND is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to display the SOUND menu

features.

Press the CURSOR UP 䊳

CURSOR DOWN ■ button

to scroll

the Sound menu features until the words TREBLE, BASS or BALANCE are highlighted.

Press the CURSOR RIGHT 䊳䊳 or LEFT 䊴䊴 button to adjust the Treble, Bass or Balance controls.

When finished, press the STATUS

/EXIT button to remove the menu

from the TV’s screen.

Main

Picture Sound Features Install

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

Brightness Color Picture Sharpness Tint More...

POWER

TV/VCR

5 89 0

MUTE

SMARTSMART


Main

Picture Sound Features Install

Sound

Treble Bass Balance AVL Incr. Surround SAP

Sound

Treble Bass Balance AVL Incr. Surround SAP

Treble Bass Balance AVL Incr. Surround More...

Sound

Treble Bass Balance AVL Incr. Surround SAP

OW TO USE THE AVL (AUTOMATIC VOLUME LEVELER) CONTROL

n most cases, the volume levels com-

ing from broadcast programming or commercials are never the same. With the AVL (Audio Volume Leveler) control turned ON, you can have the TV level out sound that is being heard. This makes for a more consistent sound by reducing the peaks and valleys that occur during program changes or commercial breaks. To turn the AVL ON, follow these steps.

Press the MENU button on the

remote to display the on-screen menu.

Press the CURSOR UP䊳or CUR-

SOR DOWN ■ button until the word SOUND is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to display the SOUND menu

features.

Press the CURSOR UP 䊳

CURSOR DOWN ■ button

to scroll

the Sound menu features until the word

AVL is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to turn the AVL control ON or

OFF.

When finished, press the STATUS

/EXIT button to remove the menu

from the TV’s screen.

Main

Picture Sound Features Install

Brightness Color Picture Sharpness Tint More...

Main

Picture Sound Features Install

Treble Bass Balance AVL Incr. Surround More...

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

POWER

TV/VCR

5 89 0

SMARTSMART


Sound

Treble Bass Balance AVL Incr. Surround SAP

VOL

MUTE

Sound

Treble Bass Balance AVL Incr. Surround SAP

Sound

Treble Bass Balance AVL Incr. Surround SAP

Off

SETTING THE INCREDIBLE SURROUND CONTROL

he Incredible Surround feature

adds greater depth and dimension to both monaural (MONO) and stereo TV sound. With the control turned ON the TV's speakers can add even wider sound separation to normal broadcasts.

Press the MENU button on the

remote to display the on-screen menu.

Press the CURSOR UP䊳or CUR-

SOR DOWN ■ button until the word

SOUND is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to display the SOUND menu

features.

Press the CURSOR UP 䊳

CURSOR DOWN ■ button

to scroll

the Sound menu features until the words INCR. SURROUND are highlighted.

Press the CURSOR RIGHT 䊳䊳

button to set the Incredible Surround

control as follows:

MONO: When in the Mono Sound Mode, Incredible Surround can be set to Mono or Spatial.

STEREO: When in the Stereo Sound Mode, Incredible Surround can be set to Stereo or Incredible Surround.

When finished, press the STATUS

/EXIT button to remove the menu

from the TV’s screen.

NOTE: If the TV signal is

being received from a mono source, pressing the INCR. SURR. button will cause either MONO or SPATIAL to appear on the the screen. If the TV signal is being received from a stereo source and the “Sound” control is set to Stereo, pressing the INCR. SURR. button will toggle two choices: STEREO and INCR. SURROUND.

SPATIAL – widens the “Mono” sound, simulating a broader, fuller sound.

INCR. SURROUND – widens the “Stereo” sound, simulating a broader, fuller sound.

SMART HELP

Main

Picture Sound Features Install

Brightness Color Picture Sharpness Tint More...

Main

Picture Sound Features Install

Treble Bass Balance AVL Incr. Surround More...

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

POWER

TV/VCR

5 89 0

MUTE

SMARTSMART


Sound

Treble Bass Balance AVL Incr. Surround SAP

Sound

Treble Bass Balance AVL Incr. Surround SAP

Sound

Treble Bass Balance AVL Incr. Surround SAP

Spatial

OR (if in Stereo)

Incr. Surround

SETTING THE TV FOR SAP (SECONDARY AUDIO PROGRAMS)

SAP signal is an additional part of

the stereo broadcast system. Sent as a third audio channel, a SAP signal can be heard apart from the current TV program sound. TV stations are free to use SAP for any number of purposes.

If a SAP signal is not present with a selected program, the SAP option cannot be selected. Also, if SAP is selected on a channel (with SAP) and you select another channel, when you return to the original channel, SAP will be OFF. You will have to reselect the SAP feature.

Press the MENU button on the

remote to display the on-screen menu.

Press the CURSOR UP䊳or CUR-

SOR DOWN ■ button until the word

SOUND is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to display the SOUND menu

features.

Press the CURSOR UP 䊳

CURSOR DOWN ■ button

to scroll

the Sound menu features until the word

SAP is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to turn the SAP control ON or

OFF.

When finished, press the STATUS

/EXIT button to remove the menu

from the TV’s screen.

Note: If SAP is not present on the channel you are tuned to, when the SAP control is set to ON the screen will read:

“SAP NOT AVAILABLE.”

Main

Picture Sound Features Install

Brightness Color Picture Sharpness Tint More...

Main

Picture Sound Features Install

Treble Bass Balance AVL Incr. Surround More...

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

POWER

TV/VCR

5 89 0

MUTE

SMARTSMART


Sound

Treble Bass Balance AVL Incr. Surround SAP

Sound

Treble Bass Balance AVL Incr. Surround SAP

Sound

Treble Bass Balance AVL Incr. Surround SAP

Off

SETTING THE TV TO RECEIVE STEREO PROGRAMMING

ou can receive broadcast stereo TV

programs. The TV has both an amplifier and twin speakers through which the stereo sound can be heard.

Press the MENU button on the

remote to display the on-screen menu.

Press the CURSOR UP䊳or CUR-

SOR DOWN ■ button until the word SOUND is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to display the SOUND menu

features.

Press the CURSOR UP 䊳

CURSOR DOWN ■ button

to scroll

the Sound menu features until the word

SOUND is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to set the Sound control to

Mono or Stereo.

When finished, press the STATUS

/EXIT button to remove the menu

from the TV’s screen.

Remember, if stereo is not

present on a selected show, the Sound control cannot be changed to Stereo. On the other hand, if stereo is present on a selected show the Sound control can be set to Mono.

When channel changes are made, the screen may indicate Mono for a second or two, then change to Stereo if the signal being received is in stereo.

SMART HELP

Main

Picture Sound Features Install

Brightness Color Picture Sharpness Tint More...

Main

Picture Sound Features Install

Treble Bass Balance AVL Incr. Surround More...

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

POWER

TV/VCR

MUTE

SMARTSMART


Sound

Treble Bass Balance AVL Incr. Surround SAP

Sound

Bass Balance AVL Incr. Surround SAP Sound

Sound

Bass Balance AVL Incr. Surround SAP Sound

Mono

Stereo

HOW TO USE THE TIMER CONTROLS

he Timer controls allow you to use

your TV as an alarm clock if set to turn itself on and off at a specific time. It also can be set to tune to a specific channel at a specific time.

Press the CLOCK button on the

remote. The Timer menu will appear on the screen.

Press the CURSOR UP 䊳 or

DOWN ■ button to highlight one of

the Timer controls you wish to set (Time, Start Time, Stop Time, Channel, Activate, or Display).

Press the CURSOR RIGHT 䊳䊳

button to adjust the selected option.

TIME: Enter the current time with the

numbered buttons. Use the Cursor Right button to move to the AM/PM area and use the Cursor Left or Right buttons to toggle AM or PM.

START TIME: Use the numbered buttons to enter a start-up time for the TV to turn on or to tune a specific channel.

STOP TIME: Use the numbered buttons to enter a time for the TV to shut itself off.

CHANNEL: Use the Numbered buttons or the CH + or – buttons to select a specific channel for the TV to tune to at the specific Start Time.

ACTIVATE: Set the Timer to preform it’s function ONCE or DAILY.

DISPLAY: Set to ON or OFF. When ON, the time will be displayed ALL the time the TV in ON. When OFF, the time will only appear when the STATUS/EXIT button is pressed.

When finished, press the STATUS

/EXIT button to remove the menu

from the TV’s screen.

Let's

Look

Inside!

Timer

Time Start Time Stop Time Channel Activate Display

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

10 :30 AM

POWER

TV/VCR

SMARTSMART


MUTE

Timer

Time Start Time Stop Time Channel Activate Display

Timer

Time Start Time Stop Time Channel Activate Display

Timer

Time Start Time Stop Time Channel Activate Display

Timer

Time Start Time Stop Time Channel Activate Display

Timer

Time Start Time Stop Time Channel Activate Display

12 :30 PM

01 :30 PM

0 10

Once

UNDERSTANDING THE AUTOLOCK CONTROLS

G: General Audience - All ages admitted. Most parents would find this program suitable for all ages. This type of programming contains little or no violence, no strong language, and little or no sexual dialogue or situations.

PG: Parental Guidance Suggested -

This programming contains material that parents may find unsuitable for younger children.) It may contain one or more of the following: Moderate violence, some sexual situations, infrequent coarse language, or some suggestive dialogue.

PG-13: Parents Strongly Cautioned - This programming contains material that parents may find unsuitable for children under the age of 13. It contains one or more of the following: violence, sexual situations, coarse language, or suggestive dialogue.

R: Restricted -This is programming is specifically designed for adults. Anyone under the age of 17 should only view this programming with an accompanying parent or adult guardian. It contains one or more of the following: intense violence, intense sexual situations, strong coarse language, or intensely suggestive dialogue.

NC-17: No one under the age of 17 will be admitted. - This type of programming should

be viewed by adults only. It contains graphic violence, explicit sex, or crude indecent language.

X: Adults Only - This type of programming contains one or more of the following: very graphic violence, very graphic and explicit or indecent sexual acts, very coarse and intensely suggestive language.

MOVIE RATINGS

OTIONPICTUREASSOCIATION OFAMERICA

)

TV-Y - (All children -- This program is designed to be appropriate for all children.) Designed for a very young audi-

ence, including children ages 2-6. This type of programming is not expected to frighten younger children.

TV-Y7 - (Directed to Older Children -

- This program is designed for children

age 7 and above.) It may be more appropriate for children who have acquired the development skills needed to distinguish between make-believe and reality. This programming may include mild fantasy and comic violence (FV).

TV-G - (General Audience -- Most parents would find this program suitable for all ages.) This type of programming

contains little or no violence, no strong language, and little or no sexual dialogue or situations.

