MC
-
10
Micro HiFi System
pg 001-020/MC10/22-Eng 12/7/00, 1:29 PM1
1
3140 115 27752
2
pg 001-020/MC10/22-Eng 12/7/00, 1:29 PM2
3140 115 27752
%
1
2
9
0
!
@
iR
STANDBY
ON
SELECT
SOURCE
SENSOR
REPEAT
DBB
INTERACTIVE SOUND
BAND
INCREDIBLE SURROUND
CD
CD
TIMER
TIMER
PROGRAM
PROGRAM
DSC
INCREDIBLE SURR.
PRESETSTOP PLAY•PAUSE
PREV NEXT
TUNING
OPEN • CLOSE
CLOCK
PROGRAM
TIMER
ON • OFF
RDS
SHUFFLE
$
3
4
5
6
VOLUME
7
8
RECORD
#
3
pg 001-020/MC10/22-Eng 12/7/00, 1:29 PM3
PLAY
STOP • OPEN
PAUSE
3
3140 115 27752
Important notes for users in the U.K.
Mains plug
This apparatus is fitted with an approved 13 Amp plug. To change a fuse in this type of plug proceed as
follows:
1 Remove fuse cover and fuse.
2 Fix new fuse which should be a BS1362 5 Amp, A.S.T.A. or BSI approved type.
3 Refit the fuse cover.
If the fitted plug is not suitable for your socket outlets, it should be cut off and an appropriate plug fitted in
its place.
If the mains plug contains a fuse, this should have a value of 5 Amp. If a plug without a fuse is used, the
fuse at the distribution board should not be greater than 5 Amp.
Note: The severed plug must be disposed of to avoid a possible shock hazard should it be inserted into a
13 Amp socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured with the following code: blue = neutral (N), brown = live (L).
As these colours may not correspond with the colour markings identifying the terminals in your plug,
proceed as follows:
¶ Connect the blue wire to the terminal marked N or coloured black.
¶ Connect the brown wire to the terminal marked L or coloured red.
¶ Do not connect either wire to the ear th terminal in the plug, marked E (or e) or coloured green (or
green and yellow).
Before replacing the plug cover, make certain that the cord grip is clamped over the sheath of the lead not simply over the two wires.
Copyright in the U.K.
Recording and playback of material may require consent. See Copyright Act 1956 and The Performer’s
Protection Acts 1958 to 1972.
Italia
DICHIARAZIONE DI
CONFORMITA’
Si dichiara che l’apparecchio MC-10
Philips risponde alle prescrizioni dell’ar t.
2 comma 1 del D.M. 28 Agosto 1995
n. 548.
Fatto a Eindhoven
Philips Consumer Electronics
Philips, Glaslaan 2
5616 JB Eindhoven, The Netherlands
4
pg 001-020/MC10/22-Eng 12/7/00, 1:29 PM4
Norge
Typeskilt finnes på apparatens
underside.
Observer: Nettbryteren er sekundert
innkoplet. Den innebygde netdelen er
derfor ikke frakoplet nettet så lenge
apparatet er tilsluttet nettkontakten.
For å redusere faren for brann eller
elektrisk støt, skal apparatet ikke
utsettes for regn eller fuktighet.
3140 115 27752
Index
English ------------------------------------------------ 6
Français -------------------------------------------- 21
Español --------------------------------------------- 36
Deutsch --------------------------------------------- 51
Nederlands ---------------------------------------- 66
Italiano ---------------------------------------------- 81
English
Français
EspañolDeutschNederlandsItalianoSvenskaDanskSuomi
pg 001-020/MC10/22-Eng 12/7/00, 1:29 PM5
Svenska --------------------------------------------- 96
Dansk --------------------------------------------- 111
Suomi --------------------------------------------- 126
Português ---------------------------------------- 141
Português
∂ППЛУИО¿ ----------------------------------------- 156
∂ППЛУИО¿Polski
Polski ---------------------------------------------- 172
5
3140 115 27751
Contents
English
General Information
Environmental Information ................................ 7
Supplied Accessories ........................................... 7
Safety Information ................................................ 7
Preparation
Rear Connections ............................................. 8-9
Inserting batteries into the Remote Control 9
Controls
Controls on the system and remote
control .............................................................. 9-10
Basic Functions
Switching ON ...................................................... 11
Power-saving automatic standby ..................... 11
Adjusting volume and sound............................ 11
Compact Disc
Playing a disc ........................................................ 12
Selecting a different track ................................. 12
Finding a passage within a track ...................... 12
Different play modes: Shuffle and
Repeat ............................................................. 12-13
Programming track numbers ........................... 13
Reviewing the programme ............................... 13
Erasing the programme ..................................... 13
Maintenance.............................................. 17
Clock/Timer
Setting the clock ................................................. 18
Setting Timer ....................................................... 18
Activating and deactivating TIMER ................. 18
Activating and deactivating SLEEP .................. 19
Specifications ........................................... 19
Troubleshooting .................................... 20
Tuner
Tuning to radio stations .................................... 14
Programming radio stations ............................. 14
Tuning to Preset Radio Stations ...................... 14
RDS ................................................................. 14-15
EON ...................................................................... 15
Searching programme type (PTY) .................. 15
RDS News and Traffic Announcement (TA) . 15
Tape Recorder
Tape playback ...................................................... 16
General Information on Recording ................ 16
Synchro Start CD recording...................... 16-17
Recording from the radio................................. 17
Recording from the Aux ................................... 17
6
pg 001-020/MC10/22-Eng 12/7/00, 1:29 PM6
3140 115 27752
General Information
¶ The type plate (which contains the serial
number) is located at the rear of the
system.
