Page 1
WideScreen Television
32PW9544
Product highlights
• 100Hz Digital Scan
• CrystalClear-III Pro with Dynamic Contrast and LTP
• Wide Screen plus
• Incredible Surround
• TXT/NexTView DualScreen
• NexTView (type 2c)
• 440 pages EasyText teletext (level 2.5)
• Active control
• Improved Graphical User Interface
• Matching 'silver shadow' stand
Remote control unit varies with model
Page 2
WideScreen Television
32PW9544
Product highlights
• 100Hz Digital Scan
• CrystalClear-III Pro with Dynamic Contrast and LTP
• Wide Screen plus
• Incredible Surround
• TXT/NexTView DualScreen
• NexTView (type 2c)
• 440 pages EasyText teletext (level 2.5)
• Active control
• Improved Graphical User Interface
• Matching 'silver shadow' stand
Remote control unit varies with model
Page 3
WideScreen Television
32PW9544
Product highlights
• 100Hz Digital Scan
• CrystalClear-III Pro with Dynamic Contrast and LTP
• Wide Screen plus
• Incredible Surround
• TXT/NexTView DualScreen
• NexTView (type 2c)
• 440 pages EasyText teletext (level 2.5)
• Active control
• Improved Graphical User Interface
• Matching 'silver shadow' stand
Remote control unit varies with model
Page 4
WideScreen Television
32PW9544
Product highlights
• 100Hz Digital Scan
• CrystalClear-III Pro with Dynamic Contrast and LTP
• Wide Screen plus
• Incredible Surround
• TXT/NexTView DualScreen
• NexTView (type 2c)
• 440 pages EasyText teletext (level 2.5)
• Active control
• Improved Graphical User Interface
• Matching 'silver shadow' stand
Remote control unit varies with model
Page 5
WideScreen Television
32PW9544
Product highlights
• 100Hz Digital Scan
• CrystalClear-III Pro with Dynamic Contrast and LTP
• Wide Screen plus
• Incredible Surround
• TXT/NexTView DualScreen
• NexTView (type 2c)
• 440 pages EasyText teletext (level 2.5)
• Active control
• Improved Graphical User Interface
• Matching 'silver shadow' stand
Remote control unit varies with model
Page 6
WideScreen Television
32PW9544
Product highlights
• 100Hz Digital Scan
• CrystalClear-III Pro with Dynamic Contrast and LTP
• Wide Screen plus
• Incredible Surround
• TXT/NexTView DualScreen
• NexTView (type 2c)
• 440 pages EasyText teletext (level 2.5)
• Active control
• Improved Graphical User Interface
• Matching 'silver shadow' stand
Remote control unit varies with model
Page 7
WideScreen Television
32PW9544
Product highlights
• 100Hz Digital Scan
• CrystalClear-III Pro with Dynamic Contrast and LTP
• Wide Screen plus
• Incredible Surround
• TXT/NexTView DualScreen
• NexTView (type 2c)
• 440 pages EasyText teletext (level 2.5)
• Active control
• Improved Graphical User Interface
• Matching 'silver shadow' stand
Remote control unit varies with model
Page 8
WideScreen Television
32PW9544
Product highlights
• 100Hz Digital Scan
• CrystalClear-III Pro with Dynamic Contrast and LTP
• Wide Screen plus
• Incredible Surround
• TXT/NexTView DualScreen
• NexTView (type 2c)
• 440 pages EasyText teletext (level 2.5)
• Active control
• Improved Graphical User Interface
• Matching 'silver shadow' stand
Remote control unit varies with model
Page 9
WideScreen Television
32PW9544
Product highlights
• 100Hz Digital Scan
• CrystalClear-III Pro with Dynamic Contrast and LTP
• Wide Screen plus
• Incredible Surround
• TXT/NexTView DualScreen
• NexTView (type 2c)
• 440 pages EasyText teletext (level 2.5)
• Active control
• Improved Graphical User Interface
• Matching 'silver shadow' stand
Remote control unit varies with model
Page 10
WideScreen Television
32PW9544
Product highlights
• 100Hz Digital Scan
• CrystalClear-III Pro with Dynamic Contrast and LTP
• Wide Screen plus
• Incredible Surround
• TXT/NexTView DualScreen
• NexTView (type 2c)
• 440 pages EasyText teletext (level 2.5)
• Active control
• Improved Graphical User Interface
• Matching 'silver shadow' stand
Remote control unit varies with model
Page 11
WideScreen Television
32PW9544
Product highlights
• 100Hz Digital Scan
• CrystalClear-III Pro with Dynamic Contrast and LTP
• Wide Screen plus
• Incredible Surround
• TXT/NexTView DualScreen
• NexTView (type 2c)
• 440 pages EasyText teletext (level 2.5)
• Active control
• Improved Graphical User Interface
• Matching 'silver shadow' stand
Remote control unit varies with model
Page 12
WideScreen Television
32PW9544
Product highlights
• 100Hz Digital Scan
• CrystalClear-III Pro with Dynamic Contrast and LTP
• Wide Screen plus
• Incredible Surround
• TXT/NexTView DualScreen
• NexTView (type 2c)
• 440 pages EasyText teletext (level 2.5)
• Active control
• Improved Graphical User Interface
• Matching 'silver shadow' stand
Remote control unit varies with model
Page 13
WideScreen Television
32PW9544
Product highlights
• 100 Hz Digital Scan
Offers a flickerfree picture.
