Page 1
MC-
M250Micro Hi-Fi System
MC-
M250
pg 001-021/M250/22-Eng 4/17/02, 4:59 PM1
1
3140 115 29251
Page 2
Important notes for users in the
U.K.
Mains plug
This apparatus is fitted with an approved 13
Amp plug. To change a fuse in this type of plug
proceed as follows:
1 Remove fuse cover and fuse.
2 Fix new fuse which should be a BS1362 5 Amp,
A.S.T.A. or BSI approved type.
3 Refit the fuse cover.
If the fitted plug is not suitable for your socket
outlets, it should be cut off and an appropriate
plug fitted in its place.
If the mains plug contains a fuse, this should
have a value of 5 Amp. If a plug without a fuse
is used, the fuse at the distribution board
should not be greater than 5 Amp.
Note: The severed plug must be disposed of to
avoid a possible shock hazard should it be
inserted into a 13 Amp socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured with
the following code: blue = neutral (N),
brown = live (L).
¶ As these colour s may not correspond with the
colour markings identifying the terminals in
your plug, proceed as follows:
– Connect the blue wire to the terminal
marked N or coloured black.
– Connect the brown wire to the terminal
marked L or coloured red.
– Do not connect either wire to the earth
terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover, make certain
that the cord grip is clamped over the sheath
of the lead - not simply over the two wires.
Italia
DICHIARAZIONE DI CONFORMITA’
Si dichiara che l’apparecchio MC-M250 Philips
risponde alle prescrizioni dell’ar t. 2 comma 1 del
D.M. 28 Agosto 1995 n. 548.
Fatto a Eindhoven
Philips Consumer Electronics
Philips, Glaslaan 2
5616 JB Eindhoven, The Netherlands
Norge
Typeskilt finnes på apparatens underside.
Observer: Nettbryteren er sekundert
innkoplet. Den innebygde netdelen er
derfor ikke frakoplet nettet så lenge
apparatet er tilsluttet nettkontakten.
For å redusere faren for brann eller elektrisk
støt, skal apparatet ikke utsettes for regn eller
fuktighet.
CAUTION
Use of controls or adjustments or
performance of procedures other than
herein may result in hazardous
radiation exposure or other unsafe
operation.
Copyright in the U.K.
Recording and playback of material may
require consent. See Copyright Act 1956 and
The Performer’s Protection Acts 1958 to 1972.
2
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM2
3140 115 29251
Page 3
2
CD
MODE TIMER SLEEP
TUNER TAPE AUX
ALBUM/PRESET
í
Ç
VOL
ë
á
á
MUTEDSC IS/DBB
É
É
Å
É
&
0
*
7
(
6
3
^
!
£
™
¡
#
)
CD/CD-R/CD-RW/MP3 COMPATIBLE
1
2
3
4
5
6
7
8
A
T
S
BAND
DISPLAY
B
D
N
OPEN•CLOSE
N
O
-
Y
SOURCE TIMER SET
MP3•ALBUM
PRESET TRACK•SEARCH•TUNEPROGRAM
%
CLOCK•RDS
+
VOLUME
-
REC
OPEN
$
iR
#
@
!
0
9
3
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM3
MC-M250 MICRO SYSTEM
3
3140 115 29251
Page 4
DK
Advarsel: Usynlig laserstråling ved åbning
når sikkerhedsafbrydere er ude af funktion.
Undgå utsættelse for stråling.
Bemærk: Netafbryderen er sekundært
indkoblet og ofbryder ikke strømmen fra
nettet. Den indbyggede netdel er derfor
tilsluttet til lysnettet så længe netstikket
sidder i stikkontakten.
S
Klass 1 laseraparat
Varning! Om apparaten används på annat
sätt än i denna bruksanvisning specificerats,
kan användaren utsättas för osynlig
laserstrålning, som överskrider gränsen för
laserklass 1.
Observera! Stömbrytaren är sekundärt
kopplad och bryter inte strömmen från
nätet. Den inbyggda nätdelen är därför
ansluten till elnätet så länge stickproppen
sitter i vägguttaget.
SF
Luokan 1 laserlaite
Varoitus! Laitteen käyttäminen
muulla kuin tässä käyttöohjeessa mainitulla
tavalla saattaa altistaa käyttäjän
turvallisuusluokan 1 ylittävälle
näkymättömälle lasersäteilylle.
Oikeus muutoksiin varataan. Laite ei
saa olla alttiina tippu-ja roiskevedelle.
Huom. Toiminnanvalitsin on kytketty
toisiopuolelle, eikä se kytke laitetta irti
sähköverkosta. Sisäänrakennettu verkkoosa on kytkettynä sähköverkkoon aina
silloin, kun pistoke on pistorasiassa.