¶ Recording is permissible if copyright or
other rights of third parties are not
infringed.
¶ This product complies with the radio
interference requirements of the European
Community.
Environmental Information
All unnecessary packaging has been omitted. We
have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags,
protective foam sheet).
Your system consists of materials which can be
recycled and reused if disassembled by a
specialized company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Supplied accessories
– 2 speaker boxes
– remote control
– AM frame aerial
– FM aerial wire
Safety Information
¶ Before operating the system, check that the
operating voltage indicated on the typeplate (or
the voltage indication beside the voltage
selector) of your system is identical with the
voltage of your local power supply. If not, please
consult your dealer. The typeplate is located at
the rear of your system.
¶ When the system is switched on, do not move it
around.
¶ Place the system on a solid base (e.g. a cabinet).
¶ Place the system in a location with adequate
ventilation to prevent internal heat build-up in
your system. Allow at least 10 cm (4 inches)
clearance from the rear and the top of the unit
and 5 cm (2 inches) from each side.
¶ Do not expose the system to excessive
moisture, rain, sand or heat sources.
¶ Under no circumstances should you repair the
system yourself, as this will invalidate the
warranty!
¶ If the system is brought directly from a cold to a
warm location, or is placed in a very damp room,
moisture may condense on the lens of the CD
unit inside the system. Should this occur, the CD
player will not operate normally. Leave the
power on for about one hour with no disc in the
system until normal playback is possible.
¶ Electrostatic discharge may cause unexpected
problems. See whether these problems
disappear if you unplug the AC power cord and
plug it in again after a few seconds.
¶ To disconnect the system from the
power supply completely, remove the AC
power plug from the wall socket.
English
pg 001-020/MC10/22-Eng 12/7/00, 1:29 PM7
7
3140 115 27752
Preparation
English
A
AM
aerial
FM
aerial
B
75Ω
E
Rear Connections
A AM Loop Antenna Connection
Connect the supplied loop antenna to the AM
ANTENNA terminal. Place the AM loop antenna
far away from the system and adjust its position
for the best reception.
B FM Wire Antenna Connection
Connect the supplied FM wire antenna to the
FM AERIAL (FM ANTENNA) 75 Ω terminal.
Adjust the position of the FM antenna for the
best reception.
Outdoor Antenna
For better FM stereo reception, connect an
outdoor FM antenna to the FM AERIAL (FM
ANTENNA) 75 Ω terminal using a 75 Ω coaxial
wire.
FM AERIAL 75Ω
FM ANTENNA 75Ω
OR
LR
speaker
8Ω
+
RIGHT
–
–
LEFT
+
AUX in
LR
C
D
AUDIO OUT
C Speakers Connection
¶ Connect the right speaker to terminal marked
RIGHT, with the colored wire to + and the
black wire to -.
¶ Connect the left speaker to terminal mar ked
LEFT, with the colored wire to + and the black
wire to -.
¶ Clip the stripped portion of the speaker wire as
shown.
12 mm
unlock
CAUTION:
– For optimal sound performance, it is
recommended to use the supplied speakers.
– Do not connect more than one speaker to any
one pair of +/- speaker terminal.
– Do not connect speakers with impedance lower
than the speakers supplied. Please refer to
SPECIFICATION section of this manual.
lock
8
pg 001-020/MC10/22-Eng 12/7/00, 1:29 PM8
3140 115 27752
Preparation
+
-
+
-
D Connecting other equipment to your
system
You can connect the audio left and right OUT
terminals of a TV, VCR, Laser Disc player, DVD
player or CD Recorder to the AUX IN terminals
at the rear of the system.
E AC Power Supply
After all other connections have been made,
connect the AC power cord of the system to
the wall outlet.
