Page 1
SMART. VERY SMART
CD Soundmachine
MCS235
Manual de Instruções
User guide
Manual del usuario
Meet Philips at the internet
Visite nosso site na internet
http://www.philips.com.br
W
MCS235
CLASS 1
LASER PRODUCT
Printed in China PDCC-JH-0632
SET/2005 OS DADOS DESTE MANUAL ESTÃO SUJEITOS A ALTERAÇÕES
Page 2
1
7
8
%
0
@
!
$
1
6
5
9
^
&
2
4
3
6 x R14 • UM-2 • C-CELLS
110V
220V
#
2
3
4
X
Page 3
English Controls/Power Supply
IMPORTANT!
- The voltage selector located at the bottom of this system is preset at 220V-240V
from the factory. For countries that operate at 110V-127V, please adjust to 110V127V before you switch on the system.
Supplied Accessories
– AC power cord
Top/front panels (See 1)
1 OPEN/CLOSE – opens/closes the CD
door.
2 § ∞ SKIP
–
selects the next/previous track
– searches forwards/backwards (press and
hold the button) within the current track
3 9
STOP –
42/; PLAY/PAUSE –
5
REPEAT–repeats a track/
6 PROG. – programs tracks and reviews the
DBB– turns the bass enhancement on/off.
7
8 Telescopic antenna - improves FM
9 LED
stops CD playback;
–
erases a CD program
starts or pause CD
playback
CD program/entire CD.
program
reception.
Display–shows the CD functions
Back/bottom panel (
0
VOL–adjusts volume level.
!
Source selector: CD,TUNER, OFF
selects CD or radio source of sound
–
–
power off switch
@ Battery door – open to inser t 8 x 1.5V
R-14/ UM-2/ C-cells
# Voltage selector – adjust to match the
local voltage 110/220V before plugging in the
set
$ TUNING 12
%
BAND –
^ AC MAINS~ - inlet for power cord.
& p – 3.5 mm stereo headphone socket
Helpful hints: The speakers will be muted
when headphones are connected to the set.
– tunes to radio stations
selects MW, FM or FM ST.waveband
See 1)
CAUTION
Use of controls or adjustments or
performance of procedures other
than herein may result in unsafe
operation.
Power Supply
Whenever convenient, use the power supply
cord if you want to conserve battery life.
Make sure you remove the plug from the set
and wall outlet before inserting batteries.
Batteries (not included)
1 Open the battery door and insert 8 batteries,
type R-14, UM-2 or C-cells, (preferably
alkaline) with the correct polarity as indicated
by the "+" and "–" symbols inside the compartment. (See 1)
2 Replace the battery door, making sure the bat-
teries are firmly and correctly in place. The set is
now ready to operate.
Batteries contain chemical substances, so
they should be disposed of properly.
Power Supply General Operation/Tuner
• Incorrect use of batteries can cause electrolyte
leakage and will corrode the compartment or
cause the batteries to burst:
• Do not mix battery types: e.g. alkaline with carbon zinc. Only use batteries of the same type
for the set.
• When inserting new batteries, do not try to mix
old batteries with the new ones.
• Remove the batteries if the set is not to be used
for a long time.
Using AC power
WARNING:Always check you have completely switched off the set, before you
change or disconnect power supply.
1 Check if the power voltage, as shown on
the type plate located on the
bottom of the set, corresponds to your
local power supply. If it does not, consult your
dealer or service center.
2 If your set is equipped with a voltage selec-
tor, adjust the selector so that it matches
with the local power supply.
3 Connect the power cord to the AC
MAINS~ inlet and the wall socket.The set is
now connected and ready for use.
4 To switch the set off completely, withdraw the
power cord from the wall socket.
5 Install the unit near the AC outlet and where
the AC power plug can be easily reached.
• Disconnect the power cord from the wall
socket to protect your set during heavy
thunderstorms.
The type plate is located on the
bottom of the set.
Helpful hints:
– To avoid unnecessary energy consumption,
always adjust the
after using the set.