• CrystalClear-III Pro with Dynamic Contrast
Scavem,Comb filter and LTP (Luminance Transient
Processing) offers a crisp and natural picture (with
SECAM notch for /39)
• WideScreenplus line interpolation
for enhanced resolution and picture quality.
• Incredible Surround
For enhanced stereo effect.
•
NEXTVIEW Program Guide (type 2c)
Direct access of program info of all programs
(1 week) and automatic programming of VCR
(in /32 and /39)
• Page link program guide
Easy acces of program info of selected channel
(/25,/95)
• TXT/NexTView DualScreen
Picture + TXT or
picture + NexTView
• 440 Pages EasyText teletext (level 2.5)
• Active Control
Automatic Digital Noise Reduction,Auto Sharpness,
Auto Format (black bar detection),Smart Controls,.
Automatically offers the best picture setting.
• Improved Graphical User interface
• Matching 'silver shadow' stand and VCR
Supporting Features
• Blackline-S Ultra Flat picture tube
• Colour Transient Improvement (CTI)
• Picture freeze and strobe
• Viewing modes:4:3,Movie Expand 14:9 & 16:9 (scroll),
Subtitle zoom (scroll),Super Zoom (scroll),Wide Screen.
• EasyTune (auto store,ACI and ATS)
• EasyLink +
• Low power standby
• 80W music output
• Dynamic Bass Enhancement
• 3 Loadspeakers
• Independent headphone volume control
Release date : August 1998
Predecessor(s) :
Date of issue : December 1998 Features and specifications subject to change without notice
Technical specifications
Chassis
• Type:FL6 designline MID2.25
• Screen diameter: 32"/82cm
• Visible screen size: 76cm
• Picture tube: Blackline-S Ultra Flat 16:9
• Image stability: 100Hz Digital Scan
• S-Video display
• Smart Picture control (5 modes)
- Soft,Natural, Rich, Sport, Personal
• Brightness,contrast,tint,sharpness,
colour control
Sound
• Sound system: 3 speaker HiFi stereo
• Output (total): 80W music output
• NICAM stereo
• Frequency response:
20Hz-15kHz,+1/-3dB (ampl.)
• Loudspeakers:
- 2 squeeter 50x90mm
- 1x subwoofer 4"
• Smart Sound control
- Movie, Speech, Music, Personal
• Balance / treble / bass control
Operation
• Easy menu-driven installation and
operation,direct access menu’s and
cursor control
• Selection of 12 menu languages
• 100 preselections
• Multi-function RC handset controlling
- TV,VCR,Sat, DVD
• On screen status display on programmes and functions (OSD)
• Sleeptimer up to 180 minutes
• Electronic lock for parental control
• Favourite programme selection
• Programme title display
(transmitted by TXT)
• On screen menu display:
- Picture,Sound, Features,Headphone,
Program list,Message,Timer,
Installation,Program name giving,
Language and country selection
• TXT/NexTView DualScreen
• Dealer message and demo modes
• Dealer Link; wireless communication
for installation and service.