TV-PG - (Parental Guidance Suggested -- This program contains

material that parents may find unsuit-

able for younger children.) This type of pro-

gramming contains one or more of the following: Moderate violence (V), some sexual situations (S), infrequent coarse language (L), or some suggestive dialogue (D).

TV-14 - (Parents Strongly Cautioned -

- This program contains some material

that many parents would find unsuitable

for children under 14 years of age.) This type

of programming contains one or more of the following: intense violence (V), intense sexual situations (S), strong coarse language (L), or intensely suggestive dialogue (D).

TV-MA - (Mature Audience Only --

This program is specifically designed to be viewed by adults and therefore may

be unsuitable for children under 17.) This type

of programming contains one or more of the following: graphic violence (V), explicit sexual situations (S), or crude indecent language (L).

TV PARENTAL GUIDELINES

(TV BROADCASTERS)

he AutoLock feature is an inte-

grated circuit that receives and processes data sent by broadcasters, or other program providers, that contain program content advisories. When programmed by the viewer, a TV with AutoLock can respond to the content advisories and block program content that may be found objectionable (such as offensive language, violence, sexual situations, etc.). This is a great feature to censor the type of viewing children may watch.

Over the next few pages you’ll learn how to block channels and

certain rated programming. Below is a brief explanation of some terms and ratings you will find in the AutoLock feature.

AutoLock offers various BLOCKING controls from which to choose:

Access Code: An Access Code

must be set to prevent children from unblocking questionable or censored programming set by their parents.

Channel Block: After an access code has been programmed, you can block individual channels including the A/V inputs.

Clear All: Allows you clear all channels being blocked from your viewing set with the Channel Block Control.

Block All: Allows you to block ALL channels and A/V inputs at one time.

Movie Ratings: Certain blocking options exist which will block programming based on ratings patterned by the Motion Pictures Association of America.

TV Ratings: Just like the Movie Ratings, programs can be blocked from viewing using standard TV ratings set by TV broadcasters.

To learn more about the Motion Picture Association of America Ratings and the TV Broadcasters Television Ratings, refer to the definitions listed on the columns to the right.

Movie Rating

PG PG-13 R NC-17 X

TV Rating

TV-Y

TV-Y7 TV-G TV-PG TV-14 TV-MA

SETTING UP THE AUTOLOCK ACCESS CODE

ver the next few pages you’ll learn

how to block channels and get a better understanding of the rating terms for certain programming.

First, let’s start by learning how to set a personal access code:

Press the MENU button on the

remote to display the on-screen menu.

Press the CURSOR UP䊳or

DOWN ■ button until the word FEA-

TURES is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to display the FEATURES

menu options.

Press the CURSOR UP 䊳 or

DOWN ■ button until the words

AUTOLOCK are highlighted.

Press the CURSOR RIGHT 䊳䊳

button. The screen will read,

“ACCESS CODE - - - - .”

Using the NUMBERED buttons,

enter 0, 7, 1, 1. “XXXX” appears on

the Access Code screen as you press the numbered buttons.

“INCORRECT CODE” will appear on the screen, and you will need to enter 0,

7, 1, 1 again.

The screen will ask you to enter a

“New Code.” Enter a “new” 4 digit

code using the NUMBERED buttons.

The screen will then ask you to CONFIRM the code you just entered. Enter your new code again. “XXXX” will appear when you enter your new code and then display the AutoLock menu options.

Proceed to the next page to learn more...

Parents - it isn’t possible for

your child to unblock a channel without knowing your access code or changing it to a new one. If your code changes, and you didn’t change it, then you know it’s been altered by someone else and blocked channels have been viewed.

SMART HELP

NOTE: The 0,7,1,1 access code shown on this page is the default code or a way to reset the code when the current access code is not known.

The AutoLock

Access Code also

can be changed

anytime using the

Setup Code feature

Main

Picture Sound Features Install

Brightness Color Picture Sharpness Tint More...

Main

Picture Sound Features Install

Timer AutoLock

POWER

TV/VCR

SMARTSMART


MUTE

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

Features

Timer AutoLock

Access Code XXXX

Features

Timer AutoLock

Access Code XXXX Incorrect

Features

Timer AutoLock

Features

Timer AutoLock

Features

Timer AutoLock

Features

Timer AutoLock

Time Start Time Stop Time Channel Activate Display

Timer Start Time Stop Time Channel Activate Display

Access Code

- - - -

Access Code XX - -

Features

Timer AutoLock

AutoLock

Block Channel Setup Code Clear All Block All Movie Rating TV Rating

New Code

- - - -

OffStop Time

Channel Activate Display

Features

Timer AutoLock

New Code XXX -

Features

Timer AutoLock

AutoLock

Block Channel Setup Code Clear All Block All Movie Rating TV Rating

Confirm Code XXXX

OffStop Time Channel Activate Display

HOW TO BLOCK CHANNELS

fter your personal access code has

been set (see previous page), you are now ready to select the channels or A/V Inputs you want to block out or censor.

Press the NUMBERED (or CH +,

–) buttons to tune the channel you

wish to block or censor.

Press the MENU button on the

remote to show the on-screen menu.

Press the CURSOR UP 䊳 or

DOWN ■ button until the word FEA-

TURES is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to display the FEATURES

menu options.

Press the CURSOR UP 䊳 or

DOWN ■ button until the words

AutoLock are highlighted.

Press the CURSOR RIGHT 䊳䊳

button.

Enter the correct access code

number. “XXXX” shows on the Access Code display as you press the NUMBERED buttons. AutoLock

menu options will be displayed.

Press the CURSOR UP 䊳 or

DOWN ■ buttons until the words BLOCK CHANNELS are highlighted.

Press the CURSOR RIGHT 䊳䊳

button to turn blocking ON or OFF for

that channel. When ON is selected the channel will be blocked.

Press the CH + or – button to

select other channels you wish to block. Repeat step 9 to block the new channel.

If you tune to a blocked chan-

nel and enter your Access Code to view the channel, ALL blocked channels will be viewable until the TV has been turned off. When the TV is powered back ON, the previously blocked channels will be blocked again.

SMART HELP

Enter your Access Code to

view a tuned channel that is

blocked with Block Channel.

NOTE: Remember, if you ever forget your Access Code, the 0,7,1,1 access code is the default code or a way to reset the code when the current access code is not known.

Main

Picture Sound Features Install

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

VOL

Brightness Color Picture Sharpness Tint More...

SMART

SOUND

MENU SURF

MUTE

SMARTSMART


POWER

TV/VCR

Main

Picture Sound Features Install

Features

Timer

AutoLock

Features

Timer

AutoLock

Features

Timer AutoLock

Timer Start Time Stop Time Channel Activate Display

Access Code

- - - -

Features

Timer AutoLock

Channel 12 Blocked By AutoLock Channel Blocking Access Code

- - - -

Access Code XXXX

AutoLock

Block Channel Setup Code Clear All Block All Movie Rating TV Rating

OffStop Time

Channel Activate Display

AutoLock

Block Channel Setup Code Clear All Block All Movie Rating TV Rating

OnStop Time

Channel Activate Display

HOW TO CLEAR ALL BLOCKED CHANNELS AT THE SAME TIME

fter blocking specific channels there

may come a time when you want to clear all the channels so they can be viewed. The following steps explain how to CLEAR ALL blocked channels.

Press the MENU button on the

remote to show the on-screen menu.

Press the CURSOR UP 䊳 or

DOWN ■ button until the word FEA-

TURES is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to display the FEATURES

menu options.

Press the CURSOR UP 䊳 or

DOWN ■ button until the words

AutoLock are highlighted.

Press the CURSOR RIGHT 䊳䊳

button.

Enter the correct access code

number. “XXXX” shows on the Access Code display as you press the NUMBERED buttons. AutoLock

menu options will be displayed.

Press the CURSOR UP 䊳 or

DOWN ■ buttons until the words

CLEAR ALL are highlighted.

Press the CURSOR RIGHT 䊳䊳

button to clear all blocked channels.

The Clear All option will read, “Cleared.”

When finished, press the STATUS

/EXIT button to remove the menu

from the TV’s screen.

NOTE: Remember, if you ever forget your Access Code, the 0,7,1,1 access code is the default code or a way to reset the code when the current access code is not known.

If you tune to a blocked chan-

nel and enter your Access Code to view the channel, ALL blocked channels will be viewable until the TV is powered OFf and then turned back ON. When the TV is powered back ON, the previously blocked channels will be blocked again.

CLEAR ALL will not work with the Movie and TV Ratings. These options must be reset individually.

SMART HELP

The Clear All option when activated

will unblock ALLblocked channels. It

will not affect programming blocked

by the Movie or TV Rating options.

Or, enter your Access Code to view a tuned

channel that is blocked

with Block Channel.

Main

Picture Sound Features Install

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

Brightness Color Picture Sharpness Tint More...

POWER

TV/VCR

SMARTSMART


MUTE

Main

Picture Sound Features Install

Features

Timer

AutoLock

Features

Timer AutoLock

Features

Timer AutoLock

Time Start Time Stop Time Channel Activate Display

Timer Start Time Stop Time Channel Activate Display

Access Code

- - - -

Features

Timer AutoLock

AutoLock

Block Channel Setup Code Clear All Block All Movie Rating TV Rating

Access Code XXXX

ClearedStop Time

Channel Activate Display

AutoLock

Block Channel Setup Code Clear All Block All Movie Rating TV Rating

OffStop Time

Channel Activate Display

AutoLock

Block Channel Setup Code Clear All Block All Movie Rating TV Rating

Channel 12 Blocked By AutoLock Channel Blocking Access Code

- - - -

Clear ?Stop Time

Channel Activate Display

HOW TO BLOCK ALL CHANNELS AT THE SAME TIME

here may come a time when you

want to Block All the television’s channels. Maybe you don’t want your children to watch TV for a given time. With the Block All control, ALL available channels (including the A/V Inputs) can be set to block at the same time.

Press the MENU button on the

remote to show the on-screen menu.

Press the CURSOR UP 䊳 or

DOWN ■ button until the word FEA-

TURES is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to display the FEATURES

menu options.

Press the CURSOR UP 䊳 or

DOWN ■ button until the words

AutoLock are highlighted.

Press the CURSOR RIGHT 䊳䊳

button.

Enter the correct access code

number. “XXXX” shows on the Access Code display as you press the NUMBERED buttons. AutoLock

menu options will be displayed.

Press the CURSOR UP 䊳 or

DOWN ■ buttons until the words BLOCK ALL are highlighted.

Press the CURSOR RIGHT 䊳䊳

button to turn Block All ON or OFF.