4
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM4
3140 115 29251
Page 5
Index
English ------------------------------------------------ 6
Français -------------------------------------------- 22
Español --------------------------------------------- 39
Deutsch --------------------------------------------- 56
Nederlands ---------------------------------------- 73
Italiano ---------------------------------------------- 90
Svenska ------------------------------------------- 107
English
Français
Español
DeutschNederlandsItalianoSvenskaDanskSuomi
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM5
Dansk --------------------------------------------- 123
Suomi --------------------------------------------- 139
Português ---------------------------------------- 155
Português
∂ППЛУИО¿ ----------------------------------------- 171
∂ППЛУИО¿Polski
Polski ---------------------------------------------- 189
5
Page 6
Contents
English
General Information
Supplied accessories ............................................ 7
Environmental information ................................ 7
Safety information ................................................ 7
About MP3 disc .................................................... 7
Preparations
Rear connections ............................................. 8–9
Optional connection ........................................... 9
Inserting batteries into the remote control ... 9
Controls
Controls on the system and remote
control .................................................................. 10
Basic Functions
Switching the system on ................................... 11
Switching the system to standby mode ........ 11
Power-saving automatic standby ..................... 11
Volume control ................................................... 11
Sound control ..................................................... 11
Power
Antennas connection
Speakers connection
Connecting other equipment to your system
Radio Reception
Tuning to radio stations .................................... 14
Programming radio stations ............................. 14
Automatic programming
Manual programming
Tuning to preset radio stations ....................... 15
RDS ....................................................................... 15
Setting the RDS clock
Tape Operation/Recording
Tape playback ...................................................... 16
Rewinding / Fast forwarding ............................ 16
General information on recording ................. 16
Preparation for recording ................................ 17
Synchro start CD recording ............................ 17
One touch recording......................................... 17
Recording timer .................................................. 17
Clock/Timer
Clock setting ....................................................... 18
Timer setting ....................................................... 18
Activating and deactivating timer
Sleep timer setting ............................................. 18
Specifications ........................................... 19
CD / MP3-CD Operations
Discs for playback .............................................. 12
Playing a disc ........................................................ 12
Text display .......................................................... 12
Selecting a different track ................................. 12
Finding a passage within a track ...................... 13
Selecting a desired Album/Track
(MP3 disc only) ................................................... 13
Different play modes: SHUFFLE
and REPEAT ......................................................... 13
Programming the disc tracks ........................... 13
Reviewing the programme ............................... 13
Erasing the programme ..................................... 13
6
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM6
Maintenance.............................................. 20
Troubleshooting ............................. 20–21
3140 115 29252
Page 7
General Information
This product complies with the radio
interference requirements of the European
Community.
Supplied accessories
– 2 speaker boxes
– remote control
– batteries (two AAA size) for remote control
– AM loop antenna
– FM wire antenna
Environmental Information
All unnecessary packaging has been omitted. We
have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags,
protective foam sheet).
Your system consists of materials which can be
recycled and reused if disassembled by a
specialised company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Safety information
● Place the system on a flat, hard and stable
surface.
● Place the system in a location with adequate
ventilation to prevent internal heat build-up in
your system. Allow at least 10 cm (4 inches)
clearance from the rear and the top of the unit
and 5 cm (2 inches) from each side.
● Do not expose the system, batteries or discs to
excessive moisture, rain, sand or heat sources
caused by heating equipment or direct sunlight.
● The lens may cloud over when the system is
suddenly moved from cold to warm
surroundings, making it impossible to play a disc.
Leave the system in the warm environment until
the moisture evaporates.
● The mechanical par ts of the set contain self-
lubricating bearings and must not be oiled or
lubricated.
● When the system is switched to Standby
mode, it is still consuming some power.
To disconnect the system from the
power supply completely, remove the AC
power plug from the wall socket.
About MP3 disc
Supported formats
– ISO9660, Joliet, Multisession
– Max. track number plus album is 300
– Max. nested directory is 8 levels
– The max. album number is 30
– The max. MP3 programme track number is
20
– Suppor ted VBR bit-rate
– Supported sampling frequencies for MP3 disc
are: 32 kHz, 44.1 kHz, 48 kHz
– Supported Bit-rates of MP3 disc are: 32, 64,
96, 128, 192, 256 (kbps)
Making your own MP3-CD
1 Rip the music from your own Digital Audio CDs
or download legal MP3 music from the Internet.
2 Record (“burn”) the music on CD-R(W) disc
with your home PC. Make sure to use a
recording speed not faster than indicated on the
CD-R(W) and avoid running other programme
simultaneously on your PC during the recording
process.
Sound Quality
Take note that MP3-CD compilations should
best contain only MP3 tracks (.mp3). To
achieve a good MP3 quality, a bit rate of
128 kbps is recommended.
English
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM7
7
3140 115 29252
Page 8
Preparations
English
FM wire antenna
AM loop
antenna
speaker
(right)
AC power cord
Rear connections
The type plate is located at the rear of the
system.