Controls on the system and
remote control
1 STANDBY ON y
– switches the system to standby/on.
– on the remote control only - switches the system
to standby.
2 SELECT SOURCE
– selects the respective sound source for CD/
TUNER/ TAPE /AUX.
– switches on the system.
3 Display
– shows the status of the system.
4 PROGRAM
for CD ................. programmes tracks and reviews
the programme.
for Tuner ............. programmes tuner stations
manually or automatically.
5 TIMER ON•OFF
– activates/deactivates or sets (on the system only)
the timer function.
6 VOLUME ( -/+ )
– adjusts the volume level.
– on the system only - adjusts the hour and minutes
for the clock/timer functions.
Inserting batteries into the
Remote Control
¶ Inser t batteries (Type R06 or AA) into the
remote control as shown in the battery
compartment.
¶ To avoid damage from possible battery leakage,
remove dead batteries or batteries that will not
be used for a long time.
Batteries contain chemical substances, so
they should be disposed off properly.
Controls (illustration on page 3)
7 CLOCK/RDS
– sets the clock function.
– displays RDS information.
8 SHUFFLE
– plays CD tracks in random order.
9 INTERACTIVE SOUND controls:
DBB .................... (Dynamic Bass Boost) enhances
the bass.
DSC ..................... (Digital Sound Control) selects
sound characteristics: OPTIMAL/
ROCK/JAZZ/POP.
INCREDIBLE SURROUND
................................. creates a super-enhanced stereo
effect.
0 iR SENSOR
– infrared sensor for remote control.
! REPEAT/BAND
for CD .................repeats a track/CD programme/
entire CD.
for Tuner ............. selects waveband.
English
9
pg 001-020/MC10/22-Eng 12/7/00, 1:29 PM9
3140 115 27752
Controls
English
@ Mode Selection
STOP 9............ stops CD playback or erase a
PLAY•PAUSE ÉÅ
( É, SIDE/Å )…starts or inter rupts CD play.
PRESET 43
( ¡, ™ ) .............. selects a preset radio station.
PREV ¡1 / NEXT 2™
( ¡, ™ ) ................ skips to the beginning of a
( à, á ) ..........fast searches back and forward
TUNING à á
( à, á ) ..........tunes to radio stations.
# Tape Deck Operation
RECORD ........ starts recording.
PLAY 2 ............ starts playback.
à / á ............... fast rewinds/winds the tape.
STOP•OPEN …stops the tape; opens the
PA US E ..............interrupts recording or playback.
$ OPEN•CLOSE
– opens/closes the CD door.
% n
– connect headphones.
^ MUTE
– interrupts and resumes sound reproduction.
& NEWS/TA
– activates RDS news and Traffic Announcement
(not for all versions).
* SLEEP
– activates/deactivates or selects the sleeper time.
CD programme.
current track/previous/
subsequent track.
within a track/CD.
tape compartment.
2
DSC
SIDE
Å
VOLUME
É
Ç
SHUFFLE
TUNERTAPECD
SLEEP AUXTIMER
INC. SURR
NEWS/TA
ë
á
2
5
9
^
DBB
MUTE
6
@
@
!
Notes for remote control:
– First select the source you wish to
control by pressing one of the source select
keys on the remote control (e.g. CD ,
TUNER, etc.).
– Then select the desired function (É,
ë
, etc.).
í
à
REPEAT PROGRAM
1
*
&
@
6
@
8
4
í
,
10
pg 001-020/MC10/22-Eng 12/7/00, 1:29 PM10
3140 115 27752
iR
D
Å
U
STANDBY
SELECT
SOURCE
SENSOR
REPEAT
CD
TIMER
DSC
INTERACTIVE SOUND
PRESETSTOP PLAY•PAUSE
PREV NEXT
TUNING
PROGRAM
INCREDIBLE SURR.
ON
DBB
BAND
CLOCK
PROGRAM
TIMER
ON•OFF
SHUFFLE
VOLUME
RDS
IMPORTANT:
Before you operate the system, complete
the preparation procedures.
Switching on
There are 3 ways to switch the system on:
¶ press 2 STANDBY ON on the system and
the last selected source switches on;
¶ press SELECT SOURCE on the system and
the last selected source switches on;
¶ press CD, TUNER, TAPE or AUX on the
remote control.
To switch the system to standby, press 2
STANDBY ON once on the system (2 on
the remote control).
¶ If in tape mode or recording mode, press
STOP•OPEN first.
➜ The volume level, interactive sound settings,
last selected source and tuner presets will be
retained in the player's memory.
Basic Functions
Adjusting volume and sound
1 Turn the VOLUME control anti-clockwise to
decrease or clockwise to increase volume on the
system (or press VOLUME -/+ on the
remote control).