When ON is selected, ALL available channels will be blocked.

When finished, press the STA-

TUS/EXIT button to remove the

menu from the screen.

If you tune to a blocked chan-

SMART HELP

Enter your Access Code to

view a tuned channel that is

blocked with Block Channel.

NOTE: Remember, if you ever forget your Access Code, the 0,7,1,1 access code is the default code or a way to reset the code when the current access code is not known.

Main

Picture Sound Features Install

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

VOL

Brightness Color Picture Sharpness Tint More...

SMART

SOUND

MENU SURF

MUTE

POWER

TV/VCR

SMARTSMART


Main

Picture Sound Features Install

Features

Timer AutoLock

Features

Timer AutoLock

Features

Timer AutoLock

Timer Start Time Stop Time Channel Activate Display

Access Code

- - - -

Features

Timer AutoLock

Channel 12 Blocked By AutoLock Channel Blocking Access Code

- - - -

Access Code XXXX

AutoLock

Block Channel Setup Code Clear All Block All Movie Rating TV Rating

Off

AutoLock

Block Channel Setup Code Clear All Block All Movie Rating TV Rating

BLOCKING PROGRAMMING BASED ON MOVIE RATINGS

here are two types of program rat-

ings within the AutoLock feature. One is based on the Movie Industry ratings while the other is based on the TV Industry ratings. Both can be used to block or censor programming that has been rated in either manner.

Let’s first look at the Movie Rating options of AutoLock:

Press the MENU button on the

remote to display the on-screen menu.

Press the CURSOR UP䊳or

DOWN ■ button until the word FEA-

TURES is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to display the FEATURES

menu options.

Press the CURSOR UP 䊳 or

DOWN ■ button until AutoLock is

highlighted.

Press the CURSOR RIGHT 䊳䊳

button. The screen will prompt you

for your Access Code.

Using the NUMBERED buttons

on the remote, enter your 4 digit Access Code. The AutoLock menu options will be displayed.

Press the CURSOR UP 䊳 or

DOWN■button to highlight the

words MOVIE RATINGS.

Press the CURSOR RIGHT 䊳䊳

button to display the MOVIE RATINGS options (G, PG, PG-13, R,

NC17, or X).

Press the CURSOR UP 䊳 or

DOWN

■ button

to highlight any of the Movie Ratings options. When highlighted, all these options can be turned

ON (which will allow blocking) or OFF (which will allow viewing).

Use the CURSOR RIGHT 䊳䊳

button on the remote to turn the rating

option ON or OFF.

When a rating is set to block,

all higher ratings will be automatically blocked as well. (Example: If the the PG-13 rating is set to block, the R, NC-17, and X ratings will also be blocked.

SMART HELP

Each Movie Rating can

be turned “ON” or “OFF.”

To view a program blocked by the Movie Rating options, enter your 4 digit access code. This will disable all blocked Movie Ratings until the TV is powered off and on again. Then the blocking options will be restored.

NOTE: Remember, if you ever forget your Access Code, the 0,7,1,1 access code is the default code or a way to reset the code when the current access code is not known.

Main

Picture Sound Features Install

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

4 7

SMART

SOUND

MENU SURF

VOL

Features

Timer AutoLock

Access Code XXXX

AutoLock

Setup Code Clear All Block All Movie Rating TV Rating Blocking Options

Brightness Color Picture Sharpness Tint More...

POWER

TV/VCR

SMARTSMART


MUTE

G PG PG-13 R NC-17 More...

Main

Picture Sound Features Install

Timer AutoLock

Features

Timer AutoLock

Features

Time AutoLock

Features

Timer AutoLock

Movie Rating

G PG PG-13 R NC-17 X

Time Start Time Stop Time Channel Activate Display

Timer Start Time Stop Time Channel Activate Display

Access Code

- - - -

Off

Movie Rating

G PG PG-13 R NC-17 X

Channel 12

OffStop Time

Blocked By AutoLock

Channel

Movie Rating

Activate Display

Access Code

- - - -

BLOCKING PROGRAMMING BASED ON TV RATINGS

his portion of the AutoLock features

cover program ratings based on the TV Industry rating system. This is known as TV Ratings within AutoLock.

After selecting the Autolock feature and entering your personal access code, the AutoLock options screen appears;

Scroll the menu using the CUR-

SOR UP 䊳 or DOWN ■ buttons

until the words TV RATINGS are highlighted.

Press the CURSOR RIGHT 䊳䊳

button to display the TV Ratings (TVY, TV-Y7, TV-G, TV-PG, TV-14, or TV-MA). When highlighted, the TV-Y

and TV-G can be turned ON (which will allow blocking) or OFF (which will allow viewing), of these rated programs.

The ratings of TV-Y7, TV-PG, TV-14, TV-MA can be customized to block V (violence), FV (fantasy violence), S (sexual situations), L (coarse language), or D (suggestive dialogue).

Press the CURSOR UP 䊳 or

DOWN ■ button to highlight the

desired rating.

Press the CURSOR RIGHT 䊳䊳

button on the remote to turn the TV-Y or TV-G rating ON or OFF. Or, press the CURSOR RIGHT 䊳䊳 button to

enter the sub-menus for the TV-Y7, TVPG, TV-14 or TV-MA ratings.

If the TV-Y7, TV-PG, TV-14 or TV-

MA sub-menu is accessed, press the

CURSOR UP 䊳 or CURSOR DOWN

■ button to select one of the options (Block All, V, S, L, D, or FV).

Press the CURSOR RIGHT 䊳䊳

button on the remote to turn the option

ON or OFF.

TV-Y- (All children -- This program is designed to be appropriate for all children.) Designed for a very young audience, including children ages 2-6. This type of program- ming is not expected to frighten younger children.

TV-Y7- (Directed to Older Children -- This program is designed for children age 7 and above.) It may be more appropriate for children who have acquired the development skills needed to distinguish between make-believe and reality. This programming may include mild fantasy and comic violence (FV).

TV-G - (General Audience -- Most parents would find this program suitable for all ages.) This type of programming contains little or no violence, no strong language and little or no sexual dialogue or situations.

TV-PG- (Parental Guidance Suggested -- This program contains material that parents may find unsuitable for younger children.)This type of programming contains one or more of the following: some suggestive dialogue (D), infrequent coarse language (L), some sexual situations (S), or moderate violence (V).

TV-14- (Parents Strongly Cautioned -- This program contains some material that many parents would find unsuitable for children under 14 years of age.) This type of pro- gramming contains one or more of the following: intensely suggestive dialogue (D), strong coarse language (L), intense sexual situations (S), or intense violence (V).

TV-MA- (Mature Audience Only -- This program is specifically designed to be viewed by adults and therefore may be unsuitable for children under 17.) This type of pro- gramming contains one or more of the following: crude indecent language (L), explicit sexual situations (S), or graphic violence (V).

To view a program blocked by the TV Rating options, enter your 4 digit access code. This will disable all blocked TV Ratings until the TV is powered off and on again. Then the blocking options will be restored.

TV Ratings and

Rating Sub-Menus

When a TV Rating is selected to block,

ALL higher ratings will be blocked also.

Channel 12

OffStop Time

Blocked By AutoLock

Channel

TV Rating

Activate Display

Access Code

- - - -

AutoLock

Block Channel Setup Code Clear All Block All Movie Rating TV Rating

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

TV-Y TV-Y7 TV-G TV-PG TV-14 TV-MA

POWER

TV/VCR

SMARTSMART


MUTE

TV Rating

TV-Y TV-Y7 TV-G TV-PG TV-14 TV-MA

TV Rating

TV-Y TV-Y7 TV-G TV-PG TV-14 TV-MA

TV Rating

TV-Y TV-Y7 TV-G TV-PG TV-14 TV-MA

TV Rating

TV-Y TV-Y7 TV-G TV-PG TV-14 TV-MA

Block All FV

Off

TV Rating

TV-Y TV-Y7 TV-G TV-PG TV-14 TV-MA

Block All V S L D

TV Rating

TV-Y TV-Y7 TV-G TV-PG TV-14 TV-MA

Block All V S L D

TV Rating

TV-Y TV-Y7 TV-G TV-PG TV-14 TV-MA

Block All V S L

USING THE AUTOLOCK BLOCKING OPTIONS

utoLock offers the viewer other

blocking features as well. With these Blocking Options, the censoring can be turned ON or OFF.

Press the MENU button on the

remote to show the on-screen menu.

Press the CURSOR UP

䊳 or

DOWN ■ button until the word FEA-

TURES is highlighted.

Press the CURSOR RIGHT 䊳䊳

button to display the FEATURES

menu options.

Press the CURSOR UP

䊳 or

DOWN ■ button until the words

AutoLock are highlighted.

Press the CURSOR RIGHT

䊳䊳

button.

Enter the correct access code

number. “XXXX” shows on the Access Code display as you press the NUMBERED buttons. AutoLock

menu options will be displayed.

Press the CURSOR UP 䊳 or

DOWN ■ buttons until the words

BLOCKING OPTIONS are highlight-

ed.

Press the CURSOR RIGHT 䊳䊳

button to display the Blocking Options (BLOCKING, UNRATED, or NO RATING) menu.

Press the CURSOR UP 䊳 or

DOWN ■ buttons to highlight the

desired feature.

When highlighted, each feature can

be turned ON or OFF using the CUR-

SOR RIGHT 䊳䊳 or LEFT 䊴䊴 buttons on the remote.

NOTE: Remember, if you ever forget your Access Code, the 0,7,1,1 access code is the default code or a way to reset the code when the current access code is not known.

BLOCKING OPTIONS: BLOCKING: This is what might be called the “master switch” for AutoLock. When in the ON position, ALLblocking/censoring

will take place. When in the OFF position, ALL blocking is disabled. UNRATED: ALL unrated programs based on the Movie Ratings or Parental (TV) Guidelines can be blocked if this feature is set

to ON and the BLOCKING feature is set to OFF. NO RATING: ALL programming with NO content advisory data can be blocked if this feature is set to ON and the BLOCKING

feature is set to OFF.

Main

Picture Sound Features Install

Brightness Color Picture Sharpness Tint More...