A Power
Before connecting the AC power cord to the
wall outlet, ensure that all other connections
have been made.
WARNING!
– For optimal performance, use only the
original power cable.
– Never make or change connections with
the power switched on.
AM
aerial
A
B
C
speaker
(left)
B Antennas Connection
Connect the supplied AM loop antenna and FM
antenna to the respective terminals. Adjust the
position of the antenna for optimal reception.
AM Antenna
To avoid overheating of the system, a safety
circuit has been built in. Therefore, your
system may switch to Standby mode
automatically under extreme conditions. If
this happens, let the system cool down
before reusing it (not available for all versions).
8
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM8
● Position the antenna as far as possible from a TV,
VCR or other radiation source.
3140 115 29252
Page 9
Preparations
FM Antenna
● For better FM stereo reception, connect an
outdoor FM antenna to the FM AERIAL (FM
ANTENNA) terminal.
C Speakers Connection
Front Speakers
Connect the speaker wires to the SPEAKERS
terminals, right speaker to "RIGHT" and left
speaker to "LEFT", coloured (marked) wire to
"+" and black (unmarked) wire to "-".
1
● Fully inser t the stripped portion of the speaker
wire into the terminal as shown.
Notes:
– For optimal sound performance, use the
supplied speakers.
– Do not connect more than one speaker to any
one pair of +/- speaker terminals.
– Do not connect speakers with an impedance
lower than the speakers supplied. Please refer to
the SPECIFICATIONS section of this manual.
2
Optional connection
The optional equipment and connecting cords
are not supplied. Refer to the operating
instructions of the connected equipment for
details.
Connecting other equipment to your
system
Connect the audio left and right OUT terminals
of a TV, VCR, Laser Disc player, DVD player or
CD Recorder to the AUX IN terminals.
Note:
– If you are connecting equipment with a
monaural output (a single audio out terminal),
connect it to the AUX IN left terminal. Alternatively,
you can use a “single to double” cinch cable (the
output sound still remain monaural).
Inserting batteries into the
remote control
Insert two batteries (type R03 or AAA) into the
remote control with the correct polarity as
indicated by the "+" and "-" symbols inside
the battery compar tment.
CAUTION!
– Remove batteries if they are exhausted
or will not be used for a long time.
– Do not use old and new or different
types of batteries in combination.
– Batteries contain chemical substances, so
they should be disposed off properly.
English
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM9
9
3140 115 29252
Page 10
Controls (illustrations on page 3)
English
Controls on the system and
remote control
1 STANDBY ON y
– to switch the system on or to standby mode.
2 Display screen
– to view the current status of the system.
3 SOURCE
– to select the respective sound source : CD,
TUNER, TAPE or AUX.
4 BAND / DISPLAY
for Tuner ............. to select waveband : FM, MW or
LW.
for CD/MP3-CD…to select disc information
display mode.
5 PROGRAM
for CD/MP3-CD…to programme disc tracks.
for Tuner ............. to programme preset radio
stations.
6 34 PRESET / MP3•ALBUM / TIMER SET
for MP3-CD .....to select previous/next album.
for Tuner ............. to select a preset radio station.
for Timer (3) ... (on the system only) to set the
timer function.
7 S T TRACK•SEARCH•TUNE
(àáon remote control)
for CD ................. to fast reverse/forward the disc.
for CD/MP3 CD…(on the system only) to select
a desired track.
for Tuner ............. to tune to a lower or higher
radio frequency.
for Tape ............... to rewind or fast forward.
8 Tape deck
9 OPEN ç
– to open tape compartment.
0 9
for CD/MP3-CD…to stop playback or to clear a
programme.
for Tape ............... to stop playback or recording.
! VOLUME +/-
– to increase or decrease the volume.
– (on the system only) to adjust the hours and
minutes for the clock/timer functions.
@ RECORD
– to start recording.
# ÉÅ / CLOCK•RDS
for CD/MP3-CD…to start or interrupt playback.
for Tuner ............. to activate RDS news.
for Tape ............... to start playback.
for Clock ............ (on the system only) to set the
clock function.
$ iR sensor
– infrared sensor for remote control.
% OPEN•CLOSE ç
– to open or close the disc tray.
^ MODE
– to shuffle and repeat a track/disc.
& ¡ / ™
– to select a desired track.
* DSC (Digital Sound Control)
– to select the desired sound effect : OPTIMAL/
ROCK/POP/JAZZ.
( IS/DBB (Incredible Surround/Dynamic
Bass Boost)
– to create a super-enhanced stereo effect.
– to enhance the bass.
) MUTE
– interrupts and resumes sound reproduction.
¡ TIMER
– to activate/deactivate the timer function.
™ SLEEP
– to activate/deactivate or set the sleep timer.
£ B
– to switch the system to standby mode.
Notes for remote control:
– First select the source you wish to control
by pressing one of the source select keys on
the remote control (for example CD,
TUNER).