Reception
• Tuning system: 100 fold PLL
• Colour transmission systems
Off-air:
/05,/19PAL B/G/I +
SECAM B/G/L/L'
/12 PALB/G + SECAM B/G/L +
NTSC M
/58 PAL+ SECAM B/G/D/K
A/V connections:
PALB/G
PAL I (UK only)
SECAM B/G
NTSC video play back
• Channel selections: 120 channels
VHF, UHF, S-Channels,
Hyperband
• Frequency range: (47.25-855.25MHz)
• Aerial input: 75 Ohm (Coax)
• VCR preselections: 0;50-99
• Frequency / Channel selection
(Germany,Austria and Benelux only)
Teletext
• EasyText (level 2.5): fast access to preferred pages and subcode page scroll
• Recept. standards:WST / TOP / FLOF
• Page memory: 440 pages A.I.used for
- Habit watch,preferred page and
subcode page lists
- Page look up table
• Program independent subtitles
Remote Control
• RC type: RC 2009
touch cursor and AV system control
Connections
• Front
- S-Video in
- video CVBS-in (cinch)
- audio L/R-in (cinch)
with automatic mono switching
- headphone jack 3.5mm
• Rear
- Euro A/V connector (RGB-in; CVBSin/out) with auto image format
detection
- Euro A/V connector (RGB-in;Y/Cin/out;CVBS-in/out) with WYSIWYR
select and image format detection
- Euro A/V connector (CVBS-in)
- 2 audio-out (cinch) Constant level
Miscellaneous
• Ambient temperature : +5/+45°C
• Mains :AC 220-240V ± 10%
• Power consumption:
<111W;Stand by: <2W
• Weight :50kg (excl. packaging)
• Dimensions (wxhxd):
86.0x52.6x55.3cm (excl.connections)
RC 2001
Page 14
WideScreen Television
32PW9544
Product highlights
• 100 Hz Digital Scan
Offers a flickerfree picture.
• CrystalClear-III Pro with Dynamic Contrast
Scavem,Comb filter and LTP (Luminance Transient
Processing) offers a crisp and natural picture (with
SECAM notch for /39)
• WideScreenplus line interpolation
for enhanced resolution and picture quality.
• Incredible Surround
For enhanced stereo effect.
•
NEXTVIEW Program Guide (type 2c)
Direct access of program info of all programs
(1 week) and automatic programming of VCR
(in /32 and /39)
• Page link program guide
Easy acces of program info of selected channel
(/25,/95)
• TXT/NexTView DualScreen
Picture + TXT or
picture + NexTView
• 440 Pages EasyText teletext (level 2.5)
• Active Control
Automatic Digital Noise Reduction,Auto Sharpness,
Auto Format (black bar detection),Smart Controls,.
Automatically offers the best picture setting.
• Improved Graphical User interface
• Matching 'silver shadow' stand and VCR
Supporting Features
• Blackline-S Ultra Flat picture tube
• Colour Transient Improvement (CTI)
• Picture freeze and strobe
• Viewing modes:4:3, Movie Expand 14:9 & 16:9 (scroll),
Subtitle zoom (scroll),Super Zoom (scroll),Wide Screen.
• EasyTune (auto store,ACI and ATS)
• EasyLink +
• Low power standby
• 80W music output
• Dynamic Bass Enhancement
• 3 Loadspeakers
• Independent headphone volume control
Release date : August 1998
Predecessor(s) :
Date of issue : December 1998 Features and specifications subject to change without notice
Technical specifications
Chassis
• Type:FL6 designline MID2.25
• Screen diameter: 32"/82cm
• Visible screen size: 76cm
• Picture tube: Blackline-S Ultra Flat 16:9
• Image stability: 100Hz Digital Scan
• S-Video display
• Smart Picture control (5 modes)
- Soft,Natural, Rich, Sport, Personal
• Brightness,contrast,tint,sharpness,
colour control
Sound
• Sound system: 3 speaker HiFi stereo
• Output (total): 80W music output
• NICAM stereo
• Frequency response:
20Hz-15kHz,+1/-3dB (ampl.)
• Loudspeakers:
- 2 squeeter 50x90mm
- 1x subwoofer 4"
• Smart Sound control
- Movie, Speech, Music, Personal
• Balance / treble / bass control
Operation
• Easy menu-driven installation and
operation,direct access menu’s and
cursor control
• Selection of 12 menu languages
• 100 preselections
• Multi-function RC handset controlling
- TV,VCR,Sat, DVD
• On screen status display on programmes and functions (OSD)
• Sleeptimer up to 180 minutes
• Electronic lock for parental control
• Favourite programme selection
• Programme title display
(transmitted by TXT)
• On screen menu display:
- Picture,Sound, Features,Headphone,
Program list,Message,Timer,
Installation,Program name giving,
Language and country selection
• TXT/NexTView DualScreen
• Dealer message and demo modes
• Dealer Link; wireless communication
for installation and service.
