Philips
Micro music system
CD, MP3-CD, USB, FM
30 W
MCM1350
Bring power to your tunes
Obsessed with sound
Listen to all your favourites on your portable music player with USB Direct and Audio in.
This Philips Micro music system also plays MP3-CD and CD-R/RW. 30 RMS max output
power and Bass Reflex speakers deliver big sound and powerful bass.
Enrich your sound experience
• Bass Reflex Speaker System delivers a powerful, deeper bass
• Digital Sound Control for optimised music style settings
• 30 W RMS Maximum output power
Enjoy your music from multiple sources
• Play MP3-CD, CD and CD-R/RW
• USB Direct for easy MP3 music playback
• Audio-in for portable music playback
Easy to use
• Motorised CD loader for convenient access
• Digital tuning with preset stations for extra convenience
Page 2
MCM1350/05
Micro music system
CD, MP3-CD, USB, FM 30 W
Highlights
Bass Reflex Speaker System
Bass Reflex Speaker System delivers a deep bass
experience from a compact loudspeaker box system.
It differs from a conventional loudspeaker box
system in the addition of a bass pipe that is
acoustically aligned to the woofer to optimise the
low frequency roll-off of the system. The result is
deeper controlled bass and lower distortion. The
system works by causing the air mass in the bass pipe
to vibrate like a conventional woofer. Combined
with the response of the woofer, the system extends
the overall low frequency sounds to create a
completely new dimension of deep bass.
Audio-in
all you have to do is to plug your portable MP3 player
into the audio system.
Digital Sound Control
Digital Sound Control offers you a choice of pre-set
Balance, Clear, Powerful, Warm and Bright controls
you can use to optimise the frequency ranges for
different musical styles. Each mode uses graphic
equalizing technology to automatically adjust the
sound balance and enhance the most important
sound frequencies in your chosen music style.
Ultimately, Digital Sound Control makes it easy for
you get the most out of your music by precisely
adjusting the sound balance to match the type of
music you are playing.
USB Direct for easy MP3 music
Specifications
Sound
• Sound enhancement: digital sound control
• Maximum output power (RMS): 30 W
Loudspeakers
• Speaker drivers: 3.5" woofer
• Speaker types: bass reflex speaker system
Audio playback
• Disc playback modes: fast forward/reverse, next/
previous track search, repeat/shuffle/programme
• Playback media: CD, CD-R/RW, MP3-CD, USB
ash drive
fl
• USB Direct playback modes: fast reverse/fast
orward, play/pause, previous/next, repeat, shuffle,
f
stop
Tuner/Reception/Transmission
• Tuner bands: FM stereo
• Station presets: 20
• Antenna: FM fixed pigtail antenna
• Tuner enhancement: auto digital tuning, auto scan
Connectivity
• Audio in (3.5 mm)
• USB: USB host
Convenience
• Alarms: CD Alarm, Radio Alarm, USB alarm
• Clock: On main display, sleep timer
• Display type: LED display
• Loader type: tray
The Audio-in connectivity allows direct playback of
Audio-in content from portable media players.
Besides the benefit of enjoying your favourite music
in the superior sound quality delivered by the audio
system, the Audio in is also extremely convenient as
Thanks to the complete file transferability, you can
easily enjoy the convenience and fun of accessing
more digital music via the built-in USB Direct.
Accessories
• Included accessories: User Manual
• Remote control: 21-key remote
Dimensions
• Gross weight: 4.3 kg
• Main speaker dimensions (W x D): 120 x 143 mm
• Main speaker height: 195 mm
• Main unit depth: 227 mm
• Main unit height: 121 mm
• Main unit width: 180 mm
• Net weight: 3.16 kg
• Packaging depth: 171 mm
• Packaging height: 295 mm
• Packaging width: 543 mm
Power
• Power supply: 220-240 V, 50 Hz
•
Issue date 2016-09-27
Version: 1.0.3
12 NC: 8670 001 29082
EAN: 48 95185 61565 3
© 2016 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