– Then select the desired function (for
exampleÉ,
í
,
ë
).
10
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM10
3140 115 29252
Page 11
N
á
á
O
-
Y
B
D
N
A
T
S
SOURCE TIMER SET CLOCK•RDS
BAND
DISPLAY
MP3•ALBUM
PRESET TRACK•SEARCH•TUNEPROGRAM
+
VOLUME
-
Basic Functions
Volume control
Press VOLUME +/- to increase or decrease
the volume level.
➜ Display shows the volume level "
VOLUMEVOLUME
VOLUME"
VOLUMEVOLUME
and a number from 0-32.
iR
REC
To switch off the volume temporarily
● Press MUTE on the remote control.
➜ Playback will continue without sound and
MUTEMUTE
"
MUTE" is displayed.
MUTEMUTE
● To restore the volume, press MUTE again or
increase the volume level.
English
IMPORTANT!
Before you operate the system, complete
the preparation procedures.
Switching the system on
● Press STANDBY ON 2 or SOURCE.
➜ The system will switch to the last selected
source.
● Press CD, TUNER, TAPE or AUX on the
remote control.
➜ The system will switch to the selected source.
Switching the system to standby
mode
● Press STANDBY ON 2 on the system or
remote control.
● If in recording mode, press 9 first.
➜ The volume level, interactive sound settings,
last selected source and tuner presets will be
retained in the player's memory.
Power-saving automatic standby
As a power-saving feature, the system will
automatically switch to Standby mode if you do
not press any buttons within 15 minutes after a
disc or tape has stopped playing.
Sound control
MUTEDSC IS/DBB
É
É
● Press DSC repeatedly to select the desired
sound effect : OPTIMAL, ROCK,JAZZ or POP.
● Press IS/DBB to switch on or off the surround
sound effect or bass enhancement.
➜ The sequences are as follows :
INCR.SURR. ™ DBB ™ DBB+INCR.SURR.
™ OFF
➜ If the DBB is activated, DBB is shown.
➜ If the IS is activated, INCR. SURR is shown.
Note:
– The effect of INCREDIBLE SURROUND may
vary with different types of music.
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM11
11
3140 115 29252
Page 12
CD/MP3-CD Operations
English
N
O
-
Y
B
D
N
A
T
S
To interrupt playback
● Press ÉÅ.
➜ The current track time flashes.
● To resume playback, press ÉÅ again.
VOLUME
-
iR
+
REC
SOURCE TIMER SET CLOCK•RDS
BAND
DISPLAY
MP3•ALBUM
PRESET TRACK•SEARCH•TUNEPROGRAM
IMPORTANT!
The lens of the CD player should never be
touched.
X
Discs for playback
This system is able to play :
– All pre-recorded audio CDs
– All finalised audio CDR and audio
CDRW discs
– MP3-CDs (CD-ROMs with MP3 tracks)
● CD-ROM, CD-I, CDV, VCD, DVD or computer
CDs, however, are not possible.
Playing a disc
1 Select CD source.
2 Press OPEN•CLOSEç on the top of the
system to open the CD compartment.
CD OPENCD OPEN
➜ “
CD OPEN” is displayed.
CD OPENCD OPEN
3 Inser t a disc with the printed side facing up and
press OPEN•CLOSEç to close the CD door.
READINGREADING
➜ “
READING” is displayed as the CD player
READINGREADING
scans the contents of a disc, and then the total
number of tracks and playing time are shown.
4 Press ÉÅ to start playback.
To stop playback
● Press Ç.
Notes:
– Disc play will also stop when you select another
source or the disc has reached the end.
– For MP3 disc, the disc reading time may exceed
10 seconds due to the large number of songs
compiled into one disc.
Text display
In CD mode
● Press DISPLAY repeatedly to see the following
information.
➜ Track number and elapsed play time of
current track.
➜ Remaining play time of current track.
➜ Total number of tracks played and total
played-back time.
➜ Total remaining number of tracks and total
remaining play time.
In MP3-CD mode
● Press DISPLAY repeatedly to select four
display modes : Number, Track, Album and ID3.
Number ➜ Album number, track number and
elapsed play time.
Track ➜ Track name and elapsed play time.
Album ➜ Album name and elapsed play time.
ID-3 ➜ ID-3 tag scrolls once and elapsed play
time.
Selecting a different track
● Press S or T (¡ or ™) repeatedly until
the desired track number appears in the display.
● If playback is stopped, pressÉÅ to start
playback.
12
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM12
3140 115 29252
Page 13
CD/MP3-CD Operations
Finding a passage within a track
1 Press and hold down on S or T (à or
á).
➜ The disc is played at high speed and low
volume.
2 When you recognize the passage you want,
release S or T (à or á).
➜ Normal playback continues.
Note:
– During a disc programme or if REPEAT/
SHUFFLE mode active, searching is only possible
within the same track.