Reception
• Tuning system: 100 fold PLL
• Colour transmission systems
Off-air:
/05,/19PAL B/G/I +
SECAM B/G/L/L'
/12 PALB/G + SECAM B/G/L +
NTSC M
/58 PAL+ SECAM B/G/D/K
A/V connections:
PALB/G
PAL I (UK only)
SECAM B/G
NTSC video play back
• Channel selections: 120 channels
VHF, UHF, S-Channels,
Hyperband
• Frequency range: (47.25-855.25MHz)
• Aerial input: 75 Ohm (Coax)
• VCR preselections: 0;50-99
• Frequency / Channel selection
(Germany,Austria and Benelux only)
Teletext
• EasyText (level 2.5): fast access to preferred pages and subcode page scroll
• Recept. standards:WST / TOP / FLOF
• Page memory: 440 pages A.I.used for
- Habit watch,preferred page and
subcode page lists
- Page look up table
• Program independent subtitles
Remote Control
• RC type: RC 2009
touch cursor and AV system control
Connections
• Front
- S-Video in
- video CVBS-in (cinch)
- audio L/R-in (cinch)
with automatic mono switching
- headphone jack 3.5mm
• Rear
- Euro A/V connector (RGB-in; CVBSin/out) with auto image format
detection
- Euro A/V connector (RGB-in;Y/Cin/out;CVBS-in/out) with WYSIWYR
select and image format detection
- Euro A/V connector (CVBS-in)
- 2 audio-out (cinch) Constant level
Miscellaneous
• Ambient temperature : +5/+45°C
• Mains :AC 220-240V ± 10%
• Power consumption:
<111W;Stand by: <2W
• Weight :50kg (excl. packaging)
• Dimensions (wxhxd):
86.0x52.6x55.3cm (excl.connections)
RC 2001
Page 15
WideScreen Television
32PW9544
Product highlights
• 100 Hz Digital Scan
Offers a flickerfree picture.
• CrystalClear-III Pro with Dynamic Contrast
Scavem,Comb filter and LTP (Luminance Transient
Processing) offers a crisp and natural picture (with
SECAM notch for /39)
• WideScreenplus line interpolation
for enhanced resolution and picture quality.
• Incredible Surround
For enhanced stereo effect.
•
NEXTVIEW Program Guide (type 2c)
Direct access of program info of all programs
(1 week) and automatic programming of VCR
(in /32 and /39)
• Page link program guide
Easy acces of program info of selected channel
(/25,/95)
• TXT/NexTView DualScreen
Picture + TXT or
picture + NexTView
• 440 Pages EasyText teletext (level 2.5)
• Active Control
Automatic Digital Noise Reduction,Auto Sharpness,
Auto Format (black bar detection),Smart Controls,.
Automatically offers the best picture setting.
• Improved Graphical User interface
• Matching 'silver shadow' stand and VCR
Supporting Features
• Blackline-S Ultra Flat picture tube
• Colour Transient Improvement (CTI)
• Picture freeze and strobe
• Viewing modes:4:3, Movie Expand 14:9 & 16:9 (scroll),
Subtitle zoom (scroll),Super Zoom (scroll),Wide Screen.
• EasyTune (auto store,ACI and ATS)
• EasyLink +
• Low power standby
• 80W music output
• Dynamic Bass Enhancement
• 3 Loadspeakers
• Independent headphone volume control
Release date : August 1998
Predecessor(s) :
Date of issue : December 1998 Features and specifications subject to change without notice
Technical specifications
Chassis
• Type:FL6 designline MID2.25
• Screen diameter: 32"/82cm
• Visible screen size: 76cm
• Picture tube: Blackline-S Ultra Flat 16:9
• Image stability: 100Hz Digital Scan
• S-Video display
• Smart Picture control (5 modes)
- Soft,Natural, Rich, Sport, Personal
• Brightness,contrast,tint,sharpness,
colour control
Sound
• Sound system: 3 speaker HiFi stereo
• Output (total): 80W music output
• NICAM stereo
• Frequency response:
20Hz-15kHz,+1/-3dB (ampl.)