➜ Display shows the volume level VOL and a
number from 0-32.
2 Press the Interactive sound control, DSC on the
system or remote control once or more to
select the desired sound effect: OPTIMAL (no
indication)/ ROCK ( ) / JAZZ ( )/
POP ( ) .
3 Press DBB to switch bass enhancement on or
off.
➜ Display shows:
4 Press INCREDIBLE SURROUND (INC.
SURR. on the remote control) to switch the
surround sound effect on or off.
➜ Display shows: if activated.
Note:
– The effect of INCREDIBLE SURROUND may
vary with different types of music.
5 Press MUTE on the remote
control to interrupt sound
reproduction instantly.
➜ Playback will continue
without sound and the display
shows MUTE.
¶ To activate sound reproduction you can:
– press MUTE again;
– adjust the volume controls;
– change source.
if the DBB is activated.
DBB
DBB
MUTE
VOL
English
DS
SI
Power-saving automatic standby
As a power-saving feature, the system
automatically switches to standby 15 minutes
after a tape or CD has reached the end and no
control is operated.
11
pg 001-020/MC10/22-Eng 12/7/00, 1:29 PM11
3140 115 27752
Compact Disc
English
STANDBY
ON
SELECT
SOURCE
DBB
INTERACTIVE SOUND
iR
SENSOR
REPEAT
BAND
IMPORTANT:
The lens of the CD player should never be
touched.
X
Playing a disc
This CD player plays Audio Discs including CDRecordables and CD-Rewritables.
¶ CD-ROM, CD-I, CDV, VCD, DVD or computer
CDs, however, are not possible.
1 Select CD source.
2 Press OPEN•CLOSE on the top
of the system to open the CD
compartment.
➜ OPEN is displayed when you
open the CD compartment.
3 Inser t a disc with the printed side
facing up and press down on OPEN•CLOSE
to close the CD door.
➜ READ is displayed as the CD player scans the
contents of a disc, and then the total number of
tracks and playing time are shown.
4 Press PLAY•PAUSE 2; (on the remote
control 2) to start playback.
➜ Current track number and elapsed playing
time of the track are displayed during disc
playback.
5 To interrupt playback press PLAY•PAUSE 2;
(on the remote control SIDE/;). Press
PLAY•PAUSE 2; (on the remote control 2)
again to resume play.
CD
PROGRAM
DSC
INCREDIBLE SURR.
PRESETSTOP PLAY•PAUSE
PREV NEXT
TUNING
CLOCK
PROGRAM
TIMER
ON • OFF
SHUFFLE
RDS
VOLUME
OPEN • CLOSE
➜ The display freezes and the elapsed playing
time flashes when playback is interrupted.
6 To stop disc playback, press STOP 9.
Note: CD play will also stop when;
– the CD door is opened.
– the disc has reached the end.
– you select another source: TAPE, TUNER or AUX.
– you select to standby.
– you press the tape deck PLAY 2 key.
Selecting a different track
¶ Press PREV ¡1 or NEXT 2™ on the system,
(on the remote control ¡ or ™) once or
repeatedly until the desired track number
appears in the display.
¶ If you have selected a track number shortly after
loading a disc or in the PAUSE position, you will
need to press PLAY•PAU S E 2; (on the
remote control 2) to start playback.
Finding a passage within a track
1 Press and hold down on PREV ¡1 or NEXT
2™.
➜ The disc is played at high speed and low
volume.
2 When you recognise the passage you want,
release PREV ¡1 or NEXT 2™.
➜ Normal playback continues.
Note:
– During a disc programme or if SHUFFLE/
REPEAT active, searching is only possible within the
same track.
Different play modes: SHUFFLE
and REPEAT
You can select and change the various play modes
before or during playback. The play modes can
also be combined with PROGRAMME.
SHUFFLE ......... tracks of the entire disc/
programme are played in
random order
SHUFFLE and REPEAT ALL…to repeat the
entire disc/ programme
continuously in random order
REPEAT ALL ...repeats the entire disc/
programme
REPEAT ............ plays the current track
continuously
12
pg 001-020/MC10/22-Eng 12/7/00, 1:29 PM12
3140 115 27752
Compact Disc
1 To select your play mode, press the SHUFFLE
or REPEAT button before or during playback
until the display shows the desired function.
2 Press PLAY•PAUSE 2; (on the remote
control 2) to start playback if in the STOP
position.
➜ If you have selected SHUFFLE, playback starts
automatically.
3 To return to normal playback, press the
respective SHUFFLE or REPEAT button until
the various SHUFFLE/ REPEAT modes are no
longer displayed.