Selecting a desired album/track
(MP3 disc only)
To select a desired album
● Press 4 or 3 repeatedly.
To select a desired track
● Press S or T (¡ or ™) repeatedly.
Different play modes: SHUFFLE
and REPEAT
You can select and change the various play
modes before or during playback.
1 Press MODE on the remote control to select :
➜ shuffle – tracks of the entire disc/
programme are played in random order.
➜ shuffle repeat all – to repeat the entire
disc/ programme continuously in random order.
➜ repeat all – to repeat the entire disc/
programme.
➜ repeat – to repeat the current track.
2 To return to normal playback, press MODE until
the various SHUFFLE/ REPEAT modes are no
longer displayed.
● You can also press 9 to cancel your play mode.
Note:
– If Shuffle is activated on a MP3-CD, all titles
stored in the disc will be played in random order.
Programming the disc tracks
Programming tracks is possible when playback is
stopped. Up to 20 tracks can be stored in the
memory in any order.
1 Press PROGRAM to enter the programming
mode.
➜ A track number is shown and prog flashes.
2 Press S or T (¡ or ™) repeatedly to
select your desired track number.
● For MP3 disc, press 4 / 3 and S / T
(¡ or ™) to select the desired album and track
for programming.
3 Press PROGRAM to confirm the track number
to be stored.
➜ The number of tracks programmed and total
playing time of the programme is shown briefly,
then the selected track and “
➜ For MP3 disc, total playing time will not be
shown.
PROGPROG
PROG”.
PROGPROG
4 Repeat steps 2-3 to select and store all desired
tracks.
MEMORY FULLMEMORY FULL
➜ “
MEMORY FULL” is displayed if you attempt
MEMORY FULLMEMORY FULL
to programme more than 20 tracks.
5 To start playback of your disc programme, press
ÉÅ.
Note:
– It is not possible to create a programme with
MP3 tracks from multiple CDs, or combined with
normal audio tracks.
Reviewing the programme
In stop mode, press and hold PROGRAM until
the display shows all your stored track numbers
in sequence.
Erasing the programme
● Press Ç once when playback is stopped or
twice during playback.
➜ prog disappears and “
Note:
– The programme will be erased when the system
is disconnected from the power supply or when the
disc tray is opened.
CLEARCLEAR
CLEAR” is displayed.
CLEARCLEAR
English
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM13
13
3140 115 29252
Page 14
Radio Reception
English
N
O
-
Y
B
D
N
A
T
S
SOURCE TIMER SET CLOCK•RDS
BAND
DISPLAY
Tuning to radio stations
1 Select TUNER source.
➜ “
2 Press BAND to select the desired waveband :
FM, MW or LW.
3 Press down on S or T (à or á) and
release button.
➜ The display will show "
station with sufficient signal strength is found.
➜ If a FM station is received in stereo, is
shown.
4 Repeat step 3 if necessar y until you find the
desired station.
● To tune to a weak station, press S or T
(à or á) briefly and repeatedly until you have
found optimal reception.
MP3•ALBUM
PRESET TRACK•SEARCH•TUNEPROGRAM
TUNERTUNER
TUNER” is displayed briefly.
TUNERTUNER
SEARCHSEARCH
SEARCH" until a radio
SEARCHSEARCH
+
VOLUME
-
Programming radio stations
You can store up to a total of 40 radio stations
in the memory.
Automatic programming
iR
REC
Automatic programming will start with a chosen
preset number. From this preset number
upwards, former programmed radio stations will
be overridden. The system will only programme
stations which are not in the memory already.
1 Press 4 or 3 to select the preset number where
programming should start.
Note:
– If no preset number is selected, default is preset
(1) and all your presets will be overridden.
2 Press PROGRAM for more than two seconds
to activate programming.
AUTOAUTO
➜ “
AUTO” is displayed and available stations are
AUTOAUTO
programmed in order of waveband reception
strength, starting from all RDS stations and
followed by FM, MW and LW bands respectively.
➜ The last preset radio station (or the first
available RDS station) will be played.
Manual programming
1 Tune to your desired station (refer to “Tuning to
radio stations”).
2 Press PROGRAM to activate programming.
➜ prog flashes in the display.
3 Press 4 or 3 to allocate a number from 1 to 40
to this station.
4 Press PROGRAM again to confirm the setting.
➜ prog disappears, the preset number and the
frequency of the preset station are shown.
5 Repeat the above four steps to store other
stations.
● You can override a preset station by storing
another frequency in its place.
14
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM14
3140 115 29252
Page 15
Radio Reception
Tuning to preset radio stations
● Press 4 or 3 until the desired preset station is
displayed.
RDS
Radio Data System is a service that allows
FM stations to show additional information. If
you are receiving a RDS station, and the
station name are displayed.
When automatic programming is used, RDS
stations will be programmed first.