• Loudspeakers:
- 2 squeeter 50x90mm
- 1x subwoofer 4"
• Smart Sound control
- Movie, Speech, Music, Personal
• Balance / treble / bass control
Operation
• Easy menu-driven installation and
operation,direct access menu’s and
cursor control
• Selection of 12 menu languages
• 100 preselections
• Multi-function RC handset controlling
- TV,VCR,Sat, DVD
• On screen status display on programmes and functions (OSD)
• Sleeptimer up to 180 minutes
• Electronic lock for parental control
• Favourite programme selection
• Programme title display
(transmitted by TXT)
• On screen menu display:
- Picture,Sound, Features,Headphone,
Program list,Message,Timer,
Installation,Program name giving,
Language and country selection
• TXT/NexTView DualScreen
• Dealer message and demo modes
• Dealer Link; wireless communication
for installation and service.
Reception
• Tuning system: 100 fold PLL
• Colour transmission systems
Off-air:
/05,/19PAL B/G/I +
SECAM B/G/L/L'
/12 PALB/G + SECAM B/G/L +
NTSC M
/58 PAL+ SECAM B/G/D/K
A/V connections:
PALB/G
PAL I (UK only)
SECAM B/G
NTSC video play back
• Channel selections: 120 channels
VHF, UHF, S-Channels,
Hyperband
• Frequency range: (47.25-855.25MHz)
• Aerial input: 75 Ohm (Coax)
• VCR preselections: 0;50-99
• Frequency / Channel selection
(Germany,Austria and Benelux only)
Teletext
• EasyText (level 2.5): fast access to preferred pages and subcode page scroll
• Recept. standards:WST / TOP / FLOF
• Page memory: 440 pages A.I.used for
- Habit watch,preferred page and
subcode page lists
- Page look up table
• Program independent subtitles
Remote Control
• RC type: RC 2009
touch cursor and AV system control
Connections
• Front
- S-Video in
- video CVBS-in (cinch)
- audio L/R-in (cinch)
with automatic mono switching
- headphone jack 3.5mm
• Rear
- Euro A/V connector (RGB-in; CVBSin/out) with auto image format
detection
- Euro A/V connector (RGB-in;Y/Cin/out;CVBS-in/out) with WYSIWYR
select and image format detection
- Euro A/V connector (CVBS-in)
- 2 audio-out (cinch) Constant level
Miscellaneous
• Ambient temperature : +5/+45°C
• Mains :AC 220-240V ± 10%
• Power consumption:
<111W;Stand by: <2W
• Weight :50kg (excl. packaging)
• Dimensions (wxhxd):
86.0x52.6x55.3cm (excl.connections)
RC 2001
Page 16
WideScreen Television
32PW9544
Product highlights
• 100 Hz Digital Scan
Offers a flickerfree picture.
• CrystalClear-III Pro with Dynamic Contrast
Scavem,Comb filter and LTP (Luminance Transient
Processing) offers a crisp and natural picture (with
SECAM notch for /39)
• WideScreenplus line interpolation
for enhanced resolution and picture quality.
• Incredible Surround
For enhanced stereo effect.
•
NEXTVIEW Program Guide (type 2c)
Direct access of program info of all programs
(1 week) and automatic programming of VCR
(in /32 and /39)
• Page link program guide
Easy acces of program info of selected channel
(/25,/95)
• TXT/NexTView DualScreen
Picture + TXT or
picture + NexTView
• 440 Pages EasyText teletext (level 2.5)
• Active Control
Automatic Digital Noise Reduction,Auto Sharpness,
Auto Format (black bar detection),Smart Controls,.
Automatically offers the best picture setting.
• Improved Graphical User interface
• Matching 'silver shadow' stand and VCR
Supporting Features
• Blackline-S Ultra Flat picture tube
• Colour Transient Improvement (CTI)
• Picture freeze and strobe
• Viewing modes:4:3, Movie Expand 14:9 & 16:9 (scroll),
Subtitle zoom (scroll),Super Zoom (scroll),Wide Screen.