Main

Picture Sound Features Install

Timer AutoLock

POWER

TV/VCR

SMARTSMART


SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

4 7

SMART

SOUND

MENU SURF

VOL

MUTE

Features

Timer AutoLock

Access Code XXXX

AutoLock

Block Channel Setup Code Clear All Block All Movie Rating TV Rating

OffStop Time

Channel Activate Display

Features

Timer

AutoLock

Features

Timer AutoLock

Features

Timer AutoLock

AutoLock

Setup Code Clear All Block All Movie Rating TV Rating Blocking Options

Time Start Time Stop Time Channel Activate Display

Timer Start Time Stop Time Channel Activate Display

Access Code

- - - -

Blocking Options

Blocking Unrated No Rating

Blocking Options

Blocking Unrated No Rating

Blocking Options

Blocking Unrated No Rating

HOW TO USE THE CLOSED CAPTION CONTROL

losed Captioning (CC) allows you

to read the voice content of television programs on the TV screen. Designed to help the hearing impaired, this feature uses on-screen “text boxes” to show dialogue and conversations while the TV program is in progress.

Press the CC button on the remote

to display the current Closed Caption set-

ting.

Press the CC button repeatedly to

choose from the four Closed Caption options (CC Off, CC 1, CC 2, CC Mute). Dialogue (and descriptions) for the action on the captioned TV program will appear on-screen if the tuned program is broadcasting CC information.

When finished, press the STATUS

/EXIT button to remove the menu from

the TV’s screen or let the option time out and disappear from the TV screen.

Not all TV programs and

product commercials are made

with Closed Caption (CC) information included. Neither are all Closed Caption modes (CC 1, or CC 2) necessarily being used during the transmission of a closed caption program. Refer to your area's TV program listings for the stations and times of Closed Caption shows.

SMART HELP

NOTE: The CC MUTE option can be

used to set the TV to turn the Closed Caption mode “ON” whenever the MUTE button on the remote is pressed. This activates the CC1 option.

Let's

Look

Insid

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

CC Off

POWER

TV/VCR

5 89

SMARTSMART


MUTE

CC 1

CC 2

CC Mute

USING THE AUDIO/VIDEO INPUT JACKS

he TV’s Audio/Video Input jacks are

for direct picture and sound connections between the TV and a VCR (or similar accessory device) that has Audio/Video Output jacks.

Connect one end of the VIDEO

(yellow) CABLE to the AV1 in VIDEO

jack on the back of the TV. Then connect one end the AUDIO (red and white) CABLES to the AV1 in AUDIO L and R(left and right) jacks on the rear of the TV.

Connect other end of the VIDEO

(yellow) CABLE to the VIDEO OUT

jack on the back of the VCR. Then connect the other ends of the AUDIO (red and white) CABLES to the AUDIO (left and right) OUT jacks on the rear of the VCR.

Turn the VCR and the TV ON.

Press the CH + or – buttons on the

remote to scroll the channels until AV1 appears in the upper left corner of the TV screen.

Slide the TV/VCR/ACC switch to

the VCR position.

Now your ready to place a prere-

corded video tape in the VCR and press

the PLAY 䊳 button

AUDIO IN

(RED/WHITE)

VCR

(EQUIPPED WITH

VIDEO AND AUDIO

OUTPUT JACKS)

VIDEO IN

(YELLOW)

BACK OF VCR

BACK OF TV

IF YOU ARE USING A

MONO DEVICE, USE

ONL YTHE AUDIO

L/MONO JACK.

75 ⍀

Monitor out

VIDEO

Mono

AUDIO

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

AV1 in

POWER

TV/VCR

5 89

SMARTSMART


MUTE

S-VIDEO

AUDIO

Let's

Look

Inside!

Monitor out

AV1 in

VIDEO

Mono

S-VIDEO

AUDIO

75 ⍀

ANTENNA

OUTOUT

VIDEO

ANTENNA

OUT

USING THE

AUDIO/VIDEO (MONITOR) OUTPUT JACKS

he Audio/Video (Monitor) Output

jacks are great for recording with a VCR or used to connect an external audio system for better sound reproduction.

For an external audio system,

connect one end of the R(ight) and

L(eft) AUDIO (Monitor Out) jacks on

the TV to the R and L audio input jacks on your amplifier or sound system. Set the audio system’s volume to a normal listening level.

Turn the TV and audio system

ON. You can hear TV sound coming

from the audio system. Adjust the volume at the audio system to a comfortable listening level.

To connect a second VCR for recording:

Connect one end of the yellow

Video Cable to the Monitor Out

VIDEO plug. Connect the other end to the VIDEO IN plug on the second VCR.

Connect one end of the red and

white Audio cable from the Monitor

Out AUDIO L and R plugs on the TV to the AUDIO IN plugs on the VCR.

Turn the VCR ON, insert a blank VHS tape and it’s ready to record what’s being viewed on the TV screen.

Let's

AUDIO IN

(RED/WHITE)

VCR Number One

VIDEO IN

(YELLOW)

BACK OF VCR

BACK OF TV

IF YOU ARE USING A

MONO DEVICE, USE

ONL YTHE AUDIO

L/MONO JACK.

VCR Number Two

BACK OF VCR

BACK OF TV

AUDIO IN

(RED/WHITE)

External audio System

For Second VCR:

For Stereo System:

Look

Inside!

Monitor out

AV1 in

VIDEO

75 ⍀

Mono

AUDIO

S-VIDEO

Monitor out

AV1 in

VIDEO

Mono

S-VIDEO

AUDIO

75 ⍀

Monitor out

VIDEO

Mono

AUDIO

AV1 in

S-VIDEO

Monitor out

AV1 in

VIDEO

Mono

S-VIDEO

AUDIO

75 ⍀

ANTENNA

OUT OUT

VIDEO

ANTENNA

OUT

AUDIO

OUTOUT

VIDEO

AUDIO

ANTENNA

OUT

USING THE S-VIDEO INPUT JACKS

he S(uper)-Video connection on the

rear of the TV can provide you with better picture detail and clarity for the playback of accessory sources such as DBS (digital broadcast satellite), DVD (digital video discs), video games, and S-VHS VCR (video cassette recorder) tapes than the normal antenna picture connections.

NOTE: The accessory device must have an S-VIDEO OUT(put) jack in order for you to complete the connection on this page.

Connect one end of the S-VIDEO

CABLE to the S-VIDEO jack on the

back of the TV. Then connect one end the AUDIO (red and white) CABLES to the AV1 in AUDIO L and R(left and right) jacks on the rear of the TV.

Connect other end of the S-

VIDEO CABLE to the S-VHS (S-

Video) OUT jack on the back of the VCR. Then connect the other ends of the AUDIO (red and white) CABLES to the AUDIO (left and right) OUT jacks on the rear of the VCR.

Turn the VCR and the TV ON. Press the CH + or – buttons on the

remote to scroll the channels until SVHS appears in the upper left corner of the TV screen.

Slide the TV/VCR/ACC switch to

the VCR position.

Now your ready to place a prere-

corded video tape in the VCR and

press the PLAY 䊳 button

AUDIO IN

(RED/WHITE)

VCR

EQUIPPED WITH

S-VHS (S-Video) JACKS

S-VIDEO

CABLE

BACK OF VCR

BACK OF TV

IF YOU ARE USING A

MONO DEVICE, USE

ONL YTHE AUDIO

L/MONO JACK.

The S-VIDEO and VIDEO

AV1 in(puts) are in parallel. The S-VIDEO input is dominant when in use. If separate video signals are connected to the S-VIDEO and VIDEO AV1 in(put), the signal from the VIDEO AV1 in(put) will not be usable.

SMART HELP

Note: SVHS will appear as a valid channel option only if a SVHS device is connected to the S-Video Input Jack. If the device is connected to the AV1 Video In, the channel will appear as AV1.

75 ⍀

Monitor out

VIDEO

Mono

AUDIO

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

AV1 in

POWER

TV/VCR

5 89

SMARTSMART


MUTE

S-VIDEO

AUDIO

Let's

Look

Inside!

Monitor out

AV1 in

VIDEO

L/ Mono

S-VIDEO

AUDIO

75 ⍀

OUTOUT

S-VHS

VIDEO

ANTENNA

SVHS

OUT

SETTING UP THE SLEEPTIMER OPTION

ave you ever fallen asleep in front

of the TV only to have it wake you up at two in the morning with a test pattern screeching in your ears? Well, your TV can save you all that trouble by automatically turning itself off.

Press the SLEEP button on the

remote control and the SLEEP timer

display will appear on the screen.

Press the SLEEP button repeatedly

to pick the amount of time (15, 30, 45, 60, 90, 120, 180, or 240 minutes) before the TV will turn itself off.

An on-screen count down will appear during the last minute before the TV shuts itself off.

The on-screen menu will time

out and disappear from the screen when you finish, or you can press the STATUS/EXIT button to clear the menu from the screen.

After a Sleeptimer setting has been made, pressing the STATUS/EXIT button will display the remaining time before the TV will shut itself off.

SMART HELP

During the last 10 seconds of

a SLEEP timer setting, an

onscreen display will read

GOOD BYE.

During the last minute of a

SLEEP timer setting, an on-

screen count down will be dis-

played. Pressing any button

during the last minute will

cancel the SLEEP timer.

15 Min

30 Min

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

POWER

TV/VCR

5 89

SMARTSMART


MUTE

45 Min

60 Min

90 Min

45 Sec

Good Bye

9 Sec

120 Min

180 Min

240 Min

SETTING THE AUTO PICTURE CONTROL

hether you’re watching a movie

or a sporting event, your TV has automatic video control settings matched for your current program source or content. The Auto Picture feature quickly resets your TV’s video controls for a number of different types of programs and viewing conditions you may have in your home. Each Auto Picture setting is preset at the factory to automatically adjust the TV’s Brightness, Color, Picture, Sharpness, Tint, Color Temperature, DNR and Contrast+ levels.

Press the AUTO PICTURE button

on the remote control. The current Auto Picture setting will appear in the middle

of the screen.

Press the AUTO PICTURE button repeatedly to select either PERSONAL,

MOVIES, SPORTS, WEAK SIGNAL, or MULTI MEDIA picture settings.

Note: The PERSONAL setting is the setting that you setup using the PICTURE options within the on-screen menu. This is the only Auto Picture setting that can be changed. All other settings are setup at the factory during the time of production.

MOVIES - Preset picture options for watching Video Tapes, or DVDs.

SPORTS - Preset picture options for watching sporting events.

WEAK SIGNAL - Preset picture options for watching programs where the reception is not at its best.

MULTI MEDIA - Preset picture options for use with video gaming.

Personal

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

5 89

SMART

SOUND

MENU SURF

VOL

MUTE

SMARTSMART


POWER

TV/VCR

Movies

Sports

Weak Signal

Multi Media

SETTING THE AUTO SOUND CONTROL

he Auto Sound feature allows the

listener to select between four different factory set sound options. Personal (which can be set by the user), Theatre (for movie viewing), Music (for musical type programming) and Voice (when the program is mainly dialogue). These setting affect the Sound menu’s Bass, Treble, AVL, and Incredible Surround controls

To select any of the options follow the directions below.