¶ You can also press STOP 9 to cancel your play
mode.
Programming track numbers
Programme in the STOP position to select and
store your disc tracks in the desired sequence. If
you like, store any track more than once. Up to
20 tracks can be stored in the memory.
1 Press PROGRAM on the system or remote
control to enter the programming mode.
➜ A track number is shown and PROGRAM
flashes.
2 Use the PREV ¡1 or NEXT 2™ on the
system, (on the remote control ¡ or ™) to
select your desired track number.
3 Press PROGRAM to confirm the track number
to be stored.
➜ The number of tracks programmed and total
playing time of the programme is shown briefly,
then the selected track and PROG.
4 Repeat steps 2-3 to select and store all desired
tracks.
➜ FULL is displayed if you attempt to
programme more than 20 tracks.
5 To start playback of your disc programme, press
PLAY•PAUSE 2; (on the remote control 2).
Reviewing the programme
In STOP mode, press and hold down
PROGRAM on the system or remote control,
for a while until the display shows all your stored
track numbers in sequence.
Erasing the programme
You can erase the progr amme by:
¶ pressing STOP 9 once in the STOP mode;
¶ pressing STOP 9 twice during playback;
¶ opening the CD compar tment;
➜ PROGRAM disappears from the display.
English
pg 001-020/MC10/22-Eng 12/7/00, 1:29 PM13
13
3140 115 27752
Tuner
English
TUNER
TUNER
STANDBY
ON
SELECT
SOURCE
DBB
INTERACTIVE SOUND
iR
SENSOR
REPEAT
BAND
PREV NEXT
Tuning to radio stations
1 Select TUNER source.
➜ TUNER is displayed briefly.
2 Press BAND once or more to select your
waveband.
3 Press down on TUNING à or á and release
button.
➜ The radio automatically tunes to a station
with sufficient reception. Display indication during
automatic tuning: SEARCH.
➜ If a FM station is received in stereo, STEREO is
shown.
4 Repeat step 3 if necessar y until you find the
desired station.
¶ To tune to a weak station, press TUNING à
or á briefly and repeatedly until you have
found optimal reception.
Programming radio stations
You can store up to a total of 40 radio stations
in the memory.
Automatic programming
Automatic programming will start with a chosen
preset number. From this preset number
upwards, former programmed radio stations will
be overridden. The system will only programme
stations which are not in the memory already.
1 Press PRESET 4 or 3 ( ¡ or ™ on the
remote control) to select the preset number
where programming should start.
Note:
– If no preset number is selected, default is preset
(1) and all your presets will be overridden.
PROGRAM
DSC
PRESETSTOP PLAY•PAUSE
TUNING
TIMER
INCREDIBLE SURR.
2 Press PROGRAM on the system or remote
PROGRAM
TIMER
ON•OFF
VOLUME
RDS
CLOCK
SHUFFLE
control for more than 2 seconds to activate
programming.
➜ AUTO is displayed and available stations are
programmed in order of waveband reception
strength: FM followed by MW and LW. The last
preset automatically stored will then be played.
Manual programming
1 Tune to your desired station (see Tuning to radio
stations).
2 Press PROGRAM on the system or remote
control to activate programming.
➜ PROGRAM flashes in the display.
3 Press PRESET 4 or 3 (¡ or ™ on the remote
control) to allocate a number from 1 to 40 to
this station.
4 Press PROGRAM again to confirm the setting.
➜ PROGRAM disappears, the preset number and
the frequency of the preset station are shown.
5 Repeat the above four steps to store other
stations.
¶ You can override a preset station by storing
another frequency in its place.
Tuning to preset stations
¶ Press PRESET 4 or 3 ( ¡ or ™ on the
remote control) until the desired preset station
is displayed.
RDS (some versions only)
Radio Data System is a service that allows
FM stations to show additional information. If
you are receiving a RDS station, and the
station name are displayed.
When automatic programming is used, RDS
stations will be programmed first.
Scrolling through different RDS
information
¶ Press RDS briefly and repeatedly to scroll
through the following information (if available):
– Station name
– Programme type such as NEWS, SPORT,
POP M ...
– Radio text messages
– Frequency
14
pg 001-020/MC10/22-Eng 12/7/00, 1:29 PM14
3140 115 27752
Tuner
Note:
– If you press RDS and the RDS signal is not
available NO RDS is displayed.
EON
Enhanced Other Network allows you to
search for an RDS station offering a certain
programme type. If EON is available, is
shown.
Searching programme type
(PTY)
PTY helps you find a desired programme type.
To enable PTY, first programme RDS stations
into the tuner memory (see Programming radio
stations)
1 While receiving an RDS station, press RDS
briefly until the programme type is displayed.