• EasyTune (auto store,ACI and ATS)
• EasyLink +
• Low power standby
• 80W music output
• Dynamic Bass Enhancement
• 3 Loadspeakers
• Independent headphone volume control
Release date : August 1998
Predecessor(s) :
Date of issue : December 1998 Features and specifications subject to change without notice
Technical specifications
Chassis
• Type:FL6 designline MID2.25
• Screen diameter: 32"/82cm
• Visible screen size: 76cm
• Picture tube: Blackline-S Ultra Flat 16:9
• Image stability: 100Hz Digital Scan
• S-Video display
• Smart Picture control (5 modes)
- Soft,Natural, Rich, Sport, Personal
• Brightness,contrast,tint,sharpness,
colour control
Sound
• Sound system: 3 speaker HiFi stereo
• Output (total): 80W music output
• NICAM stereo
• Frequency response:
20Hz-15kHz,+1/-3dB (ampl.)
• Loudspeakers:
- 2 squeeter 50x90mm
- 1x subwoofer 4"
• Smart Sound control
- Movie, Speech, Music, Personal
• Balance / treble / bass control
Operation
• Easy menu-driven installation and
operation,direct access menu’s and
cursor control
• Selection of 12 menu languages
• 100 preselections
• Multi-function RC handset controlling
- TV,VCR,Sat, DVD
• On screen status display on programmes and functions (OSD)
• Sleeptimer up to 180 minutes
• Electronic lock for parental control
• Favourite programme selection
• Programme title display
(transmitted by TXT)
• On screen menu display:
- Picture,Sound, Features,Headphone,
Program list,Message,Timer,
Installation,Program name giving,
Language and country selection
• TXT/NexTView DualScreen
• Dealer message and demo modes
• Dealer Link; wireless communication
for installation and service.
Reception
• Tuning system: 100 fold PLL
• Colour transmission systems
Off-air:
/05,/19PAL B/G/I +
SECAM B/G/L/L'
/12 PALB/G + SECAM B/G/L +
NTSC M
/58 PAL+ SECAM B/G/D/K
A/V connections:
PALB/G
PAL I (UK only)
SECAM B/G
NTSC video play back
• Channel selections: 120 channels
VHF, UHF, S-Channels,
Hyperband
• Frequency range: (47.25-855.25MHz)
• Aerial input: 75 Ohm (Coax)
• VCR preselections: 0;50-99
• Frequency / Channel selection
(Germany,Austria and Benelux only)
Teletext
• EasyText (level 2.5): fast access to preferred pages and subcode page scroll
• Recept. standards:WST / TOP / FLOF
• Page memory: 440 pages A.I.used for
- Habit watch,preferred page and
subcode page lists
- Page look up table
• Program independent subtitles
Remote Control
• RC type: RC 2009
touch cursor and AV system control
Connections
• Front
- S-Video in
- video CVBS-in (cinch)
- audio L/R-in (cinch)
with automatic mono switching
- headphone jack 3.5mm
• Rear
- Euro A/V connector (RGB-in; CVBSin/out) with auto image format
detection
- Euro A/V connector (RGB-in;Y/Cin/out;CVBS-in/out) with WYSIWYR
select and image format detection
- Euro A/V connector (CVBS-in)
- 2 audio-out (cinch) Constant level
Miscellaneous
• Ambient temperature : +5/+45°C
• Mains :AC 220-240V ± 10%
• Power consumption:
<111W;Stand by: <2W
• Weight :50kg (excl. packaging)
• Dimensions (wxhxd):
86.0x52.6x55.3cm (excl.connections)
RC 2001
Page 17
WideScreen Television
32PW9544
Product highlights
• 100 Hz Digital Scan
Offers a flickerfree picture.
• CrystalClear-III Pro with Dynamic Contrast
Scavem,Comb filter and LTP (Luminance Transient
Processing) offers a crisp and natural picture (with
SECAM notch for /39)
• WideScreenplus line interpolation
for enhanced resolution and picture quality.
• Incredible Surround
For enhanced stereo effect.
•
NEXTVIEW Program Guide (type 2c)
Direct access of program info of all programs
(1 week) and automatic programming of VCR
(in /32 and /39)
• Page link program guide
Easy acces of program info of selected channel
(/25,/95)
• TXT/NexTView DualScreen
Picture + TXT or
picture + NexTView
• 440 Pages EasyText teletext (level 2.5)
• Active Control
Automatic Digital Noise Reduction,Auto Sharpness,
Auto Format (black bar detection),Smart Controls,.
Automatically offers the best picture setting.