Scrolling through different RDS
information
● Press CLOCK•RDS briefly and repeatedly to
scroll through the following information (if
available):
– Station name
– Radio text messages
– Frequency
Note:
– If you press RDS and the RDS signal is not
available "
Setting the RDS clock
Some RDS radio station may be transmitting a
real clock time at an interval of ever y minute. It
is possible to set the clock by using a time signal
which is broadcast together with the RDS signal.
NO RDS
" is displayed.
1 Tune to a RDS station (refer to “Tuning to radio
stations”).
2 Press CLOCK•RDS for more than two
seconds.
SEARCH RDS TIMESEARCH RDS TIME
➜ "
SEARCH RDS TIME" is displayed.
SEARCH RDS TIMESEARCH RDS TIME
➜ When RDS time is read, "
displayed and the current time will be stored.
➜ If the RDS radio station does not transmit
RDS time within 90 seconds, "
displayed.
RDS TIMERDS TIME
RDS TIME" is
RDS TIMERDS TIME
NO RDS TIMENO RDS TIME
NO RDS TIME" is
NO RDS TIMENO RDS TIME
Note:
– Some RDS radio station may be transmitting a
real time clock at a minute interval. The accuracy
of the transmitted time depends on the
transmitting RDS radio station.
English
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM15
15
3140 115 29252
Page 16
Tape Operation / Recording
English
N
O
-
Y
B
D
N
A
T
S
SOURCE TIMER SET CLOCK•RDS
BAND
DISPLAY
MP3•ALBUM
PRESET TRACK•SEARCH•TUNEPROGRAM
Tape playback
1 Select TAPE source.
➜ The display shows “
TAPETAPE
TAPE” briefly.
TAPETAPE
2 Press OPEN ç to open the tape door.
3 Inser t a recorded tape and close the tape door.
● Load the tape with the open side downward and
the full spool to the left.
4 Press ÉÅ to start playback.
To stop playback
● Press Ç.
To reset the tape counter display
● In stop mode, press Ç once.
+
VOLUME
-
Rewinding / Fast forwarding
1 Stop playback, press S or T (à or á).
➜ The tape will stop automatically at the end of
rewinding or fast forwarding.
➜ During fast winding, you can monitor the tape
iR
REC
message with the tape counter.
2 Press Ç to stop rewinding or fast forwarding.
Note:
– During rewinding or fast forwarding of a tape, it
is also possible to select another source (CD or
TUNER, for example).
General information on
OPEN
recording
● For recording, use only NORMAL (IEC type I)
tapes on which the tabs have not yet been
broken. This deck is not suited for recording on
METAL (IEC IV) type tapes.
● The best recording level is set automatically.
Altering the VOLUME, INCREDIBLE
SURROUND or DBB will not affect the
recording in progress.
● At the very beginning and end of the tape, no
recording will take place during the 7 seconds
when the leader tape passes the recorder heads.
● To protect a tape from accidental erasure, have
the tape in front of you and break out the left
tab. Recording on this side is no longer possible.
If, however, you wish to record over this side
again, cover the tabs with a piece of adhesive
tape.
16
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM16
IMPORTANT!
Recording is permissible if copyright or
other rights of third parties are not
infringed upon.
3140 115 29252
Page 17
Tape Operation / Recording
Preparation for recording
1 Select TAPE source.
2 Load a recordable tape into tape deck with full
spool to the left.
3 Prepare the source to be recorded.
CD – load the disc.
TUNER – tune to the desired radio station.
AUX – connect external equipment.
When recording is in progress
➜ REC starts flashing.
● To stop recording, press 9.
● It is not possible to listen to another source.
● It is not possible to activate the timer function.
Synchro start CD recording
1 Select CD source.
● Press S or T (¡ or ™) to select the
desired track to start recording.
● You can programme the tracks in the order you
want them to be recorded (refer to “CD/MP3CD Operations - Programming the disc tracks”).
2 Press REC to star t recording.
➜ Playing of the CD programme starts
automatically from the beginning of the CD
after 7 seconds. It is not necessary to star t the
CD player separately.
One touch recording
1 Select CD, TUNER or AUX source.
2 If necessar y, star t playback of the selected
source.
3 Press REC to star t recording.
Recording timer
To record from the radio, you will need to use a
preset radio station and to set a start (ON) and
finish (OFF) time.
1 Select the preset radio station to record from
(refer to “Radio Reception - Tuning to preset
radio stations”).
2 In standby mode, press TIMER SET for more
than two seconds.
➜ flashes and a source is displayed.
3 Press SOURCE repeatedly until “REC TUN”
source is displayed.
4 Press TIMER SET to confirm the source.
SET ON TIMESET ON TIME
➜ “
SET ON TIME” is displayed, and the
SET ON TIMESET ON TIME
clock digits for the hours flash.
5 Press VOLUME +/- to set the hours.
6 Press TIMER SET again.
➜ The clock digits for the minutes flash.