Press the AUTO SOUND button on

the remote control. The current Auto Sound setting will appear in the middle of the screen.

Press the AUTO SOUND button

repeatedly to toggle between the four

settings.

Note: Only the PERSONAL control can be changed by the viewer. This changes the settings in the main onscreen menu's sound controls.

THEATRE - Preset sound options for watching movies.

MUSIC - Preset sound options for musical programming where there is little dialogue.

VOICE - Preset sound options for programming where heavy dialogue is present.

Personal

Theatre

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

POWER

TV/VCR

5 89

SMARTSMART


MUTE

Music

Voice

USING THE SURF BUTTON (AND THE ALTERNATE CHANNEL BUTTON)

A/CH BUTTON

Your remote also has an A/CH (Alternate Channel) button. Pressing this button will toggle between the current and one previously selected channel.

POWER

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SMARTSMART

SOUND

PICTU

89 0

TV/VCR

“list” or series of previously

viewed channels can be selected using the SURF button on your remote control. With this feature you can easily switch between different TV programs that currently interest you. The SmartSurf control allows you set up to 8 channels in its quick viewing “list”.

Press the CHANNEL (+) or (–)

buttons (or the NUMBER buttons)

to select a channel to add to the SURF list.

Press the SURF button on the

remote. The channel number will be displayed with the word ADD to the right.

Press the CURSOR RIGHT

button to ADD the channel to the

Surf list. The display will change from ADD to DELETE.

Repeat steps 1 through 3 to add additional channels (up to 8) to the SURF list. As soon as a ninth channel is added, the first channel in the list will be removed.

How to select Surf channels:

Press the Surf button on the

remote control.

Press the CURSOR UP or

CURSOR DOWN button to scroll

the list of up to 8 channels. As you scroll to a channel the TV will tune to that channel.

To remove a channel from the SURF list:

Follow steps 4 and 5 to select a channel in the Surf list.

While the Surf Channel List is

still displayed on the screen, press the CURSOR RIGHT button to DELETE the channel from the list. The display will change from DELETE to ADD.

Surf

5 ADD

Stereo

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

5 89

SMART

SOUND

MENU SURF

VOL

MUTE

POWER

SMARTSMART


TV/VCR

Surf

5 DELETE

Stereo

Surf 5 ADD

7 ADD

Stereo

Surf 5 DELETE

7 DELETE

Stereo

Surf 5 ADD 7 ADD

9 ADD

Stereo

Surf 5 DELETE 7 DELETE

9 DELETE

Stereo

REMOTE USE WITH ACESSORY DEVICES - DIRECT METHOD

our remote control is set to

work your TV and many infrared remote (IR) control VCRs, Cable Boxes, Satellite Systems, DBS, DVD, etc. However, an easy onetime step may be necessary before the remote will work your VCR.

Try this initial check to see if going on to the following section is necessary.

Place the TV/VCR/ACC

Mode Switch in the proper posi-

tion.

Point the remote control at

the device and press the POWER button.

Does the remote turn the

device ON? If YES, stop and try other func-

tion buttons on the remote. If they also work the device, then the remote is ready and no further steps are needed.

If NO, continue...

Cable Converter

SMART HELP

Remember, if more than

one number is listed, you may have to try more than the first ThreeDigit code given in order to locate your Device’s remote code.

NOTE: Setting up the remote is for use with external accessory devices only and not for use with other television brands.

Satellite Receiver

First look up a THREE-DIGIT

remote control number for your brand of Device before going through the simple steps on the following page.

Find your Three-Digit Code on pages 33-34.

VCR

SLEEP

A/CH STATUS/EXIT CC

RECORD

VCR

ACC

SMART

SOUND

C T

23 5

REMOTE USE WITH ACCESSORY DEVICES - CODE ENTRY METHOD

ow that you have looked up

the three-digit Remote Code Number for your brand of device, you are ready to follow the four simple steps below.

Please read through steps 1-4 before beginning.

Place the TV/VCR/ACC

Mode Switch in the proper posi-

tion.

Press the VCR RECORD

button on the remote control and

release.

Press the SmartSound button

on the remote within 30 seconds, then release.

Enter the THREE-DIGIT

REMOTE CODE NUMBER

for your desired device. The remote is now ready to send commands to the unit.

Point the remote at the

Device. Press the POWER button on the remote to turn the unit ON.

Cable Converter

SMART HELP

Remember, if this doesn’t

work the first time, repeat steps

using the same remote code number. After a second try and the remote does

not operate your device, see if there is another three-digit code number (pages 33-34) listed for your device and repeat the steps above using the new number.

If after repeated attempts the code number method does not work you device, try the SEARCH METHOD on the next page.

NOTE: Setting up the remote is for use with external accessory devices only and not for use with other television brands.

Satellite Receiver

or DBS, DVD

VCR

Direct Access Method

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

23 5

89 0

VOL

MUTE

POWER

TV/VCR

SMART


C IT

REMOTE USE WITH ACCESSORY DEVICES - SEARCH METHOD

our TV remote can be set to

work various external devices such as VCRs, Cable Boxes, Satellite Receivers, DBS, DVD, etc. by what is called the search method of remote control programming.

If the “Remote Code” number method shown on the previous page did not set your remote to work your external device, then follow the easy steps listed below.

Please read steps 1-4 before beginning.

Press the POWER button on

the device your are attempting to program to turn it ON.

Place the TV/VCR/ACC

Mode Switch in the proper posi-

tion.

Press the (A/CH) • RECORD and the SMART SOUND buttons simultaneously and hold

them down.

The device will begin to change channels after the remote identifies the correct code. When the channels start to change release the VCR RECORD and SMART SOUND buttons. The remote should be ready to operate the device.

Cable Converter

SMART HELP

This method can take up to

two minutes to perform.

Don’t let the device scan up more than five channels. If you do the remote may pass up the right code and another two minute search cycle will have to be repeated.

If no channel change happens within two minutes, repeat steps 1-4. Should a channel change still not occur, the remote will not work the desired device.

Satellite Receiver

VCR

Search Method

NOTE: Setting up the remote is for use

with external accessory devices only and not for use with other television brands.

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

5 89

SMART

SOUND PICTURE

MENU SURF

POWER

TV/VCR

SMART

MUTE

VOL

REMOTE CONTROL DIRECT ENTRY CODES

REMOTE

VCR

CODE NO.

Admiral . . . . . . . . . . . . . . . . . . . . . . . .048

Advantz . . . . . . . . . . . . . . . . . . . . . . . .358

Adventure . . . . . . . . . . . . . . . . . . . . . .000

Aiko . . . . . . . . . . . . . . . . . . . . . . . . . .278

Aiwa . . . . . . . . . . .000, 037, 307, 348, 352

Akai . . . . . . .041, 049, 053, 061, 106, 315

Alba . . . . . . . . . . . . . . . . . . . . . . . . . . .352

Amercian High . . . . . . . . . . . . . . . . . .035

Amstrad . . . . . . . . . . . . . . . . . . . .325, 332

Asha . . . . . . . . . . . . . . . . . . . . . . . . . .240

Audiovox . . . . . . . . . . . . . . . . . . . . . . .037

Baird . . . . . . . . . . . . . . . . . . . . . . . . . .107

Beaumark . . . . . . . . . . . . . . . . . . . . . .240

Bell & Howell . . . . . . . . . . . . . . . . . . .104

Blaupunkt . . . . . . . . . . . . . . .003, 006, 154

Brandt . . . . . . . . . . . . . . . . .187, 320, 321

Broksonic . . . . . . .121, 184, 211, 295, 361

Bush . . . . . . . . . . . . . . . . . . . . . . . . . .352

CCE . . . . . . . . . . . . . . . . . . . . . . .072, 278

Calix . . . . . . . . . . . . . . . . . . . . . . . . . .037

Canon . . . . . . . . . . . . . . . . . . . . . . . . .035

Capehart . . . . . . . . . . . . . . . . . . . . . . .020

Carver . . . . . . . . . . . . . . . . . . . . .081, 146

Citizen . . . . . . . . . . . . . . . . . . . . .037, 278

Colt . . . . . . . . . . . . . . . . . . . . . . . . . . .072

Combitach . . . . . . . . . . . . . . . . . . . . . .352

Craig . . . . . . . . . . .037, 047, 072, 240, 271

Curtis Mathes . . . . . . . . . . . .035, 041, 060

Cybermax . . . . . . . . . . . . . . . . . .051, 240

Daewoo . . . . . . . . . . . . . . . .020, 045, 276

Daytron . . . . . . . . . . . . . . . . . . . . . . . .020

Denon . . . . . . . . . . . . . . . . . . . . . . . . .042

Dynatech . . . . . . . . . . . . . . . . . . . . . . .000

Electrophonic . . . . . . . . . . . . . . . . . . . .037

Emerex . . . . . . . . . . . . . . . . . . . . . . . .032

Emerson . . . .000, 002, 036, 037, 043, 061

. . . . . . . . . .068, 088, 121, 164, 208, 209,

. . . . . . . . . . .211, 212, 278, 295, 361, 479

Ferguson . . . . . . . . . . . . . . .107, 320, 321

Fisher . . . . . . . . . . . . . .047, 054, 066, 104

Fuji . . . . . . . . . . . . . . . . . . . . . . .033, 035

Funai . . . . . . . . . . . . . . . . . . . . . . . . . .000

GE . . . . . . . . . . . . . . . .035, 060, 065, 202

Garrard . . . . . . . . . . . . . . . . . . . . . . . .000

Go Video . . . . . . . . . . . . . . .232, 279, 432

Gold Star . . . . . . . . . . . . . . . . . . .037, 038

Gradiente . . . . . . . . . . . . . . . . . . .000, 406

Grundig . . . . . . . . . . . .003, 007, 195, 347

HI-Q . . . . . . . . . . . . . . . . . . . . . . . . . .047

Harley Davidson . . . . . . . . . . . . . . . . .000

Harman/Kardon . . . . . . . . . . . . . .038, 075

Harwood . . . . . . . . . . . . . . . . . . .068, 072

Headquarter . . . . . . . . . . . . . . . . . . . . .046

Hinari . . . . . . . . . . . . . . . . . . . . .004, 352

Hitachi . . . . . . . . . . . . .000, 004, 041, 042,

. . . . . . . . . . . . . . . . . . .065, 105, 168, 235

Ingersol . . . . . . . . . . . . . . . . . . . . . . . .004

JVC . . . . . . . .008, 041, 067, 208, 384, 486

Jensen . . . . . . . . . . . . . . . . . . . . . . . . .041

KEC . . . . . . . . . . . . . . . . . . . . . . .037, 278

KLH . . . . . . . . . . . . . . . . . . . . . . . . . .072

Kenwood . . . . . . . . . . .038, 041, 067, 384

Kodak . . . . . . . . . . . . . . . . . . . . .035, 037

LXI . . . . . . . . . . . . . . . . . . . . . . . . . . .037

Lloyd’s . . . . . . . . . . . . . . . . . . . . .000, 206

REMOTE

VCR

CODE NO.