• Improved Graphical User interface
• Matching 'silver shadow' stand and VCR
Supporting Features
• Blackline-S Ultra Flat picture tube
• Colour Transient Improvement (CTI)
• Picture freeze and strobe
• Viewing modes:4:3, Movie Expand 14:9 & 16:9 (scroll),
Subtitle zoom (scroll),Super Zoom (scroll),Wide Screen.
• EasyTune (auto store,ACI and ATS)
• EasyLink +
• Low power standby
• 80W music output
• Dynamic Bass Enhancement
• 3 Loadspeakers
• Independent headphone volume control
Release date : August 1998
Predecessor(s) :
Date of issue : December 1998 Features and specifications subject to change without notice
Technical specifications
Chassis
• Type:FL6 designline MID2.25
• Screen diameter: 32"/82cm
• Visible screen size: 76cm
• Picture tube: Blackline-S Ultra Flat 16:9
• Image stability: 100Hz Digital Scan
• S-Video display
• Smart Picture control (5 modes)
- Soft,Natural, Rich, Sport, Personal
• Brightness,contrast,tint,sharpness,
colour control
Sound
• Sound system: 3 speaker HiFi stereo
• Output (total): 80W music output
• NICAM stereo
• Frequency response:
20Hz-15kHz,+1/-3dB (ampl.)
• Loudspeakers:
- 2 squeeter 50x90mm
- 1x subwoofer 4"
• Smart Sound control
- Movie, Speech, Music, Personal
• Balance / treble / bass control
Operation
• Easy menu-driven installation and
operation,direct access menu’s and
cursor control
• Selection of 12 menu languages
• 100 preselections
• Multi-function RC handset controlling
- TV,VCR,Sat, DVD
• On screen status display on programmes and functions (OSD)
• Sleeptimer up to 180 minutes
• Electronic lock for parental control
• Favourite programme selection
• Programme title display
(transmitted by TXT)
• On screen menu display:
- Picture,Sound, Features,Headphone,
Program list,Message,Timer,
Installation,Program name giving,
Language and country selection
• TXT/NexTView DualScreen
• Dealer message and demo modes
• Dealer Link; wireless communication
for installation and service.
Reception
• Tuning system: 100 fold PLL
• Colour transmission systems
Off-air:
/05,/19PAL B/G/I +
SECAM B/G/L/L'
/12 PALB/G + SECAM B/G/L +
NTSC M
/58 PAL+ SECAM B/G/D/K
A/V connections:
PALB/G
PAL I (UK only)
SECAM B/G
NTSC video play back
• Channel selections: 120 channels
VHF, UHF, S-Channels,
Hyperband
• Frequency range: (47.25-855.25MHz)
• Aerial input: 75 Ohm (Coax)
• VCR preselections: 0;50-99
• Frequency / Channel selection
(Germany,Austria and Benelux only)
Teletext
• EasyText (level 2.5): fast access to preferred pages and subcode page scroll
• Recept. standards:WST / TOP / FLOF
• Page memory: 440 pages A.I.used for
- Habit watch,preferred page and
subcode page lists
- Page look up table
• Program independent subtitles
Remote Control
• RC type: RC 2009
touch cursor and AV system control
Connections
• Front
- S-Video in
- video CVBS-in (cinch)
- audio L/R-in (cinch)
with automatic mono switching
- headphone jack 3.5mm
• Rear
- Euro A/V connector (RGB-in; CVBSin/out) with auto image format
detection
- Euro A/V connector (RGB-in;Y/Cin/out;CVBS-in/out) with WYSIWYR
select and image format detection
- Euro A/V connector (CVBS-in)
- 2 audio-out (cinch) Constant level
Miscellaneous
• Ambient temperature : +5/+45°C
• Mains :AC 220-240V ± 10%
• Power consumption:
<111W;Stand by: <2W
• Weight :50kg (excl. packaging)
• Dimensions (wxhxd):
86.0x52.6x55.3cm (excl.connections)
RC 2001
Page 18
WideScreen Television
32PW9544
Product highlights
• 100 Hz Digital Scan
Offers a flickerfree picture.
• CrystalClear-III Pro with Dynamic Contrast
Scavem,Comb filter and LTP (Luminance Transient
Processing) offers a crisp and natural picture (with
SECAM notch for /39)
• WideScreenplus line interpolation
for enhanced resolution and picture quality.
• Incredible Surround
For enhanced stereo effect.