2 Press PRESET 4 or 3 ( ¡ or ™ on the remote
control) until the desired programme type is
displayed.
3 Press and hold down on TUNING à or á
( à or á on the remote control) to start
searching.
➜ The radio tunes to a RDS station
broadcasting this programme type. If the
programme type is not available TYPE NOT
FOUND is displayed.
RDS Programme types
NO TYPE .......... No RDS programme type
NEWS .................... News services
AFFAIRS .......... Politics and current affairs
INFO .................... Special information programmes
SPORT ................ Sports
EDUCATE .......... Education and advanced training
DRAMA ................ Radio plays and literature
CULTURE .......... Culture, religion and society
SCIENCE .......... Science
VARIED ............. Entertainment programmes
POP M ................. Pop music
ROCK M .............. Rock music
MOR M ................. Light music
LIGHT M .......... Light classical music
CLASSICS ...... Classical music
OTHER M .......... Special music programmes
RDS News and Traffic
Announcement (TA)
You may set up the tuner in such a way that
listening to CD or tape is interrupted by the
NEWS of a RDS station. This only works if the
RDS station broadcasts a NEWS signal while
sending the news.
1 Tune to the desired RDS station.
2 Press NEWS/TA once or
more on the remote control to
select the NEWS option.
➜ NEWS ON, TA ON or OFF is
displayed briefly.
➜ NEWS is displayed if you have
activated the NEWS or TA option. Changing
listening source will not disarm the function.
Notes:
– To avoid unwanted recordings, the NEWS
announcement does not work while recording a
tape.
– When you receive RDS news or traffic
announcements during CD playback, playback will
pause and you will be able to hear the news/TA.
Playback resumes after the broadcast has finished.
In tape mode, the tape continues playing but you
will hear the news/TA only until the broadcast has
finished.
– If you are using the RDS NEWS announcement
with an EON station, the whole network is
searched for the respective news.
Disarming RDS News and Traffic
Announcement
There are a number of ways to disarm the news
feature:
¶ Press NEWS/TA on the remote control during
reception of the news option.
¶ Press standby on the system or remote control.
¶ Tune to a non-RDS-station.
C
INC. SURR
E
NEWS/TA
ME
English
pg 001-020/MC10/22-Eng 12/7/00, 1:29 PM15
15
3140 115 27752
Tape Recorder
English
INCREDIBLE SURROUND
RECORD
PLAY
Tape playback
1 Select TAPE source.
➜ The display shows TAPE throughout tape
operation.
2 Press STOP•OPEN to open the tape door.
3 Inser t a recorded tape and close the tape door.
¶ Load the tape with the open side downward and
the full spool to the left.
4 Press PLAY 2 to start playback.
5 To interrupt playback press PAUSE. To resume,
press this key again.
6 By pressing à or á on the system fast winding
of tape is possible in both directions.
7 To stop the tape, press STOP•OPEN.
¶ The keys are automatically released at the end of
the tape, except if PAUSE has been activated.
Note:
– The sound source cannot be changed while
playing or recording a tape.
STOP • OPEN
PAUSE
General Information on
Recording
¶ Recording is permissible insofar as copyright or
other rights of third parties are not infringed.
¶ For recording, use only NORMAL (IEC type I)
tapes on which the tabs have not yet been
broken. This deck is not suited for recording on
METAL (IEC IV) type tapes.
¶ The best recording level is set automatically.
Altering the VOLUME, INCREDIBLE
SURROUND, DBB or INTERACTIVE SOUND
controls will not affect the recording in progress.
¶ At the ver y beginning and end of the tape, no
recording will take place during the 7 seconds
when the leader tape passes the recorder heads.
¶ To protect a tape from accidental erasure, have
the tape in front of you and break out the left
tab. Recording on this side is no longer possible.
If, however, you wish to record over this side
again, cover the tabs with a piece of adhesive
tape.
Synchro Start CD recording
1 Select CD source.
2 Inser t a disc and if desired, programme track
numbers.
3 Press STOP•OPEN to open the tape door.
4 Inser t a suitable tape into the deck and close the
tape door.
5 Press RECORD to star t recording.
➜ Playing of the disc programme star ts
automatically from the beginning of the disc/
programme after 7 seconds. It is not necessary
to start the CD player separately.
To select and record a particular passage
within a track:
¶ Press and hold down on PREV ¡1 or NEXT
2™ (on the remote control à or á ).
¶ When you recognise the passage you want,
release PREV ¡1 or NEXT 2™.
¶ To interrupt disc playback press PLAY•PAUSE
2; (on the remote control SIDE/;).
¶ Recording will begin from this exact point in the
track when you press RECORD.