Source selectortoOFF
General operation
Switching on and off and selecting the
function
1 To select your sound source, adjust the
Source selector to: CD or
2 To switch off the set, adjust the Source
selector to
Adjusting volume and sound
Adjust the sound with the VOL and DBB
controls.
OFF
position.
TUNER.
Radio reception
1 Adjust the Source selector to
2 Adjust BAND to select your desired
waveband, MW, FM or FM ST. .
➜ FM ST. LED will light up when radio is
receiving stereo broadcast.
3 Tu r n TUNING 12to tune to a station.
Helpful hints:
To improve radio reception
• For FM, extend, incline and turn the telescopic antenna for best reception. Reduce its
length if the signal is too strong.
To tune to a weak FM station, adjust BAND
to FM (mono).
• For MW, the set uses a built-in antenna.
Direct this antenna for best reception by
turning the whole set.
TUNER
.
Page 4
CD Player
CD Player
Playing a CD
• This CD player plays Audio Discs including
CD-Recordables (CD-R) and CD-Rewritables
(CD-RW).
• MP3, CD-ROM, CD-I, CDV,VCD, DVD or
computer CDs are not possible for playback.
IMPORTANT!
CDs encoded with copyright protection
technologies by some record companies may
be unplayable by this product.
1 Adjust the Source selector to CD.
2 Open the CD door, and insert a CD with
the printed side facing up, then press the CD
door gently to close.
➜ Display shows --, and later the total
number of tracks (See 2).
3 Press
4 To pause playback, press2/;.
5 To resume, press2/;again.
6 To stop CD playback, press9.
Helpful hints:
CD play will also stop when:
– you open the CD door ;
– you select
–
2/;
to start playback.
➜
PLAY/PAUSE LED lights up.
➜
PLAY/PAUSE LED flahes.
TUNER
the CD has reached the end.
or
OFF
sound source;
Selecting a different track
• Press
• In the pause/stop position, press 2/; to start
∞/ §
SKIP once or repeatedly until
the desired track number appears in the display.
playback.
Finding a passage within a
track
1 During playback, press and hold ∞ or § .
➜ The CD is played at high speed and with
reduced volume.
2 When you recognize the passage you want,
release ∞ or § to resume normal playback.
Helpful hints:
– When your searching reaches the end of the
last track, the CD goes to stop mode.
Programming track numbers
You may store up to 20 tracks in the desired
sequence. If you like, store any track more
than once.
1 In the stop position, press PROG. to
activate programming.
➜ “0“ flashes (See 3).
➜ PROG LED also flashes.
∞
2 Press
3 Press PROG. to store the desired track
4 Repeat steps 2 to 3 to select and store all
5 To play your program, press
or §to select your desired track
number.
number.
➜ “0“ flashes for you to program the next
track.
desired tracks in this way.
➜ If you attempt to store more than 20
tracks, no track can be selected and the
display shows flashing
➜ PROG LED flashes during playback.
----
.
2/;
.
Helpful hints :
– When playback of your program comes
to the stop position, your set will return
to normal playback.To re-enter program
mode, press PROG. in the stop position.
Erasing a program
You can erase the contents of the memory
by:
– pressing
– selecting
– opening the CD door;
9.
TUNERorOFF
;
REPEAT play mode
You can play the current track or the whole
disc repeatedly, and combine REPEAT
modes with PROG (PROGRAM).
1 To select play mode, press REPEAT once or
more.
➜ REPEAT LED flashes – plays the
current track continuously.
➜ RREPEAT LED lights up – repeats the
entire CD/program
2 Press 2; to star t playback if in the stop/pause
position.
3 To return to normal playback, press
repeatedly until the REPEAT LED lights off.
– You can also press 9 to cancel your play
mode.
REPEAT
Page 5
Hearing Safety
Listen at a moderate volume.
• Using headphones at a high volume can impair your hearing. This product can produce sounds in
decibel ranges that may cause hearing loss for a normal person, even for exposure less than a
minute. The higher decibel ranges are offered for those that may have already experienced some
hearing loss.
• Sound can be deceiving. Over time your hearing "comfor t level" adapts to higher volumes of
sound. So after prolonged listening, what sounds "normal" can actually be loud and harmful to
your hearing. To guard against this, set your volume to a safe level before your hearing adapts and
leave it there.