7 Press VOLUME +/- to set the minutes.
8 Press TIMER SET to confirm the recording
start time.
SET OFF TIMESET OFF TIME
➜ “
SET OFF TIME” is displayed, and the
SET OFF TIMESET OFF TIME
clock digits for the hours flash.
9 Repeat steps 5-7 to set the finish time.
10 Press TIMER SET to confirm the timer settings.
➜ is shown and the recording timer is now
set.
Note:
– The recording timer will not be activated if the
system is in tape play mode.
English
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM17
17
3140 115 29252
Page 18
Clock/Timer
English
N
O
-
Y
B
D
N
A
T
S
SOURCE TIMER SET CLOCK•RDS
BAND
DISPLAY
Clock setting
There are two possible methods for setting the
clock: manually or automatically by using RDS.
Automatic clock setting
Refer to page 15 on “Setting the RDS clock”.
Manual clock setting
1 In standby mode, press and hold
CLOCK•RDS.
➜ The clock digits for the hours flash.
2 Press VOLUME +/- to set the hours.
3 Press CLOCK•RDS again.
➜ The clock digits for the minutes flash.
4 Press VOLUME +/- to set the minutes.
5 Press CLOCK•RDS to confirm the time.
Timer setting
● The system can be used as an alarm clock,
whereby the CD, TUNER or TAPE is switched on
at a set time. The clock time needs to be set first
before the timer can be used.
● You can also use it to record a favourite tuner
programme at a set period (refer to “Recording
timer”)
● During setting, if no button is pressed within 90
seconds, the system will exit timer setting mode
automatically.
MP3•ALBUM
PRESET TRACK•SEARCH•TUNEPROGRAM
VOLUME
-
2 Press SOURCE repeatedly (or CD, TUNER,
TAPE on the remote control) to select the
sound source.
3 Press TIMER SET to confirm your desired
mode.
➜ The selected source is shown.
iR
+
REC
Display sequence scrolls “
flashes. The clock digits for the hours flash.
4 Press VOLUME +/- to set the hours.
SET ON TIMESET ON TIME
SET ON TIME” and
SET ON TIMESET ON TIME
5 Press TIMER SET again.
➜ The clock digits for the minutes flash.
6 Press VOLUME +/- to set the minutes.
7 Press TIMER SET to confirm the time.
➜ The timer is now set and activated.
Activating and deactivating timer
● In standby or during playback, press TIMER
once on the remote control.
➜ Display shows if activated, and disappears if
deactivated.
Sleep timer setting
The sleep timer enables the system to switch off
by itself after a set period of time. The clock time
needs to be set first before the sleep timer can
be used.
1 Press SLEEP on the remote control repeatedly
to select a preset time.
➜ The selections are as follows (time in
minutes):
6060
4545
3030
1515
OFFOFF
60 ™
45 ™
6060
4545
SLEEP XXSLEEP XX
➜ "
SLEEP XX" or "
SLEEP XXSLEEP XX
30 ™
15 ™
3030
1515
OFFOFF
OFF" is displayed. "
OFFOFF
OFF ™
OFFOFF
6060
60 …
6060
XXXX
XX" is the
XXXX
time in minutes.
2 When you reach the desired length of time, stop
pressing the SLEEP button.
➜ Once SLEEP is activated, "
across the display at repeated intervals.
To deactivate the sleep timer
● Press SLEEP repeatedly until "
or press the STANDBY ON button.
SLEEP ONSLEEP ON
SLEEP ON" scrolls
SLEEP ONSLEEP ON
0FF0FF
0FF" is displayed,
0FF0FF
1 In standby mode, press TIMER SET for more
than two seconds.
18
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM18
3140 115 29252
Page 19
Specifications
AMPLIFIER
Output power ....................................... 2 x 10 W RMS
............................................................ 20 W + 20 W MPO
Signal-to-noise ratio .......................... ≥ 65 dBA (IEC)
Frequency response ......... 40 – 20000 Hz, ± 3 dB
Input sensitivity AUX ....................... 0.5 V (max. 2 V)
Impedance loudspeakers ......................................... 8 Ω
Impedance headphones .................... 32 Ω -1000 Ω
CD/MP3-CD PLAYER
Number of programmable tracks ......................... 20
Frequency range .................................. 20 – 20000 Hz
Signal-to-noise ratio ............................................ 75 dBA
Channel separation ..........................≥ 60 dB (1 kHz)
Total harmonic distortion ........................... < 0.003%
MPEG 1 Layer 3 (MP3-CD) .......... MPEG AUDIO
MP3-CD bit rate ....................................... 32-256 kbps
(128 kbps advised)
Sampling frequencies ....................... 32, 44.1, 48 kHz
TUNER
FM wave range ...................................87.5 – 108 MHz
MW wave range ................................ 531 – 1602 kHz
LW wave range .....................................153 – 279 kHz
Sensitivity at 75 Ω
– mono, 26 dB signal-to-noise ratio ............ 2.8 µV
– stereo, 46 dB signal-to-noise ratio ........ 61.4 µV
Selectivity ................................................................. ≥ 28 dB
Total harmonic distortion ..................................... ≤ 5%
Frequency response ..... 63 – 12500 Hz (± 3 dB)
Signal-to-noise-ratio ...................................... ≥ 50 dBA
SPEAKERS
2-way Bass reflex system
Dimensions (w x h x d) . 130 x 220 x 215 (mm)
GENERAL INFORMATION
AC Power ..................................... 220 – 230 V / 50 Hz
Dimensions (w x h x d) .. 140 x 220 x 250 (mm)
Weight (with/without speakers)
............................................................... approx. 6.3 / 3.3 kg
Standby power consumption .......................... < 3 W
Specifications and external appearance are
subject to change without notice.