•
NEXTVIEW Program Guide (type 2c)
Direct access of program info of all programs
(1 week) and automatic programming of VCR
(in /32 and /39)
• Page link program guide
Easy acces of program info of selected channel
(/25,/95)
• TXT/NexTView DualScreen
Picture + TXT or
picture + NexTView
• 440 Pages EasyText teletext (level 2.5)
• Active Control
Automatic Digital Noise Reduction,Auto Sharpness,
Auto Format (black bar detection),Smart Controls,.
Automatically offers the best picture setting.
• Improved Graphical User interface
• Matching 'silver shadow' stand and VCR
Supporting Features
• Blackline-S Ultra Flat picture tube
• Colour Transient Improvement (CTI)
• Picture freeze and strobe
• Viewing modes:4:3, Movie Expand 14:9 & 16:9 (scroll),
Subtitle zoom (scroll),Super Zoom (scroll),Wide Screen.
• EasyTune (auto store,ACI and ATS)
• EasyLink +
• Low power standby
• 80W music output
• Dynamic Bass Enhancement
• 3 Loadspeakers
• Independent headphone volume control
Release date : August 1998
Predecessor(s) :
Date of issue : December 1998 Features and specifications subject to change without notice
Technical specifications
Chassis
• Type:FL6 designline MID2.25
• Screen diameter: 32"/82cm
• Visible screen size: 76cm
• Picture tube: Blackline-S Ultra Flat 16:9
• Image stability: 100Hz Digital Scan
• S-Video display
• Smart Picture control (5 modes)
- Soft,Natural, Rich, Sport, Personal
• Brightness,contrast,tint,sharpness,
colour control
Sound
• Sound system: 3 speaker HiFi stereo
• Output (total): 80W music output
• NICAM stereo
• Frequency response:
20Hz-15kHz,+1/-3dB (ampl.)
• Loudspeakers:
- 2 squeeter 50x90mm
- 1x subwoofer 4"
• Smart Sound control
- Movie, Speech, Music, Personal
• Balance / treble / bass control
Operation
• Easy menu-driven installation and
operation,direct access menu’s and
cursor control
• Selection of 12 menu languages
• 100 preselections
• Multi-function RC handset controlling
- TV,VCR,Sat, DVD
• On screen status display on programmes and functions (OSD)
• Sleeptimer up to 180 minutes
• Electronic lock for parental control
• Favourite programme selection
• Programme title display
(transmitted by TXT)
• On screen menu display:
- Picture,Sound, Features,Headphone,
Program list,Message,Timer,
Installation,Program name giving,
Language and country selection
• TXT/NexTView DualScreen
• Dealer message and demo modes
• Dealer Link; wireless communication
for installation and service.
Reception
• Tuning system: 100 fold PLL
• Colour transmission systems
Off-air:
/05,/19PAL B/G/I +
SECAM B/G/L/L'
/12 PALB/G + SECAM B/G/L +
NTSC M
/58 PAL+ SECAM B/G/D/K
A/V connections:
PALB/G
PAL I (UK only)
SECAM B/G
NTSC video play back
• Channel selections: 120 channels
VHF, UHF, S-Channels,
Hyperband
• Frequency range: (47.25-855.25MHz)
• Aerial input: 75 Ohm (Coax)
• VCR preselections: 0;50-99
• Frequency / Channel selection
(Germany,Austria and Benelux only)
Teletext
• EasyText (level 2.5): fast access to preferred pages and subcode page scroll
• Recept. standards:WST / TOP / FLOF
• Page memory: 440 pages A.I.used for
- Habit watch,preferred page and
subcode page lists
- Page look up table
• Program independent subtitles
Remote Control
• RC type: RC 2009
touch cursor and AV system control
Connections
• Front
- S-Video in
- video CVBS-in (cinch)
- audio L/R-in (cinch)
with automatic mono switching
- headphone jack 3.5mm
• Rear
- Euro A/V connector (RGB-in; CVBSin/out) with auto image format
detection
- Euro A/V connector (RGB-in;Y/Cin/out;CVBS-in/out) with WYSIWYR
select and image format detection
- Euro A/V connector (CVBS-in)
- 2 audio-out (cinch) Constant level
Miscellaneous
• Ambient temperature : +5/+45°C
• Mains :AC 220-240V ± 10%
• Power consumption:
<111W;Stand by: <2W
• Weight :50kg (excl. packaging)
• Dimensions (wxhxd):
86.0x52.6x55.3cm (excl.connections)
RC 2001
Loading...