6 For brief interruptions during recording, press
PAUSE. To resume recording, press PAUSE
again.
16
pg 001-020/MC10/22-Eng 12/7/00, 1:30 PM16
3140 115 27752
Tape Recorder
A A B C
7 To stop recording, press STOP•OPEN.
Recording from the Radio
Tune to the desired radio station (see Tuning to
1
radio stations).
2 Press STOP•OPEN to open the tape door.
3 Inser t a suitable tape into the deck and close the
tape door.
4 Press RECORD to star t recording.
5 For brief interruptions, press PAUSE. To resume
recording, press PAUSE again.
6 To stop recording, press STOP•OPEN.
Cleaning the Cabinet
¶ Use a soft cloth slightly moistened with a mild
detergent solution. Do not use a solution
containing alcohol, spirits, ammonia or abrasives.
Cleaning Discs
¶ When a disc becomes dir ty,
clean it with a cleaning cloth.
Wipe the disc from the centre
out.
¶ Do not use solvents such as
benzine, thinner, commercially
available cleaners, or antistatic
spray intended for analogue records.
Recording from AUX
1 Select AUX source.
2 If necessar y, prepare the additional appliance for
recording.
3 Press RECORD to star t recording.
Maintenance
Cleaning the Heads and the Tape Paths
¶ To ensure good recording and playback quality,
clean the heads A, the capstan(s) B, and
pressure roller(s) C after every 50 hours of
tape operation.
¶ Use a cotton swab slightly moistened with
cleaning fluid or alcohol.
¶ You can also clean the heads by playing a
cleaning tape once.
English
Cleaning the disc lens
¶ After prolonged use, dirt or dust may
accumulate at the disc lens. To ensure good
playback quality, clean the disc lens with Philips
CD Lens Cleaner or any commercially available
cleaner. Follow the instructions supplied with
cleaner.
pg 001-020/MC10/22-Eng 12/7/00, 1:30 PM17
Demagnetising the heads
¶ Use a demagnetising tape available at your
dealer.
17
3140 115 27752
Clock/Timer
CD
English
CD
STANDBY
ON
SELECT
SOURCE
DBB
INTERACTIVE SOUND
iR
SENSOR
REPEAT
BAND
PREV NEXT
Setting the clock
There are two possible methods for setting the
clock: manually or automatically by using RDS.
Automatic clock setting (RDS versions
only)
1 Tune to a RDS station (see TUNER).
2 Press CLOCK for more than 2 seconds.
➜ SEARCH RDS TIME is displayed for a
maximum of 90 seconds; the time is then
displayed.
➜ NO RDS TIME is displayed if no time signal
has been received and you will have to set the
clock manually.
Manual clock setting
1 In standby, press CLOCK.
➜ The clock digits for the hours flash.
2 Tu r n VOLUME to set the hours: clockwise for
hours up; anti-clockwise for hours down.
3 Press CLOCK again.
➜ The clock digits for the minutes flash.
4 Tu r n VOLUME to set the minutes: clockwise for
minutes up; anti-clockwise for minutes down.
5 Press CLOCK to confirm the time.
PROGRAM
DSC
PRESETSTOP PLAY•PAUSE
TUNING
TIMER
INCREDIBLE SURR.
Setting TIMER
PROGRAM
TIMER
ON•OFF
VOLUME
RDS
CLOCK
SHUFFLE
¶ The system can be used as an alarm clock,
whereby the CD or TUNER is switched on at a
set time. The clock time needs to be set first
before the timer can be used.
¶ During setting, if no button is pressed within 90
seconds, the system will exit timer setting mode
automatically.
1 In any mode, press TIMER ON•OFF for more
than 2 seconds.
2 Tu r n VOLUME clockwise (or press SELECT
SOURCE) to select sound source.
3 Press TIMER ON•OFF to confirm your
desired mode.
➜ The selected source
is shown. The clock digits for the hours flash.
or
TUNER
TUNER
4 Tu r n VOLUME to set the hours: clockwise for
hours up; anti-clockwise for hours down.
5 Press TIMER ON•OFF again.
➜ The clock digits for the minutes flash.
6 Tu r n VOLUME to set the minutes: clockwise for
minutes up; anti-clockwise for minutes down.
7 Press TIMER ON•OFF to confirm the time.
➜ The timer is now set and activated.
Activating and deactivating
TIMER
¶ In standby or during playback, press TIMER
ON•OFF on the system once (TIMER on the
remote control).
➜ Display shows TIMER if activated, and
disappears if deactivated.
18
pg 001-020/MC10/22-Eng 12/7/00, 1:30 PM18
3140 115 27752
Clock/Timer
TUNERAPE
Activating and deactivating
SLEEP
The sleep timer enables the system to switch off
by itself after a set period of time. The clock time
needs to be set first before the sleep timer can
be used.