English
TAPE DECK
Frequency response
Normal tape (type I) ...... 80 – 12500 Hz (8 dB)
Signal-to-noise ratio
Normal tape (type I) .................................... 50 dBA
Wow and flutter ......................................... ≤ 0.4% DIN
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM19
19
3140 115 29252
Page 20
A A B C
Maintenance
English
Cleaning the Cabinet
● Use a soft cloth slightly moistened with a mild
detergent solution. Do not use a solution
containing alcohol, spirits, ammonia or abrasives.
Cleaning Discs
● When a disc becomes dir ty,
clean it with a cleaning cloth.
Wipe the disc from the centre
out.
● Do not use solvents such as
benzene, thinner, commercially
available cleaners, or antistatic spray intended for
analogue records.
Cleaning the disc lens
● After prolonged use, dirt or dust may
accumulate at the disc lens. To ensure good
playback quality, clean the disc lens with Philips
CD Lens Cleaner or any commercially available
cleaner. Follow the instructions supplied with
cleaner.
Cleaning the Heads and the Tape Paths
● To ensure good recording and playback quality,
clean the heads A, the capstan(s) B, and
pressure roller(s) C after every 50 hours of
tape operation.
Caution: Do not rotate the heads during
cleaning.
● Use a cotton swab slightly moistened with
cleaning fluid or alcohol.
● You can also clean the heads by playing a
cleaning tape once.
Demagnetizing the heads
● Use a demagnetizing tape available at your
dealer.
Troubleshooting
WARNING
Under no circumstances should you try to repair the system yourself, as this will invalidate the
warranty. Do not open the system as there is a risk of electric shock.
If a fault occurs, first check the points listed below before taking the system for repair. If you
are unable to remedy a problem by following these hints, consult your dealer or service centre.
Problem Solution
CD OPERATION
NO DISCNO DISC
“
NO DISC” is displayed. – Inser t a disc.
NO DISCNO DISC
20
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM20
– Check if the disc is inser ted upside down.
– Wait until the moisture condensation at the lens
has cleared.
– Replace or clean the disc, see “Maintenance”.
– Use a finalised CD-RW or CD-R.
3140 115 29252
Page 21
Troubleshooting
RADIO RECEPTION
Radio reception is poor. – If the signal is too weak, adjust the antenna or
connect an external antenna for better
reception.
– Increase the distance between the Micro HiFi
System and your TV or VCR.
TAPE OPERATION / RECORDING
Recording or playback cannot be made. – Clean deck par ts, see “Maintenance”.
– Use only normal (IEC I) tape for recording.
CHECK TAPECHECK TAPE
“
CHECK TAPE” is displayed. – Apply a piece of adhesive tape over the missing
CHECK TAPECHECK TAPE
The tape deck door cannot open. – Remove and reconnect the AC power plug and
GENERAL
The system does not react when buttons – Remove and reconnect the AC power plug and
are pressed. switch on the system again.
Sound cannot be heard or is of poor – Adjust the volume.
quality. – Disconnect the headphones.
The left and right sound outputs are – Check the speaker connections and location.
reversed.
The remote control does not function – Select the source (CD or TUNER, for example)
properly. before pressing the function button (É,í,ë).
The timer is not working. – Set the clock correctly.
The Clock/Timer setting is erased. – Power has been interrupted or the power cord
tab space.
switch on the system again.
– Check that the speaker s are connected correctly.
– Check if the stripped speaker wire is clamped.
– Make sure the MP3-CD was recorded within
32-256 kbps bit rate with sampling frequencies
at 48 kHz, 44.1 kHz or 32 kHz.
– Reduce the distance between the remote
control and the system.
– Inser t the batteries with their polarities
(+/– signs) aligned as indicated.
– Replace the batteries.
– Point the remote control directly toward
IR sensor on the front of the system.
– Press TIMER to switch on the timer.
– If a recording is in progress, stop the recording.
has been disconnected. Reset the clock/timer.
English
pg 001-021/M250/22-Eng 4/17/02, 5:00 PM21
21
3140 115 29252
Loading...