Loewe . . . . . . . . . . . . . . . . . . . . . . . . .004

Logik . . . . . . . . . . . . . . . . . . . . . .004, 072

MEI . . . . . . . . . . . . . . . . . . . . . . . . . . .035

MGA . . . . . . . . . . . . . . . . . . . . . .043, 061

MGN Technology . . . . . . . . . . . . . . . .240

MTC . . . . . . . . . . . . . . . . . . . . . .000, 240

Magnavox . . . . . . .000, 035, 081, 146, 181

Marta . . . . . . . . . . . . . . . . . . . . . . . . . .037

Matsui . . . . . . . . . . . . . . . . .004, 348, 352

Matsushita . . . . . . . . . . . . . .035, 162, 454

Memmorex . . . . . . . . . . . . . . . . . . . . .307

Memorex . . . . . . .000, 035, 037, 039, 046,

. . . . . . . . . . .047, 048, 104, 240, 266, 307

Metz . . . . . . . . . . . . . . . . . . . . . .003, 347

Minolta . . . . . . . . . . . . . . . . . . . .042, 105

Mitsubishi . . .043, 061, 067, 075, 173, 443

Motorola . . . . . . . . . . . . . . . . . . .035, 048

Multitech . . . . . . . . . . . . . . . . . . .000, 072

NAD . . . . . . . . . . . . . . . . . . . . . . . . . .058

NEC . . . . . . . . . . .036, 040, 041, 067, 104

Nikko . . . . . . . . . . . . . . . . . . . . . . . . .037

Nikon . . . . . . . . . . . . . . . . . . . . . .034, 253

Noblex . . . . . . . . . . . . . . . . . . . . . . . . .240

Nordmende . . . . . . . . . . . . . .297, 320, 321

Okano . . . . . . . . . . . . . . . . . . . . . . . . .346

Olympus . . . . . . . . . . . . . . . . . . .035, 226

Optimus . . . . . . . . . . . .037, 048, 058, 104,

. . . . . . . . . . . . . . . . . . . . . .162, 432, 454

Optonica . . . . . . . . . . . . . . . . . . . . . . .062

Orion . . . . . . . . . .004, 295, 348, 352, 479

Panasonic . . . . . . . . . .035, 077, 162, 225,

. . . . . . . . . . . . . . . . . . . . . .226, 378, 454

Penney . . . . . . . . . . . . .035, 037, 038, 040,

. . . . . . . . . . . . . . . . . . . . . .042, 065, 105

Pentax . . . . . . . . . . . . . . . . .042, 065, 105

Philco . . . . . . . . . . . . . . . . . . . . . . . . .035

Philips . . . . . . . . . .035, 062, 081, 110, 403

Pilot . . . . . . . . . . . . . . . . . . . . . . . . . . .037

Pioneer . . . . . . . . . . . . . . . . . . . . .058, 067

Portland . . . . . . . . . . . . . . . . . . . . . . . .020

Profax . . . . . . . . . . . . . . . . . . . . . . . . .322

Profitronic . . . . . . . . . . . . . . . . . . . . . .240

Protec . . . . . . . . . . . . . . . . . . . . . . . . .072

Pulsar . . . . . . . . . . . . . . . . . . . . . .039, 051

Quarter . . . . . . . . . . . . . . . . . . . . . . . .046

Quartz . . . . . . . . . . . . . . . . . . . . . . . . .046

Quasar . . . . . . . . . . . . .035, 077, 162, 454

RCA . . . . . . . . . . . . . .042, 060, 065, 077,

. . . . . . . . . . . . . . . . . . .105, 106, 149, 202

Radio Shack . . . . . . . . . . . . . . . . .000, 037

Radix . . . . . . . . . . . . . . . . . . . . . . . . . .037

Randex . . . . . . . . . . . . . . . . . . . . . . . .037

Realistic . . . . . . . .000, 035, 037, 045, 047

. . . . . . . . . . . . . . . . . . 048, 062, 066, 104

Ricoh . . . . . . . . . . . . . . . . . . . . . .034, 253

Runco . . . . . . . . . . . . . . . . . . . . . . . . .039

SEG . . . . . . . . . . . . . . . . . . . . . . . . . . .322

SEI . . . . . . . . . . . . . . . . . . . . . . . . . . .004

STS . . . . . . . . . . . . . . . . . . . . . . . . . . .042

Saba . . . . . . . . . . . . . . . . . . .297, 320, 321

Saisho . . . . . . . . . . . . . . . . . . . . . . . . .004

Salora . . . . . . . . . . . . . . . . . . . . . . . . .075

Samsung . . . . . . . . . . . .045, 051, 053, 240

Sanky . . . . . . . . . . . . . . . . . . . . . .039, 048

Sansui . . . . . . . . . . . . . .000, 041, 067, 271

REMOTE

VCR

CODE NO.

Sanyo . . . . . . . . . .046, 047, 104, 240, 268

Saville . . . . . . . . . . . . . . . . . . . . . . . . .352

Scott . . . . . . .043, 045, 121, 164, 211, 212

Sears . . . . . . . . . .000, 035, 037, 042, 046,

. . . . . . . . . . . . . . .047, 054, 066, 104, 105

Sharp . . . . . . . . . . . . . . . . . . . . . .046, 062

Shintom . . . . . . . . . . . . . . . . . . . . . . . .072

Shogun . . . . . . . . . . . . . . . . . . . . .051, 240

Shoral . . . . . . . . . . . . . . . . . . . . . . . . .004

Siemens . . . . . . . . . . . . . . . . . . . . . . . .003

Singer . . . . . . . . . . . . . . . . . . . . . . . . .072

Sinudyne . . . . . . . . . . . . . . . . . . . . . . .004

Sony . . . . . . . . . .000, 011, 022, 032, 033,

. . . . . . . . . . . . . . . . . . .034, 035, 253, 275

Sunkel . . . . . . . . . . . . . . . . . . . . . . . . .348

Sunpak . . . . . . . . . . . . . . . . . . . . . . . .253

Sylvania . . . .000, 035, 043, 081, 103, 110

Symphonic . . . . . . . . . . . . . . . . . . . . . .000

TMK . . . . . . . . . . . . . . . . . .036, 208, 240

Tatung . . . . . . . . . . . . . . . . . . . . . . . . .041

Teac . . . . . . . . . . . . . . . . . . . . . . .000, 041

Technics . . . . . . . . . . . . . . . . . . . .035, 162

Teknika . . . . . . . . . . . . . . . .000, 035, 037

Telefunken . . . . . . . . . . . . . .187, 320, 321

Tansal . . . . . . . . . . . . . . . . . . . . . . . . .322

Thomas . . . . . . . . . . . . . . . . . . . . . . . .000

Thomson . . . . . . . . . . . . . . . . . . . . . . .320

Toshiba . . . . . . . . .043, 045, 066, 212, 366

Totavision . . . . . . . . . . . . . . . . . .037, 240

Towada . . . . . . . . . . . . . . . . . . . . . . . .322

Unitech . . . . . . . . . . . . . . . . . . . . . . . .240

Universum . . . . . . . . . . . . . . . . . . . . . .325

Vactor . . . . . . . . . . . . . . . . . . . . . . . . .045

Vactor Research . . . . . . . . . . . . . .038, 040

Video Concepts . . . . . . . . . .040, 045, 061

Videosonic . . . . . . . . . . . . . . . . . . . . . .240

Wards . .000, 035, 042, 047, 048, 060, 062,

. . . . . . . . . . .072, 081, 149, 161, 212, 240

XR-1000 . . . . . . . . . . . . . . .000, 035, 072

Yamaha . . . . . . . . . . . . . . . . . . . . . . . .038

Zenith . . . . . . . . . . . . . .000, 033, 034, 039

CABLE REMOTE CONVER

TOR CODE NO.

ABC . . . . . . . . . . . . . .001, 003, 007, 008,

. . . . . . . . . . . . . . . . . . .011, 013, 014, 017

Aliegio . . . . . . . . . . . . . . . . . . . . . . . .153

Andover . . . . . . . . . . . . . . . . . . . . . . . .544

Antronix . . . . . . . . . . . . . . . . . . . . . . .022

Archer . . . . . . . . . . . . . . . . . . . . .022, 153

Balcor . . . . . . . . . . . . . . . . . . . . . . . . .056

British Telecom . . . . . . . . . . . . . . . . . .105

Cable Star . . . . . . . . . . . . . . . . . . . . . .056

Cablatenna . . . . . . . . . . . . . . . . . . . . . .022

Cabletime . . . . . . . . . . .161, 271, 377, 448

Cableview . . . . . . . . . . . . . . . . . . . . . .022

Century . . . . . . . . . . . . . . . . . . . . . . . .153

Citizen . . . . . . . . . . . . . . . . . . . . . . . . .153

Clyde . . . . . . . . . . . . . . . . . . . . . . . . . .086

Colour Voice . . . . . . . . . . . . . . . .025, 031

Comtec . . . . . . . . . . . . . . . . . . . . . . . .274

Comtronics . . . . . . . . . . . . . . . . . . . . .040

Contec . . . . . . . . . . . . . . . . . . . . . . . . .019

Cryptovision . . . . . . . . . . . . . . . . . . . .600

Deceat . . . . . . . . . . . . . . . . . . . . . . . . .423

REMOTE CONTROL DIRECT ENTRY CODES

CABLE REMOTE CONVER

TOR CODE NO.