¶ Press SLEEP on the remote
control once or more.
➜ Display shows SLEEP and
one of the sleep time options
in sequence: 60, 45, 30,15,
SLEEP OFF, 60... if you have
selected a time. Once SLEEP is activated, SLEEP
ON scrolls across the display at repeated
intervals.
AMPLIFIER
Output power .......................................... 2 x 5 W RMS
............................................................. 10 W + 10W MPO
Signal-to-noise ratio .......................... ≥ 65 dBA (IEC)
Frequency response ......... 40 – 20000 Hz, ± 3 dB
Input sensitivity AUX ....................... 0.5 V (max. 2 V)
Impedance loudspeakers ......................................... 8 Ω
Impedance headphones .................... 32 Ω -1000 Ω
CD PLAYER
Frequency range .................................. 20 – 20000 Hz
Signal-to-noise ratio ............................................ 75 dBA
TUNER
FM wave range ...................................87.5 – 108 MHz
MW wave range ................................ 531 – 1602 kHz
LW wave range .....................................153 – 279 kHz
Sensitivity at 75 Ω
– mono, 26 dB signal-to-noise ratio ............ 2.8 µV
– stereo, 46 dB signal-to-noise ratio ........ 61.4 µV
Selectivity ................................................................. ≥ 28 dB
Total harmonic distortion ..................................... ≤ 5%
Frequency response ..... 63 – 12500 Hz (± 3 dB)
Signal-to-noise-ratio ...................................... ≥ 50 dBA
X
C
SLEEP
INC. SURR
¶ To deactivate, press SLEEP on the remote
control once or more until SLEEP OFF is
shown, or press STANDBY ON on the system
or remote control.
➜ SLEEP OFF scrolls across the display.
Specifications
TAPE DECK
Frequency response
Normal tape (type I) ... 120 – 10000 Hz (8 dB)
Signal-to-noise ratio
Normal tape (type I) .................................... 48 dBA
Wow and flutter ......................................... ≤ 0.4% DIN
SPEAKERS
Bass reflex system
Dimensions (w x h x d) . 155 x 220 x 220 (mm)
GENERAL INFORMATION
AC Power ................................................... 230 V / 50 Hz
Dimensions (w x h x d) ... 140 x 223 x 253(mm)
Weight (with/without speakers) ..................................
............................................................... approx. 6.0 / 2.8 kg
Standby power consumption .......................... < 3 W
Subject to modification
English
19
pg 001-020/MC10/22-Eng 12/7/00, 1:30 PM19
3140 115 27752
Troubleshooting
English
WARNING
Do not open the system as there is a risk of electric shock! Under no circumstances
should you try to repair the system yourself, as this will invalidate the warranty
¶ If a fault occurs, first check the points listed below before taking the system for repair.
¶ If you are unable to remedy a problem by following these hints, consult your dealer or service centre.
Symptom Remedy
CD PLAYER OPERATION
“NO DISC” is displayed. ¶ Check if the disc is inserted upside down.
¶ Wait until the moisture condensation at the lens
has cleared.
¶ Use a finalised CD-R(W).
¶ Replace or clean the disc, see Maintenance.
RADIO RECEPTION
Poor radio reception. ¶ The signal is too weak, adjust the antenna or
connect an external antenna for better
reception.
¶ Increase the distance from TV or VCR.
TAPE DECK OPERATION
Recording or playback cannot be ¶ Clean deck parts, see Maintenance.
made. ¶ Use only NORMAL (IEC I) tape for recording.
¶ Apply a piece of adhesive tape over the missing
tab space.
GENERAL
Does not react when any buttons ¶ Press STANDBY ON to switch off the system.
is pressed. Remove the AC power plug from the wall
outlet, then reconnect the power plug and
switch on the system again.
No or poor sound. ¶ Adjust the volume.
¶ Disconnect the headphones.
¶ Check that the speakers are connected
correctly.
¶ Check if the stripped speaker wire is clamped.
Reversed left and right sound. ¶ Check the speaker connections and location.
Remote control does not function properly. ¶ Select the source (CD, TUNER, etc.)
before pressing the function button (É,í,ë,
etc.).
¶ Reduce the distance to the system.
¶ Insert the batteries with their polarities
(+/– signs) as indicated.
¶ Replace the batteries.
Timer is not working. ¶ Set the clock.
¶ Press TIMER ON•OFF to switch on the timer.
¶ If recording is in progress, stop recording.
20
pg 001-020/MC10/22-Eng 12/7/00, 1:30 PM20
3140 115 27752
Loading...