To establish a safe volume level:
• Set your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, without distortion.
Listen for reasonable periods of time:
• Prolonged exposure to sound, even at normally "safe" levels, can also cause hearing loss.
• Be sure to use your equipment reasonably and take appropriate breaks.
Be sure to observe the following guidelines when using your headphones.
• Listen at reasonable volumes for reasonable periods of time.
• Be careful not to adjust the volume as your hearing adapts.
• Do not turn up the volume so high that you can't hear what's around you.
•You should use caution or temporarily discontinue use in potentially hazardous situations.
• Do not use headphones while operating a motorized vehicle, cycling, skateboarding, etc.; it may
create a traffic hazard and is illegal in many areas.
Maintenance & safety (See 4)
CD player and CD handling
• If the CD player cannot read CDs correctly,
use a cleaning CD to clean the lens before
taking the set to repair.
• The lens of the CD player should never be
touched!
• Sudden changes in the surrounding
temperature can cause condensation on the
lens of your CD player. Playing a CD is then
not possible. Do not attempt to clean the
lens but leave the set in a warm environment
until the moisture evaporates.
•Always close the CD door to avoid dust on
the lens.
•To clean the CD, wipe in a straight line from
the center towards the edge using a soft,
lint-free cloth. Do not use cleaning agents as
they may damage the disc.
• Never write on a CD or attach any stickers
to it.
• Place the set on a flat, hard and stable surface
• Do not expose the set, batteries, CDs to
• The apparatus shall not be exposed to drip-
• Adequate ventilation with a minimum gap of
• Do not cover the ventilation openings with
• No objects filled with liquids, such as vases,
• No naked flame sources, such as lighted can-
• The mechanical par ts of the set contain self-
•To clean the set, use a dry cloth. Do not use
Safety information
so that the system does not tilt.
humidity, rain, sand or excessive heat caused
by heating equipment or direct sunlight.
ping or splashing.
15cm (6 inches) between the ventilation
holes and surrounding surfaces is necessary
to prevent heat build-up.
items such as newspapers, table-cloths, curtains, etc.
shall be placed on the apparatus.
dles, should be placed on the apparatus.
lubricating bearings and must not be oiled or
lubricated.
any cleaning agents containing alcohol, ammonia, benzene or abrasives as these may harm
the housing.
Page 6
Troubleshooting
If a fault occurs, first check the points listed below before taking the set for repair.
If you are unable to remedy a problem by following these hints, consult your dealer or service centre.
WARNING:
Do not open the set as there is a risk of electric shock. Under no
circumstances should you try to repair the set yourself, as this will
invalidate the guarantee.
Problem
– Possible cause
• Remedy
No sound /power
– Volume not adjusted
• Adjust the VOL
– Power cord not securely connected
• Connect the AC power cord properly
– Batteries dead/ incorrectly inserted
• Insert (fresh) batteries correctly
– Headphones connected to the set
Disconnect headphones.
•
– CD contains non-audio files
• Press
∞ , §
once or more to skip to a CD audio
track, instead of the data file.
Display does not function properly / No
reaction to operation of any of the
controls
– Electrostatic discharge
• Switch off and unplug the set. Reconnect after a
few seconds
Severe radio hum or noise
– Electrical interference: set too close to TV, VCR or
computer
• Increase the distance
-- indication
– No CD inserted
•
Insert a CD
– CD badly scratched or dirty
•
Replace/ clean CD, see Maintenance
– Laser lens steamed up
•Wait until lens has cleared
– CD-R/CD-RW is blank or not finalized
•
Use a finalized CD-R/CD-RW or suitable CD
Audio disc only
Note:
Make sure the CD is not encoded with
Copyright protection technologies, as some
do not conform to the Compact Disc standard.
The CD skips tracks
– CD damaged or dirty
• Replace or clean CD
– Program is active
• Quit program mode
Note: A CD badly scratch or dirty may result in
improper operation.
Poor radio reception
– Weak radio signal
• FM: Adjust the FM telescopic aerial
Loading...