Eastern . . . . . . . . . . . . . . . . . . . . .002, 274

Everquest . . . . . . . . . . . . . . . . . . .015, 040

Filmnet . . . . . . . . . . . . . . . . . . . . . . . .443

Focus . . . . . . . . . . . . . . . . . . . . . . . . . .400

France Telecom . . . . . . . . . . . . . . . . . .451

GC Electronics . . . . . . . . . . . . . . . . . .056

GEC . . . . . . . . . . . . . . . . . . . . . . . . . .086

Ganard . . . . . . . . . . . . . . . . . . . . . . . . .153

Gemini . . . . . . . . . . . . . . . . .015, 070, 242

General Instrument . . . . . . . .011, 276, 476

Gold Star . . . . . . . . . . . . . . . . . . . . . . .040

Grundig . . . . . . . . . . . . . . . . . . . . . . . .529

Hamlin . . . . . . . . . . . . .009, 020, 034, 259

Hitachi . . . . . . . . . . . . . . . . . . . . . . . . .011

Hytex . . . . . . . . . . . . . . . . . . . . . . . . . .007

Jasco . . . . . . . . . . . . . . . . . . . . . . . . . .153

Jerrold . . . . . . . . . . . . .003, 011, 012, 014,

. . . . . . . . . . . . . . . . . . .015, 024, 276, 476

M.N.E. T. . . . . . . . . . . . . . . . . . . . . . . .443

MNet . . . . . . . . . . . . . . . . . . . . . . . . . .443

Macon . . . . . . . . . . . . . . . . . . . . . . . . .033

Magnavox . . . . . . . . . . . . . .027, 032, 334

Memorex . . . . . . . . . . . . . . . . . . . . . . .000

Movie Time . . . . . . . . . . . . . . . . . . . . .063

NSC . . . . . . . . . . . . . . . . . . . . . . .063, 070

Oak . . . . . . . . . . . . . . . . . . . . . . .007, 019

Optimus . . . . . . . . . . . . . . . . . . . . . . . .021

Panasonic . . . . . . . . . . . . . . .000, 021, 107

Paragon . . . . . . . . . . . . . . . . . . . . . . . .000

Philips . .025, 027, 031, 153, 242, 290, 334

Pioneer . . . . . . . . . . . . . . . . . . . . .533, 753

Popular Mechanics . . . . . . . . . . . . . . . .400

Pulsar . . . . . . . . . . . . . . . . . . . . . . . . .000

RCA . . . . . . . . . . . . . . . . . . . . . . . . . .021

Radio Shack . . . . . . . . . . . . . . . . . . . .015

Recoton . . . . . . . . . . . . . . . . . . . . . . . .400

Regal . . . . . . . . . . . . . . . . . . . . . .020, 259

Regency . . . . . . . . . . . . . . . . . . . . . . . .002

Rembrandt . . . . . . . . . . . . . . . . . .011, 070

Runco . . . . . . . . . . . . . . . . . . . . . . . . .000

SL Marx . . . . . . . . . . . . . . . . . . . . . . .040

Salora . . . . . . . . . . . . . . . . . . . . . . . . .382

Samsung . . . . . . . . . . . . . . . . . . . . . . .040

Satbox . . . . . . . . . . . . . . . . . . . . . . . . .375

Scientific Atlanta . . . . . . . . .008, 017, 477

Signal . . . . . . . . . . . . . . . . . . . . .015, 040

Signature . . . . . . . . . . . . . . . . . . . . . . .011

Sprucer . . . . . . . . . . . . . . . . . . . . . . . .021

Star Sight . . . . . . . . . . . . . . . . . . . . . . .542

Starcom . . . . . . . . . . . . . . . . . . . .003, 015

Stargate . . . . . . . . . . . . . . . . . . . .015, 040

Starquest . . . . . . . . . . . . . . . . . . . . . . .015

Sylvania . . . . . . . . . . . . . . . . . . . . . . . .001

TV85 . . . . . . . . . . . . . . . . . . . . . . . . . .063

Tandy . . . . . . . . . . . . . . . . . . . . . . . . .258

Tele+1 . . . . . . . . . . . . . . . . . . . . . . . . .443

Teleservice . . . . . . . . . . . . . . . . . . . . . .281

Teleview . . . . . . . . . . . . . . . . . . . . . . .040

Texscan . . . . . . . . . . . . . . . . . . . . . . . .001

Timeless . . . . . . . . . . . . . . . . . . . . . . .274

Tocom . . . . . . . . . . . . . . . . .012, 013, 059

Toshiba . . . . . . . . . . . . . . . . . . . . . . . .000

Tudl . . . . . . . . . . . . . . . . . . . . . . . . . . .286

Tusa . . . . . . . . . . . . . . . . . . . . . . . . . . .015

Unike . . . . . . . . . . . . . . . . . . . . . .022, 153

CABLE REMOTE CONVER

TOR CODE NO.

United Artists . . . . . . . . . . . . . . . . . . . .007

United Cable . . . . . . . . . . . . . . . . . . . .003

Universal . . . . . . . . . . .022, 056, 153, 191

Videoway . . . . . . . . . . . . . . . . . . . . . .250

Viewstar . . . . . . . . . . . . . . . .027, 063, 258

Visi Cable+ . . . . . . . . . . . . . . . . . . . . .461

Westminster . . . . . . . . . . . . . . . . . . . . .105

Wolsey Gaine . . . . . . . . . . . . . . . . . . .544

Zenith . . . . . . . . . . . . . . . . . .000, 054, 525

Zentek . . . . . . . . . . . . . . . . . . . . . . . . .400

REMOTE

DBS

CODE NO.

Alpha Star . . . . . . . . . . . . . . . . . . . . . .772

Echostar . . . . . . . . . . . . . . . . . . . . . . . .775

HTS . . . . . . . . . . . . . . . . . . . . . . . . . . .775

Hitachi . . . . . . . . . . . . . . . . . . . . . . . . .819

Hughes Network System . . . . . . . . . . .749

Jerrold . . . . . . . . . . . . . . . . . . . . . . . . .627

Magnavox . . . . . . . . . . . . . . . . . .722, 724

Memorex . . . . . . . . . . . . . . . . . . . . . . .724

Panasonic . . . . . . . . . . . . . . . . . . . . . .701

Philips . . . . . . . . . . . . . . . . . . . . .722, 724

Primestar . . . . . . . . . . . . . . . . . . . . . . .627

RCA . . . . . . . . . . . . . . . . . . . . . . . . . .566

Sony . . . . . . . . . . . . . . . . . . . . . . . . . .639

Toshiba . . . . . . . . . . . . . . . . . . . . . . . .790

Uniden . . . . . . . . . . . . . . . . . . . . . . . . .724

REMOTE

Satellite

CODE NO.

AST . . . . . . . . . . . . . . . . . . . . . . . . . . .351

Akai . . . . . . . . . . . . . . . . . . . . . . . . . . .515

Alba . . . . . . . . . . . . . . . . . . .352, 515, 613

Aldea . . . . . . . . . . . . . . . . . . . . . . . . . .288

Amstrad . . . .080, 252, 345, 461, 509, 689

Ankaro . . . . . . . . . . . . . . . . .220, 288, 369

Anitron . . . . . . . . . . . . . . . . . . . . . . . .183

Armstrong . . . . . . . . . . . . . . . . . . . . . .243

Astra . . . . . . . . . . . . . . . . . . . . . . . . . .108

Avalon . . . . . . . . . . . . . . . . . . . . . . . . .396

Axis . . . . . . . . . . . . . . . . . . . . . . . . . . .369

BT . . . . . . . . . . . . . . . . . . . . . . . .515, 668

Beko . . . . . . . . . . . . . . . . . . . . . . . . . .189

Best . . . . . . . . . . . . . . . . . . . . . . . . . . .369

Boca . . . . . . . . . . . . . . . . . . . . . .243, 513

Bush . . . . . . . . . . . . . . . . . . . . . . . . . .067

Cambridge . . . . . . . . . . . . . . . . . .344, 515

Channel Master . . . . . . . . . . . . . . . . . .362

Commlink . . . . . . . . . . . . . . . . . . . . . .288

Connexions . . . . . . . . . . . . . . . . . . . . .396

Conrad . . . . . . . . . . . . . . . . . . . . . . . . .607

Crown . . . . . . . . . . . . . . . . . . . . . . . . .243

DDC . . . . . . . . . . . . . . . . . . . . . . . . . .362

DNT . . . . . . . . . . . . . . . . . . . . . . . . . .396

Echostar . . . . . . . . . . . . . . . . . . . . . . . .396

Farguson . . . . . . . . . . . .067, 183, 189, 336

Fidelity . . . . . . . . . . . . . . . . . . . . . . . .252

Finiux . . . . . . . . . . . . . . . . . . . . .108, 397

Fuba . . . . . . . . . . . . . . . . . . . . . . .369, 396

G-Bat . . . . . . . . . . . . . . . . . . . . . . . . . .183

Galaxis . . . . . . . . . . . . . . . . . . . . . . . .286

Gooding . . . . . . . . . . . . . . . . . . . . . . . .571

Grundig . . . . . . . . . . . .173, 189, 571, 750

Hinari . . . . . . . . . . . . . . . . . . . . . . . . .183

REMOTE

Satellite

CODE NO.

Hirschmann . . . . . . . . . . . . . . . . .397, 573

Houston . . . . . . . . . . . . . . . . . . . . . . . .668

Huth . . . . . . . . . . . . . . . . . . .220, 243, 268

ITT . . . . . . . . . . . . . . . . . . . . . . . . . . .108

Intervision . . . . . . . . . . . . . . . . . . . . . .592

JVC . . . . . . . . . . . . . . . . . . . . . . .515, 571

Kathrein . . . . . . . . . . . .092, 504, 622, 658

La Sat . . . . . . . . . . . . . . . . . . . . .513, 607

Lennox . . . . . . . . . . . . . . . . . . . . . . . .592

Lupus . . . . . . . . . . . . . . . . . . . . . . . . .369

Luxor . . . . . . . . . . . . . . . . . . . . . .108, 573

Manhatten . . . . . . . . . . . . . . . . . . . . . .592

Maspro . . . . . . . . . . . . . . . . .092, 336, 750

Matsui . . . . . . . . . . . . . . . . . . . . . . . . .571

Mediamarkt . . . . . . . . . . . . . . . . . . . . .248

Minerva . . . . . . . . . . . . . . . . . . . . . . . .571

Mintec . . . . . . . . . . . . . . . . . . . . . . . . .576

Morgan’s . . . . . . . . . . . . . . . . . . .243, 513

Newhaus . . . . . . . . . . . . . . . . . . . . . . .220

Nikko . . . . . . . . . . . . . . . . . . . . . .360, 713

Nokia . . . . . . . . . . . . . . . . . .108, 397, 573

Nordmende . . . . . . . . . . . . . . . . . . . . .362

Orbitech . . . . . . . . . . . . . . . . . . . . . . . .501

Pace . . . . . . . . . . .067, 183, 336, 455, 791

Paliadium . . . . . . . . . . . . . . . . . . . . . .571

Palsat . . . . . . . . . . . . . . . . . . . . . . . . . .501

Philips . . . . . . . . . . . . .200, 292, 571, 750

Phonotrend . . . . . . . . . . . . . . . . . .288, 592

Plasmatic . . . . . . . . . . . . . . . . . . . . . . .442

Proset . . . . . . . . . . . . . . . . . . . . . . . . .288

Quadral . . . . . . . . . . . . . . . . . . . .362, 628

RFT . . . . . . . . . . . . . . . . . . . . . . .220, 288

Radix . . . . . . . . . . . . . . . . . . . . . . . . . .396

SAT . . . . . . . . . . . . . . . . . . . . . . .351, 461

SEG . . . . . . . . . . . . . . . . . . . . . . . . . . .369

Saba . . . . . . . . . . . . . . . . . . . . . . . . . . .336

Salora . . . . . . . . . . . . . . . . . . . . . . . . .108

Satec . . . . . . . . . . . . . . . . . . . . . . . . . .183

Schwaiger . . . . . . . . . . . . . . . . . .183, 504

Seemann . . . . . . . . . . . . . . . .396, 578, 626

Skymaster . . . . . . . . . . . . . . . . . .288, 626

Sony . . . . . . . . . . . . . . . . . . . . . . . . . .704

Star Trak . . . . . . . . . . . . . . . . . . . . . . .421

Strong . . . . . . . . . . . . . . . . . . . . . . . . .421

Sunstar . . . . . . . . . . . . . . . . . . . . . . . .513

Tantec . . . . . . . . . . . . . . . . . . . . . . . . .336

Techni Sat . . . . . . . . . . . . . . . . . .262, 501

Teleka . . . . . . . . . . . . . . . . . . . . .243, 613

Tonna . . . . . . . . . . . . . . . . . . . . . . . . .668

Triad . . . . . . . . . . . . . . . . . . . . . . . . . .351

Universum . . . . . . . . . . . . . . . . . . . . . .571

Vtech . . . . . . . . . . . . . . . . . . . . . . . . . .351

Wisi . . . . . . . . . . . . . . . . . . . . . . .351, 396

REMOTE

DVD

CODE NO.

Kenwood . . . . . . . . . . . . . . . . . . . . . . .534

Mitsubishi . . . . . . . . . . . . . . . . . . . . . .521

Panasonic . . . . . . . . . . . . . . . . . . . . . .490

Philips . . . . . . . . . . . . . . . . . . . . . . . . .539

Pioneer . . . . . . . . . . . . . . . . . . . . . . . .550

RCA . . . . . . . . . . . . . . . . . . . . . . . . . .522

Sony . . . . . . . . . . . . . . . . . . . . . . . . . .552

Toshiba . . . . . . . . . . . . . . . . . . . . . . . .503

USING THE REMOTE’S VCR BUTTONS

hen using the TV remote

with a VCR, first make certain it is set to control your VCR (by the REMOTE CODE or SEARCH method).

Set the TV/VCR/ACC mode

switch to VCR on the remote.

Point the top of the remote

toward the front of the VCR (remote sensor window) when pressing the buttons.

SMART HELP

Remember, the VCR but-

tons on the remote will not operate your VCR if those features are not found on your VCR remote control.

Note: All VCR functions (particularly Search, Rewind, Fast Forward, etc.) will operate the same as with the original VCR remote control provided with the VCR.

POWER BUTTON

Press to turn the VCR ON and OFF.

TV/VCR BUTTON

Press while in the VCR mode (VCR indicator on the front of the unit will light) to view the playback of a tape. Press again to place in the TV position (VCR indicator light will go off) to view one program while recording another program. When used in the TV mode, the TV/VCR/CLOCK button will access the TV's Clock menu options.

NUMBER BUTTON

Press buttons for direct VCR channel selections.

AUSE BUTTON II

Press to temporarily stop the tape during a playback or recording. Press again to release Pause.

FAST FORWARD BUTTON 䊳䊳

Press to rapidly advance the tape. For some VCR’s you may need to press the STOP button first, then the FAST FORWARD button. In playback mode hold the button down to view the picture moving rapidly in the forward direction.

CHANNEL + & – BUTTONS

Press to scan up or down through the VCR channel numbers.

RECORD BUTT

Hold the (A/CH) • RECORD button down to begin a VCR recording.

VCR SYSTEM

SWITCH

Set in the VCR position to send remote commands to the VCR.

PLAY BUTTON 䊳

Press to begin playback of a video tape.

REWIND BUTTON 䊴䊴

Press to rewind tapes. For some VCR’s the STOP button may have to be pressed first, then REWIND. In playback mode hold down the button to view picture moving rapidly in reverse.

STOP BUTTON ■

Press to stop the motion of a tape in playback, rewind, fast forward, etc.

SLEEP

A/CH STATUS/EXIT CC CLOCK

RECORD

VCR

ACC

SMART

SOUND

MENU SURF

VOL

23 5

MUTE

POWER

TV/VCR

SMARTSMART


TROUBLESHOOTING TIPS

• Check the TV power cord. Unplug the TV, wait 10 seconds, then reinsert plug into outlet and push POWER button again.

• Check that outlet is not on a wall switch. Be sure fuse is not blown on AC Power strip.

• Check antenna connections. Are they properly secured to the TV's 75Ω plug?

• Check the TUNER MODE control for CABLE or ANTENNA setting.

• Check Audio/Video Input jack connections if using a VCR or other external device.

• Check batteries. Replace with AA Heavy Duty (Zinc Chloride) or Alkaline batteries if necessary.

• Clean the remote and the remote sensor window on the TV.

• Check the TV power cord. Unplug the TV, wait 10 seconds, then reinsert plug into outlet and push POWER button again. Be sure fuse is not blown on AC Power strip.

• Check to be sure TV outlet is not on a wall switch.

• Check the VOLUME buttons.

• Check the MUTE button on the remote control.

• Check Audio/Video Input jack connections if using a VCR or other external device.

• Repeat channel selection.

• Add desired channel numbers (CHANNEL control) into TV memory.

• Check to be sure the TUNER MODE control is set to the CABLE option.

lease make these simple

checks before calling for service. These tips can save you time and money since charges for TV installation and adjustment of customer controls are not covered under your warranty.

Cleaning and Care

• To avoid possible shock hazard be sure the TV is unplugged from the electrical outlet before cleaning.

• When cleaning the TV screen take care not to scratch or damage the screen surface (avoid wearing jewelry or using anything abrasive). Wipe the front screen with a clean cloth dampened with water. Use even, easy, vertical strokes when cleaning.

• Gently wipe the cabinet surfaces with a clean cloth or sponge dampened in a solution of cool clear water. Use a clean dry cloth to dry the wiped surfaces.

• Never use thinners, insecticide sprays, or other chemicals on or near the cabinet, as they might cause permanent marring of the cabinet finish.

CAUTION: Avideo source (such as a video game, Compact Disc Interactive - CDI, or TV information channel) which shows a constant non-moving pattern on the TV screen, can cause picture tube damage. When your TV is continuously used with such a source the pattern of the non-moving portion of the game could leave an image permanently on the picture tube. When not in use, turn the video source OFF. Regularly alternate the use of such video sources with normal TV viewing.

No Power

No Picture

No Sound

Remote Does Not

Work

TV Displays Wrong

Channel or No

Channels Above 13

• Turn the TV OFF for several seconds, then power the set back ON.

• Unplug the TV for FIVE minutes. Plug the TV back into the AC outlet and power the TV ON. This should correct the problem.

• Check the Picture menu options for proper control settings.

• Pressthe Auto Picture button on the remote to change the color options. If the color resets itself, readjust the Picture menu option control.

Unusual Screen

Coloring

GLOSSARY TO TELEVISION TERMS

Auto Picture Booster • A control that will automatically ampli-

fy “weak video signals” to a point where they are acceptable for viewing.

Auto Programming • The procedure of adding or deleting channel numbers into the Television’s memory circuits. In this way the Television “remembers’’ only the locally available or desired channel numbers and skips over any unwanted channel numbers.

Coaxial Cable • Asingle solid antenna wire normally matched with a metal plug (F-type) end connector that screws (or pushes) directly onto a 75 Ohm input found on the Television or VCR.

Closed Caption • Broadcast standard which allows you to read the voice content of television programs on the TV screen. Designed to help the hearing impaired this feature uses onscreen "text boxes" to show dialogue and conversations while the TV program is in progress.

Front Audio/Video Inputs • Located on the front of the TV these connectors (phono type plug) are used for the input of audio and video signals. Designed for easy use with VCRs or cameras.

Menu • An on-screen listing of feature controls shown on the Television screen that are made available for user adjustments.

On-screen Displays (OSD) • Refers to the wording or messages generated by the television (or VCR) to help the user with specific feature controls (color adjustment, programming, etc.).

Quadra Surf • The feature that allows the programming of four separate Surf lists holding up to 10 channels each.

Remote Sensor Window • A window or opening found on the Television control panel through which infrared remote control command signals are received.

Surf • The action of scanning specific channel in a limited channel list.

Status/Exit • Allows the user to quickly confirm what channel number is currently being viewed. Status can also be used to clear the Television of on screen displays or information (rather than waiting for the displays to “time out” or automatically disappear from the screen).

Twin Lead Wire • The more commonly used name for the two strand 300 Ohm antenna wire used with many indoor and outdoor antenna systems. In many cases this type of antenna wire requires an additional adapter (or balun) in order to connect to the 75 Ohm Input terminals designed into the more recent Televisions and VCRs.

Tuner Mode • Designed for first time set up and use where the TV is set for antenna or cable TV signal connections.

INDEX

Alternate Channel Control . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Audio/Video Input Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Audio/Video Output Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . .24

SmartLock

Access Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Block All Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Blocking Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Blocking Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Clear All Blocked Channels . . . . . . . . . . . . . . . . . . . . . . . .17

Definitions/Understanding Auto Lock . . . . . . . . . . . . . . . .14

Movie Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

TV Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

AVL (Automatic Volume Leveler) Control . . . . . . . . . . . . . . .9

Balance Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Bass Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Brightness Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Closed Caption Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Color Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Color Temperature Control . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Contrast + (Black Stretch) Control . . . . . . . . . . . . . . . . . . . . .7

DNR (Digital Noise Reduction) Control . . . . . . . . . . . . . . . . .6

Glossary of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Incredible Surround Control . . . . . . . . . . . . . . . . . . . . . . . . .10

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Picture Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Surf Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Registration Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Remote Control Use with Accessory Devices:

Code Entry List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33-34

Code Entry Method of Identification . . . . . . . . . . . . . . . .31

Direct Access Method of Identification . . . . . . . . . . . . . .30

Search Method of Identification . . . . . . . . . . . . . . . . . . . .32

VCR Related Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

S-Video Input Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

SAP (Secondary Audio Program) Control . . . . . . . . . . . . . . .11

Sharpness Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Sleeptimer Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

SmartPicture Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

SmartSound Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Sound Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Stereo/Mono Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Timer Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Tint Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Treble Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Troubleshooting Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

RENEWED

90 DAY

LIMITED WARRANTY

Philips MS3250C99 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
